OmniTek OTR 1001 User manual

Advanced Measurement Technology
OTR 1001
User Guide
Software Version: 3.1
October 2013

OmniTek OTR 1001 User Guide, v3.1
© 2011-2013 OmniTek. All rights reserved
This documentation contains proprietary information of OmniTek. No part of this documentation
may be reproduced, stored in a retrieval system or transmitted in any form or by any means,
electronic, mechanical, recorded or otherwise without the prior written permission of OmniTek.
The information contained in this documentation was prepared by OmniTek with all reasonable
care and is believed to be accurate. However OmniTek does not assume responsibility for loss or
damage resulting from omissions, inaccuracies or errors contained herein. The information
contained in this document is subject to change and revisions hereto or new additions may be
issued to incorporate such changes.
Warranty
OmniTek systems are warranted for one year from date of purchase. This includes all feature
upgrades and bug fixes to the application software, plus repair or replacement of the hardware
(at the discretion of OmniTek). Extended warranty agreements are also available, please consult
your local dealer.
Contact Information
OmniTek
Intec Unit 2.3, Wade Road, Basingstoke, Hants RG22 8NE, UK
Tel: [phone] Fax: [phone]
Email: [email protected] Web: www.omnitek.tv
Conventions Used in this Guide
The following typographical conventions are used:
Convention Meaning or Use
<item> Placeholder for item of the named type
Italic font Reference to a signal
Or: reference to a separate document
Bold font Reference to a file/software package
xxxxxx Link to additional information.

OmniTek OTR 1001 User Guide, v3.1a
Contents
A OTR 1001 Equipment Guide
Introduction........................................................................................................................A-1
Safety Statement.................................................................................................................A-2
A.1 System Features and Instrument Options.....................................................................A-3
A.2 Installation....................................................................................................................A-6
Preliminary steps:...............................................................................................................A-6
Mounting in a rack .............................................................................................................A-6
Cabling...............................................................................................................................A-6
Adding the Graphics Display.............................................................................................A-8
Adding Mouse and Keyboard ............................................................................................A-8
Common Set-ups................................................................................................................A-9
Optional Additions...........................................................................................................A-10
A.3 Power Up....................................................................................................................A-11
Applying Power................................................................................................................A-11
Start-Up Procedure...........................................................................................................A-11
Shutting Down..................................................................................................................A-11
A.4 Display Modes............................................................................................................A-12
Switching between Windows Mode and Full Screen Mode ............................................A-12
A.5 Installing Additional Software Options......................................................................A-13
A.6 Updating to the Latest Version...................................................................................A-14
A.7 General Care...............................................................................................................A-15
Cleaning ...........................................................................................................................A-15
Changing the Battery........................................................................................................A-15
B OTR 1001 System Control
B.1 General Controls ..........................................................................................................B-1
The Control Panel...............................................................................................................B-1
Using a Mouse....................................................................................................................B-3
Menus.................................................................................................................................B-3
Toolbars..............................................................................................................................B-5
Keyboard Controls .............................................................................................................B-7
B.2 Settings.........................................................................................................................B-8
B.3 Window Displays.......................................................................................................B-10
Status Bar .........................................................................................................................B-10
Button Bar........................................................................................................................B-11
Picking out Items to work with........................................................................................B-11
Window Properties........................................................................................................... B-12
B.4 Presets.........................................................................................................................B-14
Using Presets from other OmniTek systems....................................................................B-15
Recording Presets.............................................................................................................B-15
Preset Selection ................................................................................................................B-18
Assigning Presets to Function Keys.................................................................................B-19
B.5 File Selection..............................................................................................................B-21
B.6 Saving Files................................................................................................................B-22

OmniTek OTR 1001 User Guide, v3.1a
C The View Window
C.1 Overview......................................................................................................................C-2
Selecting the View Window...............................................................................................C-2
Definitions..........................................................................................................................C-2
Basic Screen Layout...........................................................................................................C-3
C.2 View Window Operations............................................................................................C-6
View Selection ...................................................................................................................C-6
Full/Multiple Tile display...................................................................................................C-8
Setting Overall Window Properties....................................................................................C-9
Setting Tile Properties......................................................................................................C-10
Saving and Recalling Specific Tile Selections.................................................................C-11
C.3 Video Stream..............................................................................................................C-12
Video Stream Selection....................................................................................................C-12
Input Video Standard .......................................................................................................C-13
C.4 Freezing the display ...................................................................................................C-14
D Screen Layout
D.1 Overview......................................................................................................................D-1
D.2 Selecting Edit Mode.....................................................................................................D-2
D.3 Changing the Range of Views Displayed ....................................................................D-3
D.4 Changing Size, Position etc..........................................................................................D-5
D.5 Saving the New Layout................................................................................................D-6
E Image Analysis
E.1 General Steps................................................................................................................ E-1
E.2 Focus of Analysis......................................................................................................... E-2
E.3 Waveform View........................................................................................................... E-4
Selection............................................................................................................................. E-5
Configuration Issues........................................................................................................... E-5
Display Properties .............................................................................................................. E-6
Composite Waveforms....................................................................................................... E-8
Waveform Measurement.................................................................................................... E-9
Shared Waveform Markers ................................................................................................ E-9
E.4 Vectorscope................................................................................................................ E-11
Selection........................................................................................................................... E-11
Configuration Issues......................................................................................................... E-12
Display Properties ............................................................................................................ E-12
E.5 Gamut View ............................................................................................................... E-14
Selection........................................................................................................................... E-14
Configuration Issues......................................................................................................... E-15
Display Properties ............................................................................................................ E-15
E.6 Status.......................................................................................................................... E-16
The Status Overview........................................................................................................ E-16
Status Summary................................................................................................................ E-17
Selection........................................................................................................................... E-18
Configuration Issues......................................................................................................... E-18
Display Properties ............................................................................................................ E-19
Resetting the display ........................................................................................................ E-19
E.7 Video Information Displayed..................................................................................... E-20

