Harman AMX DXLINK DX-TX-4K60 Quick user guide

AV FOR AN IT WORLD
HARDWARE REFERENCE MANUAL
DXLINK™ TWISTED PAIR 4K60
TRANSMITTER/RECEIVER
DX-TX-4K60, DX-RX-4K60

Important Safety Instructions
READ these instructions.
KEEP these instructions.
HEED all warnings.
FOLLOW all instructions.
DO NOT use this apparatus near water.
CLEAN ONLY with dry cloth.
DO NOT block any ventilation openings. Install in accordance with the manufacturer's instructions.
DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
ONLY USE attachments/accessories specified by the manufacturer.
USE ONLY with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-o v e r.
REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
DO NOT EXPOSE THIS APPARATUS TO DRIPPING OR SPLASHING AND ENSURE THAT NO OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, ARE PLACED ON THIS APPARATUS.
To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from
the AC receptacle.
Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device
shall remain readily operable.
DO NOT overload wall outlets or extension cords beyond their rated capacity as this can cause electric shock or fire.

Warnings
ESD Warning: The icon to the left indicates text regarding potential danger associated with the discharge of
static electricity from an outside source (such as human hands) into an integrated circuit, often resulting in damage
to the circuit.
WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture.
WARNING: No naked flame sources - such as candles - should be placed on the product.
WARNING: Equipment shall be connected to a MAINS socket outlet with a protective earthing connection.
WEEE Notice
The Directive on Waste Electrical and Electronic Equipment (WEEE), which entered into force as European law on
14/02/2014, resulted in a major change in the treatment of electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of WEEE, and in addition, to promote the reuse,
recycling and other forms of recovery of such wastes so as to reduce disposal. The WEEE logo on the product or on
its box indicating collection for electrical and electronic equipment consists of the crossed-out wheeled bin, as shown
below.
This product must not be disposed of or dumped with your other household waste. You are liable of dispose of all
your electronic or electrical waste equipment by relocating over to the specified collection point for recycling of such
hazardous waste. Isolated collection and proper recovery of your electronic and electrical waste equipment at the
time of disposal will allow us to help conserving natural resources. Moreover, proper recycling of the electronic and
electrical waste equipment will ensure safety of human health and environment. For more information about
electronica and electrical waste equipment disposal, recovery, and collection points, please contact your local city
center, household waste disposal service, shop from where you purchased the equipment, or manufacturer of the
equipment.
RoHS Compliance
This product is in compliance with Directive 2011/65/EU and (EU) 2015/863 of the European Parliament and of the
Council of 31/03/2015 on the restriction of the use of certain hazardous substances in electrical and electronic
equipment.
REACH
REACH (Regulation No 1907/2006) addresses the production and use of chemical substances and their potential
impacts on human health and the environment. Article 33 (1) of REACH Regulation requires suppliers to inform the
recipients if an article contains more than 0.1% (per weight per article) of any substance(s) on the Substances of
Very High Concern (SVHC) Candidate List (‘REACH candidate list’).
This product contains the substance ‘’lead’’ (CAS-No. 7439-92-1) in a concentration of more than 0.1% per weight.
At the time of release of this product, except for the lead substance, no other substances of REACH candidate list
are contained in a concentration of more than 0.1% per weight in this product.
Note: On June 27, 2018, lead was added to the REACH candidate list. The inclusion of lead in the REACH candidate
list does not mean that lead-containing materials pose an immediate risk or results in a restriction of permissibility
of its use.

CAUTION FCC AND IC STATEMENT FOR USERS (USA AND CANADA ONLY)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
CAN ICES-3 (B)/NMB-3(B)
FCC SDOC SUPPLIER’S DECLARATION OF CONFORMITY
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Caution: Changes or modifications not expressly approved by Harman could void the user’s authority to operate the
equipment.

