OneTech 1B-25xxHEC User manual

DVR User Manual
For H.264 4/8/16-channel digital video recorder
All rights reserved
Page 1 of 109

DVR User Manual
CAUTION
Please read this user manual carefully to ensure that you can use the device correctly and safely
We do not warrant all the content is correct. The contents of this manual are subject to change without notice
This device should be operated only from the type of power source indicated on the marking label. The voltage of the power
must be verified before using the same. Kindly remove the cables from the power source if the device is not to be used for a long
period of time.
Do not install this device near any heat sources such as radiators, heat registers, stoves or other devices that produce heat
Do not install this device near water. Clean only with a dry cloth
Do not block any ventilation openings and ensure proper ventilation around the machine
Do not power off the DVR when the device is functioning. The correct operation to shut down the DVR is to first stop recording
and then use “shut-down” button from the menu, and finally switch off the main power.
This machine is for indoor use only. Do not expose the machine in rain or moist environment. In case any solid or liquid get
inside the machine‟s case, please turn off the device immediately and get it checked by a qualified technician.
Do not try to repair the device by yourself without technical aid or approval.
When this product is in use, the relevant contents of Microsoft, Apple and Google will be involved in. The pictures and
screenshots in this manual are only used to explain the usage of our product. The ownerships of trademarks, logos and other
intellectual properties related to Microsoft, Apple and Google shall belong to the above-mentioned companies.
This manual is suitable for 4/8/16-channel digital video recorders. All examples and pictures used in the manual are from
16-channel DVR.
Page 2 of 109

DVR User Manual
Table of Contents
1Introduction ................................................................................................................................................1
1.1 DVR Introduction.............................................................................................................................................................1
1.2 Main Features .................................................................................................................................................................1
2Hardware Installation.................................................................................................................................4
2.1 Install Hard Drive &DVD Writer........................................................................................................................................4
2.1.1 Install Hard Drive.....................................................................................................................................................................................4
2.1.2 Install DVD Writer....................................................................................................................................................................................5
2.2 Front Panel Descriptions.................................................................................................................................................5
2.3 Rear Panel Instructions...................................................................................................................................................6
2.4 Remote Controller.........................................................................................................................................................10
2.5 Control with Mouse........................................................................................................................................................12
2.5.1 Connect Mouse.....................................................................................................................................................................................12
2.5.2 Use Mouse............................................................................................................................................................................................12
3Basic Function Instruction......................................................................................................................14
3.1 Startup & Shutdown.......................................................................................................................................................14
3.1.1 Startup..................................................................................................................................................................................................14
3.1.2 Shutdown..............................................................................................................................................................................................14
3.2 Login .............................................................................................................................................................................15
3.3 Live Preview..................................................................................................................................................................15
3.3.1 Live Playback........................................................................................................................................................................................15
4Main Menu Setup Guide ..........................................................................................................................17
4.1 Basic Configuration .......................................................................................................................................................18
4.1.1 System..................................................................................................................................................................................................18
4.1.2 Date & Time..........................................................................................................................................................................................19
4.1.3 DST......................................................................................................................................................................................................19
4.2 Live Configuration .........................................................................................................................................................20
Page 3 of 109

DVR User Manual
4.2.1 Live.......................................................................................................................................................................................................20
4.2.2 Main Monitor.........................................................................................................................................................................................21
4.2.3 Spot......................................................................................................................................................................................................21
4.2.4 Mask.....................................................................................................................................................................................................21
4.3 Record Configuration ....................................................................................................................................................22
4.3.1 Enable ..................................................................................................................................................................................................23
4.3.2 Record Bitrate.......................................................................................................................................................................................23
4.3.3 Time......................................................................................................................................................................................................24
4.3.4 Stamp ...................................................................................................................................................................................................24
4.3.5 Recycle Record.....................................................................................................................................................................................25
4.3.6 Snap.....................................................................................................................................................................................................26
4.4 Schedule Configuration.................................................................................................................................................26
4.4.1 Schedule...............................................................................................................................................................................................26
4.4.2 Motion...................................................................................................................................................................................................27
4.4.3 Sensor..................................................................................................................................................................................................27
4.5 Alarm Configuration.......................................................................................................................................................28
4.5.1 Sensor..................................................................................................................................................................................................28
4.5.2 Motion...................................................................................................................................................................................................29
4.5.3 Video Loss............................................................................................................................................................................................31
4.5.4 OtherAlarm...........................................................................................................................................................................................31
4.5.5 Alarm Out..............................................................................................................................................................................................31
4.6 Network Configuration...................................................................................................................................................32
4.6.1 Network ................................................................................................................................................................................................32
4.6.2 Sub-stream...........................................................................................................................................................................................33
4.6.3 Email ....................................................................................................................................................................................................34
4.6.4 Server...................................................................................................................................................................................................34
4.6.5 Other Settings.......................................................................................................................................................................................35
Page 4 of 109