OmniTek OTR 1001 User Guide, v3.1a
F Video Proxy
F.1 Basic Picture Display....................................................................................................F-1
Selection..............................................................................................................................F-1
Configuration Issues............................................................................................................F-2
Display Properties ...............................................................................................................F-2
F.2 Picture Overlays............................................................................................................F-4
Crosshair..............................................................................................................................F-4
Timecodes ...........................................................................................................................F-5
Closed Captions & Teletext Subtitles .................................................................................F-7
F.3 Safe Action/Safe Title Cages ........................................................................................F-9
Set-Up................................................................................................................................F-10
Displaying the cages..........................................................................................................F-11
Saving and Re-loading ......................................................................................................F-11
F.4 Region of Interest (ROI) .............................................................................................F-12
Enabling/Disabling the ROI..............................................................................................F-12
Setting the Size and Position of the ROI...........................................................................F-13
F.5 Picture Zoom...............................................................................................................F-14
G Pixel Data (VIEW_DATA option)
G.1 Overview of Display ....................................................................................................G-1
Selection.............................................................................................................................G-2
Display Properties ..............................................................................................................G-2
Setting the focus for the display.........................................................................................G-3
G.2 Standard View..............................................................................................................G-4
Overview of Display Features............................................................................................G-4
G.3 Extended View.............................................................................................................G-5
Overview of Display Features............................................................................................G-5
H DCI Support (VIEW_XR_DCI option)
H.1 CIE Colour Chart .........................................................................................................H-1
Selection.............................................................................................................................H-2
Configuration Issues...........................................................................................................H-2
Display Properties ..............................................................................................................H-3
H.2 Histogram.....................................................................................................................H-5
Selection.............................................................................................................................H-5
Configuration Issues...........................................................................................................H-6
Display Properties ..............................................................................................................H-6
I Stereo 3D Analysis and Camera Alignment (VIEW_3D & ALIGNMENT options)
Terminology........................................................................................................................ I-1
I.1 Stereo 3D Overview...................................................................................................... I-2
I.2 Enabling 3D Monitoring ............................................................................................... I-3
Defining the 3D Video Format............................................................................................ I-4
Applying Auto-correction ................................................................................................... I-4
I.3 Visual Comparison of S3D Left/Right Images............................................................. I-5
Selection.............................................................................................................................. I-7
Configuration Issues............................................................................................................ I-7
Display Properties ............................................................................................................... I-8
I.4 Depth Analysis of Stereo 3D video............................................................................... I-9
Background ......................................................................................................................... I-9
Configuration Issues.......................................................................................................... I-10

OmniTek OTR 1001 User Guide, v3.1a
I.5 Depth Map................................................................................................................... I-12
Selection............................................................................................................................ I-13
Configuration Issues.......................................................................................................... I-13
Display Properties ............................................................................................................. I-13
I.6 Depth Plan................................................................................................................... I-14
Selection............................................................................................................................ I-16
Configuration Issues.......................................................................................................... I-16
Display Properties ............................................................................................................. I-17
I.7 Depth Map Histogram................................................................................................. I-18
Selection............................................................................................................................ I-18
Configuration Issues.......................................................................................................... I-18
Display Properties ............................................................................................................. I-19
I.8 Camera Rig Alignment................................................................................................ I-20
3D Meters Display ............................................................................................................ I-20
Selection............................................................................................................................ I-21
Configuration .................................................................................................................... I-21
Display Properties ............................................................................................................. I-22
Single Camera Alignment................................................................................................. I-23
Camera Pair Alignment..................................................................................................... I-24
I.9 Luma/Chroma Comparisons ....................................................................................... I-25
1. 3D Chroma Sabres ........................................................................................................ I-25
2. Colour Comparison on Waveform Display................................................................... I-28
3. Colour Comparison on the Vectorscope Display.......................................................... I-30
4. Colour Comparison using Histogram Display.............................................................. I-32
I.10 Error Reporting ........................................................................................................... I-35
Configuration Issues.......................................................................................................... I-38
Display Properties ............................................................................................................. I-38
J Logging
J.1 Event Logs..................................................................................................................... J-1
Overview............................................................................................................................. J-1
Event Log Display............................................................................................................... J-1
Selection.............................................................................................................................. J-2
Upper Part of the Event Log ...............................................................................................J-3
Lower Part of the Event Log............................................................................................... J-4
Configuration Issues............................................................................................................ J-6
Display Properties ............................................................................................................... J-6
Event Log: Live Log........................................................................................................... J-7
Event Log: Session Logs..................................................................................................... J-8
J.2 Loudness Logs............................................................................................................. J-10
Loudness Log Display....................................................................................................... J-10
Selection............................................................................................................................ J-10
Recording Loudness Logs................................................................................................. J-11
J.3 Closed Caption Log..................................................................................................... J-14
Selection............................................................................................................................ J-14
Configuration Issues.......................................................................................................... J-15
Display Properties ............................................................................................................. J-15
The Live Log..................................................................................................................... J-17
Recording Closed Caption Logs ....................................................................................... J-18
J.4 SNMP.......................................................................................................................... J-21

