Omron WD30-ME User manual

OPERATION MANUAL
Cat. No. M071-E1-01A
WD30-ME/-SE/-ME01/-SE01
DeviceNet Wireless Units

Copyrights and Trademarks
DeviceNet is a registered trademark of the OpenDeviceNet Vendor Association (ODVA).
S-S Technologies, Inc. holds the copyrights for DeviceNet master unit and all software included with
the DeviceNet wireless slave station.
Notice
(1) This manual may not be copied, reproduced, or reprinted, in whole or in part, without permission.
(2) The specifications listed within this manual may be revised without prior notice.
(3) The information in this manual was compiled with the utmost care. However, if you should find any
errors or inconsistencies, please contact the OMRON business office. Be sure to tell us the revi-
sion number of the manual in which you found the error.

i
Introduction 1
1Introduction
Thank you for purchasing this DeviceNet wireless unit.
This DeviceNet wireless unit was developed based on OMRON’s advanced
control technology and experience.
Carefully read and understand the functions and performance of this device
before using the DeviceNet master and DeviceNet slave together as a struc-
tured system.
Personnel to whom this manual is directed
This User's Manual was designed for use by the following personnel.
Persons with a knowledge of electronics (electricians or those with similar
training) and who:
• are in charge of introducing FA equipment
• design FA system
• install and connect FA equipment
• manage FA sites
Precautions for use • This equipment should be used as indicated in the general specifications.
• If this equipment is used under conditions or in an environment such as
those listed below, the user should contact the OMRON business office
for assistance. All uses and safety measures should be considered care-
fully according to the ratings and functions of the equipment.
1. Using the equipment under conditions or in environments not indicated
in this manual
2. Using the equipment to control nuclear power, for railway facilities, for
airline facilities, for automobiles, for combustion facilities, for medical
equipment, for entertainment equipment, or for safety equipment.
3. Using the equipment in a manner that is expected to have an effect on
human life or property, and particularly for applications that require safe-
ty measures
• The information contained in this manual is required for the correct use of
the DeviceNet wireless unit. Be sure to carefully read and understand this
User's Manual, the DeviceNet User's Manual, and the DeviceNet Slave
Manual before using this equipment. After reading this User's Manual,
store it in a safe location where it can be referred to at any time as neces-
sary. The frequency band used for this equipment is also used for the
manufacture of products such as microwave ovens, in scientific applica-
tions, and in medical equipment.
Countries where this product can be used
This product has been approved for wireless standards in the countries listed
below. Consult your OMRON representative before using this product in other
countries.
WD30-ME/-SE: Austria, Belgium, Canada, Denmark, Finland, France, Ger-
many, Greece, Iceland, Ireland, Italy, Japan, Luxembourg, Netherlands, Nor-
way, Portugal, Spain, Sweden, Switzerland, UK, USA
WD30-ME01/-SE01: Japan, USA

ii
Introduction 1
FCC Notice:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
IC Notice:
To prevent radio interference to the licensed service, this device is intended to
be operated indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is subject to
licensing.
!Caution To ensure that the WLAN transmitter complies with current FCC regulations
limiting both maximum RF output power and human exposure to radio fre-
quency radiation, a separation distance of at least 20cm must be maintained
between the unit’s antenna and the body of the user and any nearby persons
at all times and in all applications and uses.
CE Notice
English Hereby, Omron Corporation, declares that this WD30-ME/-SE is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Finnish Omron Corporation vakuuttaa täten että WD30-ME/-SE tyyppinen
laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
Dutch Bij deze verklaart Omron Corporation dat deze WD30-ME/-SE
voldoet aan de essentiële eisen en aan de overige relevante
bepalingen van Richtlijn 1999/5/EC.
Swedish Härmed intygar Omron Corporation att denna WD30-ME/-SE står I
överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Danish Undertegnede Omron Corporation erklærer herved, at følgende
udstyr WD30-ME/-SE overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF
German Hiermit erklärt Omron Corporation die Übereinstimmung des
Gerätes WD30-ME/-SE mit den grundlegenden Anforderungen und
den anderen relevanten Festlegungen der Richtlinie 1999/5/EG.
Italian Con la presente Omron Corporation dichiara che questo WD30-
ME/-SE è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Spanish Por medio de la presente Omron Corporation declara que el
WD30-ME/-SE cumple con los requisitos esenciales y cualesquiera
otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE
Portuguese Omron Corporation declaraque este WD30-ME/-SE está conforme
com os requisitos essenciais e outras disposições da Directiva
1999/5/CE.
Norwegian Omron Corporation erklærer herved, at følgende utstyr WD30-ME/-
SE overholder de vesentlige krav og øvrige relevante
bestemmelser i direktiv 1999/5/EF
French Par la Présente Omron Corporation déclare que l’appareil WD30-
ME/-SE est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
La France étant le seul pays ayant une directive locale qui
différelégèrement de la directive Européenne, ce produit ne peut
être utilisé en France.
Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Omron Corporation ∆ΗΛΩΝΕΙ ΟΤΙ WD30-ME/-
SE ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ
ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/EK

