Onix N4120 User manual

N Series
(N4120 , N8240 , N1648)
User Manual
Network Standalone DVR
Standalone DVR Manual v2.1

1
Contents
CONTENTS 1
NOTICE BEFORE USING PRODUCT 7
SAFETY WARNING & PRECAUTION 8
PRODUCT DESCRIPTION 오류! 책갈피가 정의되어 있지 않
습니다.
PRODUCT SPECIFICATION 12
Package Contents 14
Front Panel Layout 15
LED Status Lights 15
USB Port 15
CD/DVD-RW (Optional Type) 15
Front Panel Buttons 15
Rear Panel 16
Remote Control Unit Layout 17
PRODUCT INSTALLATION 18
CONNECTION OUTLINE (4CH CASE) 18
VIDEO CONNECTION 19
Input 19
Output 19
AUDIO CONNECTION 20
Input 20
Output 20

2
ALARM/SENSOR/PTZ CONNECTION 21
Alarm 21
Sensor 21
PTZ 21
NETWORK CONNECTION 22
HARD DISK DRIVE 22
POWER CONNECTION 22
SYSTEM INSTALLATION COMPLETE 22
STANDALONE DVR SET MANUAL 23
STARTING THE SYSTEM 23
SURVEILLANCE MODE 23
Main Screen 23
Video Screen 24
Control Panel 25
Split Screen Modes 27
PLAYBACK MODE 33
SEARCH MODE 35
Quick Search Mode 36
Search 37
MENU MODE 44
Initial Menu 45
SEARCH MENU 46
Recording Configuration 47
PTZ Configuration 54
System Configuration 55
System Information 69
Backup 71
Log Viewer 72

3
STANDALONE CLIENT 74
CONFIGURATION 75
GUI Main Feature 75
Display Configuration 76
Storage Space Setup 78
Creating Recording Repositories 80
Device List Configuration 82
Device Configuration 84
MD (Motion Detection) Configuration 85
Bookmark Configuration 86
Network Event Configuration 87
Recording Configuration by Events 88
Recording Duration Configuration by Events 89
Recording / Schedule Configuration 91
PTZ(Pan/Tilt/Zoom) Configuration 92
Preset Configuration 93
Network Configuration 94
System Configuration (General Tab) 95
System Configuration (Account Tab) 96
System Configuration (Version Tab) 97
STANDALONE CLIENT FUNCTION MANUAL 98
MAIN GUI FEATURE 99
Information Panel 100
Menu Display Bar 101
Server/ Device List 102
Bookmark 103
Control Panel 104
PTZ Control Panel 105

4
2-Way Audio Control Panel 107
I/O control Panel 108
Playback Control Panel 109
Event List Panel 111
Display 112
Floating Bar 113
SURVEILLANCE SCENARIO 114
Login Process 114
Assigning & Moving Server/Device List 116
Disconnecting / Removing Assigned Channels 118
Connection Fail of the registered video channels 120
Controlling selected surveillance video channels 121
Enhanced Function for Server List/Surveillance Area 122
OSC(On Screen Command) Function 123
E-MAP CONFIGURATION 124
EVENT LIST/ REALTIME EVENT VIEW 125
Event List/ Search Event View 126
RECORD 127
Continuous Recording (On / Off) 127
MD(Motion Detection) Recording 128
Emergency Recording Command Button 129
PLAYBACK 130
Playback Mode 130
Search Filter Button 130
REMOTE SEARCH 132
To execute Remote Search 132
To end Remote Search 132
BACKUP 133
Backup Manager 134
Backup Viewer 139

5
WEBCLIENT OPERATION ENVIRONMENT & INSTALLATION
149
MINIMAL SPEC. OF PC REQUIRED TO OPERATE WEBCLIENT 149
CONNECTION & INSTALLATION OF WEBCLIENT 149
Web Browser-Based Connection of WebClient 149
Install ActiveX – 1st Stage 150
Install ActiveX – 2nd Stage 150
3rd Stage 151
4th Stage (Win Vista, Win7) 152
HOW TO USE WEBCLIENT 153
LIVE MODE (LIVE SURVEILLANCE) 153
Selection of Channel Split Mode 154
PTZ Control 154
Audio Control 155
Add-in Functions 155
SEARCH 155
Selection of Replay Time 156
Replay Control 157
SETUP 157
Streaming Setup 157
Recording Setup 158
MOBILE DVR VIEWER MANUAL 159
INSTALLATION BY USING ITUNES 160
DIRECT INSTALLATION FROM IPHONE 162
UNINSTALLATION 163
CONSTITUTION OF MAIN SCREEN 164