OmniTek OTR 1001 User Guide, v3.1a
K Audio Monitoring (AUDIO option)
K.1 Audio Input ..................................................................................................................K-1
K.2 PPMs Display...............................................................................................................K-2
Selection.............................................................................................................................K-3
Configuration Issues...........................................................................................................K-4
Display Properties ..............................................................................................................K-4
Error Reporting ..................................................................................................................K-5
K.3 Surround Sound............................................................................................................K-6
Stereo Mix Down...............................................................................................................K-6
Surround Sound View........................................................................................................K-7
Selection.............................................................................................................................K-8
Configuration Issues...........................................................................................................K-8
Display Properties ..............................................................................................................K-8
K.4 Loudness (AUDIO_LOUD option)............................................................................K-10
Configuration ...................................................................................................................K-11
Loudness View.................................................................................................................K-12
Display Properties ............................................................................................................K-13
Loudness History..............................................................................................................K-14
Selection...........................................................................................................................K-17
Display Properties ............................................................................................................K-17
Loudness and the Surround Sound View.........................................................................K-19
K.5 Lissajous Figures........................................................................................................K-20
Selection...........................................................................................................................K-20
Display Properties ............................................................................................................K-21
K.6 Surround Sound Lissajous Display ............................................................................K-22
Selection...........................................................................................................................K-22
Display Properties ............................................................................................................K-22
K.7 Audio Status...............................................................................................................K-23
Status Overview Display..................................................................................................K-23
Status Summary Display..................................................................................................K-23
Selection...........................................................................................................................K-24
Configuration Issues.........................................................................................................K-24
Display Properties ............................................................................................................K-24
Audio Information Displayed...........................................................................................K-24
Resetting the display ........................................................................................................K-25
K.8 AES/EBU Audio ........................................................................................................K-26
Adding the AES card........................................................................................................K-26
Cabling.............................................................................................................................K-26
Configuration ...................................................................................................................K-27
Analysing the Input..........................................................................................................K-27
K.9 Audio Playback ..........................................................................................................K-28
Playing back over headphones or the internal speaker ....................................................K-28
Playing back over the AES card outputs..........................................................................K-30

OmniTek OTR 1001 User Guide, v3.1a
L Dolby Audio Support (AUDIO_DOLBY options)
L.1 Background .................................................................................................................. L-1
L.2 Configuring the OTR 1001 for Dolby analysis............................................................ L-3
L.3 Dolby PPMs ................................................................................................................. L-5
L.4 Dolby Loudness............................................................................................................ L-6
L.5 Dolby Metadata............................................................................................................ L-7
Displaying Metadata .......................................................................................................... L-7
Dolby E Data...................................................................................................................... L-8
Dolby Digital Data ............................................................................................................. L-9
Channel Data (Both Dolby E and Dolby D) ...................................................................... L-9
L.6 Playing out the Extracted Audio ................................................................................ L-10
Configuration for Multi-channel Dolby Playback ........................................................... L-10
Multi-Channel Playback................................................................................................... L-10
M Physical Layer Measurements (EYE options)
M.1 Overview..................................................................................................................... M-1
Views Offered................................................................................................................... M-1
Adding Transport Layer Measurement to the OTR 1001................................................. M-2
Upgrading EYE_xx option................................................................................................ M-2
M.2 Set-Up.......................................................................................................................... M-3
Cabling .............................................................................................................................. M-3
Configuration .................................................................................................................... M-3
M.3 Jitter Display ...............................................................................................................M-4
Selection............................................................................................................................ M-5
Display Properties ............................................................................................................. M-5
M.4 Eye Diagram................................................................................................................ M-7
Selection............................................................................................................................ M-8
Display Properties ............................................................................................................. M-9
Obtaining Measurements from the Eye Diagram............................................................ M-11
M.5 Cable Length ............................................................................................................. M-13
Configuration .................................................................................................................. M-13
N Timing Measurements
N.1 Reference Timing Measurements.................................................................................N-2
Set-up .................................................................................................................................N-3
Display ...............................................................................................................................N-3
Display Properties ..............................................................................................................N-3
N.2 AV Delay (Lip-Sync Delay) Measurements................................................................N-5
In-Service AV Delay Measurement (AV_ISD option)......................................................N-5
Using Dedicated Test Sequences .......................................................................................N-7
N.3 Loop Delay Measurement..........................................................................................N-11
O Simultaneous Monitoring (VIEW_2 option)
O.1 Overview......................................................................................................................O-1
O.2 Enabling and Disabling Simultaneous Monitoring......................................................O-2
O.3 Picking the Input analysed in a particular tile..............................................................O-3