iii
Safety Precautions 2
2 Safety Precautions
Observe the following points to ensure safe operation of this equipment.
• Do not use this equipment for real-time control (I/O control that requires a
response rate the same as that of DeviceNet).
• Do not apply excess vibrations or shock to this equipment. Do not drop
this equipment.
• Do not use this equipment in any of the following environments:
Areas with corrosive or combustible gasses
Areas with large amounts of dust or dirt
Areas containing water, oils, or chemical agents
Areas with severe fluctuations in humidity that results in condensation
Areas with static electricity or excessive noise
• Do not place the communications cables nearby other cables with high
voltage or strong currents.
• Do not attach connectors to the communications cables while they are
supplied by the power supply.
• Use the cables specified in this manual for connections with the communi-
cations cables.
• Prevent objects such as chips from getting inside the equipment while the
cover is open.
• Do not install this equipment in areas where it will be subject to excess
external force, or in walkways.
• Tighten installation screws at the rated torque specified in this User's
Manual.
• Do not use this equipment near other devices that may malfunction due to
the electronic waves emitted by the DeviceNet wireless unit.

iv
Proper Use of This Equipment 3
3 Proper Use of This Equipment
1. Turn the power source OFF before performing any wiring work.
2. When adjusting the installation position, use double-sided tape or rope to
fix the equipment and prevent it from falling.
3. Do not use this equipment in areas exposed to direct sunlight, in areas of
very high humidity, near televisions or radios, near motors or drills that emit
sparks, near strong magnets, or near fluorescent lights.
4. Do not turn or bend the antennas. Do not wrap electric wires around the
antennas.
5. Install the equipment so that the antennas are not near any electric wires
or metal plates. Install the equipment as far away as possible from electric
wires and metal plates.
6. Communications performance will vary according to environment. Other
wireless devices that operate within the same frequency band may inter-
fere with this equipment. Be sure to perform the tests provided for this
equipment (such as the installation test) before operating it.

v
DeviceNet Manuals 4
4 DeviceNet Manuals
The following manuals are available for information relating to DeviceNet. Be
sure to thoroughly read and understand the applicable manuals before install-
ing or operating DeviceNet devices and make sure that you are using the
most recent version of the manual.
DeviceNet Operation Manual (W267)
Describes the functions and applications of DeviceNet including available
Master Units, their specifications, functions, operating procedures, and appli-
cations. Always read this manual thoroughly before installing or operating
DeviceNet devices.
DeviceNet Slaves Operation Manual (W347)
Describes available Slave Units, their specifications, functions, operating pro-
cedures, and applications. This manual has been separately produced in
response to the increase in Slave Unit models since the production of the
DeviceNet Operation Manual (W267). Use this manual in conjunction with the
DeviceNet Operation Manual (W267).
DeviceNet Configurator Operation Manual (W328)
Describes the operating procedures of the DeviceNet Configurator, which is
used to freely allocate remote I/O areas, and allows multiple Master Units to
be mounted to one PLC or connected to one DeviceNet Network to perform
independent remote I/O communications. Refer to this manual when operat-
ing a DeviceNet Network with a DeviceNet Configurator.
MULTIPLE I/O TERMINAL Operation Manual (W348)
Describes available MULTIPLE I/O TERMINALs, their specifications, func-
tions, operating procedures, and applications. This manual has been sepa-
rately produced in response to the increase in MULTIPLE I/O TERMINAL
models since the production of the DeviceNet Operation Manual (W267). Use
this manual in conjunction with the DeviceNet Operation Manual (W267).

