FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
FinsGateway
FinsGatewayFinsGateway
FinsGateway
Modem Module
Modem ModuleModem Module
Modem Module
User
UserUser
User’
’’’s Manual
s Manuals Manual
s Manual
First Version
November, 1999
OMRON Corporation

Page: 2
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
Contents
1
11
1 Introduction
IntroductionIntroduction
Introduction ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................3
33
3
2
22
2 System Requireme
System RequiremeSystem Requireme
System Requirements
ntsnts
nts ................................
................................................................
................................................................
................................................................
.................................................
..................................
.................4
44
4
3
33
3 Setting the PLC Modem
Setting the PLC ModemSetting the PLC Modem
Setting the PLC Modem................................
................................................................
................................................................
................................................................
..............................................
............................
..............5
55
5
3.1 Communications Settings for the PLC Modem............................................................................... 5
3.2 Serial Communications Driver Settings.......................................................................................... 7
4
44
4 Operation
OperationOperation
Operation ................................
................................................................
................................................................
................................................................
................................................................
................................................................
....................................
........
....8
88
8
4.1 Registering Telephone Numbers...................................................................................................... 8
4.2 Serial Communications Driver Settings........................................................................................ 10
4.3 Close the Line ................................................................................................................................. 11
5
55
5 Caution
CautionCaution
Caution................................
................................................................
................................................................
................................................................
................................................................
................................................................
......................................
............
......12
1212
12
5.1 Communications Settings............................................................................................................... 12
5.2 Speed Setting.................................................................................................................................. 12
5.3 Connecting the PLC Modem........................................................................................................... 13
5.4 Send the AT Command................................................................................................................... 13
6
66
6 Troubleshooting
TroubleshootingTroubleshooting
Troubleshooting................................
................................................................
................................................................
................................................................
.........................................................
..................................................
.........................14
1414
14
©Copyright OMRON Corporation 1995,1996-1998,1999 All Rights Reserved.
FinsGateway was developed using Microsoft Visual C++ Version 5.0 and Version 4.1, Borland Delphi Version 2.0,
and Microsoft FrontPage98.
Copyrights of the FinsGateway manual and software are owned by OMRON Corporation, except the following
items.
FinsGateway is released containing the following items copyrighted by Microsoft Corporation. These are:
ATL.DLL; MFC42.DLL; MSVCRT.DLL; MSVCP50.dll; and OLEAUT32.dll. These modules included in
FinsGateway are redistributed based on a license agreement between Microsoft Corporation and OMRON
Corporation. Under this license agreement, these modules cannot be distributed by the customer.
FINS and FinsGateway are trademarks of OMRON Corporation.
Microsoft, Windows, WindowsNT, and Visual C++ are registered trademarks of Microsoft Corporation.
Pentium and Intel are registered trademarks of Intel Corporation.
IBM is a registered trademark of International Business Machines Corporation.
All corporate names and product names mentioned in this manual are trademarks or registered trademarks of
each company.
The symbols äand âare omitted in this document.

Page: 3
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
1 Introduction
The Modem Module is an add-on software for FinsGateway remote communication.
You can develop a remote PLC data acquisition application quickly and easily using the
modem module.
Analog Phone Line
FinsGateway + Modem Module
PLC
PLC

Page: 4
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
2 System Requirements
The Modem Module is an add-on software for FinsGateway. Therefore, the environment must
support the operation of FinsGateway. The following system specifications are recommended
to operate the Modem Module.

Page: 5
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
3 Setting the PLC Modem
3 – 1 Communications Settings for the PLC Modem
Modems can detect the communication settings automatically to communicate with the
computer when the computer sends the AT command to the modem. That is why you do not
need to set the communications settings for the computer modem.
However, the PLC modem cannot detect the communications settings, because PLC is not a
computer and does not send the AT command to the modem. The communications settings for
the PLC modem must match the settings of the computer modem and the PLC.
Modems can detect the
communications settings
automatically to communicate with
the computer when the computer
sends the AT command to the
modem.
The communications settings
for the PLC modem must
match the settings of the
computer modem and the
PLC.

Page: 6
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
1. Plug the PLC modem into the COM port of the computer.
2. Click on the Start button, point to Programs, point to FinsGateway, and point to PLC Modem
Setup.
3. Select the COM port for the modem in the COM port box.
4. Select the communications settings in the dialog to match the communications settings of the
PLC.
default: BaudRate: 9600bps, Data Bits: 7, Stop Bit: 1, Parity: Even
5. Click on the [Set] button.
The PLC modem setting is done. Unplug the modem from the computer and plug it into the
PLC.

Page: 7
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
3 – 2 Serial Communications Driver Settings
1. Exit PLC Reporter if it is running.
2. Click on the Start button, point to Programs, point to FinsGateway, and point to Serial
Communications Setup.
3. Click the Communications Line tab and select the check box of the COM port for the modem
to add the phone line.
4. Click [OK] to close the dialog.
5. Set the network address for the added phone line if necessary.

Page: 8
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
4 Operation
Register a telephone number to identify each destination modem and PLC.
4 – 1 Registering Telephone Numbers
1. FgwTapiCaller Settings
Click on the Start button, point to Programs, point to FinsGateway, and point to FgwTapiCaller.
2. Select Phone Line Type
Click on the Dialing Properties button. Select Tone dialing or Pulse dialing in the Dialing
Properties dialog to set the dialing type.
Click the Tone dialing or Pulse
dialing in the Dialing Properties
dialog to select the dialing type.