Hardware Reference Manual
1
CONTENTS
INTRODUCTION.................................................................................................................................................................................. 3
OVERVIEW...............................................................................................................................................................................................................3
FEATURES ................................................................................................................................................................................................................3
PACKAGE CONTENTS .........................................................................................................................................................................................4
SPECIFICATIONS ...................................................................................................................................................................................................5
DX-TX-4K60 .......................................................................................................................................................................................................5
DX-RX-4K60.......................................................................................................................................................................................................6
TRANSMISSION DISTANCE...........................................................................................................................................................................7
PANEL DESCRIPTION ..........................................................................................................................................................................................7
DX-TX-4K60 TRANSMITTER .........................................................................................................................................................................7
DX-RX-4K60 RECEIVER ..................................................................................................................................................................................8
PINOUT INFORMATION.................................................................................................................................................................. 10
RS232 ..................................................................................................................................................................................................................... 10
TWISTED PAIR CABLE....................................................................................................................................................................................... 10
RJ-45 LEDS....................................................................................................................................................................................................... 11
QUICK REFERENCE TABLES FOR MODES....................................................................................................................................12
DIP SWITCH FUNCTION..................................................................................................................................................................15
#1 TOGGLE SETTINGS...................................................................................................................................................................................... 15
#2 TOGGLE SETTINGS...................................................................................................................................................................................... 15
#3 TOGGLE SETTINGS...................................................................................................................................................................................... 16
SCENARIOS / DIP SWITCH SETTINGS TABLE........................................................................................................................................... 17
INSTALLATION AND WIRING........................................................................................................................................................18
INSTALLATION.................................................................................................................................................................................................... 18
WIRING.................................................................................................................................................................................................................. 18
STEPS FOR DEVICE WIRING........................................................................................................................................................................... 18
NETLINX BINDING OF DXLINK MODULES WITH AN ENOVA DGX SWITCHER....................................................................... 21
AVOIDING NETWORK (ETHERNET) LOOPS.......................................................................................................................................... 22
APPLYING POWER......................................................................................................................................................................................... 22
CONFIGURING USB FOR USE WITH A DGX OR DVX........................................................................................................................ 23
ID PUSHBUTTON OPERATION ......................................................................................................................................................24
ID PUSHBUTTON BOOT STATES AND LED BEHAVIOR........................................................................................................................ 27
RS232 AND IR OPERATIONS .........................................................................................................................................................28
RS232 OPERATIONS ......................................................................................................................................................................................... 28
IR OPERATIONS.................................................................................................................................................................................................. 29
NETWORK CONFIGURATION ........................................................................................................................................................ 31
STATIC IP MODE –DEFAULT PARAMETERS............................................................................................................................................. 31
DHCP MODE........................................................................................................................................................................................................ 31
TCP/IP ADDRESS CONFIGURATION ........................................................................................................................................................... 32
OFFLINE RECOVERY MECHANISM .............................................................................................................................................................. 32
NETLINX PROGRAMING .................................................................................................................................................................33
DEVICE NUMBERING AND PORTS .............................................................................................................................................................. 33
NELINX CONTROL IN ENDPOINT MODE (SWITCHER) ........................................................................................................................ 33
SEND COMMANDS TO CONTROL A DEVICE...................................................................................................................................... 34
TELNET CONTROL......................................................................................................................................................................................... 35
NETLINX CONTROL IN ENDPOINT MODE (STANDALONE)............................................................................................................... 35

Hardware Reference Manual
2
SEND COMMANDS TO CONTROL A DEVICE...................................................................................................................................... 36
TELNET CONTROL......................................................................................................................................................................................... 37
WEB UI CONTROL ......................................................................................................................................................................................... 37
WEB UI CONTROL.............................................................................................................................................................................39
PREPARATIONS BEFORE LOGGING INTO WEB UI................................................................................................................................. 39
WEB UI OF DX-TX-4K60 ................................................................................................................................................................................. 40
WEB INTRODUCTION .................................................................................................................................................................................. 40
WEB UI OF DX-RX-4K60................................................................................................................................................................................. 51
WEB UI INTRODUCTION............................................................................................................................................................................. 52
FIRMWARE UPGRADE ..................................................................................................................................................................... 64
UPGRADE FIRMWARE THROUGH NETLINX ............................................................................................................................................. 64
BEFORE YOU START ..................................................................................................................................................................................... 64
TRANSFERRING KIT FILES ........................................................................................................................................................................... 64
UPGRADE THE FIRMWARE THROUGH USB PORT................................................................................................................................. 65
APPENDIX A: FACTORY DEFAULT CONFIGURATION ..............................................................................................................66
APPENDIX B: TELNET COMMANDS ............................................................................................................................................. 68
APPENDIX C: ICSP COMMANDS...................................................................................................................................................75
DX-TX-4K60 ........................................................................................................................................................................................................ 75
DX-RX-4K60........................................................................................................................................................................................................ 92
DX-TX-4K60&DX-RX-4K60 COMMANDS..............................................................................................................................................113
WARRANTY TERMS AND CONDITIONS ...................................................................................................................................117

