Onkyo HTP-360 User manual

HTP-360
SERVICE MANUAL
SERVICE MANUAL

HTP-360
EXPLODED VIEWS-1
SKW-360 : PASSIVE SUBWOOFER
HTP-360
SP07a-d
----- SP01a-d (Subwoofer ass’y) -----
SP03
SP04
x 8 pcs.
SP02
x 4 pcs.
SP04
x 8 pcs.
SP05
SP06

HTP-360
EXPLODED VIEWS-2
SKF-360F / SKC-360C / SKM-360S
HTP-360
SP10a-d SP10a-d
SP13a-d
SP15a-d SP15a-d
"SKF-360F (L)" "SKF-360F (R)"
"SKC-360C"
TERMINAL :
White / Black
TERMINAL :
Red / Black
TERMINAL :
Green / Black
<Notes>
USA and Canadian models : inch nut.
Other models : mm nut.
<Note>
Cannot remove the speaker grill.
"SKM-360S (R)""SKM-360S (L)"
NOT MAGNETICALLY SHIELDED NOT MAGNETICALLY SHIELDED
TERMINAL :
Blue / Black
TERMINAL :
Gray / Black

1/2 PAGE
HTP-360
EXPLODED VIEWS PARTS LIS
T
<Notes>
(B) : Black model
(S) : Silver model
<MDD> : USA model
<MDC> : Canadian model
<MWO> : Asian model
<MWF> : Taiwanese model
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED SKW-360 : PASSIVE SUBWOOFER
EXPLODED SP01a SUBWOOFER ASS'Y SKW-360 BLACK MD 1 ASF7131B-BM20 (B)<MDD, MDC>
EXPLODED SP01b SUBWOOFER ASS'Y SKW-360 BLACK MO 1 ASF7131B-BM20 (B)<MWO>
EXPLODED SP01c SUBWOOFER ASS'Y SKW-360 SILVER MC 1 ASF71310-BM20 (S)<MDC>
EXPLODED SP01d SUBWOOFER ASS'Y SKW-360 SILVER MO 1 ASF71310-BMWO (S)<MWO, MWF>
EXPLODED SP02 PLASTIC FOOT BLACK 4 BRF70003-1011
EXPLODED SP03 SPEAKER UNIT 20cm(8") 6ohm 50W RoHS 1 W20178H
EXPLODED SP04 WOOD SCREW 4 x 25 BIND HEAD (SP UNIT/FOOT) 16 NSS72501-0801
EXPLODED SP05 WIRE ASS'Y --- 1 VWW70002-2200
EXPLODED SP06 CONNECTOR TERMINAL : BLACK/PURPLE 1 CJC70001-0000
EXPLODED SP07a BACK LABEL BLACK / WHITE 1 YLL70002-0000 (B)<MDD, MDC>
EXPLODED SP07b BACK LABEL GRAY / WHITE 1 YLL70018-0000 (B)<MWO>
EXPLODED SP07c BACK LABEL BLACK / WHITE 1 YLL70003-0000 (S)<MDC>
EXPLODED SP07d BACK LABEL GRAY / WHITE 1 YLL70004-0000 (S)<MWO, MWF>
EXPLODED SKF-360F : FRONT SPEAKERS (L)/(R)
EXPLODED SP10a COMPLETE UNIT "SKF-360F (B) L & R" / (Inch nut) 1 ANM5TP360-BM01 (B)<MDD, MDC>
EXPLODED SP10b COMPLETE UNIT "SKF-360F (B) L & R" / (mm nut) 1 ANM5TP360-BM06 (B)<MWO>
EXPLODED SP10c COMPLETE UNIT "SKF-360F (S) L & R" / (Inch nut) 1 ANM5TP360-BM02 (S)<MDC>
EXPLODED SP10d COMPLETE UNIT "SKF-360F (S) L & R" / (mm nut) 1 ANM5TP360-BM03 (S)<MWO, MWF>
EXPLODED SKC-360C : CENTER SPEAKER
EXPLODED SP13a COMPLETE UNIT "SKC-360C (B)" / (Inch nut) 1 ANC5TP360-BM01 (B)<MDD, MDC>
EXPLODED SP13b COMPLETE UNIT "SKC-360C (B)" / (mm nut) (WFx2) 1 ANC5TP360-BM06 (B)<MWO>
EXPLODED SP13c COMPLETE UNIT "SKC-360C (S)" / (Inch nut) 1 ANC5TP360-BM02 (S)<MDC>
EXPLODED SP13d COMPLETE UNIT "SKC-360C (S)" / (mm nut) (WFx2) 1 ANC5TP360-BM03 (S)<MWO, MWF>
EXPLODED SKM-360S : SURROUND SPEAKERS (L)/(R)
EXPLODED SP15a COMPLETE UNIT "SKM-360S (B) L & R" / (Inch nut) 1 ANU5TP360-BM01 (B)<MDD, MDC>

2/2 PAGE
EXPLODED SP15b COMPLETE UNIT "SKM-360S (B) L & R" / (mm nut) 1 ANU5TP360-BM06 (B)<MWO>
EXPLODED SP15c COMPLETE UNIT "SKM-360S (S) L & R" / (Inch nut) 1 ANU5TP360-BM02 (S)<MDC>
EXPLODED SP15d COMPLETE UNIT "SKM-360S (S) L & R" / (mm nut) 1 ANU5TP360-BM03 (S)<MWO, MWF>
EXPLODED SATELLITE PACKAGE
EXPLODED --- SATELLITE PACKAGE (B) --- 1 ANB5TP360-BM01 (B)<MDD, MDC>
EXPLODED --- SATELLITE PACKAGE (B) --- 1 ANB5TP360-BM06 (B)<MWO>
EXPLODED --- SATELLITE PACKAGE (S) --- 1 ANB5TP360-BM02 (S)<MDC>
EXPLODED --- SATELLITE PACKAGE (S) --- 1 ANB5TP360-BM03 (S)<MWO, MWF>
