OmniPro OmniDry AC8400 User manual

Owner’s Manual
OmniDry Wall & Cavity Drying System
AC8400
Please Read and Save These Instructions
Specifications
Motor Specifications
5.7 Inch/ 145mm, 2-Stage Tangential By-Pass
120 VAC
106 Inches of water column – Vacuum
Over 2600 LPM – Air Flow
1200 Watts
9.3 Amps
Double ball bearing construction
UL Recognized, Category PRGY8
Other Specifications
Thermal protection in case of overheating due to
blocked intake.
PVC (Vinyl) Tubing 3/8” ID x 1/2” OD
Hose Barb Adapter 3/8” x 1/4” MPT

OPERATING INSTRUCTIONS
1. Check the OmniDry unit for any obstructions of the intake
holes before plugging in the unit.
2. Set the machine in the desired position for operation.
3. Cut tubing to the desired length and attach to barb fittings.
4. Drill 1/2” holes in the base of the wall to be dried and insert the
tubing.
5. Plug the cord into a GFCI outlet.
Do not use an extension cord in conjunction with the standard
power cord.
TROUBLESHOOTING
Unit will not turn
ON
Not Plugged In
Switch is worn
Tripped circuit
breaker
Short in power
cord
Plug machine in proper
outlet
Replace switch
Reset Breaker
Replace power cord or
replace cord end
Unit is making
strange noises
Motor bearing is
worn
Replace motor
Motor runs but no
airflow is detected
Intake vent is
obstructed
Turn unit off. Remove
obstruction. Restart motor.
Motor Stops
running
Intake vent is
obstructed
Remove obstruction. Allow
motor to cool. Motor will
start automatically
WARRANTY INFORMATION
WARRANTOR:
OmniPro Manufacturing
4282 S 590 W
Salt Lake City, UT
Toll Free: [phone]
WARRANTY AND LIMITATION OF LIABILITY
OmniPro Restoration (the “Company”) warrants to the first end user purchaser
that the equipment and parts thereof, when shipped, will be free from defects in
materials and the Company’s workmanship. If any such defects exist or later
appear, the Company shall provide prompt remedial action, as stated herein, to
correct the defect. The Company shall have no obligation or liability under this
Warranty unless the customer has obtained a Return Material Authorization
(RMA). To get an RMA, call OmniPro Manufacturing at 800-637-3789 and ask for
the Returns Department, which will then issue an RMA number and will arrange
for repair or replacement, at our option, according to the following schedule:
This warranty covers the OmniDry Wall & Cavity Drying System
Year One – 100% labor and parts (All components other than those noted in this
document)
Years Two through Five - Only materials and workmanship of the housing are
covered.
PVC Hoses, Brass Barb fittings and gaskets are not
warranted.
Warranty service shall only be performed by a service provider
authorized by the Company.
Freight to the Company is the responsibility of the end user.
The end user is responsible for normal care and proper return
packaging.
Equipment or parts thereof, manufactured by others are
warranted hereunder only to the extent of such manufacturer’s
warranty to the Company.
Since after purchase, the Equipment and Parts thereof are
under the sole control of the Purchaser, this Warranty is
subject to, and shall be applicable only, if the following
conditions are met:
a) The Company’s instructions as to usage, operation and
maintenance have been followed.
b) The Equipment and Parts thereof, have been used under
normal indoor operating conditions.
c) The Equipment and Parts thereof have been correctly
operated and maintained and have not been damaged by
misuse, neglect or accident.
d) The purchaser has not attempted or performed corrective
work or change on the Equipment and/or Parts thereof.
e) The Company shall have received notice (RMA Request)
of any defect no later than thirty (30) days after the
purchaser first had knowledge of the same.
This warranty is in lieu of any and all other warranties,
express, implied or statutory including, without limitation,
warranties of merchantability and fitness for a particular
purpose or use.
LIMITATION OF LIABILITY
THE COMPANY SHALL HAVE NO LIABILITY
WHATSOEVER IN ANY EVENT FOR PAYMENT OF ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES,
INCLUDING, WITHOUT LIMITATION, WATER
DAMAGE (THE END USER SHOULD TAKE
PRECAUTIONS AGAINST SAME), LOST PROFITS,
DELAY, OR LOSS OF USE, OR DAMAGES FOR INJURY
TO ANY PERSON OR PROPERTY. BY ACCEPTING THE
EQUIPMENT AND/OR PARTS THEREOF, THE FIRST
END USER PURCHASER OR SUBSEQUENT USER
AGREES THAT THE COMPANYSHALL NOT BE LIABLE
FOR INDEMNIFICATION OR CONTRIBUTION (IN
WHOLE OR PART) EITHER EXPRESSLY OR BY
IMPLICATION.
IF FOR ANY REASON ANY OF THE FOREGOING
PROVISIONS SHALL BE INEFFECTIVE, THE
COMPANY’S LIABILITY FOR DAMAGES ARISING OUT
OF ITS MANUFACTURE OR SALE OF ITS EQUIPMENT
OR PARTS, OR USE THEREOF, WHETHER SUCH
LIABILITY IS BASED ON WARRANTY, CONTRACT,
NEGLIGENCE, STRICT LIABILTY IN TORT OR
OTHERWISE, SHALL NOT IN ANY EVENT EXCEED
THE FULL PURCHASE PRICE OF SUCH EQUIPMENT
AND PARTS THEREOF.
Any action against the Company based upon any liability or obligation
arising from or under any law applicable to the sale of its Equipment
or Parts, or the use thereof, must be commenced within six months
after the cause of such action arises.

Read operator’s instructions and Warnings before
using this equipment.
WARNING: Do not allow anything to cover the
intake vent. Overheating the motor could damage
the OmniDry Wall & Cavity Drying unit.
CAUTION: Do not block the air output with
anything other than the supplied plug-off system.
This will cause an overpressure condition and may
damage the OmniDry Wall & Cavity Drying unit.
WARNING




 
  
 



In order to achieve the best air pressure for wall drying, OmniPro
Manufacturing recommends that the 3/8” ID vinyl hoses be cut as
shown above. Lengthening the hoses will result in a loss of pressure
unless the pressure is equalized by capping-off one or more of the
hoses to compensate. H
ose caps are incorporated into the front of the
OmniDry Wall & Cavity Drying unit.