Hardware Reference Manual
3
Introduction
Overview
The Transmitters and Receiver are designed for transmission of an HDMI signal over twisted pair cable up
to 328 feet (100 m). Functionality is briefly described below.
DX-TX-4K60
The DX-TX-4K60 is an HDMI transmitter with 4K@60Hz 4:4:4 and HDCP 2.2 compatibly. It receives an
HDMI signal and an audio signal from a source device. The audio can be either digital audio embedded
with the HDMI, or analog stereo audio. Both the video and audio are transported over twisted pair cable to
an Enova DGX Digital Media Switcher, an applicable Enova DVX Solution, or directly to a DX-RX-4K60.
The RS-232 port on a DX-TX-4K60 supports bidirectional serial data via the twisted pair cable to/from the
RS-232 port on a DX-RX-4K60. The IR TX and IR RX ports on a DX-TX-4K60 each support unidirectional
IR data via the twisted pair cable to/from the IR RX and IR TX ports on a DX-RX-4K60. The USB Host /
Device ports on a DX-TX-4K60 support transmitting USB data via the twisted pair cable to/from a DX-RX-
4K60. It can be controlled through sending ICSP commands from a NetLinx Central Controller and also
supports CEC control and pass through to control the 3rd-Party devices.
DX-RX-4K60
The DX-RX-4K60 is an HDMI receiver with 4K@60Hz 4:4:4 and HDCP 2.2 compatibly. It receives an HDMI
signal with embedded audio over twisted pair cable from an Enova DGX Digital Media Switcher, an
applicable Enova DVX Solution, or directly from a DX-TX-4K60. The RS-232 port on a DX-T=RX-4K60
supports bidirectional serial data via the twisted pair cable to/from the RS-232 port on a DX-TX-4K60. The
IR TX and IR RX ports on a DX-RX-4K60 each support unidirectional IR data via the twisted pair cable
to/from the IR RX and IR TX ports on a DX-TX-4K60. The USB Host and Device ports on a DX-RX-4K60
each support transmitting USB data via the twisted pair cable to/from the USB Device and Host ports on a
DX-TX-4K60. The DX-RX-4K60 features SmartScale® Technology (integrated EDID output scaling) to
ensure an appropriate output resolution, plus it supports a Manual (override) option for setting up custom
resolutions and a Bypass option. It can be controlled through sending ICSP commands from a NetLinx
Central Controller and also supports CEC control and pass through to control 3rd-Party devices.
These DXLink products support several different modes which are available for system setup and use.
For a brief explanations of the modes please refer to the “Quick Reference Table”.
Features
Supports 4K@60Hz 4:4:4 8bit and HDCP 2.2;
SmartScale® on the Receivers works to automatically recognize any device’s supported resolutions and signal
type parameters, allowing updating source and destination devices without manual setup. Also included is the
ability to control detailed timing parameters for customized video output formats. (SmartScale is the ability to
configure the scaling output by automatically selecting destination defined resolutions.);
Supports USB1.1 and USB2.0 Host or device connections set by the Mode switch on the front panel, and
supports hosts like a Desktop or Laptop and USB devices like keyboards, mice, and cameras;
Standard twisted pair cable saves time and installation effort;
Transports video signals over distances up to 100m/330ft via DXLINK ports via Cat 6/6a/7 cable;
Supports CEC control and pass through;

Hardware Reference Manual
4
The 232 port (RS-232 serial) supports bidirectional transfer of serial data between Central Controller and TX/RX
(Endpoint Mode);
The IR port supports bidirectional transfer of IR data between Central Controller and RX (Endpoint Mode);
The DX-TX-4K60 transmitter supports HDMI loop out for connecting a local display;
Embedded Audio in in Transmitter and de-embedded Audio out in Receiver;
Power over DXLink (twisted pair cable) support when used with a switcher or with an approved AMX Power over
DXLink device;
DXLink modules are compatible with all V Style versatile mounting options including rack, surface, and pole;
Package Contents
DX-TX-4K60:
1 x DX-TX-4K60 Transmitter
1 x 12V Power Cord
1 x AC Power Cable with US Pins
1 x AC Power Cable with CN Pins
1 x AC Power Cable with EU Pins
1 x AC Power Cable with UK Pins
1 x Broadband IR Receiver (30KHz-50KHz)
1 x IR Emitter
1 x Phoenix Male Connector (3.5mm, 3 Pins)
1 x Phoenix Male Connector (3.5mm, 2 Pins)
2 x Mounting Bracket (with Screws)
4 x Rubber foot
DX-RX-4K60:
1 x DX-RX-4K60 Receiver
1 x DC 12V Power Cord
1 x AC Power Cable with US Pins
1 x AC Power Cable with CN Pins
1 x AC Power Cable with EU Pins
1 x AC Power Cable with UK Pins
1 x Broadband IR Receiver (30KHz-50KHz)
1 x IR Emitter
1 x Phoenix Male Connector (3.5mm, 3 Pins)
1 x Phoenix Male Connector (3.5mm, 2 Pins)
2 x Mounting Bracket (with Screws)
4 x Rubber foot