DVR User Manual
4.7 User Management Configuration...................................................................................................................................37
4.8 P.T.Z Configuration........................................................................................................................................................39
4.9 Advanced.......................................................................................................................................................................42
4.9.1 Reset....................................................................................................................................................................................................42
4.9.2 Import/Export ........................................................................................................................................................................................42
4.9.3 Block/Allow list......................................................................................................................................................................................42
5Search, Playback & Backup....................................................................................................................43
5.1 Time Search..................................................................................................................................................................43
5.2 Event Search.................................................................................................................................................................44
5.3 File Management...........................................................................................................................................................45
5.4 Search by Image...........................................................................................................................................................46
5.5 Backup ..........................................................................................................................................................................47
6Manage DVR .............................................................................................................................................48
6.1 Check System Information ............................................................................................................................................48
6.1.1 System Information...............................................................................................................................................................................48
6.1.2 Event Information..................................................................................................................................................................................48
6.1.3 Log Information.....................................................................................................................................................................................48
6.1.4 Network Information..............................................................................................................................................................................48
6.1.5 Online Information.................................................................................................................................................................................48
6.1.6 Record Information................................................................................................................................................................................49
6.2 Manual Alarm ................................................................................................................................................................49
6.3 Disk Management .........................................................................................................................................................49
6.4 Upgrade.........................................................................................................................................................................50
6.5 Logoff ............................................................................................................................................................................50
7Remote Surveillance................................................................................................................................51
7.1 IE Remote Surveillance.................................................................................................................................................51
7.1.1 On LAN.................................................................................................................................................................................................51
Page 5 of 109

DVR User Manual
7.1.2 On WAN................................................................................................................................................................................................51
7.2 Remote Surveillance through Apple PC........................................................................................................................53
7.2.1 On LAN.................................................................................................................................................................................................54
7.2.2 On WAN................................................................................................................................................................................................56
7.3 Remote Preview............................................................................................................................................................57
7.4 Remote Playback & Backup..........................................................................................................................................60
7.4.1 Remote Playback..................................................................................................................................................................................60
7.4.2 Remote Backup ....................................................................................................................................................................................65
7.5 Remote System Configuration.......................................................................................................................................66
7.6 Tools .............................................................................................................................................................................67
7.7 Remote Information.......................................................................................................................................................67
8Mobile Surveillance..................................................................................................................................69
8.1 By Phones with Windows mobile OS ............................................................................................................................69
8.2 By Phones with Symbian OS.........................................................................................................................................70
8.3 By phones with Iphone OS............................................................................................................................................72
8.4 By phones with Android OS...........................................................................................................................................80
8.5 By Phones with Blackberry OS......................................................................................................................................85
Appendix A FAQ .........................................................................................................................................91
Appendix B Calculate Recording Capacity .............................................................................................97
Appendix C Compatible Devices..............................................................................................................98
Appendix D 4-CH Specifications.............................................................................................................100
Appendix D 8-CH Specifications.............................................................................................................101
Appendix D 16-CH Specifications ..........................................................................................................102
Page 6 of 109

DVR User Manual
1
1 Introduction
1.1 DVR Introduction
This model DVR (Digital Video Recorder) is designed especially for CCTV system. It adopts high performance video
processing chips and embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard
H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote
control, mobile view(by phones), etc., which ensure its powerful functions and high stability. Due to these distinctive
characteristics, it is widely used in banks, telecommunication, transportation, factories, warehouse, and irrigation and so on.
1.2 Main Features
COMPRESSION FORMAT
Standard H.264 compression with low bit rate and better image quality
LIVE SURVEILLANCE
Support HDMI/ VGA/BNC output
Support channel security by hiding live display
Display the local record state and basic information
Support USB to make full control
RECORD MEDIA
Support two SATAHDD to record for a longer time without any limitation
BACKUP
Support USB 2.0 devices to backup
Support built-in SATADVD writer to backup
Support saving recorded files withAVI standard format to a remote computer through internet
Page 7 of 109

