Onkyo HTP-330 User manual

HTP-330
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOME THEATER SPEAKER PACKAGE
Silver model
MODEL HTP-330(S)
Ref. No. 3888
042005
Front Speakers (L / R)
"SKF-330F"
Center Speaker
"SKC-330C"
Surround Speakers (L / R)
"SKM-330S"
Passive Subwoofer
"SKW-330"
S : ColorS MD MD : USA model
S : ColorS MC MC : Canadian model
S : ColorS MT MT : Asian model
S : ColorS MP MP : European model
Cannot remove the speaker grill.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

HTP-330
SPECIFICATIONS
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Bass-reflex type
8 ohm
100 W
84 dB/m/w
30 Hz - 150 Hz
0.91 cubic feet (26 L)
9-1/16" x 17-1/8" x 15-7/16"
(230 x 435 x 392 mm)
17.2 lbs. (7.8 kg)
8" (20 cm) Cone
Spring type color coded
Front Speaker (SKF-330F)
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
Other :
2 Way Bass-reflex
8 ohm
100 W
83 dB/W/m
80 Hz - 22 kHz
10 kHz
0.042 cubic feet (1.2 L)
5-13/16" x 7-15/16" x 4"
(148 x 202 x 101 mm)
2.0 lbs. (0.9 kg)
3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
1
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Magnetic shielding
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
Other :
2 Way Bass-reflex
8 ohm
100 W
86 dB/W/m
80 Hz - 22 kHz
10 kHz
0.081 cubic feet (2.3 L)
14-3/16" x 5" x 5-3/16"
(360 x 127 x 131 mm)
3.5 lbs. (1.6 kg)
3-1/8" (8 cm) Cone (Woofer) x 2
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
2
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Magnetic shielding
Surround Speaker (SKM-330S)
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
2 Way Bass-reflex
8 ohm
100 W
82 dB/W/m
80 Hz - 22 kHz
10 kHz
0.042 cubic feet (1.2 L)
5-13/16" x 7-15/16" x 4"
(148 x 202 x 101 mm)
1.5 lbs. (0.7 kg)
3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
1
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Specifications and appearance are subject to change
without prior notice.
Passive Subwoofer (SKW-330) Center Speaker (SKC-330C)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

HTP-330
HTP-330
EXPLODED VIEWS-1
SKW-330 : PASSIVE SUBWOOFER
SP06
x 8 pcs.
SP07
SP09a /
SP09b
SP08 SP04
SP01a /
SP01b
SP03
SP05
x 4 pcs.
SP02
x 4 pcs.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

HTP-330
HTP-330
EXPLODED VIEWS-2
SKF-330F / SKC-330C / SKM-330S
SP13a /
SP13b
SP10a /
SP10b
SP12a /
SP12b
SP17a /
SP17b
SP19a /
SP19b
SP16a /
SP16b
SP18a /
SP18b
SP14a /
SP14b
SP15a /
SP15b
SP11a /
SP11b
"SKF-330F (L)" "SKF-330F (R)" "SKC-330C"
"SKM-330S (R)""SKM-330S (L)"
TERMINAL :
White / Black
TERMINAL :
Red / Black
TERMINAL :
Green / Black
TERMINAL :
Blue / Black
TERMINAL :
Gray / Black
NOT MAGNETICALLY SHIELDED NOT MAGNETICALLY SHIELDED
<Notes>
USA and Canadian models : inch nut.
Other models : mm nut.
<Note>
Cannot remove the speaker grill.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

