Omnitron Systems RuggedNet GHPoE/Si User manual

RuggedNet® GHPoE/Si and GHPoEBT/Si
Unmanaged 6 Port
60W Pre-BT PoE and 60/100W IEEE 802.3bt
Gigabit Switches
User Manual
38 Tesla, Irvine, CA 92618 USA
Phone: [phone]; Fax: [phone]
General and Copyright Notice
This publication is protected by U.S. and international copyright laws. All rights
reserved. The whole or any part of this publication may not be reproduced, stored
in a retrieval system, translated, transcribed, or transmitted, in any form, or by
any means, manual, electric, electronic, electromagnetic, mechanical, chemical,
optical or otherwise, without prior explicit written permission of Omnitron Systems
Technology, Inc.
The following trademarks are owned by Omnitron Systems Technology, Inc.:
FlexPointTM, FlexSwitchTM, iConverter®, miConverterTM, NetOutlook®, OmniLight®,
OmniConverter®, RuggedNet®, Omnitron Systems Technology, Inc.TM, OSTTM and
the Omnitron logo.
All other company or product names may be trademarks of their respective owners.
The information contained in this publication is subject to change without notice.
Omnitron Systems Technology, Inc. is not responsible for any inadvertent errors.
Warranty
This product is warranted to the original purchaser (Buyer) against defects in
material and workmanship for a period of two (2) years from the date of shipment.
A ve (5) year warranty may be obtained by the original purchaser by registering
this product at www.omnitron-systems.com/support within ninety (90) days from the
date of shipment. During the warranty period, Omnitron will, at its option, repair or
replace a product which is proven to be defective with the same product or with a
product with at least the same functionality.
For warranty service, the product must be sent to an Omnitron designated facility,
at Buyer’s expense. Omnitron will pay the shipping charge to return the product
to Buyer’s designated US address using Omnitron’s standard shipping method.
Limitation of Warranty
The foregoing warranty shall not apply to product malfunctions resulting from
improper or inadequate use and/or maintenance of the equipment by Buyer, Buyer-
supplied equipment, Buyer-supplied interfacing, unauthorized modications or
tampering with equipment (including removal of equipment cover by personnel not
specically authorized and certied by Omnitron), or misuse, or operating outside
the environmental specication of the product (including but not limited to voltage,
ambient temperature, radiation, unusual dust, etc.), or improper site preparation
or maintenance.
No other warranty is expressed or implied. Omnitron specically disclaims the implied
warranties of merchantability and tness for any particular purpose.
The remedies provided herein are the Buyer’s sole and exclusive remedies. Omnitron
shall not be liable for any direct, indirect, special, incidental, or consequential
damages, whether based on contract, tort, or any legal theory.
Page 2

Environmental Notices
The equipment covered by this manual must be disposed of or recycled in
accordance with the Waste Electrical and Electronic Equipment Directive (WEEE
Directive) of the European Community directive 2012/19/EU on waste electrical and
electronic equipment (WEEE) which, together with the RoHS Directive 2015/863/
EU, for electrical and electronic equipment sold in the EU after July 2019. Such
disposal must follow national legislation for IT and Telecommunication equipment
in accordance with the WEEE directive: (a) Do not dispose waste equipment with
unsorted municipal and household waste. (b) Collect equipment waste separately.
(c) Return equipment using collection method agreed with Omnitron.
The equipment is marked with the WEEE symbol shown to indicate that it
must be collected separately from other types of waste. In case of small items the
symbol may be printed only on the packaging or in the user manual. If you have
questions regarding the correct disposal of equipment go to www.omniton-systems.
com/support or e-mail to Omnitron at [email protected].
Safety Warnings and Cautions
ATTENTION: Observe precautions for handling electrostatic discharge
sensitive devices.
WARNING: Potential damage to equipment and personal injury.
WARNING: Risk of electrical shock.
WARNING: Hot surface.
RuggedNet®GHPoE/Si and GHPoEBT/Si
User Manual
Product Overview
The RuggedNet GHPoE/Si and GHPoEBT/Si are industrial unmanaged Ethernet
switches that feature ber or copper uplink ports and four 10/100/1000 RJ-45
copper Power-over-Ethernet user ports.
The GHPoE/Si is a pre-IEEE 802.3bt switch featuring up to 60W per user port
models. The GHPoEBT/Si is an IEEE 802.3bt compliant PoE switch featuring 60W
and 100W per user port models.