OmniTek OTR 1001 User Guide, v3.1a
P The Gen Window (GEN/GEN_BASIC option)
Selection..............................................................................................................................P-1
P.1 Overview.......................................................................................................................P-2
Controls...............................................................................................................................P-3
P.2 Gen Window Set-Up.....................................................................................................P-5
Saving and Recalling Specific Gen Window Set-ups.........................................................P-7
P.3 Capture from Input........................................................................................................P-8
P.4 Basic Test Pattern Generation.....................................................................................P-10
1. Playing out Colour Bars................................................................................................P-10
2. Using the provided Pathological Test Patterns .............................................................P-11
3. Live Input Pass-through................................................................................................P-12
4. Displaying the Test Signal on a Monitor ......................................................................P-12
Q Gen Actions (GEN option)
Q.1 Loading Patterns from Disk .........................................................................................Q-1
Q.2 Creating Test Patterns ..................................................................................................Q-3
Zoneplates ..........................................................................................................................Q-3
Line Patterns.......................................................................................................................Q-6
Q.3 Saving Patterns.............................................................................................................Q-8
Q.4 Deleting Patterns ..........................................................................................................Q-9
Q.5 Playing Out Test Patterns.............................................................................................Q-9
Preparation for Play-Out ....................................................................................................Q-9
Play-Out ...........................................................................................................................Q-10
Q.6 Modifying the output..................................................................................................Q-11
Enable SMPTE 352..........................................................................................................Q-12
Gain..................................................................................................................................Q-12
Bounce..............................................................................................................................Q-12
Panning.............................................................................................................................Q-12
Wide Screen Signalling....................................................................................................Q-12
Video Index......................................................................................................................Q-12
Output Range and Gamma...............................................................................................Q-12
Q.7 Interpreting Image Files .............................................................................................Q-15
General Rules...................................................................................................................Q-15
Individual Images.............................................................................................................Q-16
Saved Images....................................................................................................................Q-16
Q.8 Adding Simple Audio Tones......................................................................................Q-18
Q.9 Adding Timecodes .....................................................................................................Q-19
Q.10 Adding Deliberate Bit Errors .....................................................................................Q-20
Q.11 Saving and Recalling Pattern Selections....................................................................Q-22
Q.12 Dual-Generator Operation..........................................................................................Q-22
Enabling Dual-Generation Operation...............................................................................Q-23
Configuring the Generators..............................................................................................Q-24
Playing out Test Signals...................................................................................................Q-25
Synchronising Generators ................................................................................................Q-25

OmniTek OTR 1001 User Guide, v3.1a
R Sequence Capture & Play-Out (CAP_MOTION; GEN_MOTION options)
R.1 Capturing Video Clips..................................................................................................R-1
Initial Set-up.......................................................................................................................R-2
Capture...............................................................................................................................R-3
Twin-Channel Capture.......................................................................................................R-4
R.2 RVF Files .....................................................................................................................R-4
R.3 Sequence Play-Out.......................................................................................................R-5
Loading a Sequence ...........................................................................................................R-5
Playing out a Sequence ......................................................................................................R-6
Modifying the Output.........................................................................................................R-6
R.4 Working with Stereo 3D Video (GEN_2 option).........................................................R-7
Loading 3D Images............................................................................................................R-7
Playing Out a 3D Pattern....................................................................................................R-8
Saving 3D Patterns to Disk ................................................................................................R-8
S Picture Quality Analysis (PQA and IS_VSD options)
S.1 Overview.......................................................................................................................S-1
Architecture.........................................................................................................................S-3
Operating Modes.................................................................................................................S-4
S.2 Setting Up the OTR for Quality Analysis .....................................................................S-5
Step 1: Switch into PQA Mode...........................................................................................S-5
Step 2: Setting the OTR up for the required Operating Mode ............................................S-6
Step 3: Align Test and Reference Signals...........................................................................S-9
S.3 Picture Difference Display..........................................................................................S-11
Selection............................................................................................................................S-12
Configuration Issues..........................................................................................................S-12
Display Properties .............................................................................................................S-13
S.4 PQA Meters Display ...................................................................................................S-15
Selection............................................................................................................................S-15
Configuration ....................................................................................................................S-16
Display Properties .............................................................................................................S-16
S.5 PQA Charts .................................................................................................................S-17
Selection............................................................................................................................S-17
Configuration Issues..........................................................................................................S-18
Display Properties .............................................................................................................S-19
Capturing and Comparing Picture Quality Graphs ...........................................................S-21
S.6 Status...........................................................................................................................S-23
Selection............................................................................................................................S-24
Configuration Issues..........................................................................................................S-24
Video Information Displayed............................................................................................S-24
S.7 Remote Control...........................................................................................................S-25