Page: 9
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
3. Type the name and the telephone number of the destination to call in the telephone number
setup dialog.
You can enter a comma (, ), or – in the telephone number box to make the telephone
number easy to identify.
4. Click on the Modem Setup button in the telephone number setup dialog to start the modem
settings dialog.
Select the modem in the Modem to use field and set the communication settings to match
the settings of the remote PLC.
5. Click the Unit setup button in the telephone number setup dialog to start the modem settings
dialog.
Select the COM port which connecting the Modem.
6. Confirm that the new telephone number appears in the telephone numbers dialog
7. Click [OK] to finish the telephone number setup. Click [cancel] to cancel the settings and
quit.

Page: 10
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
4 – 2 Serial Communications Driver Settings
1. Dial the destination.
After the telephone number is registered, Click the [Dial] button and start dialing. You can
monitor status and perform one-shot communications with a remote PLC after dialing is
completed successfully.
The line status dialog appears when dialing. After dialing is completed successfully, the dialog
is minimized automatically.
Click the icon to see th
e
dialog again.

Page: 11
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
4 – 3 Close the Line
1. Click the [Hang up] button in the FgwTapiCaller.
Closing the Line Manually
You can also close the line by clicking on the Disconnect button in the line status dialog.
Close the line manually.

Page: 12
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
5 Caution
5 – 1 Communications Settings
Some modems have fixed settings: 10 bits for character bits. Select the one of the 4 settings
below for the communications settings.
Start bits Data bits Stop bits Character
bits
Parity
1 fixed 7Even 110
1 fixed 7Odd 110
1 fixed 7None 210
1 fixed 8None 110
Confirm that the communications settings of the computer and the PLC match, except the
speed.
Refer to the PLC manual to see how to set the communications settings for the PLC.
5 – 2 Speed Setting
You can set the speed for the computer with the communications settings of Modem Module,
and set the speed at the PLC with the PLC modem settings utility. The speed setting will vary
between modems.
Computer - Modem
19200 bps Modem - Modem
33600 bps Modem - PLC
9600 bps

Page: 13
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
5 – 3 Connecting the PLC Modem
Prepare the cable according to the figures below to connect the modem to the PLC. The cable
included with the modem works to connect to a computer but not a PLC.
Modem
25pin
Connector hood
FG
20 ER
6DR
7SG
5CS
4RS
3RD
2SD
1FG
PLC CPU unit
9pin
Connector hood
FG
9SG
5CS
4RS
3RD
2SD
1--
(Shield)
For wiring details, refer to the modem and PLC manuals.
5 – 4 Send the AT Command
The PLC modem setup utility may not work for old modems. If the utility does not work, send
the AT command to set it.
Send any AT command using the PLC modem setup utility. See the modem manual for the
setting details.
Function
Set the number of rings for auto answer.
The example shows setting 1 ring.
Save the settings in non-volatile RAM.
The example is saving the settings to profile 0.
Select the profile to load when the modem is
turned on. The example is loading profile 0.
AT Command
ATS0=1
AT&W0
AT&Y0
Flow control or the CD/DR/ER signal control settings may be required for the modem. See the
modem manual and determine the AT commands to set them.

Page: 14
FinsGateway Modem Module User’s Manual
©
©©
© Copyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights ReservedCopyright OMRON Corporation 1999 All Rights Reserved
Copyright OMRON Corporation 1999 All Rights Reserved
6 Troubleshooting
Is the equipment turned on?
Is the equipment turned on?Is the equipment turned on?
Is the equipment turned on?
Confirm that that the modem and the PLC are turned on.
Is the equipment all
Is the equipment allIs the equipment all
Is the equipment all con
concon
conn
nn
ne
ee
ected?
cted?cted?
cted?
Confirm that the modems are connected to the computer and the PLC. Confirm that the
modem and the telephone lines are wired. Refer to the modem manual for the wiring.
Is it the right cable?
Is it the right cable?Is it the right cable?
Is it the right cable?
A special cable is required to connect the PLC and the modem. Prepare the right cable.
Is the right type selected for the telephone line?
Is the right type selected for the telephone line?Is the right type selected for the telephone line?
Is the right type selected for the telephone line?
Confirm that the right type of telephone line is selected: tone dialing or pulse dialing.
Is the PLC modem set?
Is the PLC modem set?Is the PLC modem set?
Is the PLC modem set?
Set the PLC modem. The modem will not work with the default settings. The settings will be
erased if the modem has been turned off for a long time. Set the modem again.
Is the telephone number right?
Is the telephone number right?Is the telephone number right?
Is the telephone number right?
Is Modem Module dialing the right number?
Do the communications settings of the PLC and the modem match?
Do the communications settings of the PLC and the modem match?Do the communications settings of the PLC and the modem match?
Do the communications settings of the PLC and the modem match?
Confirm that the communications settings of the PLC and the modem match.
Are the modem settings right?
Are the modem settings right?Are the modem settings right?
Are the modem settings right?
Confirm that the right modem is selected if multiple modems are installed.
Confirm that the modem is connected to the right COM port.
Confirm that the COM port for the internal modem matches the settings.
Table of contents
Other Omron Modem manuals
Popular Modem manuals by other brands

Paradyne
Paradyne HotWire 7915 user guide

TRENDnet
TRENDnet TFM-560U - DATA SHEETS Quick installation guide

WePresent
WePresent WiPG-1600 user manual

VitaSound Audio
VitaSound Audio VitaSound TV PAE-200 user manual

SCS
SCS PACTOR III installation guide

Liquid Controls
Liquid Controls 81538 Set-up and Connection Guide