The RuggedNet switches functions can be congured using easily accessible
DIP-switches.
RuggedNet 6 Port Module
The modules are Power Sourcing Equipment (PSE) that provides up to 100W
(depending on the model number) per RJ-45 user port and supports frame sizes
up to 10,240 bytes.
Front Panel
The front of the module provides access to the RJ-45 PoE and uplink ports.
RJ-45 PoE, Uplinks and Fixed-Fiber Ports
The RJ-45 PoE Ethernet user port supports 10BASE-T, 100BASE-TX and
1000BASE-T protocols, auto-negotiation and auto MDI/MDI-X crossover.
The module is available with one or two gigabit SFP transceiver uplink ports or
two 10/100/1000BASE-T RJ-45 copper uplink ports or two LC xed gigabit ber
uplink ports.
The SFP ports support SERDES 1000BASE-X ber transceivers (multimode,
single-mode and single-mode singe-ber) and SGMII 10/100/1000BASE-T copper
transceivers. The SFP interfaces operate in auto-negotiation and support full
duplex operation.
Fixed-ber 1000BASE-X connectors are available with multimode (MM) dual ber,
single-mode (SM) dual ber and single-mode single-ber (SF) options. Dual ber
options are available with ST, SC and LC connectors. Single-ber options are
available with SC connectors.
Page 3 Page 4

Page 5
Front Panel Layout
Reset Button
A Reset Button is available on the front of the switch to restore the switch to factory
default values and clear buffers and memory. Press and hold the reset button for
more than 5 seconds to restore the switch to factory default values.
Installation Procedure
1) Congure DIP-switches
2) Installing the Module
3) Apply DC Power
4) Connect Cables
5) Verify Operation
1) Congure DIP-switches
DIP-switches are located on the top of the module. The DIP-switches are used to
congure modes of operation, networking features and PoE reset.
DIP-switch Bank Locations
Page 6
The table below provides a description of each DIP-switch position and function.
Switch 1 Uplink Port 2 Uplink Ports
SW1 Reserved Device Mode
SW2 Switch Mode
SW3 Reserved Uplink Redundancy
SW4 Reserved
SW5 MAC Learning
SW6 Forced PoE Power
SW7 L2CP
SW8 PoE Reset
DIP-switch Denitions
SW1 and SW2: Mode of Operation
The modules support Switch, Directed Switch and Dual Device modes.
The modes are described with MAC learning enabled. When MAC learning is
disabled, unicast packets are forwarded to all ports.
SW1 SW2 Function
LEFT LEFT Switch Mode (factory default)
LEFT RIGHT Directed Switch Mode
RIGHT LEFT Dual Device Mode - Switch Mode
RIGHT RIGHT Dual Device Mode - Directed Switch Mode
Modes of Operation
Switch Mode
When congured for Switch Mode (factory default), the module operates as a
standard layer 2 switch. Data ow will follow MAC address mapping.
Directed Switch Mode
When congured for Directed Switch Mode, trafc from ports P1 - P4 is only
forwarded to the uplink port F1, preventing the broadcast trafc from ooding other
network ports. Incoming trafc from F1 follows MAC address mapping.
Directed Switch Mode Single Uplink Port

Page 7
For models with two uplink ports (copper or ber), the data trafc on the additional
uplink port (F2) is also forwarded to port F1.
Directed Switch Mode Dual Uplink Port
When models with two uplink ports are congured for Directed Switch Mode and
Uplink Redundancy (per DIP-switches 3 and 4), trafc is forwarded to both the
primary and secondary uplink ports. The secondary port will block all trafc while
the primary port is active. When the primary port goes down, the secondary port
will be active and all trafc will be forwarded out the secondary port (F2).
Directed Switch Mode with Uplink Redundancy
Page 8
Dual Device Mode
Dual Device Mode is only supported on models with two uplink ports.
When congured for Dual Device Mode, the module is congured as two logically
independent Layer 2 switches. Port F1 is associated with ports P1 and P2 and Port
F2 is associated with ports P3 and P4. Data ow will follow MAC address mapping.
Dual Device Mode
Congured for Dual Device Mode and Directed Switch Mode, the trafc from ports P1
and P2 is only forwarded to uplink port F1 and ports P3 and P4 are only forwarded
to uplink port F2. This prevents broadcast trafc from ooding other network ports.