OmniTek OTR 1001 User Guide, v3.1a
T The Config Window
T.1 Overview...................................................................................................................... T-1
Saving and Recalling Specific System Set-ups.................................................................. T-1
T.2 Video Config Page....................................................................................................... T-2
The Parameters................................................................................................................... T-4
Input Video Standards........................................................................................................ T-4
RGB Input Section............................................................................................................. T-4
XYZ Input Section (where included)................................................................................. T-4
Picture Content Section...................................................................................................... T-4
Error Checking Section...................................................................................................... T-5
Picture Quality (where included) ....................................................................................... T-6
Eye/Jitter Settings (where included) .................................................................................. T-7
Timecode Settings.............................................................................................................. T-7
Caption Settings ................................................................................................................. T-7
Picture View Aspect Ratio................................................................................................. T-8
T.3 Audio Config Page....................................................................................................... T-9
Selecting the Audio Type................................................................................................. T-10
Parameters........................................................................................................................ T-10
T.4 System Page ............................................................................................................... T-12
System Configuration Settings......................................................................................... T-12
3D Settings (where included)........................................................................................... T-14
Waveform Graticules ....................................................................................................... T-15
Time ................................................................................................................................. T-16
System Information.......................................................................................................... T-16
IP Address Information.................................................................................................... T-16
Licences............................................................................................................................ T-16
Button Bar options ........................................................................................................... T-16
T.5 Video Inputs Page ...................................................................................................... T-17
T.6 Audio Inputs Page...................................................................................................... T-17
Channel Allocation........................................................................................................... T-18
U Importing/Exporting Settings and User Files
U.1 Overview......................................................................................................................U-1
U.2 Calling up the Manage User Files Dialogue ................................................................U-3
Log Files Folder .................................................................................................................U-4
USB Drives ........................................................................................................................U-4
U.3 Exporting User Files.....................................................................................................U-5
Exporting Files from their Default location.......................................................................U-5
Exporting Generator Patterns from other locations............................................................U-7
U.4 Importing Files into the User area................................................................................U-8
U.5 Deleting User Files.......................................................................................................U-9
Deleting Files from their Default location .........................................................................U-9
Deleting Generator Patterns from other locations............................................................U-10
U.6 Importing/Exporting/Deleting the Configuration.......................................................U-11
U.7 Importing/Exporting/Deleting the System Settings ...................................................U-11

OmniTek OTR 1001 User Guide, v3.1a
V Extended Video Support (VIDEO_HD option + others)
V.1 HD and HSDL Dual-Link Support (Added by VIDEO_DL) ......................................V-2
V.2 3G Level A Signal Support (Added by VIDEO_3G) ..................................................V-3
V.3 3G Level B Dual-Link Signals (Added by VIDEO_3G).............................................V-4
V.4 3G Level B Dual-Stream Signals (Added by VIDEO_3G) .........................................V-5
V.5 Digital Cinema Support................................................................................................V-5
App. I: ANC Packet Descriptor Creation................................................................................ I-1
Overview............................................................................................................................. I-1
Description Creation ........................................................................................................... I-3
The Elements....................................................................................................................... I-4
Layout................................................................................................................................ I-12
App. II: Remote Control using SNMP....................................................................................II-1
II.1 Set-Up...........................................................................................................................II-1
II.2 Controlling the OTR 1001............................................................................................II-2
App. III : Resetting the Screen Resolution ...........................................................................III-1
III.1 Procedure.....................................................................................................................III-2

OmniTek OTR 1001 User Guide, v3.1a
A-1
A: Equipment Guide
Introduction
The OmniTek OTR 1001 is an extremely versatile instrument for video test and measurement.
The base instrument is an image analyzer, offering picture monitoring and waveform,
vectorscope, gamut and status displays. However, the OTR is offered with a wide range of
instrument options, some of which enhance the facilities it offers as an image analyzer while
other options add test signal generation facilities. Further options allow the OTR to be set up to
carry out picture quality assessments, a range of timing tests and physical layer measurements.
As an image analyzer, the OTR 1001 can provide high precision waveforms, vectorscope and
gamut displays; real-time picture monitoring; comprehensive SDI input status information; audio
monitoring capabilities; and transport layer analysis including eye-pattern and jitter displays.
(The options offered depend on the software options that are installed.)
As a test signal generator, the instrument can generate a wide range of standard test patterns and
zoneplates; play-out video images and sequences from disk (including 3D sequences), and add
gain, noise, bounce and audio tones to the resulting test signal (again depending on which
options are installed). It is also able to generate and add timecodes, WSS, video index and
SMPTE 352 codes.
The OTR also has the ability to freeze the screen display and to capture images from the
incoming video
The OTR 1001 is available in 1001c and 1001m versions. The OTR 1001c is designed to be
driven from the control panel on the front of the instrument but both the OTR 1001c and the
OTR 1001m may be driven using a mouse and keyboard. Most instrument features can be
selected using either method but there are some facilities that are only available when a mouse is
attached. For example, a mouse is needed to set up new screen layouts. However, once any
layout has been recorded as a preset, it can be called into use from the control panel –without
any need for a mouse.
In designing the system, we have given close consideration to our existing customers and made
the interface as familiar as possible to them, while also making it easy for users of other
manufacturers’ systems by designing it to follow a similar methodology.