DVR User Manual
2
RECORD & PLAYBACK
Record modes: Manual, Schedule, Motion detection and Sensor alarm recording
Support recycle after HDD full
Resolution, frame rate and picture quality are adjustable
Support 4/8/16-ch WD1 real time
4 audio channels available
Two record search mode: time search and event search
Support 4/8/16 screen playback simultaneously
Support deleting and locking the recorded files one by one
Support remote playback in Network Client through LAN or internet
ALARM
1 channel alarm output and 4/8/16 channel alarm inputs available
Support schedule for motion detection and sensor alarm
Support pre-recording and post recording
Support linked channels recording once motion or alarm triggered on certain channel
Support linked PTZ preset ，auto cruise and track of the corresponding channel
PTZ CONTROL
Support various PTZ protocols
Support 128 PTZ presets and 8 auto cruise tracks
Support remote PTZ control through internet
SECURITY
Customize user right: log search, system setup, two way audio, file management, disk management, remote login, live
view, manual record, playback, PTZ control and remote live view
Support 1 administrator and 63 users.
Support event log recording and checking, events unlimited
Page 8 of 109

DVR User Manual
3
NETWORK
Support TCP/IP, DHCP, PPPoE, DDNS protocol
Support IE browser to do remote view
Support setup client connection amount
Support dual stream. Network stream is adjustable independently to fit the network bandwidth and environment.
Support picture snap and color adjustment in remote live
Support remote time and event search, and channel playback with picture snap
Support remote PTZ control with preset and auto cruise
Support remote full system configuration, changing all the DVR parameters remotely
Support mobile surveillance by smart phones , symbian, WinCE, Iphone or Gphone, 3G network available
Support CMS to manage multi devices on internet
Page 9 of 109

DVR User Manual
4
2 Hardware Installation
Notice: Check the unit and the accessories after getting the DVR.
Please don‟t power up the unit till the physical installation is complete.
2.1 Install Hard Drive &DVD Writer
2.1.1 Install Hard Drive
Notice: 1. This series supports two SATA hard drives. Please use the hard drive the manufacturers recommend specially for
security and safe field.
2. Please calculate HDD capacity according to the recording setting. Please refer to “Appendix B Calculate Recording
Capacity”.
Step1: Unscrew and Open the top cover.
Step2: Connect the power and data cables. Place the HDD onto the bottom case as Fig2.1.
Step3: Screw the HDD as Fig2.2
Note: For the convenience to install, please connect the power and data cables firstly, and then screw to fix.
Fig 2.1 Connect HDD Fig 2.2 Screw HDD
Page 10 of 109

DVR User Manual
5
2.1.2 Install DVD Writer
Notice: 1. The writers must be the compatible devices we recommend. Please refer to “Appendix C Compatible Devices”
2. This device is only for backup.
Step1: Unscrew and Open the top cover.
Step2: Connect the power and data cables. Place the DVD writer onto the bottom case as Fig2.3.
Step3: Screw the DVD writer as Fig2.4
Fig 2.3 Connect the DVD Writer Fig 2.4 Screw the Writer
2.2 Front Panel Descriptions
Notice: The front panel descriptions are only for reference; please make the object as the standard.
Item
Type
Name
Description
1
Work state
indicator
Power
Power Indicator, when connected, the light is blue.
HDD
The light turns blue when reading/writing HDD.
Net
The light turns blue when it is able to access the network.
Backup
The light turns blue when backing up files and data.
Play
The light turns blue when playing video.
REC
The light turns blue when recording
Page 11 of 109

DVR User Manual
6
Item
Type
Name
Description
2
Compound
button
MENU/+
1. Enter menu in live 2. Increase the value in setup
BACKUP/-
1. Decrease the value in setup 2. Enter backup mode in live
RECORD/FOCUS
1. Record manually 2. FOCUS function enables at PTZ mode.
REW/SPEED
1. Rewind key 2. SPEED function enables at PTZ mode
SEARCH/ZOOM
1. Enter search mode 2.ZOOM function enables at PTZ mode.
PLAY /IRIS
1. Enter play interface 2. IRIS function enables at PTZ mode
FF/ P.T.Z.
1. Fast forward 2. Enter PTZ mode in live
STOP/ESC
1. Quit play mode 2. Exit the current interface or status
3
Digital button
1-9
Input number 1-9 or choose camera
0/10+
Input number0, 10 and the above number together with other
digital keys
4
Input button
Direction button
Change direction to select items
Multi-screen
Change screen display mode like1/4/9/16 channel
Enter button
Confirm selection
5
IR receiver
IR
For remote controller
6
USB
USB port
To connect external USB devices like USB flash, USB HDD for
backup or update firmware; or connect to USB mouse
2.3 Rear Panel Instructions
Page 12 of 109