vi
Manual Outline 5
5 Manual Outline
5-1 Outline of This Manual
Section 1 DeviceNet Wireless Unit
This section explains the features of the DeviceNet Wireless Unit, including system structure, types of units, basic func-
tions, and configurator outline.
Section 2 Hardware Settings and Checking of Operations
This section gives specific explanations of the operations and procedures necessary for you to use the DeviceNet wire-
less unit. Follow the explanations in this section to perform operation check procedures.
Section 3 Sample Program
This section contains an example program for monitoring the status of the DeviceNet wireless unit.
Section 4 DeviceNet Wireless Unit Station Specifications
This section explains the settings and installation procedures for the parts and switches of the DeviceNet wireless unit.
Section 5 Test
This section explains the procedures for the system tests required for using the DeviceNet wireless unit.
Section 6 Relay Function
This section gives detailed explanations of the relay function of the wireless slave stations used to enlarge the communi-
cations area.
Section 7 Message Communication Function
This section gives detailed explanations of the basic format and commands for the Explicit messages used in the Mes-
sage Communications Function performed by setting and reading the status of the DeviceNet wireless master station.
Section 8 Using the Configurator
This section explains how to monitor the conditions and make the various settings of the wireless network used for the
configurator.
Section 9 Communications Timing
This section explains the remote I/O communications response time and the delay time between wireless networks when
the DeviceNet wireless unit is connected.
Section 10 Troubleshooting
This section contains information regarding troubleshooting and inspection methods to be performed by daily inspectors
when errors occur.
Appendices
The appendices include DeviceNet wireless unit profiles and lists of connecting devices that are required when connect-
ing with a DeviceNet master manufactured by a different company.

vii
Manual Outline 5
5-2 Instruction Markings:
Instruction markings are used throughout this manual to indicate additional information.
These markings are described below.
This mark indicates information/instructions that should be followed precisely.
This mark indicates additional information that the user would find constructive.

ix
TABLE OF CONTENTS
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
2 Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
3 Proper Use of This Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
4 DeviceNet Manuals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
5 Manual Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
SECTION 1
DeviceNet Wireless Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-1 DeviceNet Wireless Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-2 Basic Functions of the DeviceNet Wireless Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-3 Configurator Outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-4 Application Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1-5 Points for Consideration with Wireless Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SECTION 2
Hardware Settings and Checking of Operations. . . . . . . . . . . 19
2-1 Basic Operation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2-2 Pre-work Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2-3 Hardware Settings and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2-4 System Initial Setting and Starting Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2-5 Operation Confirmation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2-6 Other Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2-7 Deciding the Antenna Installation Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SECTION 3
Sample Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3-1 Status Monitoring Program Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3-2 Example of Using an Explicit Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
SECTION 4
DeviceNet Wireless Unit Station Specifications. . . . . . . . . . . . 55
4-1 DeviceNet Wireless Master Station Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4-2 DeviceNet Wireless Slave Station Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4-3 Common Specifications to All DeviceNet Wireless Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
SECTION 5
Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
5-1 Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5-2 Installation Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
5-3 Confirmation Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5-4 Wireless Channel Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

x
TABLE OF CONTENTS
SECTION 6
Relay Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
6-1 Relay Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6-2 Actual Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
SECTION 7
Message Communication Function. . . . . . . . . . . . . . . . . . . . . . 85
7-1 Explicit Messages Addressed to the DeviceNet Wireless Master Station . . . . . . . . . . . . . . . . . 86
7-2 List of Explicit Messages Addressed to DeviceNet Wireless Master Station. . . . . . . . . . . . . . . 88
7-3 Explicit Messages Addressed to DeviceNet Slave Connected before
DeviceNet Wireless Slave Station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
SECTION 8
Using the Configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
8-1 Additional Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
8-2 Wireless Network Configuration Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
8-3 Wireless Network Parameter Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
8-4 Wireless Channel Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
8-5 Running Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
SECTION 9
Communications Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
9-1 Remote I/O Communications Performances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
9-2 Message Communication Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
SECTION 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
10-1 Normal Indication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
10-2 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
10-3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Appendices
A Device Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
B Connection-related Devices Model List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
C Current Consumption List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
D Optional Products List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171

