Oncam OBE-20-SPA User manual

Evolution Stainless Steel
Pendant Arm - Wall Mount
QUICK START GUIDE

Important
Read these instructions carefully before installing or operating this camera.
This accessory should be installed by a qualified service person and the
installation should conform to local and national regulations.
Overloading the Pendant Arm will result in structural failure of the product and risk to
property and life.
Fixing used should be of appropriate strength and suitable for use around stainless
steel.
Chloride from cleaning products will cause the stainless steel to lose chrome content
and therefore corrode. Chlorine from poorly maintained swimming pools can also
become chloride.
Placing this Pendant Arm on or near ferrous material will cause the product to become
stained and to collect corrosion over time.
For best results the stainless steel should be cleaned regularly with a lint free cloth and
sunflower oil or equivalent.
Failure to use the Anti-Bird Roost Bar may lead to birds roosting on the arm which may
lead to faeces damaging or affecting the structural integrity of the arm and camera.
SKU OBE-20-SPA
Material Electropolished marine grade 316L stainless steel
Weight 2.2 kg (4.9 lbs)
Thread Compatible with female 1 1/2” NPT
Reach 305mm
Conduit Concentric M20 and 3/4”

STAINLESS STEEL PENDANT ARM
BOX CONTENTS
APendant Arm DAnti Bird Roost Bar Screws
BPendant Arm Cap EPenny Washers
CAnti Bird Roost Bar FConduit Cap
A
B
C
D
F
E

20mm
[1.0"]
25.4
PRINT AT
100% SCALE
FIXING = 10mm or 3/8".
WIRE = Ø10 mm or Ø3/8"
Ø10
mm Ø3/8"
DRILLING
TEMPLATE
006-0054-0389 - ISSUE 1
1
2
3
4
USE APPROPRIATE
M10 OR 3/8”
WALL FIXINGS
* (NOT SUPPLIED)
ETHERNET CABLE
DRILL ALL 5 HOLES
SCREW ON PENDANT ARM CAP
WALL MOUNT INSTALLATION

20mm
[1.0"]
25.4
PRINT AT
100% SCALE
FIXING = 10mm or 3/8".
WIRE = Ø10 mm or Ø3/8"
Ø10
mm Ø3/8"
DRILLING
TEMPLATE
006-0054-0389 - ISSUE 1
1
2
ETHERNET CABLE
WALL MOUNT WITH CONDUIT INSTALLATION
DRILL4CORNERHOLESONLY

3
4
USE APPROPRIATE
M10 OR 3/8”
WALL FIXINGS
* (NOT SUPPLIED)
M20 OR 3/4” NPT
5
SCREW ON PENDANT ARM CAP

OBE-20-SPP - Evolution Stainless
Steel Pendant Arm Pole Mount
OPTIONAL ACCESSORY POLE MOUNT
SKU OBE-20-SPP
Material Electropolished marine grade 316 stainless steel
Weight 0.89 kg (1.96 lbs)

OBE-20-SPC - Evolution Stainless
Steel Pendant Arm Corner Mount
OPTIONAL ACCESSORIES - CORNER MOUNT
SKU OBE-20-SPC
Material Electropolished marine grade 316 stainless steel
Weight 1.65 kg (3.65lbs)