DVR User Manual
7
Fig 2.5 Rear Panel for 4-ch
Item
Name
Description
1
Audio in
4-ch audio inputs
2
DC 12V
Power input
3
Alarm out
1-ch relay output. Connect to external alarm.
4
GND
Grounding
5
Alarm in
Connect to external sensor1-4
6
Audio out
Audio output, connect to the sound box
7
CVBS port
CVBS video signal output
8
Spot
Connect to monitor as an AUX output channel by channel. Video would be displayed
without OSD.
9
RS485
Connect to keyboard or speed dome
10
Video in
Video input channels from 1-4
11
HDMI port
Connect to high-definition display device
12
USB port
To connect external USB devices like USB flash, USB HDD for backup or update
firmware; or connect to USB mouse
13
LAN
Network port
14
VGA port
VGA output, connect to monitor
15
Fan
For cooling the device
Page 13 of 109

DVR User Manual
8
Fig 2.6 Rear Panel for 8-ch
Item
Name
Description
1
Audio in
4-ch audio inputs
2
DC 12V
Power input
3
Alarm out
1-ch relay output. Connect to external alarm.
4
GND
Grounding
5
Alarm in
Connect to external sensor1-8
6
Audio out
Audio output, connect to the sound box
7
CVBS port
CVBS video signal output
8
Spot
Connect to monitor as an AUX output channel by channel. Video would be displayed
without OSD.
9
RS485
Connect to keyboard or speed dome
10
Video in
Video input channels from 1-8
11
HDMI port
Connect to high-definition display device
12
USB port
To connect external USB devices like USB flash, USB HDD for backup or update
firmware; or connect to USB mouse
13
LAN
Network port
14
VGA port
VGA output, connect to monitor
15
Fan
For cooling the device
Page 14 of 109

DVR User Manual
9
Fig 2.7 Rear Panel for 16-ch
Item
Name
Description
1
Audio in
4-ch audio inputs
2
DC 12V
Power input
3
Alarm out
1-ch relay output. Connect to external alarm.
4
GND
Grounding
5
Alarm in
Connect to external sensor1-16
6
Audio out
Audio output, connect to the sound box
7
CVBS port
CVBS video signal output
8
Spot
Connect to monitor as an AUX output channel by channel. Video would be displayed
without OSD.
9
RS485
Connect to keyboard or speed dome
10
Video in
Video input channels from 1-16
11
HDMI port
Connect to high-definition display device
12
USB port
To connect external USB devices like USB flash, USB HDD for backup or update
firmware; or connect to USB mouse
13
LAN
Network port
14
VGA port
VGA output, connect to monitor
15
Fan
For cooling the device
Page 15 of 109

DVR User Manual
10
2.4 Remote Controller
It uses two AAA size batteries.
Open the battery cover of the Remote Controller.
Place batteries. Please take care of the polarity (+ and -).
Replace the battery cover.
Fig 2.8 Remote Controller
Button
Function
Power Button
Switch off—to stop DVR. Use it before turning off the power
Record Button
To record manually
-/-- /0-9 Digital Button
Input number or choose camera
Fn1 Button
Unavailable temporarily
Multi Button
To choose multi screen display mode
Next Button
To switch the live image
SEQ
To enter into auto dwell mode
Audio
To enable audio output in live mode
Switch
To switch the output between BNC and VGA
Direction button
To move cursor in setup or pan/title PTZ
Enter Button
To confirm the choice or setup
Menu Button
To enter into menu
Page 16 of 109