OmniTek OTR 1001 User Guide, v3.1a
A-2
Safety Statement
To avoid injury and prevent damage to the OTR or to any products connected to it, use this
product only as specified and take the following safety precautions. Where the OTR is being
used alongside other equipment, you must also ensure that you act in accordance with the advice
given in the documentation supplied with those other products.
Only use the power cord that is both specified for this product and certified for the
country of use.
Ensure that the product is properly grounded through the grounding conductor within the
power cord.
Ensure that it is always possible for the user to switch off the power to the unit if need be.
Keep all product surfaces clean and dry.
Ensure that the unit is properly ventilated.
Do not operate in an explosive atmosphere or in damp/wet conditions.
Do not operate the OTR 1001 with either the cover or any of the panels removed or
otherwise displaced from their standard positions.
Do not operate an OTR 1001 that has been damaged (or that you suspect has been
damaged).
When replacing the power supply fuse, only use a fuse of the specified type and rating.
When replacing the on-board battery, only use a battery of the specified type and rating.
Do not connect or disconnect test leads while they are connected to a voltage source.
Do not touch exposed connections and components without first disconnecting the unit
from mains power.
Please note: The only user-serviceable parts are the fuse associated with the power supply and
the battery on the motherboard that backs up the system clock. There are no other user-
serviceable parts.

OmniTek OTR 1001 User Guide, v3.1a
A-3
A.1 System Features and Instrument Options
The main features of the OTR 1001 are summarised in the following table.
Feature
Description
Monitoring system
Centred around a single ‘View’ window – divided into ‘tiles’, each of which
may be used to show the result of a separate type of analysis applied to the
video under test. Individual tiles may be shown full screen or directed to a
separate monitor. Default set of four tiles, readily extended to any number and
arrangement to tiles.
Presets
Save and re-call of unlimited number of ‘View’ window layouts, recorded
complete with details of individual Views that are displayed. Similar ability to
save and re-call configurations and test signal selections.
Control systems
Optional front panel controls; alternative keyboard and mouse control; range
of ‘Soft’ buttons offering context-sensitive selection of actions.
Video formats
supported
SD and HD video supported as standard; DL and 3G support added through
software options.
Configuration
System configured through dedicated ‘Config’ pages. Individual displays
configured through ‘Properties’ controls.
Image Analysis:
General Features
Analysis of full raster/active picture/selected area as required.
Fully digital processing.
Waveform
High resolution Waveform View displaying YCbCr, RGB, YRGB or
composite waveforms. Cursors provided for measurement with automatic
read-out of results.
Vectorscope
Choice of 100% and 75% graticules.
Gamut
Choice of Bar chart; CIE Colour Chart and Histogram views.
Pixel Data
Standard display of data from both the active area and the blanking;
‘Extended’ display with interpretation, especially of ANC packets; option of
defining own ANC packet descriptors.
Audio
Audio displays include PPMs, True Peak, Loudness History, Status
information, Surround Sound and Lissajous displays. Wide-range of industry-
standard graticules and ballistics applied.
3D Toolset
Additional displays/display modes analysing depth in Viewer’s world, luma
& chroma differences between left and right images, and camera alignment.
Picture Quality
Special ‘PQA’ Mode in which the OTR may be used to carry out ‘Full-
reference’ Picture Quality Analysis (PQA) of both live and stored SD, HD or
3G video.
Picture Display
Full-resolution video images on which timecodes and other embedded data
can be displayed; alternative pulse cross and full frame displays. Aspect ratio
from WSS, Video Index, AFD or set manually. Safe Area and Safe Title
cages.
Status Information
Comprehensive Status information with automatic flagging of those sections
where an error has occurred.

OmniTek OTR 1001 User Guide, v3.1a
A-4
Feature
Description
Timecode Support
LTC, VITC and ATC timecodes supported as standard.
Error tracking and
logging
Automatic Live log, plus option of user-defined session logs –saved on disk
as XML files e.g. for subsequent analysis. Also option of alarm as response to
error events. Also possible to log captions and loudness.
Eye and Jitter
Eye and Jitter displays and waveform measurements available through
addition of appropriate EYE_ options. Also estimate of cable length.
Timing measurements
A/V Delay measurements and Reference Timing measurements.
Test Signal
Generation:
Generation of zoneplate and line pattern test signals including Pathological
test patterns. Images and video clips stored on disk can also be used as test
signals. Full raster images/sequences and 3D supported through additional
options.
Capture of Video Clips
Single frame capture provided with the test signal generator. Full frame and
sequence capture provided as options.
Remote control
Support for remote control using SNMP protocol.
Screen freeze and
capture
Single frame GUI freeze and capture offered as standard.
Instrument Options
The OTR 1001 is offered with a wide range of options that enhance the facilities it offers in
various ways (see below).
Video Standard Support
VIDEO_SD
Support for SD video (included as standard)
VIDEO_HD
Support for HD video (included as standard)
VIDEO_DL
Adds support for Dual Link video
VIDEO_3G
Adds support for 3G video
Monitoring Options
VIEW
Included as standard
Picture monitoring: pulse cross, full raster, flashing errors.
Comprehensive Video Status; Display freeze and capture.
Timecodes, Closed Captions; Teletext;
Cage: Safe Area, Safe Action graticule on picture and SDI output.
VIEW_WFM
Included as standard
YCbCr, RGB, YRGB, Composite Waveforms; Vectorscope; Logging, Alarms;
Gamut display.
VIEW_DATA
Pixel data display (presented either as bare data or with data interpretation).
VIEW_2
Adds support for dual simultaneous monitoring for SD, HD and 3GA.
(Simultaneous monitoring of two 3GB or Dual Link inputs not supported.)
VIEW_XR_DCI
Adds XYZ monitoring, CIE colour chart, histograms, and support for 12 bit.
VIEW_3D
Adds 3D Toolset.
ALIGNMENT
Adds ability to align a camera to reference (also provided by VIEW_3D option).
PQA
Adds picture quality analysis (requires AV_ISD).
AV_ISD
Adds ‘In-Service’ audio/video delay measurement.

