One Remote Beolink 1000 User manual

Beokompatible functions
OneRemote Interface type 2530
Technisat Digicorder
Beo4 and Beolink 1000 are remote control terminals from Bang & Olufsen. OneRemote supplies interface modules that allow third party equipment to be operated via a Bang & Olufsen remote control system.
Made in Denmark by www.oneremote.dk

Operating using a Beolink 1000 or other old remote controllers.
Older remote controls do not have coloured
buttons, and use is not logical.
As Beolink 1000 has no coloured buttons the
Zapmode option needs to be set, to make the
the up/ down arrows serve as P+ and P-.
See page 6 about option programming.
The P button on older Bang & Olufsen
remote controls does the exact same operation
as theObutton on never remote controls.
g Exit/ back
x SFI/ EPG
phZ Green function
phX Yellow function
phC Blue function
phV Red function
pC Up
pV Down
Daily use
OO OK
Q*1 SFI/ EPG
E*1 Exit/ Back
W*1 P+
R*1 P-
o1 Text
o2 Option
o3 info
eExit
*1 As the un-shifted function of the coloured function
buttons has been assigned to other functions, they
have to be preceded with a Oto retrieve their
actual coloured functions.
oQ Green function
oW Yellow function
oE Red function
oRBlue function
Playback operation
O0 Play/ pause
qStop
OA Rew
OS FF
O8 Record
Other operations
o4 A/B Sound
o5 Menu alternativ
o7 TV/ Radio
o9 Power manuel

Congratulations
With a OneRemote INT controller from www.oneremote.dk
built in to your device, you can connect the device to any Bang
& Olufsen TV and fully operate it your Bang & Olufsen remote
control terminal. This guide explains how.

INT internal controller -how it works
A OneRemote INT controller is a small microcomputer, which is specifically made to be
built in to a non Bang & Olufsen device, equipped with a Scart output socket. This could
be a Satellite receiver, DVD player etc.
A Bang & Olufsen TV receives IR data from its remote control, a Beolink1000, Beo4,
Beo5 or another.
When a Scart source is selected on the B&O TV, where a device with an INT controller is
connected, the TV echoes control data from the remote control to the device. These data is
retransmitted via this Scart connection to the device. Control data flows through the
existing Scart cable, therefore no further cables is needed.
With a OneRemote OneWay or TwoWay cable, the device can be placed up to 25 metres
away from the TV. It could be placed in another room, under a sofa or where ever it suits,
as operation is handled via the Scartcable.
If both the TV and the device are equipped with a HDMI connection, a HDMI cable can
be added to improve picture and sound quality.
The microcomputer then translates the B&O control data, to data that controls the specific
device that it is built into.
If the Bang & Olufsen TV that the device is connected to is the main TV of a Beolink
system, all link rooms can get to the device and even operate it.

OneRemote operation in a B&O system
To be able to operate the device correctly with the Beo4 the user has to be familiar with
operations with the original remote control as described in the device’s user manual.
The beo4 remote control is not equipped with many keys, so we have designed a ‘layout’
that works logically, even when shifting between different devices. To get a universal
layout for different devices, we needed to redefine a few of the beo4 buttons to other
functions:
Coloured buttons.
To make room for important functions, we have moved the coloured buttons, to a
lower layer. To send a ‘red’ button command Omust be pressed before the red
button. The same goes with the other 3 coloured buttons. This way we have freed
the direct function of the coloured buttons, to important operations.
In a OneRemote environment the red button is used as Back, Backup or return.
The green button is used as EPG, Guide or similar. Finally the blue and yellow
button is used for programme stepping.
Programme stepping, up/ down manoeuvring in menus.
Most set top boxes or TV’s has 4 arrow buttons for moving up, down, left and
right in on screen menus. In addition they have separate programme stepping
buttons for zapping through programmes. B&O remote control does not have
separate buttons for programme zapping and menu manoeuvring.
We therefore have chosen the direct blue and yellow buttons to be used as
programme stepping buttons. The four up, down, left and right buttons have been
assigned for manoeuvring in on screen menus, in our basic setup.
It is possible to use the up and down arrow for programme stepping.
See page 6 about option programming.
Go or Record shifted operation.
Some of the buttons has been assigned 2 or three functions. To get to these they
have to be preceded with Oor q.
Buttons that has been assigned secondary functions on this controller can be seen
in the operating table on page 2.

Option programming
The OneRemote controller inside your device can be programmed with different options,
to fit different setup and needs.
An option programming is done by pressing a series of buttons in a special scheme that
does not occur during daily use. A programming must be ended within 3 seconds.
To abort an ongoing programming sequence, press any other button than qor the
numeric buttons 0to 9.
Option 7x –auto power off enable.
In some cases it is not wanted that the device automatically powers off, when the TV is
powered off. Use this option to enable or disable this.
qqqqqq71 Device powers off with TV.
qqqqqq70 Device never powers off.
Option 8x –menu button block enable.
Some B&O TVs not only echoes the MENU button from the remote control to the device
attached to the Scart socket. It also opens the TV’s own ON-screen menu. Use this option
to avoid that the device acts on this command, if your setup has this conflict.
qqqqqq81 Use the MENU button.
qqqqqq80 Ignore the Menu button..

2530u2uk
