Omron 50j6 User manual

50J6

Receiver, RF Keyless Entry System

Table of contents

1. Constitution of the Radio Frequency Keyless Entry system with Door Lock

Controller for vehicle ...................................................................................... 1

2. User’s manual (provisionally) .......................................................................... 2

3. Block diagram ................................................................................................ 3

4. Specification ................................................................................................... 4

5 PCB

5.1 Circuit diagram ........................................................................................... 5

5.2 Parts layout (front)...................................................................................... 6

5.3 Pattern layout .................................................................................... 7

5.4 Parts list ...................................................................................................... 9

5.5 Connector ..................................................…................................................. 12

6. Photographs .................................................................................................... 13

1. Constitution of the Radio Frequency Keyless Entry

System with Door Lock Controller for vehicle

The radio frequency keyless entry is a system that it controlls locking and unlocking the door by

wireless remote controller. This system consists of two components. The TRANSMITTER is a device that

transmits the signal when the button is pressed. The transmission signal consists of several synchronous

codes, unique identification code, security code and function code. The RECEIVER is fixed inside the

vehicle. It works intermittently to prevent the battery exhaustion. When the receiver detects the

synchronous code, it runs continuously to receive the signals completely. After receiveing the signal, the

receiver decides which operation will be performed. The user can select the following operations by

pressing the button of the remote transmitter.

OPERATION ACTION

LOCK Lock the door

UNLOCK Unlock the door （Open the window）

PANIC Beep the horn and flush the small light. (it continues 30 seconds)

This receiver also controls wired operation. When the key is in the driver’s side key cylinder, all doors will

Unlock if the key is turned to UNLOCK and hold more than one second. In case of the operation time is shorter,

the only diver’s side door is mechanically unlocked. It is also available to control the door lock status by using

the remote door control switch(both driver’s and passenger’s side).

Transmitter

f = 313.85MHz

- 1 -

2. User’s manual (provisionally)

REMOTE TRANSMITTER

You can lock and unlock your vehicle with the remote transmitter.

LOCK

When you push the LOCK button, all the doors will lock.

You cannot lock any of the doors with the remote transmitter if any door is open or the key is in the

ignition switch.

UNLOCK

When you push the UNLOCK button , all the doors will unlock.

You cannot unlock any of the doors with the remote transmitter if the key is in the ignition switch.

When you push the UNLOCK button more than about 1.0 second , the window will open.

PANICMODE

 Panic mode allows you to remotely sound your vehicle’s horn to attract attention. To activate this

mode , press and hold the PANIC button for about one seconds. Your vehicle’s horn will beep for about

30 seconds.

To cancel Panic mode before 30 seconds , press any button on the remote transmitter. You can also

turn the ignition switch is in ON

- 2 -

3. Block diagram

This is the block diagram concerning to the receiver.

RECEIVING

MODULE

EEPROM

12V (car battery)

POWER

SOURCE

(

)

data

DOOR

MOTOR

output DRIVING

CIRCUIT

Figure 3.1 block diagram of the receiver

- 3 -

4. Specification

4.1 RF block

Local clock frequency 325.8MHz

Frequency generation Crystal resonator

Modulation Single Superheterodyne

Bandwidth ±200KHz

Sensitivity 30dBuV

4.2 Others

Dimension 50 mm×40 mm×25 mm

Weight 25 g

Battery Power Source (DC 5V)

Operation Voltage DC 5V, 10mA

Operation temperature -30℃~ +80℃

- 4 -

5. PCB

5.1 Circuit diagram

Figure 5.1 Circuit diagrams

- 5 -

5.2 Parts layout

Figure 5.2 Parts layout (front)

- 6 -

5.3 Pattern layout

Figure 5.3 Pattern layout (front)

- 7 -

igure 5.4 pattern layout (back)

- 8 -

5.4 Parts list



PARTNAME MANUFACTURE QTY



TYPE SPECIFICATION REMARKS

    

1



WAVEDETECTIONIC INFINEON 1 TDA5211GEG 28‑PIN IC1

    

2



SAWFILTER EPSON 1 FF‑555315.1M 315.1MHz SAW1

    

3



CERAMICFILTER MURATA 1 SFECV10M7JA00‑R0 3‑PIN CF1

    

4



CRYSTAL RIVER 1 FCX‑03‑10.18125 CI=150ΩCL=SERIES



X1

 OSCILLATOR   ‑30‑30 10.18125MHz+387Hz



5



DOUBLETRANSISTOR NEC 1 UPA801‑T1 6‑PINMINIMOLD



WT1

     2SC4226(X2) 

6



TRANSISTOR ROHM 1 2SC4081T106R  TR1

    

7



ZENERDIODE NEC 1 RD24SB‑T1 200mW,24V ZD100

    

8



CERAMICCAPACITOR * 2 CCM‑L10CH1H040C‑T2 4pF,50V CX3,CX4

     1005SIZE 

9



CERAMICCAPACITOR 1 CCM‑L10CH1H050C‑T2 5pF,50V C1

 *   1005SIZE 



CERAMICCAPACITOR * 1 CCM‑L10CH1H100D‑T2 10pF,50V C2

     1005SIZE 



CERAMICCAPACITOR * 1 CCM‑L10CK1H010C‑T2 1pF,50V C3

     1005SIZE 



CERAMICCAPACITOR * 6 CKM‑L10R1H102K‑T2 1000pF,50V C4,5,6,9,16



     1005SIZE 18



CERAMICCAPACITOR * 1 CCM‑L10CH1H120J‑T2 12pF,50V C7

     1005SIZE 



CERAMICCAPACITOR * 1 CCM‑L10CH1H330J‑T2 33pF,50V C8

     1005SIZE 



CERAMICCAPACITOR * 1 CCM‑L10CH1H101J‑T2 100pF,50V C10

     1005SIZE 



CERAMICCAPACITOR MURATA 2 GRP155B11C103KA01E 0,01uF,16V C11,13

     1005SIZE 



CERAMICCAPACITOR MURATA 3 GRP155B11A104KA01E 0.1uF,10V C12,14,C101



     1005SIZE 



CERAMICCAPACITOR MURATA 1 GRP155B11H471KA01E 470pF,50V C15

     1005SIZE 



CERAMICCAPACITOR MURATA 1 GRP155B11A473KA01E 0.047uF,10V C17

     1005SIZE 

NOTE:

 ･･    DESIGNED CHECKED APPROVED

 ･･      

 ･･    G8D‑246S‑B

 ･･    SHEETNo(1/3)

Ａ ･･   DETEAILEDLISYOFPARTS

SYM  DATE    E/CCONTENTS E/CNo SIGN DWGNO.



No



PARTNAME MANUFACTURE QTY



TYPE SPECIFICATION REMARKS

     

20



TANTALUMCAPACITOR MURATA 1 GRM31CB10J106KC01L 10uF,6.3V C100

      3216SIZE 

21



CHIPCAPACITOR MURATA 1 CCM‑L10CH1H220J‑T2 22pF CX1

      1005SIZE 

22



CHIPINDUCTOR MURATA 1 LQP18MN10NG00D 10nH LX1

      1608SIZE 

23



CHIPINDUCTOR MURATA 2 LQW18AN33NG00D 33nH LX2,LX3

      1608SIZE 

24



CHIPINDUCTOR MURATA 1 LQP15MN33NG00D 33nH L1

      1005SIZE 

25



CHIPINDUCTOR MURATA 1 LQP15MN15NG00D 15nH L2

      1005SIZE 

26



SQUARE * 2 RK10CAZ100KJ‑T1 100kΩ,1/16W R1,5