6
ADD SERVER 165
SETUP CHANNELS 166
DELETE CHANNEL 167
DELETE SERVER LIST 168
CONSTITUTION OF LIVE SCREEN 169
PROCEDURE OF PERFORMANCE OF RECORDED VIDEO 170

7
Product Description
Notice before Using Product
Please beware of the following precautions before installing the DVR.
① Please avoid placing the system near moisture or dust
② Please avoid placing the system near direct sunlight or heat
source
③ Please place the system on a solid surface without any
vibrations and away from magnetic appliances
④ Please place the system in a room temperature environment
(Recommended room temperature of 5℃ ~ 40℃)
⑤ Please make sure no foreign metallic/magnetic objects enter
through the ventilation openings of the unit
⑥ Please place the system in a well ventilated area
⑦ Some Radio or TV signals may interfere with system, please
place the system away at least 3 feet from home electronic
appliances such as Radio/Stereo/Television/Projectors
⑧ Never place any heavy objects on top of the unit
⑨ Never disassemble the product, electronic shock may result
in serious injury or death
Notice before Using Product

8
Product Description
Safety Warning & Precaution
The following warnings and cautions are for your own safety and to
prevent damage of the DVR system and/or other properties.
Warning (Review these warnings or you may be seriously
injured or killed)
Turn off the system before installing
the system. Do not plug in several
electric devices to the same outlet.
[This may cause heating, fire, or
electric shock]
Do not place any liquid container
on the system, such as water,
coffee, or beverage
[If liquid is poured onto the system,
it can cause system breakdown or
cause fire]
Prevent power cable from being
severely bent or pressed by a
heavy object.[This may cause fire]
Clean the dust around the system
on regular basis. When cleaning
the system, always use dry cloth.
[This may cause system
breakdown or electric shock]
Install the system in a place with
sufficient air ventilation.
[Keep at least 15cm distance
between the back of the system
and a wall]
Safety Warning & Precaution

9
Product Description
Avoid any place with moisture, dust,
or soot.
[This can cause fire or electric shock]
When pulling the power cable from
the plug, do so gently. Do not touch
the plug with wet hands and avoid
using the plug if the holes on the
outlet are too loose.
[This may cause fire or electric shock]
Do not attempt to disassemble,
repair, or modify the system on
your own. It is extremely
dangerous due to high voltage
running through the system.
[This may cause fire, electric
shock, or serious injuries]
Install the system on a plain
surface with sufficient air
ventilation. Do not place the
system on elevated surface.
[This may cause system break
down or serious Injuries]
Install the system in a cool place
without direct sunlight and always
maintain room temperature.
[This may cause fire]
Avoid using aged old power
cables or long extensions.
[This may cause fire]

10
Product Description
Caution (Review these cautions or you may be seriously
injured or cause property damage)
Do not install the system in a place
with high magnetic, electric wave, or
wireless devices such as radio or TV
[Install the system in a place
without magnetic objects, electric
frequencies, or vibration]
Install the system in a place
with appropriate moisture and
temperature level
[Avoid installing the system with
high (over 40℃) or low (under
5℃) temperature]
Prevent any substances from
being inserted into the system
[This may cause system
breakdown]
Do not place any heavy object
on the system
[This may cause system
breakdown]
The system can be damaged
from a strong impact or vibration
[The system may not operate
properly]
If there is strange sound or smell, un
plug the power cable immediately
and contact the service center.
[This may cause fire or electric shock]

11
Product Description
Product Description
Product Overview
“Standalone DVRs" are Standalone DVRs that support H/W
compression, Realtime Display, and Two-way Audio function. Their
stability was maximized by adopting Embedded Linux as the
Operating System. By supporting strong Remote Surveillance and
Remote Playback through network, they can be the optimized
security solutions for IP Surveillance Generation.
Product Description