OmniTek OTR 1001 User Guide, v3.1a
A-5
Audio Options
AUDIO
Audio monitoring: PPM, phase with Clip, Over, Silence, Mute indication;
Play-out; Audio Status, Surround Sound, Lissajous (included as standard)
AUDIO_LOUD
Loudness PPMs; True Peak values; Loudness Range; Loudness History
(automatically installed in systems for which earlier AUDIO option was
purchased)
AUDIO_AES
AES audio card: requires AUDIO
AUDIO_DOLBY_E
Full decode + all AUDIO features + stereo mix-down monitoring: requires
AUDIO
AUDIO_DOLBY_D
Full Dolby Digital decode: requires AUDIO
Physical Layer –Note: Video standard support of selected EYE option must match system video
standard support. Also may require hardware swap out and replacement at the factory.
EYE_SD
SD Eye Height, Eye Diagram and Jitter; and estimated cable length
EYE_HD
SD / HD Eye Height, Eye Diagram and Jitter; and estimated cable length:
requires VIDEO_HD
EYE_3G
SD / HD / 3G Eye Height, Eye Diagram and Jitter; and estimated cable length:
requires VIDEO_HD & VIDEO_3G
Generator Options
GEN_BASIC
Basic static test pattern generator –included as standard
GEN
SD / HD Generator: zoneplates, line patterns, active video stills, gain, noise,
bounce insertion; audio tone generation; VITC, ATC, WSS, VINDEX,
SMPTE 352 generation; single frame capture
GEN_MOTION
Sequence Play-out from PC RAM: requires GEN
GEN_ADV
RVF Generation and ANC Generation, custom ANC streaming, CC
generation: requires GEN
GEN_2
Simultaneous generation of two output streams. Enables generation of Stereo 3D
video: requires GEN.
Capture Options
CAP_MOTION
Full Motion Capture: records uncompressed to RAM; requires GEN
CAP_ADV
RVF and ANC Capture, RVF still or sequence capture; Trigger on errors;
requires GEN.
Note:
Enhancing your system may involve adding extra software facilities or additional hardware or
occasionally both.
New hardware is generally supplied with instructions for fitting. The exception to this is where
an EYE_ option is added: in this case, the OTR system may need to be returned to have the
necessary hardware factory-fitted. (Your dealer will advise you on this.)
Extra software facilities are made available by providing an updated licence file, and again
instructions will be provided alongside the new licence file.
When installing new facilities, it is a good idea to check that you are using the most up-to-date
version of the software. How this is done is described in Section A.5. (Details of the version you
are currently using are given on the System page of the OTR’s Config window.)

OmniTek OTR 1001 User Guide, v3.1a
A-6
A.2 Installation
The OTR 1001 is supplied with the software and any additional hardware that is required to support
the instrument options that have been purchased e.g. AES and Eye/Jitter cards already installed.
So after a couple of preliminary steps (see below), the job of installing the OTR 1001 is simply
one of locating the instrument where you want to use it and attaching the appropriate cables.
Preliminary steps:
Checking the Pack Contents
Alongside the OTR 1001 in the OTR 1001 pack, you should find:
Appropriate national power cord (UK/US/Europe/Australia)
USB Stick (in the mini-box)
Quick Start Guide Cards (in the mini-box)
Note: This list is subject to change. A packing list for the OTR you have bought is included in
the pack.
Before starting to install the OTR 1001 for use in your facility, check that you have received all
of items listed above. Note: Any additional boards that are required to support additional
application options you have purchased will be already installed in the OTR 1001.
We recommend saving the shipping carton and all packing materials in case you subsequently
need to ship the OTR 1001 anywhere.
Mounting in a rack
The OTR 1001 can be used mounted in a standard 19" rack.
Cabling
The remaining task therefore to make the appropriate connections for the task it is to perform.
The majority of these connections will be to the connectors on the back panel of the instrument,
which are detailed in the following diagram and table.
Interface
Port
Reference
Loop Power Socket
Extracted
Clock
Eye/Jitter
Card Outputs
SDI IN 1,2 Analog Out
SDI OUT 1,2
Eye/Jitter
Card Inputs
AES Card (where fitted)
I/O Port B
I/O Port A
Eye/Jitter Card (where fitted)
USB
Ports
DVI-I Out Ethernet
Connectors
SDI IN1 SDI IN2 SDI OUT1 SDI OUT2 ANA OUT
SDI IN1 SDI IN2 SDI OUT1 SDI OUT2 ANA OUT
EYE IN1 EYE IN2 EYE OUT1 EYE OUT2 EX CLK
Figure A-1: Rear views of an OTR 1001, one showing the optional Jitter card fitted
and the other the optional AES Audio card fitted.