Incoming trafc from F1 and F2 follows MAC address mapping.
Dual Device with Directed Switch Mode

Page 9
SW3 and SW4: Uplink Redundancy
Uplink redundancy mode is only supported on models with two uplink ports.
The modes are described with MAC learning enabled. When MAC learning is
disabled, the module will send data to all ports.
SW3 SW4 Function
LEFT LEFT Switch Mode (factory default)
LEFT RIGHT Switch Mode (factory default)
RIGHT LEFT Redundant Mode - no return to primary (F1)
RIGHT RIGHT Redundant Mode - return to primary (F1)
Uplink Redundancy
When congured for Uplink Redundant Mode “no return to primary”, the uplink
ports operate as redundant links. A fault on the primary Port F1, will cause a fail
over to the secondary Port F2 within 50msec. Port F1 will become the secondary
port once the failure condition has been restored because “no return to primary”
has been selected.
Redundant Uplink
When congured for Uplink Redundant Mode “return to primary’, a fault on the
primary Port F1, will cause a fail over to the secondary Port F2 within 50msec.
The module will return to the primary Port F1 after the failure condition has been
restored for 6 seconds.
Page 10
SW5: MAC Learning - “MAC Learning/Off”
When this DIP-switch is in the LEFT “MAC Learning” position (factory default), all
ports on the module will learn the source MAC address of each received packet and
store the address so packets destined for the stored addresses can be forwarded
to the appropriate port on the module. When the DIP-switch is in the RIGHT “Off”
position, learning is turned off and all received unicast packets are forwarded to
all ports.
SW6: Forced PoE - “Off/ PoE Forced”
This DIP-switch allows the PoE power to be forced ON when connected to a PD
with non-standard detection characteristics. The DIP-switch controls the forced
capability for the RJ-45 user ports on the module.
When this DIP-switch is in the LEFT “Off” position, all RJ-45 user port will
automatically perform the detection, classication and powering functions for the
attached PD. When this DIP-switch is in the RIGHT “PoE Forced” position, all RJ-45
user ports will provide a maximum of 60 or 100 watts of power (depending on the
model) to the PD.
SW7: L2CP - “L2CP Tunnel/Discard”
When this DIP-switch is in the LEFT “L2CP Tunnel” position (factory default), all
L2CP frames will be tunneled through the module. When this DIP-switch is in the
RIGHT “Discard” position, all L2CP frames will be discarded.
SW8: PSE Reset - “Off/PoE Reset”
The module can be congured to disable (reset) the PoE output power for 5 seconds
after a loss of receive link on any uplink port. This feature is typically used to allow
a PD to re-initialize after a failure on the incoming uplink.
When this DIP-switch is in the LEFT “Off” position (factory default), PoE output power
does not reset on a loss of receive link on any uplink port. When this DIP-switch is
in the RIGHT “PoE Reset” position, the module will disable PoE output power for 5
seconds following a loss of receive link on any uplink port.
When uplink redundancy is enabled, the loss of link on either F1 or F2 will not cause
the PD to be re-initialized even though the PSE Reset is enabled. The PD will be
re-initialized on a loss of receive link on both uplink ports.
When Dual Device Mode is enabled, the loss of receive link on a uplink port will
re-initialize the PDs associated with the that uplink port. Ports P1 and P2 will drop
PoE power when a loss of receive link on F1 is detected and ports P3 and P4 will
drop PoE power when a loss of receive link on F2 is detected.

Page 11 Page 12
2) Installing the Module
The module can be wall or rack mounted using the optional Wall Mount Plate
(8260-3). Refer to the Wall Mount Plate user manual (040-08260-301x) for the
proper installation guidelines.
Wall Mounting
The wall mounting height of the module should be less than or equal to 2 meters
(6.6 feet) from the oor. Use the four mounting holes on the module to secure the
module to the wall. The module can accommodate #6 screws (not included).
Installation of the module should be such that the air ow in the front, back, side
and top vents of the switch are not compromised or restricted.
The accessory cables should have their own strain relief and do not pull down on
the module.
Rack Mounting
The module can be rack mounted using the optional Rack Mount Shelf (8260-0).
Refer to the Rack Mount Shelf user manual (040-08260-001x) for the proper
installation guidelines.
Follow the same guidelines above when rack mounting the module.