12
Product Description
Product Specification
Specification N4120 N8240 N1648
Video Input 4 8 16
Video H.264
CODEC Audio ADPCM
Video Output [BNC x 1, RCA x 1] CVBS, [BNC] SPOT x 1,
VGA x 1
Video Signal NTSC/ PAL
Operating System Embedded Linux
Pentaplex Function Live Display, Recording, Playback,
Backup & Remote access
Interface Control Unit’s Frontal Buttons, Remote Controller,
Mouse
Audio In(RCA) 4 4 4
Audio Out 1 Port RCA, LINE Level (Functional Live
Audio)
Sensor Input
(Type - NC/NO) 4 4 4
Alarm Output
(Type - NC/NO) 1 1 1
ODD CD-RW, DVD-RW(SATA) x 1ea
(Optional)
Storage
MaxHDD SATA x2ea
(w/o ODD)
SATA x2ea
(w/o ODD)
SATA x2ea
(w/o ODD)
CIF 120/100 240/200 480/400
2CIF 120/100 240/200 240/200
Video
Recording
(NTSC/PAL) D1 120/100 120/100 120/100
Motion Detection
Can be selected / 1 Channel has
selection of 44x30 blocks with H/W based
motion detection
Recording Modes Manual, Motion Detection, Schedule,
Sensor

13
Product Description
Function Watermark, Pre-recording, Dual Streaming, 2-way
Front LED Record, Alarm, Network
Backup Media DVD-RW, USB Memory Stick
Firmware Upgrade DVD-RW, USB Memory Stick, Network
Search Modes Calendar, Event, Quick, Specific Time
Watch Dog Hardware Watchdog Support
PTZ Connection 1 Port Terminal Block, RS-485
PTZ Protocol Pelco-D, Samsung SCC-641 and approx.
90 protocols support
Network 1 Port Ethernet 10/100 Base-T
Network Protocol TCP/IP, HTTP, FTP, DHCP, PPPoE, DDNS,
SMTP
DDNS www.neodhs.com/ www.dyndns.com
DVR Recovery Mode System Auto Restart, Network Auto
Reconnect
CMS (Optional) Max. 128CH CMS/ NDVR Support
Communication Port RS232, RS485, Ethernet, 2USB(Mouse/
Backup)
Storage Temp. 20 ~ 60℃ / 20~95% RH
Operation Temp. 5 ~ 40℃ / 20~80% RH
Power 110-220V / 60-50Hz
Dimension 360mm(W) x 236mm(D) x 60mm(H)
Weight 2Kg (w/o storage)
Remote Software StaNet™ (NetClient), WebClient Support
EMC Certificate CE, FCC, KCC

14
Product Description
Package Contents
DVR System
Adapter
Remote
Control Unit
S/W
Installation
CD
Power Cable
(Option)
User Manual
(Option)
Batteries
(AAA)
(Option)
Mouse
(Option)

15
Product Description
Front Panel Layout
LED Status Lights
REC LED on when recording
EVENT LED on when events occur
NET LED on when network is connected
USB Port
USB Storage can be connected for backup and F/W upgrade
purposes.
CD/DVD-RW (Optional Type)
Blank DVD/CD (depending on the optical drive type) can be
inserted to back up data or to upgrade the firmware.
Front Panel Buttons
SEARCH Launch the search function
MENU Launch the system menu
REC Start Recording
Back Back from the current action
▲(Up) Move up within split video channels or menu items
▼(Down) Move down within split video channels or menu items
◀(Left) Move left within split video channels or menu items
▶(Right) Move right within split video channels or menu items
Enter Select a channel or a menu item

16
Product Description
Rear Panel
① Video In [BNC]Camera Input
② CVBS Out [BNC]Main Composite Video Out
③ SPOT Out [BNC]SPOT Out
④ CVBS Out [RCA]Main Composite Video Out
⑤ Audio In [RCA]LINE(MIC) Audio In
⑥ Audio Out [RCA]Audio Out
⑦ VGA Out VGA Output
⑧ RS-232 RS-232 Serial COM Port
⑨ Network Port [RJ-45]Ethernet Port
⑩ Sensor In Sensor Connection
(Non Powered Type)
⑪ Alarm Out Alarm Connection
(Non Powered Type)
⑫ RS-485 RS485 for PTZ Control
⑬ Power In Adapter Power (DC12V)

17
Product Description
Remote Control Unit Layout
POWER Power ON/OFF
FREEZE
Pauses live view
screen for quick
scan/review of event
REC Start Recording
MENU Launches the menu
BACK Back from the current
action
Navigate through
menus.
Select the item.
SEARCH Launches the search
STOP Stop playback
PTZ Launches the PTZ
setup
REW Rewind playback
PLAY/PAUSE Play/Pause playback
FF Fast forward playback

18
Product Description
Product installation
Connection Outline (4CH case)
Product installation