OmniTek OTR 1001 User Guide, v3.1a
A-7
The back panel offers the following connectors:
Connector:
Use:
SDI Card
SDI IN1, SDI IN2
SDI video inputs
Connection: 2 x BNC with 75ohm termination
Return Loss: >15dB up to 1.485GHz, then >10dB to 2.97GHz
Bit Rates: 270Mbit, 1.485Gbit, 2.97Gbit (SMPTE 259M, 292M, 424M)
SDI OUT1, SDI OUT2
SDI video outputs, providing either Generator output or loop-through of input
video (see Section P.4)
Connection: 2 x BNC with 75ohm termination
Bit Rates: 270Mbit, 1.485Gbit, 2.97Gbit (SMPTE 259M, 292M, 424M)
Jitter: < 0.2UI, 10Hz to 100kHz
ANA OUT
Analog (Monitor) output
Connection: 8-pin Lemo
Video Output: RGB with bi- or tri-level sync on green, 0.7Vpk-pk video; or
YPrPb with bi- or tri-level sync on Y, 0.7Vpk-pk video; or Composite & S-
Video (in PAL or NTSC) 0.7Vpk-pk video.
Return Loss: >20dB up to 30MHz
Jitter Card (where fitted)
EYE IN1, EYE IN2
Eye/Jitter card inputs:
Connection: 2 x BNC with 75ohm termination
Return Loss: >15dB up to 1.485GHz, then >10dB to 2.97GHz
Bit Rates: 270Mbit, 1.485Gbit, 2.97Gbit (SMPTE 259M, 292M, 424M)
EYE OUT1, EYE OUT2
Eye/Jitter card outputs, providing loop-through of Eye/Jitter card inputs
Connection: 2 x BNC with 75ohm termination
Bit Rates: 270Mbit, 1.485Gbit, 2.97Gbit (SMPTE 259M, 292M, 424M)
Jitter: < 0.2UI, 10Hz to 100kHz
EX CLK
Extracted Jitter clock. 800mV p-p into 75ohm load.
SD frequency: 27MHz; HD frequency: 74.25 or 74.18MHz
AES Card (where fitted)
I/O Port A
AES Card Port A. Breakout cabling (XLR connectors) to four digital inputs,
four digital outputs and a clock input.
I/O Port B
AES Card Port B. Breakout cabling (XLR connectors) to four digital inputs,
four digital outputs and a clock output.
Other Connectors
DVI-I Out
DVI Connector, supporting both DVI and VGA monitors.
Ethernet Connectors
2 x RJ-45 gigabit Ethernet connectors. Note: The network port by the USB
ports is currently disabled. This will be supported in a future software release.
USB Ports
2 x USB 2.0 ports on the rear, plus 2 x USB 2.0 on the front, available for
connecting USB 1 or USB 2 mouse, keyboard, memory stick etc.
Reference Loop
Connection: 2 x BNC connectors, linked internally. Resistance 5ohm
Return loss: >25dB to 30MHz
Interface Port
26-way HD port
Headphone Jack
3.5mm stereo jack (on front).

OmniTek OTR 1001 User Guide, v3.1a
A-8
Adding the Graphics Display
The graphics output from the OTR 1001 can be displayed by plugging a DVI monitor or a VGA
monitor into the DVI-I Out connector on the back panel. Depending on the VGA monitor cable,
this can either be plugged in directly or via the VGA –DVI cable included with the OTR.
Note: A high-resolution computer monitor is needed when working with 3G video.
DVI-I Out
SDI IN1 SDI IN2 SDI OUT1 SDI OUT2 ANA OUT
Figure A-2: Rear view of an OTR 1001 showing the DVI-I Out connector and the Interface port.
Display Resolution
With a DVI monitor, the screen resolution is automatically set to the correct resolution for the
monitor. However, with some VGA monitors, the OTR is not able to set the optimum resolution
automatically and may even give no display at all.
The point at which this might cause a problem is either the very first time you use the OTR or
immediately after switching to a different monitor. If the screen resolution is poor or you don’t
get any display, follow the steps given in Appendix IV of this User Guide.
Adding Mouse and Keyboard
The OTR 1001 offers four USB ports through which a USB mouse, USB keyboard or combined
USB mouse and keyboard may be plugged in –two on the front panel and two on the back panel.
Devices plugged into any of these ports will be automatically recognised by the underlying
Windows system and immediately made available for use, with the standard mouse actions of
pointing and clicking having their usual effects.