3) Apply DC Power
This module is intended for installation in restricted access areas. (“Les matériels
sont destinés à être installés dans des EMPLACEMENTS À ACCÈS RESTREINT”).
A restricted access area can be accessed only through the use of a special key, or
other means of security.
The over current protection for connection with centralized DC shall be provided in
the building installation, and shall be a UL listed circuit breaker rated 20 Amps, and
installed per the National Electrical Code, ANSI/NFPA-70.
The GHPoE/Si and GHPoEBT/Si (60W models) requires +50 to +57VDC inclusive
of tolerances (4.46A @ 56VDC max rated power) and the GHPoEBT/Si (100W
models) requires +52 to +57VDC inclusive of tolerances (7.31A @ 56VDC max
rated power). See specication table for specic model requirements.
Appropriate overloading protection should be provided on the DC power source
outlets utilized.
Top View with DC Power Connector
WARNING: OnlyaDC power source that complies with
safety extra low voltage (SELV) requirements can be
connected to the DC-input power supply.
WARNING REGARDING EARTHING GROUND:
o
o
o
o
This equipment shall be connected to the DC supply
system earthing electrode conductor or to a bonding
jumper from an earthing terminal bar or bus to which the
DC supply system earthing electrode is connected.
This equipment shall be located in the same immediate
area (such as adjacent cabinets) as any other equipment
that has a connection between the earthed conductor of
the same DC supply circuit and the earthing conductor,
and also the point of earthing of the DC system. The DC
system shall not be earthed elsewhere.
The DC supply source is to be located within the same
premises as this equipment.
There shall be no switching or disconnecting devices in
the earthed circuit conductor between the DC source and
the earthing electrode conductor.
Locate the DC circuit breaker of the external power source, and switch the circuit
breaker to the OFF position.
Prepare a power cable using a three conductor insulated wire (not supplied) with
12AWG to 14AWG thickness. Cut the power cable to the length required.
Strip approximately 3/8 of an inch of insulation from the power cable wires.
Connect the ground wire to the grounding screws on the back of the module.
Ground Screw Location
Connect the power cables to the module by fastening the stripped ends to the DC
power connector.
Power Connections

Page 14
Power Options
WARNING: The positive lead of the power source must be connected to the
“+” terminal on the module and the negative lead of the power source to the
“-“ terminal on the module as shown above.
The power connections on the module are isolated. This provides support of positive
or negative power connections.
WARNING: Note the wire colors used in making the positive, negative and
ground connections. Use the same color assignment for the connection at
the circuit breaker.
Connect the power wires to the circuit breaker and switch the circuit breaker ON.
If any modules are installed, the Power LED(s) will indicate the presence of power.
During the installation, ensure that the ground potentials are maintained throughout
the system connections. This includes but not limited to the power source ground
and any shielded cabling grounds.
NEVER ATTEMPT TO OPEN THE CHASSIS OR
SERVICE THE POWER SUPPLY. OPENING THE
CHASSIS MAY CAUSE SERIOUS INJURYOR DEATH.
THERE ARE NO USER REPLACEABLE OR
SERVICEABLE PARTS IN THIS UNIT.
WARNING!!!
Make sure to disconnect both power connectors and the ground cables before
removing the equipment.
Page 13
4) Connect Cables
a. When using SFP models, insert the SFP ber transceiver into the SFP
receptacle on the front of the module (see the SFP Data Sheet 091-17000-001
for supported Gigabit transceivers).
NOTE: The release latch of the SFP ber transceiver must be in the closed
(up) position before insertion.
b. Connect an appropriate multimode or single-mode ber cable to the ber port
on the front of the module. It is important to ensure that the transmit (TX) is
attached to the receive side of the transceiver at the other end and the receive
(RX) is attached to the transmit side. When using single-ber (SF) models, the
TX wavelength must match the RX wavelength at the other end and the RX
wavelength must match the TX wavelength at the other end.
c. Connect the Ethernet 10/100/1000 RJ-45 port using a Category 5 or better
cable to an external 10BASE-T, 100BASE-TX or 1000BASE-T Ethernet device.