1
SECTION 1
DeviceNet Wireless Unit
This section explains the features of the DeviceNet Wireless Unit, including system structure, types of units, basic functions, and
configurator outline.
1-1 DeviceNet Wireless Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-1-1 System configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-1-2 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-1-3 Types of units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-1-4 Model list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-2 Basic Functions of the DeviceNet Wireless Unit . . . . . . . . . . . . . . . . . . . . . . 4
1-2-1 Replacing data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-2-2 I/O allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1-2-3 DeviceNet wireless unit status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1-2-4 Slave error flag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1-2-5 Disconnect/Connect Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1-2-6 DeviceNet node addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1-2-7 DeviceNet wireless unit default setting values. . . . . . . . . . . . . . . . . 11
1-2-8 Serial Number Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1-3 Configurator Outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-3-1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-3-2 Operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1-3-3 Outline of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1-4 Application Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1-5 Points for Consideration with Wireless Systems . . . . . . . . . . . . . . . . . . . . . . 16
1-5-1 Construction of multiple wireless systems . . . . . . . . . . . . . . . . . . . . 16

2
DeviceNet Wireless Unit Section 1-1
1-1 DeviceNet Wireless Unit
The DeviceNet wireless unit, consisting of a DeviceNet wireless master sta-
tion and a DeviceNet wireless slave station, allows wireless communication
with the DeviceNet slave.
Basically, the wireless master station is connected to the DeviceNet network
and acts as either a virtual DeviceNet slave or wireless network master station
for the DeviceNet master unit. The wireless slave station acts as either a wire-
less network slave station or a virtual DeviceNet master with the DeviceNet
slave unit.
This unit conforms to the following radio wave standards.
Conformance with these standards means that the antenna can be installed
separately. The unit can be purchased as a set with a pencil antenna (WD30-
ME/-SE) or with a magnet-base antenna (WD30-ME01/-SE01). (The dia-
grams in this manual are for the WD30-ME/-SE.)
1-1-1 System configuration
1-1-2 Features
DeviceNet slaves can be
made wireless Wireless DeviceNet slaves allows for a variety of field level applications.
WD30-ME/-SE Japan: ARIB STD-T66
USA: FCC part 15.247
Canada: IC RSS 210
Europe: ETS 300 440
WD30-ME01/-SE01 Japan: ARIB STD-T66
USA: FCC part 15.247
DeviceNet master unit
DeviceNet network
Configurator
Wireless network
DeviceNet cable
DeviceNet slaves
Wireless slave station Wireless slave station
Wireless master
station
DC24V power
supply

3
DeviceNet Wireless Unit Section 1-1
We recommend that this function be used for applications that are not
required to operate in real time (such as displays for indicators and manufac-
turing instruction data transmissions).
Errors can be monitored DeviceNet slave error information (including errors in wireless slave stations)
can be assigned to two or four status words and monitored from the PLC.
Abundant number of
wireless channels allows
the construction of
multiple systems in the
same area
Since the wireless region is divided into 34 frequencies from 2,400 to
2,483.5MHz, you can select an unused frequency for building multiple sys-
tems.
Using a spectral spread method (DS: direct spread) as a modulation method
achieves high-quality communications even in areas of excess noise.
Relay functions make
possible an extension in
communications
distances
Although communications distances vary according to the installation environ-
ment, the goal indoors is 60m in line of sight.
The relay functions allow an increase in the communications area (to a maxi-
mum of 3 stages).
DeviceNet slaves may also be connected to the relay station.
However, relay station system settings can only be performed from the config-
urator.
Diversity functions Multi-pass phasing is improved with a diversity system (which requires 2
antennas).
The effects of this function are observed when used in areas where variations
in radio waves (such as reflections) occur.
Maximum number of I/O
per wireless master
station increased
Depending on the switch settings of the wireless master station, the maximum
number of I/O per wireless master station can be increased to 100 words/
100 words (IN/OUT). The maximum number of wireless slave stations that
can be connected has increased to 64.
Magnet-base antenna
added to lineup Using the magnet-base antenna, the station itself can be installed inside a
control panel with the antenna installed outside. Also, because it is mounted
with a magnet, the position of the antenna can be adjusted easily when, for
example, the control panel is moved. Attenuation in the antenna cable (2m),
however, limits the maximum communications distance to approximately 50m
indoors.
1-1-3 Types of units
DeviceNetwirelessmaster
station (Wireless master
station)
• Connects to the DeviceNet network and acts as a virtual DeviceNet slave.
• Maximum number of I/O as DeviceNet slave: IN/OUT = 32 words (512
points)/32 words (512 points) or 100 words (1,600 points)/100 words
(1,600 points) depending on the DIP switch setting. However, if Status is
selected, IN/OUT = 30 words (480 points)/32 words (512 points) or
96 words (1,536 points)/100 words (1,600 points) depending on the DIP
switch setting.
• As the wireless network master station, it controls a maximum of 64 wire-
less slave stations and sends remote I/O transmissions.
• The wireless master station was tested at the test laboratories of a third
part organization authorized by the ODVA. It is authorized as being in
conforming to ODVA conformance software.
Multi-pass phasing is the phenomenon of a radio wave being transmitted form a single point,
passing through multiple propagation paths, and then arriving at a single point.
Multi-pass
phasing

