Omron WD30-ME User manual

DeviceNet Wireless Units WD30 127
DeviceNet Wireless Units
WD30
Wireless DeviceNet Units Connects
Slaves without Wires
• Up to 3,200 I/O points can be communicated through a Master Unit.
• Uses spread spectrum technology for superior noise resistance in
manufacturing environments.
• Long-range communications have been achieved with a relay function
(3 repeaters max.).
• Message communications are supported.
• Approval for compliance with China, U.S., and European radio wave
standards.
• RoHS Compliant
System Configuration
WD30-ME
(WD30-SE)
WD30-SE01
(WD30-ME01)
DCN1-3C
T- branch Tap with
Terminator
DCN1-3C
T- branch Tap with
Terminator
DCN1-3C
T- branch Tap with
Terminator
DRS1-T
Terminating Resistor
Terminal Block
Programmable Slave
CPM2C-S1@OC-DRT
DCN2-1
T- branch Connector
DeviceNet network
CompoBus/S
PLC I/O Link Unit
DRT2
DRT2
Terminator
DCN2-1
T- branch
Connector
DCN2-1 T-branch Connector
(Layer 2)
(Layer 1)
Power
Supply
S8VS
Power
Supply
S8VS
Power
Supply
S8VS
Note: It is possible to connect
I/O Slaves for the WT30.
DRT2
DRS2-1
DRT2
DRT2
Terminator
DRS2-1
DeviceNet Slave
DRT2
DRT2
PC Card
(includes Configurator Software)
3G8E2-DRM21
Configurator Software
WS02-CFDC1-J
DRT2
Terminator
DRS2-1
DRS1-T
Terminating Resistor
Terminal Block
Power
Supply
S8VS
Terminator
DRS2-1
DCN2-1
T- branch
Connector
Digital
Process Controller
E5ER-DRT
DCN2-1
T- branch
Connector
Terminator
DRS2-1
DRT2 DRS1-T
Terminating Resisto
r
Terminal Block
DRS1-T
Terminating
Resistor
Terminal Block
Power
Supply
S8VS
Terminator
DRS2-1
DCN2-1
T- branch
Connector
Power
Supply
S8VS
Power
Supply
S8VS
Power
Supply
S8VS
DRT2 DCN1-3C
T- branch Tap with
Terminator
Digital Process Controller
E5ER-DRT
Power
Supply
S8VS
IN
CS1W-DRM21
CX-Integrator
Configurator
Repeater
Slave
Repeater
Slave
Slave
Master
Slave
Master
Slave
DeviceNet Unit
WT30
I/O Slave
Note: Relay Stations can be used to create up to three layers, and DeviceNet Slaves
can be connected to each layer. Terminators are required when Slaves are
connected to a Relay Station or Slave Station. Refer to the WD30 DeviceNet
Wireless Operation Manual for details on Terminator installation.
Name Number of I/O points (words used)
DeviceNet Wireless Master 1,600 inputs max. (100 words)
1,600 outputs max. (100 words)
DeviceNet Wireless Slave 512 inputs max. (32 words)
512 outputs max. (32 words)