DVR User Manual
11
Exit Button
To exit the current interface
Focus/IRIS/Zoom/PTZ
To control PTZ camera. Move camera/zoom/IRIS/Focus
Preset Button
To enter into preset setting in PTZ mode
Cruise Button
To enter into cruise setting in PTZ mode
Track Button
To enter into track setting in PTZ mode
Wiper Button
To enable wiper function in PTZ mode
Light Button
To enable light function in PTZ mode
Clear Button
To return to the previous interface
Fn2 Button
Unavailable temporarily
Info Button
Get information about DVR like firmware version, HDD information
To control playback. Play/Pause/Stop/Previous Section/Next
Section/Rewind/Fast Forward
Snap Button
To take snapshots manually
Search Button
To enter into search mode
Cut Button
To set the start/end time for backup in playback mode
Backup Button
To enter into backup mode
Zoom Button
To zoom in the images
PIP Button
To enter into picture in picture setting mode
Note: You shall press P.T.Z button to enter into PTZ setting mode, choose a channel and press P.T.Z button again to hide the
P.T.Z control panel. Then you can press preset, cruise, track, wiper or light button to enable the relevant function.
Note: Key points to check in case the remote doesn‟t work.
1. Check batteries polarity.
2. Check the remaining charge in the batteries.
3. Check IR controller sensor for any masking.
4. Check the ID of the remote with respect to the DVR.
Page 17 of 109

DVR User Manual
12
If it still doesn't work, please try using a good known remote, or contact your dealer.
The interface of remote controller is shown in Fig 2.8 Remote Controller.
Operation processes with remote controller to control multi-DVR
The default device ID of the DVR is 0. It‟s not necessary to reset the device ID when a remote is to be used to control a single
DVR. However when controlling multiple DVRs with multiple remote controllers, you would need to configure the device ID,
please refer to below steps:
Activate remote controller to control the DVR: Turn the IR sensor of the remote controller towards the IR receiver on the front
panel, press the number key 8 twice on the remote, then input device ID of the DVR to be controlled (Range from: 0-65535;
the default device ID is 0) and press ENTER to confirm.
You can check the device ID of a DVR from System SetupBasicDevice ID. You can also set multiple DVRs with the same
device ID however this can cause interference if the DVRs are kept close to each other.
2.5 Control with Mouse
2.5.1 Connect Mouse
It supports USB mouse through the ports on the rear panel.
Notice: If mouse is not detected or doesn't work, check below steps:
1. Make sure the mouse is plugged in the USB mouse port not the USB port on the front panel.
2. Try with a good know mouse.
2.5.2 Use Mouse
During live:
Double-click on any camera window for the full screen mode. Double-click again to return to the previous screen mode.
Right click to reveal the control menu on the screen. Right click to hide the control menu.
Page 18 of 109

DVR User Manual
13
In Configuration:
Click to enter a particular option. Right click to cancel the option or to return to the previous menu.
In order to input a value in a particular screen, move cursor to the input box and click. An input window will appear as Fig2.9. It
supports digits, alphabets and symbols as inputs. Click Shift button to input Capital letters and symbols; click Shift button again
to return.
You can change some values using the mouse wheel, such as time. Move
cursor onto the value and roll the wheel when the value blinks.
It supports mouse drag. For e.g. setting up motion detection area, click
customized, hold down the left button and drag to set motion detection area.
Setting up Schedule: hold left button and drag to set schedule time.
Fig 2.9 Digital Numbers and Letters Input Window
In Playback:
Click to choose the options. Right click to return to live mode.
In Backup:
Click to choose the options. Right click to return to previous picture.
In PTZ Control:
Click left button to choose the buttons to control the PTZ. Click right button to return to live.
Note: Mouse is the default tool for all operations unless an exception, as indicated.
Page 19 of 109

DVR User Manual
14
3 Basic Function Instruction
3.1 Startup & Shutdown
Please make sure all the connections are done properly before you power on the unit. Proper startup and shutdown are crucial
to expanding the life of your DVR.
3.1.1 Startup
Step1: Connect with the source power.
Step2: The device will boot and the power LED would turn blue.
Step3 AWIZZARD window will pop up and show some information about time zone，time setup，network configuration, record
configuration and disk management. User can setup here and refer to the concrete setup steps from the corresponding
chapters. If users don‟t want to setup Wizard, please click Exit button to exit.
Note: This DVR can only display options on either VGA/HDMI monitor or BNC monitor at a given point of time, if there is live
image display without menu options then please check if there is display on other device/monitor, or long press Stop/ESC key
to wait for login dialog box to appear. Long press Stop/ESC key can switch the output between BNC and VGA/HDMI.
3.1.2 Shutdown
You can shut down the device by using IR remote controller and mouse.
By IR remote controller:
Step1: Press Power button to display the shutdown window. The unit will shut down by clicking “OK” button.
Step2: Disconnect the power.
By mouse:
Step1: Enter into Menu and select “Shut Down” icon. This will take you to a shutdown window.
Step2: Click OK. Then the unit will power off after a while.
Page 20 of 109