1/2 PAGE
HTP-330
EXPLODED VIEWS PARTS LIS
T
<Notes>
<MD> : USA model
<MC> : Canadian model
<MT> : Asian model
<MP> : European model
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) MARKS
EXPLODED SKW-330 : PASSIVE SUBWOOFER
EXPLODED SP01a CABINET ASS'Y SKW-330 1 ANK8W330S-BM10 <MD>
EXPLODED SP01a CABINET ASS'Y SKW-330 1 ANK8W330S-BM10 <MC>
EXPLODED SP01a CABINET ASS'Y SKW-330 1 ANK8W330S-BM10 <MT>
EXPLODED SP01b CABINET ASS'Y SKW-330 / E1 GRADE 1 ANK8W330S-BM70 <MP>
EXPLODED SP02 PLASTIC FOOT D87.5 x D37.5 x H50 HIPS, BLACK 4 BPE800007-00AA
EXPLODED SP03 STAND BOARD --- 1 ANF810037-1510
EXPLODED SP04 NAME PLATE SKW-330 / ONKYO NAME PLATE PVC 1 BPL800157-0001
EXPLODED SP05 WOOD SCREW D8 x D4 x L75 PAN HEAD (FOR FOOT) 4 NST8550514750
EXPLODED SP06 WOOD SCREW 4STT+20A (FOR SPEAKER) 8 837440204
EXPLODED SP07 WOOFER SPEAKER 20cm 8ohm 50W 1 W20178B
EXPLODED SP08 WIRE ASS'Y #22, L=260 1 VWT133441-0260
EXPLODED SP09a BACK LABEL BLACK / E2 GRADE 1 YLB810001-0054 <MD>
EXPLODED SP09a BACK LABEL BLACK / E2 GRADE 1 YLB810001-0054 <MC>
EXPLODED SP09a BACK LABEL BLACK / E2 GRADE 1 YLB810001-0054 <MT>
EXPLODED SP09b BACK LABEL GRAY / E1 GRADE 1 YLB810001-0063 <MP>
EXPLODED SKF-330F : FRONT SPEAKERS (L)
EXPLODED SP10a COMPLETE UNIT "SKF-330F (S) L" / (Inch nut) 1 ASL5M0330-BM02 <MD>
EXPLODED SP10a COMPLETE UNIT "SKF-330F (S) L" / (Inch nut) 1 ASL5M0330-BM02 <MC>
EXPLODED SP10b COMPLETE UNIT "SKF-330F (S) L" / (mm nut) 1 ASL5M0330-BM01 <MT>
EXPLODED SP10b COMPLETE UNIT "SKF-330F (S) L" / (mm nut) 1 ASL5M0330-BM01 <MP>
EXPLODED SP11a BACK LABEL (L) BLACK 1 YLB510186-0008 <MD>
EXPLODED SP11a BACK LABEL (L) BLACK 1 YLB510186-0008 <MC>
EXPLODED SP11b BACK LABEL (L) GRAY 1 YLB510186-0002 <MT>
EXPLODED SP11b BACK LABEL (L) GRAY 1 YLB510186-0002 <MP>
EXPLODED SKF-330F : FRONT SPEAKERS (R)
EXPLODED SP12a COMPLETE UNIT "SKF-330F (S) R" / (Inch nut) 1 ASL5M0330-BM02 <MD>
EXPLODED SP12a COMPLETE UNIT "SKF-330F (S) R" / (Inch nut) 1 ASL5M0330-BM02 <MC>
EXPLODED SP12b COMPLETE UNIT "SKF-330F (S) R" / (mm nut) 1 ASL5M0330-BM01 <MT>
EXPLODED SP12b COMPLETE UNIT "SKF-330F (S) R" / (mm nut) 1 ASL5M0330-BM01 <MP>
EXPLODED SP13a BACK LABEL (R) BLACK 1 YLB510186-0009 <MD>
EXPLODED SP13a BACK LABEL (R) BLACK 1 YLB510186-0009 <MC>
EXPLODED SP13b BACK LABEL (R) GRAY 1 YLB510186-0003 <MT>
EXPLODED SP13b BACK LABEL (R) GRAY 1 YLB510186-0003 <MP>
EXPLODED SKC-330C : CENTER SPEAKER
EXPLODED SP14a COMPLETE UNIT "SKC-330C (S)" / (Inch nut) 1 ASL5C0330-BM02 <MD>
EXPLODED SP14a COMPLETE UNIT "SKC-330C (S)" / (Inch nut) 1 ASL5C0330-BM02 <MC>
EXPLODED SP14b COMPLETE UNIT "SKC-330C (S)" / (mm nut) 1 ASL5C0330-BM01 <MT>
EXPLODED SP14b COMPLETE UNIT "SKC-330C (S)" / (mm nut) 1 ASL5C0330-BM01 <MP>
EXPLODED SP15a BACK LABEL BLACK 1 YLB510186-0007 <MD>
EXPLODED SP15a BACK LABEL BLACK 1 YLB510186-0007 <MC>
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2/2 PAGE
EXPLODED SP15b BACK LABEL GRAY 1 YLB510186-0001 <MT>
EXPLODED SP15b BACK LABEL GRAY 1 YLB510186-0001 <MP>
EXPLODED SKM-330S : SURROUND SPEAKERS (L)
EXPLODED SP16a COMPLETE UNIT "SKM-330S (S) L" / (Inch nut) 1 ASL5U0330-BM02 <MD>
EXPLODED SP16a COMPLETE UNIT "SKM-330S (S) L" / (Inch nut) 1 ASL5U0330-BM02 <MC>
EXPLODED SP16b COMPLETE UNIT "SKM-330S (S) L" / (mm nut) 1 ASL5U0330-BM01 <MT>
EXPLODED SP16b COMPLETE UNIT "SKM-330S (S) L" / (mm nut) 1 ASL5U0330-BM01 <MP>
EXPLODED SP17a BACK LABEL (L) BLACK 1 YLB510186-0011 <MD>
EXPLODED SP17a BACK LABEL (L) BLACK 1 YLB510186-0011 <MC>
EXPLODED SP17b BACK LABEL (L) GRAY 1 YLB510186-0005 <MT>
EXPLODED SP17b BACK LABEL (L) GRAY 1 YLB510186-0005 <MP>
EXPLODED SKM-330S : SURROUND SPEAKERS (R)
EXPLODED SP18a COMPLETE UNIT "SKM-330S (S) R" / (Inch nut) 1 ASL5U0330-BM02 <MD>
EXPLODED SP18a COMPLETE UNIT "SKM-330S (S) R" / (Inch nut) 1 ASL5U0330-BM02 <MC>
EXPLODED SP18b COMPLETE UNIT "SKM-330S (S) R" / (mm nut) 1 ASL5U0330-BM01 <MT>
EXPLODED SP18b COMPLETE UNIT "SKM-330S (S) R" / (mm nut) 1 ASL5U0330-BM01 <MP>
EXPLODED SP19a BACK LABEL (R) BLACK 1 YLB510186-0010 <MD>
EXPLODED SP19a BACK LABEL (R) BLACK 1 YLB510186-0010 <MC>
EXPLODED SP19b BACK LABEL (R) GRAY 1 YLB510186-0004 <MT>
EXPLODED SP19b BACK LABEL (R) GRAY 1 YLB510186-0004 <MP>
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

HTP-330
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: [phone] Fax: [phone]
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone] http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone] http://www.eu.onkyo.com/
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]
ONKYO CORPORATION
http://www.onkyo.com/
HOMEPAGE
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: [phone] Fax: [phone]
http://www.ch.onkyo.com/