Description
15W
IEEE 802.3af
PoE
30W
IEEE 802.3at
PoE+
60W
Pre-BT and IEEE
802.3.bt PoE
(Type 3)
100W
IEEE 802.3bt
PoE
(Type 4)
Power Supply Voltage
Range 46.0 to 57.0 VDC 51.0 to 57.0 VDC 51.0 to 57.0 VDC 53.0 to 57.0 VDC
Voltage Range at PSE
port Output 44.0 to 56.0 VDC 50.0 to 56.0 VDC 50.0 to 56.0 VDC 52.0 to 56.0 VDC
Maximum Power from
PoE/PSE port 15.4 watts 30 watts 60 watts 100 watts
Minimum Voltage at
PoE/PD port input* 37.0 VDC 42.5 VDC 42.5 VDC 41.1 VDC
Minimum Power at
PoE/PD port* 12.95 watts 25.5 watts 51 watts 71 watts
* at 100 meters using Cat5
PoE, PoE+ and 802.3bt Requirements

Page 16
5) Verify Operation
Verify the module is operational by viewing the LED indicators.
Power
LED Indicators
Legend Indicator Description
Pwr A
and
Pwr B
OFF Unit not powered
Green - ON Unit powered
Green - Blinking at 1Hz
Unit powered and indicates the Reset switch has been
depressed for the required length of time causing a restore to
factory default condition.
Power LED Indicators
NOTE: The number of power LED indicators will depend on the model of the module.
Uplink Ports
LED Indicators - SFP and Copper Uplink Models
Legend Indicator Description
10
(100+1000)
OFF No link
Green - ON Port linked at 10Mbps
Green - Blinking at 10Hz Port data activity at 10Mbps
Green - Blinking at 1Hz Port linked at 10Mbps and in redundant secondary mode
100
OFF No link
Amber - Blinking at 1Hz Port linked at 100Mbps and receiving Far End Fault Indicator
(FEFI)
Green - ON Port linked at 100Mbps
Green - Blinking at 10Hz Port data activity at 100Mbps
Green - Blinking at 1Hz Port linked at 100Mbps and in redundant secondary mode
1000
OFF No link
Amber - Blinking at 1Hz Port not linked at 1000Mbps and receiving AN Remote Fault
Green - ON Port linked at 1000Mbps
Green - Blinking at 10Hz Port data activity at 1000Mbps
Green - Blinking at 1Hz Port linked at 1000Mbps and in redundant secondary mode
Uplink LED Indicators - SFP and Copper Models
Fiber Ports
LED Indicators - Fixed Fiber Models
Legend Indicator Description
1000
OFF No link
Amber - Blinking at 1Hz Port not linked at 1000Mbps and receiving AN Remote Fault
Green - ON Port linked at 1000Mbps
Green - Blinking at 10Hz Port data activity at 1000Mbps
Green - Blinking at 1Hz Port linked at 1000Mbps and in redundant secondary mode
Fiber LED Indicators - Fixed Fiber Models
Page 15
RJ-45 User Ports
LED Indicators
Legend Indicator Description
10
(100+1000)
OFF No link
Amber -ON Port linked at 10Mbps Half-duplex
Amber - Blinking at 10Hz Port data activity at 10Mbps Half-duplex
Green - ON Port linked at 10Mbps
Green - Blinking at 10Hz Port data activity at 10Mbps
100
OFF No link
Amber -ON Port linked at 100Mbps Half-duplex
Amber - Blinking at 10Hz Port data activity at 100Mbps Half-duplex
Green - ON Port linked at 100Mbps
Green - Blinking at 10Hz Port data activity at 100Mbps
1000
OFF No link
Amber -ON Port linked at 1000Mbps Half-duplex
Amber - Blinking at 10Hz Port data activity at 1000Mbps Half-duplex
Green - ON Port linked at 1000Mbps
Green - Blinking at 10Hz Port data activity at 1000Mbps
PoE/PSE
OFF Port PSE inactive
Amber - ON Port PSE inactive due to power demand exceeding the power
source
Green - single blink Powered by 802.3af PoE 15W
Green - two blinks Powered by 802.3at PoE 30W
Green - three blinks Powered by High-Power PoE 60W
Green - four blinks Powered by High-Power PoE 100W
RJ-45 LED Indicators
NOTE: The PSE LED may turn Amber (ON) when a non-PD device is connected to the
port.
NOTE: When disconnecting and reconnecting the cable from the RJ-45 PSE ports, it is
required to wait at least 5 seconds before reconnecting the cable to the RJ-45 PSE port.