Hardware Reference Manual
5
Specifications
DX-TX-4K60
Technical
Input/Output
1 x HDMI IN, 1 x Audio IN, 1 x HDMI OUT, 1 x ICS LAN 10/100, 1 x IR RX,
1 x IR TX, 1 x RS-232, 1 x DXLINK, 1 x USB HOST, 1 x USB, 1 x DC 12V IN
Input Signal Type
HDMI with 4K@60Hz 4:4:4 HDCP 2.2
Input Resolution
Supported
VESA:
800x6008, 1024x7688, 1280x7688,1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1440x9008, 1600x9008, 1600x12008, 1680x10508,
1920x12008
SMPTE:
1280x7206,7,8, 1920x10806,7,8, 3840x21602,3,5,6,8, 4096x21602,3,5,6,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz,
6 = at 50 Hz, 7 = at 59.94 Hz, 8 = at 60 Hz
Established Timing including interlaced formats:
1280 x 1024 @ 75 Hz, 1152 x 870 @ 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz, 87 Hz, 832 x 624 @ 75 Hz
800 x 600 @ 56 Hz, 60 Hz, 75 Hz, 720 x 400 @ 70 Hz, 88 Hz
640 x 480 @ 60 Hz, 67 Hz, 72 Hz, 75 Hz
CEA Video Information Code (VIC) Formats:
VIC = 1, 640 x 480p 59.94/60 Hz 4:3
VIC = 2, 720 x 480p 59.94/60 Hz 4:3
VIC = 3, 720 x 480p 59.94/60 Hz 16:9
VIC = 4, 1280 x 720p 59.94/60 Hz 16:9
VIC = 5, 1920 x 1080i 59.94/60 Hz 16:9
VIC = 6, 720(1440) x 480i 59.94/60 Hz 4:3
VIC = 7, 720(1440) x 480i 59.94/60 Hz 16:9
VIC = 14, 1440 x 480p 59.94/60 Hz 4:3
VIC = 15, 1440 x 480p 59.94/60 Hz 16:9
VIC = 16, 1920 x 1080p 59.94/60 Hz 16:9
VIC = 17, 720 x 576p 50 Hz 4:3
VIC = 18, 720 x 576p 50 Hz 16:9
VIC = 19, 1280 x 720p 50 Hz 16:9
VIC = 20, 1920 x 1080i 50 Hz 16:9
VIC = 21, 720(1440) x 576i 50 Hz 4:3
VIC = 22, 720(1440) x 576i 50 Hz 16:9
VIC = 29, 1440 x 576p 50 Hz 4:3
VIC = 30, 1440 x 576p 50 Hz 16:9
VIC = 31, 1920 x 1080p 50 Hz 16:9
VIC = 32, 1920 x 1080p 23.97/24 Hz 16:9
VIC = 33, 1920 x 1080p 25 Hz 16:9
VIC = 34, 1920 x 1080p 29.97/30 Hz 16:9
VIC = 39, 1920 x 1080i 50 Hz 16:9
VIC = 41, 1280 x 720p 100 Hz 16:9
VIC = 42, 720 x 576p 100 Hz 4:3
VIC = 43, 720 x 576p 100 Hz 16:9
VIC = 44, 720(1440) x 576i 100 Hz 4:3
VIC = 45, 720(1440) x 576i 100 Hz 16:9
VIC = 47, 1280 x 720p 119.88/120 Hz 16:9
VIC = 48, 720 x 480p 119.88/120 Hz 4:3
VIC = 49, 720 x 480p 119.88/120 Hz 16:9
Input Video Level
0.5-1.0 Vp-p
Maximum Pixel Clock
600 MHz
Output
1 x DXLINK OUT, 1 x HDMI OUT
Output Signal Type
HDMI with 4K@60Hz 4:4:4; HDBaseT 2.0
Video Impedance
100 Ω
Audio Format Supported
HDMI IN: Fully supports audio formats in HDMI 2.0 specification, including PCM
2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD MA and DTS:X
Analog AUDIO IN: stereo
General
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 70°C (4°F to 158°F)
Humidity
5% to 85%, non-condensing
ESD Protection
Human-body Model:

Hardware Reference Manual
6
±8kV (Air-gap discharge)
±5kV (Contact discharge)
Surge Protection
Voltage: ±1 kV
Power Supply
DC 12V 3A or powered by Enova DGX Switchers/DVX Switchers
Power Consumption
(Maximum)
Local 12V Power Supplied: 12.5W
Power over DXLink Supplied: 13.0W
Device Dimension
(W x H x D)
220mm x 25mm x 160mm /8.66’’ x 0.98’’ x 6.30’’ (Without Mounting Brackets)
Product Weight
Approx. 0.9 kg / 2.0 lb
Certification
CE/FCC/ETL/PSE/RCM
DX-RX-4K60
Technical
Input/output
1 x DXLINK, 1 x IR TX, 1 X IR RX, 1 x RS232, 1 x ISC LAN10/100, 1 x AUDIO
OU T,
1 x USB HOST (Type-B), 1 x USB DEVICE (Type-A), 1 x DC 12V IN
Output Signal Type
HDMI with 4k@60Hz 4:4:4, HDCP 2.2
Output Resolution Support
VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1400x10508, 1440x9008, 1600x9008, 1600x12008,
1680x10508, 1920x12008
SMPTE:
1280x7206,8, 1920x10806,8, 3840x21602,3,5,6,8, 4096x21602,3,5,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at
50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz, 9 = 75 Hz
NOTE:
Scaler Mode: 3840x2160@60Hz RGB/YCbCr 4:4:4,
4096x2160@60Hz RGB/YCbCr 4:4:4;
Bypass Mode: 3840x2160@60Hz RGB/YCbCr 4:4:4,
4096x2160@60Hz YCbCr 4:2:0.
Output Video Level
0.5-1.0 Vp-p
Maximum Pixel Clock
600MHz
Output
1 x HDMI OUT, 1 x AUDIO OUT
Output Signal Type
HDMI
Video Impedance
100 Ω
Audio Format Supported
HDMI OUT:
Bypass Mode: Fully supports audio formats in HDMI 2.0 specification, including
PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD MA and DTS:X;
Scaler Mode: PCM 2.0
Analog AUDIO IN/OUT: stereo
General
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
5% to 85%, non-condensing
Surge Protection
Voltage: ±1 kV
Power Supply
DC 12V 3A or powered by Enova DGX Switchers/DVX Switchers
Power Consumption
(Maximum)
Local 12V Power Supplied: 18.2W
Power over DXLink Supplied: 20.2W
Device Dimension
(W x H x D)
220mm x 25mm x 160mm /8.66”x 0.98”x 6.30” (Without Mounting Brackets)
Product Weight
Approx. 1.0 kg / 2.2 lb
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)
±5kV (Contact discharge)
Certification
CE/FCC/ETL/PSE/RCM

Hardware Reference Manual
7
Transmission Distance
Cable Type
Range
Supported Video
1080P@60Hz, 48bpp
1080P@60Hz,3D
4K@30Hz, 4:4:4, 32bpp
4K@60Hz, 4:2:0, 32bpp
4K@60Hz, 4:4:4, 24bpp
Cat 6
Cat 6a/7
70m/230ft
100m/330ft
Hardware Description
DX-TX-4K60 Transmitter
Front View
POWER LED: On indicates when the Transmitter is powered on.
STATUS LED: On indicates the Transmitter is connected and communicating properly.
HDCP LED: On indicates HDCP-protected content is being transmitted, Blinking indicates Non-HDCP Protected
content is being transmitted, and Off indicates No content is being transmitted.
LINK LED: On indicates the ethernet cable is connected and an active link is established, Blinking indicates
receiving ethernet data packets.
ID Pushbutton: Place the transmitter in ID mode for setting the NetLinx ID (Device only) and provides additional
functionality, such as placing the device in Static IP mode or DHCP Mode (See “ID Push Button Operation”
Section).
USB MODE: Switch between USB Host (default setting) or USB device mode.
DIP SWITCH: For LAN port, DXLINK and network control modes configuration (See “DIP Switch Function”
section).
Rear View
Power Jack: Connect to the DC 12V power adapter provided.
HDMI IN: Connect to an HDMI Source. Support digital video and embedded digital audio. The HDMI connector
also supports a DVI-D signal with the use of a DVI-to-HDMI cable adapter.
POWER LED
STATUS LED
HDCP LED ID Pushbutton
USB MODE
DIP SWITCH
LINK LED
Power Jack
HDMI IN HDMI OUT IR RX RS-232
DXLINK
HOST
USBIR TXAUDIO IN ICS LAN 10/100

Hardware Reference Manual
8
AUDIO IN: Audio input, 3.5mm Mini-Stereo Jack.
HDMI OUT: Connect to an HDMI display. Support digital video and embedded digital audio.
ICS LAN 10/100: RJ45 port, TCP/IP Port. For ethernet 10/100 connectivity (receive commands or download
upgrade file).
IR RX: Connect to an IR receiver provided.
IR TX: Connect to an IR emitter provided.
RS-232: Connect an RS232 device for serial communication or RS232 pass-through.
DXLINK: Connect to a DXLink receiver such as DT-RX-4K60 or DXLink input boards via the twisted pair cable.
HOST: USB Type-B connector. Connect to a USB host device.
NOTE:When you want to connect USB devices to the Host PC of the transmitter, ensure the USB Mode Switch on
front panel is set to “USB HOST” position.
USB: USB Type-A connector. Connect to USB devices (such as keyboard, mouse, or interactive whiteboard).
DX-RX-4K60 Receiver
Front View
POWER LED: On indicates when the receiver is powered on.
SCALER LED: On indicates the video scaler is on active, and Off indicates the scaler is straightway.
STATUS LED: On indicates the receiver is programmed and communicating properly.
HDCP LED: On indicates HDCP-protected content is being transmitted, Blinking indicates Non-HDCP Protected
content is being transmitted, and Off indicates No content is being transmitted.
LINK LED: On indicates the ethernet cable is connected and an active link is established, and Blinking indicates
receive ethernet data packages.
ID Pushbutton: Places the receiver in ID Mode for setting the NetLinx ID (Device only) and provides additional
functionality, such as placing the device in Static IP mode or DHCP mode.
USB MODE: Switch to USB Host (default setting) or USB device mode.
DIP SWITCH: For LAN port, DXLINK and network control modes configuration (See “DIP Switch Function”
section).
Rear View
Power Jack: Connect to the DC 12V power adapter provided.
DXLINK: Connect to DXLink transmitter such as DX-TX-4K60 or output boards via a twisted pair cable.
POWER LED STATUS LED LINK LED USB MODE
SCALER LED DIP SWITCH
ID PushbuttonHDCP LED
Power Jack HDMI OUTIR TXHOST ICS LAN 10/100
DXLINK USB IR RX RS-232 AUDIO OUT