4
Basic Functions of the DeviceNet Wireless Unit Section 1-2
DeviceNet wireless slave
station (Wireless slave
station)
• As an slave station for the wireless network, it exchanges remote I/O com-
munications with the wireless master station via the wireless line.
• Acts as a virtual DeviceNet master with DeviceNet slaves.
• Connects with a maximum of 63 DeviceNet slaves and performs a maxi-
mum of 64 words (1,024 points) I/O control. (Even if multiple wireless
slave stations are used, the maximum number of nodes for DeviceNet
slaves is 63.)
1-1-4 Model list
Note When set to “status”
Accessories The following accessories are included with purchase of both wireless master
station and slave station:
• 2 antennas (ME/-SE: pencil antenna; ME01/-SE01: magnet-base
antenna)
• User’s manual
• Sticker (Attach in a visible location.)
• 2 installation screws (with nuts)
• Declaration of Conformity (CE) (Provided with ME/-SE models only.)
Applicable connectors Use DeviceNet micro-connectors for communications connectors. A list of
recommended connectors in the appendix.
1-2 Basic Functions of the DeviceNet Wireless Unit
1-2-1 Replacing data
Initializing the wireless
master station When the power supply is turned on, the wireless master station adds each
registered wireless slave station. When wireless communication begins with
an slave station, if the number of I/O points on the DeviceNet slave connected
to the slave station and the I/O points registered for the wireless master sta-
tion are identical, it is added. If they are not identical, an I/O configuration
error will occur.
Type No. of inputs/
outputs No. of words in PLC I/O memory I/O connection Unit voltage Installation Model
IN OUT
DeviceNet
wireless
master station
None Status: 2 or
4 words (See
note.)
0 words None Supplied by
power for
external
communica-
tions
Screws Model
WD30-ME
Model
WD30-
ME01
DeviceNet
wirelessslave
station
None 0 words 0 words None Model
WD30-SE
Model
WD30-
SE01

5
Basic Functions of the DeviceNet Wireless Unit Section 1-2
Processing when an error
occurs Even if an error occurs in the DeviceNet network below a wireless slave sta-
tion after initialization is complete, the wireless network polling communication
will continue as normal. The user should monitor the status at his device
(PLC, computer) when an error occurs, and apply the appropriate error pro-
cessing program for the type of error and the area in which it occurred.
DeviceNet master unit
Configurator
Wireless master station
Wireless network
DeviceNet network
I/O configuration check
Addition process
Wireless slave station
IN: 1 word (16 points), OUT: 1 word (16 points)
If the number of I/O points on
the wireless master station
and the wireless slave station
is different, an I/O
configuration error will occur.
WNODE IN points
I/O points
I/O points
OUT points
01 1 word (16 points) 1 word (16 points)
--- --- ---
WNODE=01