Specications
Description
RuggedNet®GHPoE/Si (60W Pre-BT)
10/100/1000BASE-T with Gigabit Fiber or Copper Uplinks
Ruggedized Unmanaged High-Power PoE Ethernet Switch
Standard Compliances
IEEE 802.3,
IEEE 802.3af (15.40 watts max),
IEEE 802.3at (30 watts max)
High Power 60W PoE
Environmental REACH, RoHS and WEEE
PoE Modes IEEE Alternate A (Alt A)
4-Pair
Frame Size Up to 10,240 bytes
Port Types
Copper: RJ-45: 10/100/1000BASE-T
Fiber: Fixed: ST, SC, LC 1000BASE-X Fiber
SFP: 10/100/1000BASE-T SGMII Copper
Transceiver or 1000BASE-X Fiber
Transceiver
Cable Types
Copper: EIA/TIA 568A/B, Cat 5 UTP and higher
Fiber: Multimode: 50/125, 62.5/125µm
Single-mode: 9/125µm
DC Power Requirements
60W (Pre-BT)
+46 to +57VDC; inclusive of tolerance
4.46A @ 56VDC
2 Pin Terminal (non-isolated)
Dimensions (W x D X H) 1.5” x 5.5” x 5.5” (38.1 mm x 139.7 mm x 139.7 mm)
Weight 1.70 lb.; 772 grams
Operating Temperature Extended: -40 to 75°C
Storage: -40 to 80°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m (operational)
MTBF (hours) 273,000
Warranty 5 year product warranty with 24/7/365 free Technical Support
Page 18Page 17
Description
RuggedNet®GHPoEBT/Si (60/100W BT)
10/100/1000BASE-T with Gigabit Fiber or Copper Uplinks
Ruggedized Unmanaged IEEE 802.3bt PoE Ethernet Switch
Standard Compliances
IEEE 802.3,
IEEE 802.3af (15.40 watts max),
IEEE 802.3at (30 watts max)
IEEE 802.3bt (60 and 100 watts max)
Environmental REACH, RoHS and WEEE
PoE Modes IEEE Alternate A (Alt A)
4-Pair
Frame Size Up to 10,240 bytes
Port Types
Copper: RJ-45: 10/100/1000BASE-T
Fiber: Fixed: ST, SC, LC 1000BASE-X Fiber
SFP: 10/100/1000BASE-T SGMII Copper
Transceiver or 1000BASE-X Fiber
Transceiver
Cable Types
Copper: EIA/TIA 568A/B, Cat 5 UTP and higher
Fiber: Multimode: 50/125, 62.5/125µm
Single-mode: 9/125µm
DC Power Requirements
60W Models:
+46 to +57VDC; inclusive of
tolerance
4.46A @ 56VDC
2 Pin Terminal (non-isolated)
100W Models:
+46 to +57VDC; inclusive of
tolerance
7.31A @ 56VDC
2 Pin Terminal (non-isolated)
Dimensions (W x D X H) 1.5” x 5.5” x 5.5” (38.1 mm x 139.7 mm x 139.7 mm)
Weight 1.70 lb.; 772 grams
Operating Temperature Extended: -40 to 75°C
Storage: -40 to 80°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m (operational)
MTBF (hours) 273,000
Warranty 5 year product warranty with 24/7/365 free Technical Support

Regulatory Compliances
Safety: UL 60950-1,
UL-62368-1,
IEC 60950-1:2005+A1 :2009,
IEC 62368:2014/A11:2017,
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011
+A2:2013,
CAN/CSA C22.2 No. 60950-1,
CAN/CSA C22.2 No. 62368-1-14,
CE Mark
EMC: EN 55032/EN 55024 CE Emissions/Immunity,
IEC 61000-6-4 Industrial Emissions,
IEC 61000-6-2 Industrial Immunity
EMI: CISPR 32,
FCC 47 Part 15 Subpart B Class A
EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV,
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10V/m,
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV,
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV,
IEC 61000-4-6 CS: Signal: 10 V,
IEC 61000-4-8 (Magnetic Field),
IEC 61000-4-11 (General Immunity in Industrial
Environments )
IP Rating: IP40 Protection
Customer Support Information
If you encounter problems while installing this product, contact Omnitron Technical
Support:
Phone: [phone]
Fax: [phone]
Address: Omnitron Systems Technology, Inc.
38 Tesla
Irvine, CA 92618, USA
Email: [email protected]
URL: www.omnitron-systems.com
040-03200-001CD 7/20
Page 20Page 19