Hardware Reference Manual
9
HOST: USB Type-B connector. Connect to a USB host device.
NOTE:When you want to connect USB devices to the Host PC of the receiver, ensure the USB Mode Switch on
front panel is set to “USB HOST” position.
USB: USB Type-A connector. Connect to USB devices (such as keyboard, mouse, interactive whiteboard).
ICS LAN 10/100: RJ45 port, TCP/IP Port. For ethernet 10/100 connectivity (receive commands or download
upgrade file).
IR RX: Connect to an IR receiver.
IR TX: Connect to an IR emitter.
RS-232: Connect a RS232 device for serial communication or RS232 pass-through.
HDMI OUT: Connect to an HDMI display.
AUDIO OUT: 3.5mm stereo jack. Connect to an audio device for analog audio output.

Hardware Reference Manual
10
Pinout Information
RS232
Connects to a RS232 device with the 3-pole, 3.5mm captive screw connectors. Wire as shown below:
Twisted Pair cable
The pinout in the following picture is for twisted pair cable that connects to the ICS LAN 10/100 connector (on
modules only) or to the DXLink connector on all Transmitters and Receivers. Use either the T568A or T568B pinout
specification for termination of the twisted pair cable used between the units in a standalone setup or between
Transmitters and Receivers and an enclosure in a full system.
In a typical installation, the cables should be stretched to their full length between Transmitters and Receivers and
the enclosure or between units in a standalone system. Service loops or coils of the cable may reduce the overall
cable performance and should be minimized whenever possible.

Hardware Reference Manual
11
RJ-45 LEDs
ICS LAN 10/100 Connector LEDs (DXLINK Modes only)
The following information applies to the LEDs on the ICS LAN 10/100 connector on DXLink modules.
Note that #1 Toggle must be set to ON or ICS LAN functionality will not be provided.
ICS LAN 10/100 Connector LEDs
(Modules only)
Green LED:
On: Link status is active.
Off: Link status is not active.
Yellow LED:
On: Speed status is 10/100 Mbps.
DXLINK Connector LEDs
The following information applies to the LEDs located on the DXLink (RJ-45) connectors on the rear of DXLink units.
DXLINK (RJ-45) LEDs
Green LED:
On: Connection established.
Off: Connection not established.
Yellow LED:
On: Authenticated HDCP.
Flashing: Video active; no HDCP.
Off: No Video.
Yellow LE D
Green LED
Yellow LE D
Green LED

Hardware Reference Manual
12
Quick Reference Tables for Modes
The modes listed in the following three tables are those supported by DXLink Transmitters and Receivers. The Quick
Reference Tables are intended to help users navigate the many modes available for system setup and use. For
complete information on any of the modes listed, see the relevant sections or chapter referenced at the end of the
Descriptions.
Quick Reference Table - Modes for Handling System Architecture
Mode Description
DXLink Modes DXLink Modes refer to the type of physical components and how they are connected
to make up the system. When Transmitters and Receivers are cabled into a system
and powered on, they automatically detect the DXLink Mode they are being used in.
Endpoint Mode:
When the system is setup to use Transmitters and/or Receivers with an Enova
DGX Digital Media Switcher or an applicable Enova DVX Solution, the system is in
Endpoint Mode.
Or
When a TX is directly connected to an RX but, in addition, the TX and/or RX is
connected to a NetLinx Central Controller via a LAN or directly connected to the
Controller, the system is in Endpoint Mode.
Extender Mode:
When a TX is directly connected to an RX, the system is in Extender Mode.
For further information, reference #2 Toggle DIP switch settings for DXLink Mode and
DXLink System SEND_COMMANDs.
Quick Reference Table - Modes for Handling Addressing/Networking
Mode Description
IP Addressing
Modes
IP Addressing Modes refer to network connection settings. By default, all network
connection settings are turned OFF.
Static IP Mode:
This mode configures the network connection to one stable IP address the device
will use continuously.
DHCP Mode:
This mode configures the network connection to choose a new IP address for
each network session.
Change IP Addressing Modes, send commands through NetLinx (see “APPENDIX C:
ICSP Commands”), press ID Pushbutton or set on the web UI.
ID Mode ID (Identify) Mode refers to the protocol for enabling a user to establish device
addresses. This Mode, accessible through NetLinx Studio, places the entire system on
hold while it waits for an event from a NetLinx device in the named system (e.g.,
pressing the ID Pushbutton on the TX or RX). For further information, see “Assign a
Device Address (ID Mode)” part of “DIP Switch Function” section.
Ethernet Modes
Ethernet Modes refer to the LAN configuration settings.
Auto Mode:
This mode configures the LAN driver to discover its own settings based on the
network it is connected to.