128 DeviceNet Wireless Units WD30
Ordering Information
●Peripheral Devices (Micro Connectors) ●Peripheral Devices
Note: For details on peripheral devices, refer to this catalog.
*The price depends on the license.
Specifications
●General Specifications
*Select a power supply with excess capacity. (We recommend a minimum of 25 W.)
●Wireless Interface Specifications
*Depends on many factors in the installation environment.
●DeviceNet Interface Specifications (Summary)
*FINS message communications are not supported. Explicit messages must be
handled in the ladder program. Refer to the WD30 DeviceNet Wireless Units
Operation Manual for details.
●Compliance with China Radio Standards
In China, radio frequency channel 51 cannot be used. Use channels 2
to 34 or channels 52 to 83. Also, use is prohibited on or near aircraft.
●Certified Standards
●Compliance with UL Standards
Use a class 2 power supply for compliance with UL standards.
Main class 2 power supply: OMRON S8VS (30 W or 60 W)
Switching Power Supply
Dimensions (Unit: mm)
●WD30 DeviceNet Wireless Unit
*With the WD30-AT001, only the WD-ME/SE or WD30-ME01/SE01 can be used.
Type Number of I/O
(number of allocated words) Antenna type Model
DeviceNet Wireless Master 1,600 inputs max. (100 words)
1,600 outputs max. (100 words)
Pencil-type antenna WD30-ME
Magnetic base antenna WD30-ME01
DeviceNet Wireless Slave 512 inputs max. (32 words)
512 outputs max. (32 words)
Pencil-type antenna WD30-SE
Magnetic base antenna WD30-SE01
Magnetic base antenna (one) -- -- WD30-AT001 *
●Enclosed Accessories
The following accessories are included with
a Wireless Master or Wireless Slave.
• Two Antennas
• Instruction Sheet
• Declaration of CE marking certification
• Two M4 screws (with nuts, flat washers,
and spring washers)
Name Specifications Model
Shielded T-branch
Connector
Connector with one
branch
Screws DCN2-1
Smart Click DCN2-1S
Cable with
Shielded
Connectors
Cables with connectors on
both ends
Screws DCA1-5CN@@W1
Smart Click DCA1-5CS@@W1
Cables with connector
socket on one end
Screws DCA1-5CN@@F1
Smart Click DCA1-5CS@@F1
Shielded
Te r m i n a t o r Plug Connector Screws DRS2-1
Smart Click DRS2-1S
Name Model
Configurator (PC Card) 3G8E2-DRM21-V1
Configurator Software WS02-CFDC1-E
FA Integrated Tool Package CXONE-AL@@C-E
Item Specifications
DeviceNet communications
power supply voltage
11 to 25 VDC
(supplied from the communications connector)
Current consumption *4 W (350 mA max. (startup), average: 120 mA)
Ambient operating temperature -10°C to 50°C
Ambient operating humidity 25% to 85% (with no condensation)
Ambient storage temperature -20°C to 65°C
Vibration resistance
10 to 55 Hz, 0.35-mm amplitude at 50 m/s2
acceleration with 10 sweeps in X, Y and Z directions
for 8 minutes each
Shock resistance 150m/s2, 6 directions, 3 times each
Weight Approx. 200 g
Item Specifications
Wave type Spread Spectrum (direct sequence; DS-SS)
Communications method Simplex (half duplex)
Frequency band 2.4 GHz (2401 MHz to 2480.2 MHz)
Number of channels 66 channels
Antenna power 10 mW
Data transfer speed between
wireless units 100 kbps
Transmission distance *Indoors: 60 m (approx. 50 m with magnetic base
antennas)
Outdoors: 300 m (unobstructed)
Relay stations 3 repeaters max.
Max. number of sets in the same
area *10 sets max.
Max. number of wireless Slaves 64 max.
Item Specifications
Communications
functions *Master/Slave connections
Remote I/O functions, Explicit message
communications
Self-diagnostic
functions
Unit WDT error, hardware errors (such as memory
and CAN errors), and setting errors
DeviceNet
communications
Duplicate node address errors, Bus OFF
detection, and connection timeout
Device profiles Communication
control unit
Refer to Appendix A of the WD30 DeviceNet
Wireless Units Operation Manual for various
DeviceNet IDs (vendor, device type =
communication adapter, product code, product
revision, product name, serial number, status,
and I/O unit IDs.)
Approved radio
standards
Japanese radio standards ARIB STD-T66
U.S. radio standards FCC part15.247
Canadian radio standards IC RSS 210
Chinese radio standards 信部無［2002］353号
Compliant radio
standards EU radio standards EN 300 440-2
Approved standards Safety standards cULus Listing: UL508/CSA C22.2
No.142
Compliant standards Safety standards EN 60950-1
EMC standards EN 301 489-17
●DeviceNet Wireless Units
WD30-ME
WD30-SE
●DeviceNet Wireless Units
WD30-ME01
WD30-SE01
●Magnetic Base Antenna (1 Antenna)
WD30-AT001
(Included with the WD30-ME01 and WD30-SE01.)
Refer to the WD30 DeviceNet Wireless Units Datasheet (Cat. No. M502, M503) or
WD30 DeviceNet Wireless Units Operation Manual (Cat. No. M071) for more detailed specifications.
39
13.3
115
94
20
10.5 3.8dia.
35.8dia.
(Cable length: 2,000)
MS
WD30--ME V1
WIRELESS UNIT
NS
No.
35
16
59.5
13
159
85
74
62
80
MS
WD30--ME V1
WIRELESS UNIT
NSWS
No.
59.5
13
85
8035

Read and Understand This Catalog
Please read and understand this catalog before purchasing the products. Please consult your OMRON representative if you have any questions or
comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified)
from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT, MERCHANTABILITY, OR
FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USERALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMSALL OTHER
WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS
IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT
LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS
OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY HANDLED, STORED, INSTALLED,AND MAINTAINED AND NOT
SUBJECTTO CONTAMINATION,ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of products in the customer's
application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying ratings and limitations of use that apply to the
products. This information by itself is not sufficient for a complete determination of the suitability of the products in combination with the end product,
machine, system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible
uses of the products, nor is it intended to imply that the uses listed may be suitable for the products:
 Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or uses not described in this catalog.
 Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical equipment, amusement machines, vehicles,
safety equipment, and installations subject to separate industry or government regulations.
 Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FORAN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY WITHOUT ENSURING THAT THE
SYSTEMASAWHOLE HAS BEEN DESIGNED TOADDRESS THE RISKS,AND THAT THE OMRON PRODUCTSARE PROPERLY RATED AND
INSTALLED FOR THE INTENDED USE WITHIN THE OVERALLEQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any consequence thereof.
Disclaimers
CHANGE INSPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other reasons.
It is our practice to change model numbers when published ratings or features are changed, or when significant construction changes are made.
However, some specifications of the products may be changed without any notice. When in doubt, special model numbers may be assigned to fix or
establish key specifications for your application on your request. Please consult with your OMRON representative at any time to confirm actual
specifications of purchased products.
DIMENSIONS ANDWEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are shown.
PERFORMANCE DATA
Performance data given in this catalog is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the
result of OMRON’s test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON
Warranty and Limitations of Liability.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however, no responsibility is assumed for clerical,
typographical, or proofreading errors, or omissions.
2011.8
In the interest of product improvement, specifications are subject to change without notice.
OMRON Corporation
Industrial Automation Company
http://www.ia.omron.com/
(c)Copyright OMRON Corporation 2011 All Right Reserved.

Authorized Distribution Brand：
Website：
Welcome to visit www.ameya360.com
Contact Us：
Address：
401 Building No.5, JiuGe Business Center, Lane 2301, Yishan Rd
Minhang District, Shanghai , China
Sales：
Direct [phone]
Email [email protected]
QQ 800077892
Skype ameyasales1 ameyasales2
Customer Service：
Email [email protected]
Partnership：
Tel [phone]-8333
Email [email protected]