6
Basic Functions of the DeviceNet Wireless Unit Section 1-2
1-2-2 I/O allocation
I/O for DeviceNet slaves is allocated in the wireless slave stations by ascend-
ing order of DeviceNet node address without leaving any unused areas, and
then in the wireless master station by ascending order of slave station wire-
less node address (WNODE) without leaving any unused areas.
• The IN and OUT areas are allocated in units of 16 points (1 word). In the
case of 8-point units, the lower byte (bits 0 to 7) is allocated and the upper
byte (bits 8 to 15) is set to 00 Hex.
• The following four types of I/O allocations can be set using the DIP switch.
1,2,3... 1. Status 2 words (32 points), I/O IN/OUT = 30 words (480 points)/32 words
(512 points)
2. I/O IN/OUT = 32 words (512 points)/32 words (512 points)
DeviceNet master unit
DeviceNet network
Wireless network
DeviceNet slaves
DeviceNet slaves
DeviceNet slaves
DeviceNet slaves
#1
#2
#3
#4
Terminal resistor
Network power supply
#1 IN #1 OUT
#2 IN #2 OUT
IN OUT
IN
#3 IN #3 OUT
#4 IN #4 OUT
OUT
Allocated in ascending order of WNODE
# 1 IN #1 OUT
#2 IN #2 OUT
WNODE=01
WNODE=02
#3 IN #3 OUT
#4 IN #4 OUT
IN OUT
WNODE=02 WNODE=01
Wireless
master
station
Wireless slave
station Wireless slave
station
Allocated in ascending
order of DeviceNet node
address
Allocated in ascending
order of DeviceNet node
address
Wd+0
+1
+31
IN area 015
Wd+0
+1
+31
OUT area 015
For wireless master
station NNODE
Status
(2 words, fixed)
IN
(Max. 30 words)
OUT
(Max. 32 words)
Wd+0
+1
+31
0
15
Wd+0
+1
+31
015
IN area OUT area
IN
(Max. 32 words)
OUT
(Max. 32 words)

7
Basic Functions of the DeviceNet Wireless Unit Section 1-2
3. Status 4 words (64 points), I/O IN/OUT = 96 words (1,536 points)/
100 words (1,600 points)
4. I/O IN/OUT = 100 words (1,600 points)/100 words (1,600 points)
The default settings are "(2) I/O IN/OUT = 32 words (512 points)/32 words
(512 points)".
015 015
Wd+0
+1
+99
INarea
Wd+0
+1
+99
OUTarea
OUT
(Max.100words)
Status
(4words,fixed)
IN
(Max.96words)
Wd+0
+1
+99
015
Wd+0
+1
+99
015
INarea OUTarea
IN
(Max.100words)
OUT
(Max.100words)

8
Basic Functions of the DeviceNet Wireless Unit Section 1-2
1-2-3 DeviceNet wireless unit status
The format for the IN area status area is shown below.
Confirm this status at the CPU unit, and prepare an error processing program
for sending commands to (Explicit messages) and obtaining detailed status
reports (wireless network status, DeviceNet master status) from wireless
master stations showing error flags. (Refer to SECTION 3 Sample Program.)
1. When maximum number of I/O = 32 words/32 words:
2. When maximum number of I/O = 100 words/100 words:
1-2-4 Slave error flag
1. When maximum number of I/O = 32 words/32 words:
2. When maximum number of I/O = 100 words/100 words:
Each of the following for the DeviceNet master status of added wireless slave
stations is set to an OR value.
Incorrect switch setting/EEPROM error (bit address 00)
Repetitive node address/Busoff detection (bit address 01)
Configuration error (bit address 03)
Structural error (bit address 04)
Send error (bit address 05)
Communication error (bit address 06)
Verify error (bit address 07)
Also, if a wireless slave station has been registered but not added, the bit will
be 1. For example, if a wireless slave station error occurs for WNODE = 16,
the uppermost bit for "status begin word +0" (16) becomes 1.
Each wireless master station can control a maximum of 512 (or 1,600) I/O points. However, there
are limits to the number of I/O points per node for each master unit. Therefore, systems should
be designed without exceeding the limitations for the number of I/O points per node for each
master unit.
Master unit
I/O point
limitations
15 187 0
Status begins Wd+0
Wd+1 Slave error flag
Wd+1
Wd+2
Wd+3
15 187 0
Status begins Wd+0
Slave error flag
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17
48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33
64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49