Hardware Reference Manual
13
Quick Reference Table - Modes for Handling Addressing/Networking
Mode Description
Ethernet Modes
(continued)
Speed/Duplex Mode:
This mode configures the LAN driver to calculate its speed as either 10 or 100
and to communicate in either half- or full-duplex.
Ethernet Mode discovery and configuration information is available through
Telnet commands.
Change or get Ethernet Modes, send Telnet commands, see the “APPENDIX C: ICSP
Commands” section.
Central Controller
Connection
Modes
Central Controller Connection Modes refer to the modes of communication used for
connection to the Central Controller as specified via the SET CONNECTION Telnet
command and web UI.
Auto Mode:
This mode utilizes TCP communication. It looks for a matching System Number and
attempts to come online with the first Central Controller it sees with that System
Number.
TCP URL Mode:
TCP; the Central Controller is specified via URL.
UDP URL Mode:
UDP; the Central Controller is specified via URL.
NDP Mode (Default):
UDP; utilizes the NDP binding process to assign the DXLink Module (the physical
device) to a Central Controller (or Virtual Central Controller) via NetLinx Studio. Once
bound, communications are conducted via UDP.
Auto-setup Mode In auto-setup mode, endpoints are automatically discovered by and connected to an
Enova DGX 100 Series
Switcher using a single IP address. For this mode, all of the following requirements
must be met. If not, the endpoint will no longer reside in auto-setup mode and must
be either bound to the integrated Central Controller or reconfigured to meet the
requirements.
Endpoint must be connected to a DXLink Input Board in an Enova DGX 100 Series
Switcher (or Enova DGX with upgraded 100 Series CPU).
Endpoint must have IP mode set to DHCP for setup (self-configures to Static IP
on private LAN).
Endpoint must have the Central Controller connection type set to NDP.
Endpoint must not be bound to a Central Controller via NDP (traditional binding
process).
Endpoint DIP switch setting for Toggle #3 (network connectivity) is ignored while
in auto-setup mode
IMPORTANT: If auto-setup is being used, Telnet is the only way to access some of the
network settings. Also note that some network settings will disable auto-setup.
For additional information on the auto-setup feature, see “the Hardware Reference
Manual – Enova DGX 100 Series Digital Media Switchers”.

Hardware Reference Manual
14
Quick Reference Table - Modes for Handling Video Processing
Mode Description
Scaling Scaling Modes refer to how the system alters or maintains a source device’s resolution
as it is passed along to the destination device. The Scaling Mode can be set through
RX Web UI, with SEND_COMMANDs, or through DGX Configuration Software when
scaling is being done via an Enova DXLink Output Board.
Auto Mode (Default):
Auto Mode (SmartScale®) allows the destination device to choose the resolution
it needs.
Manual Mode:
Manual Mode allows the user to configure the resolution the video will display
through a destination device.
Bypass Mode:
Bypass Mode allows the video signal to display over the destination device without
altering the signal’s resolution.

Hardware Reference Manual
15
DIP Switch Function
The DIP Switch is located on the front panel of DX-TX-4K60 and DX-RX-4K60, the functions is descripted as follows.
#1 Toggle is used for enabling/disabling the physical ICS LAN 10/100 port.
#2 Toggle is used for setting Modules to either automatically or manually determine the DXLink Mode.
#3 Toggle is used for enabling/disabling network connectivity of the DXLink Transmitter or Receiver to a
connected NetLinx Central Controller (used for IR ports, serial ports, and commands to the DXLink unit).
# 4 Toggle is not functional.
#1 Toggle Settings
Setting DIP Switch #1 to Enable/Disable Access to LAN 10/100 Port.
OFF (Default): When the #1 Toggle is set to OFF, network activity over the ICS LAN 10/100 port is disabled.
ON: When the #1 Toggle is set to ON, network activity over the ICS LAN 10/100 port is enabled.
Installation Options:
Option A: For a network connection between a Transmitter and a Receiver where only one of them is
connected to a LAN, set the #1 Toggle to ON for the unit that is connected to the network.
Note: Option A – Do not connect both the Transmitter and the Receiver to a common LAN as a network loop will result.
Option B: When a Transmitter or Receiver is connected to a DXLink input or output on an Enova DGX Digital
Media Switcher or Enova DVX switcher, the switcher provides a network connection allowing the Transmitter
or Receiver to appear in the online tree in NetLinx Studio (#3 Toggle must be set to ON). For connecting the
Transmitter or Receiver to other equipment using the ICS LAN 10/100 port, the #1 Toggle must be set to
ON.
Note: Option B: Because the DXLink connection carries network activity passed from the switcher, do not connect the
ICS LAN 10/100 port on the Transmitter or Receiver to the same LAN as the switcher because a network loop will
result.
#2 Toggle Settings
#2 Toggle can be set to automatically or manually select the DXLink Mode (to either Extender or Endpoint) for a
given Transmitter/Receiver Module. Default state for #2 Toggle OFF is auto selection of DXLink Mode based on
connection to another device. When it’s ON, the default is Endpoint Mode (used for Central Controller controlled
serial/IR data transfer).
OFF (Default): When #2 Toggle is set to OFF, the Transmitter and Receiver will each auto-discover* what
1 2 3 4
ON DIP

Hardware Reference Manual
16
type of DXLink equipment they are connected to and will automatically self-configure to be in one of two
DXLink Modes based on the connection:
Extender Mode – This mode is automatically selected when a TX and RX are connected directly to each other (a
standalone pair). The Transmitter and Receiver act like a simple extender, and serial and IR data is passed through
them.
Endpoint Mode – This mode is automatically selected when a module is connected directly to a DXLink port on a
switcher. Serial and IR operations are handled by the host providing control of endpoints. The Central Controller’s
programming specifies where IR and serial commands are sent (this is handled independently from the routing of
the video signals).
* Any time the DXLink connection is re-established or power is cycled on a module, the auto-discovery process will
take place, as long as the #2 Toggle remains in the OFF position.
ON: When #2 Toggle is set to ON, the auto-discover feature is disabled and the module can be manually set
to either Endpoint Mode (default) or Extender Mode. In Endpoint Mode, when the module is connected to a
switcher or a separate NetLinx Central Controller **, IR and serial operation are only handled via the host.
** When standalone modules require IR and/or Serial control by a separate NetLinx Central Controller, then they
need to be in Endpoint Mode. Only one must be connected via the ICS LAN 10/100 port to the Central Controller or
to a LAN with the Central Controller on it. This requires #1 Toggle to be ON to enable the ICS LAN port. #2 Toggle
needs to be ON to place the modules in Endpoint Mode (if needed), and #3 Toggle needs to be ON to enable network
connectivity.
Note: On either setting, the DXLink Mode may be set via SEND_COMMANDs (see “APPENDIX C: ICSP Commands”
section). When #2 Toggle is set to the OFF position, the auto-discovery process will overwrite the DXLink Mode setting.
However, when the #2 Toggle is set to the ON position, auto-discovery is disabled and the mode set by
SEND_COMMANDs will persist (i.e., the DXLink Mode setting cannot be overwritten).
Setting DIP Switch #3 for Network Connectivity, default setting is OFF, the transmitter and receiver will not
try to connect to the network and will not acquire an IP address;
Setting DIP Switch #4 is Reserved.
Note:
For easiest access to the DIP switch toggles, we recommend setting them before installation.
DIP switch settings on any of these DXLink products are read only on reboot. After the settings are read, any
adjustments of the toggles will not be implemented and will not affect the system.
#3 Toggle Settings
The #3 Toggle is used for enabling/disabling network connectivity (IP addressing) of the DXLink Transmitter or
Receiver. If enabled, it allows the Transmitter or Receiver to be configured to connect to a NetLinx Central Controller
(used for controlling the DXLink unit and allowing Ethernet traffic).
OFF (default) – When the #3 Toggle is set to OFF, the Transmitter or Receiver will not try to connect to the
network and will not acquire an IP address.
ON – When the #3 Toggle is set to ON, the Transmitter or Receiver will attempt to connect to the network
via DHCP or static IP, depending on how the unit has been set up. The Transmitter and Receiver will not
display in NetLinx Studio and will not accept commands or queries unless the #3 Toggle is ON.
Note: After the #3 Toggle is set to ON, a network connection is established, and the NetLinx Studio screen is refreshed,
Transmitters and Receivers display in the Online Tree as Unbound NDP (Network Detect Proxy) Devices. To facilitate
IRL and KIT file transfers, they can be bound to the integrated NetLinx Central Controller in a switcher or to another
NetLinx Central Controller. A Virtual NetLinx Central Controller can also be used for file transfers.
