Onkyo HTP-350(B)/(S) User manual

HTP-350
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOME THEATER SPEAKER PACKAGE
Black and Silver models
MODEL HTP-350(B)/(S)
Ref. No. 4002
032007
Front Speakers (L / R)
"SKF-350F" Center Speaker
"SKC-350C"
Surround Speakers (L / R)
"SKM-350S"
Passive Subwoofer
"SKW-350"
Cannot remove the speaker grill.
B : ColorB MD MD : USA model
S : ColorS MC MC : Canadian model
S : ColorS MK MK : Korean model
S : ColorS MO MO : World wide model
S : ColorS MA MA : Australian model

HTP-350
HTP-350
EXPLODED VIEWS-1
SKW-350 : PASSIVE SUBWOOFER
SP09
SP01a /
SP01b
SP05
SP03
x 8 pcs.

HTP-350
EXPLODED VIEWS-2
SKF-350F / SKC-350C / SKM-350S
HTP-350
SP12a /
SP12b
SP10a /
SP10b /
SP10c
SP10a /
SP10b /
SP10c
SP16a /
SP16b
SP17a /
SP17b
SP15a /
SP15b /
SP15c
SP15a /
SP15b /
SP15c
SP13a /
SP13b /
SP13c
SP14a /
SP14b
SP11a /
SP11b
"SKF-350F (L)" "SKF-350F (R)" "SKC-350C"
"SKM-350S (R)""SKM-350S (L)"
TERMINAL :
White / Black
TERMINAL :
Red / Black
TERMINAL :
Green / Black
TERMINAL :
Blue / Black
TERMINAL :
Gray / Black
NOT MAGNETICALLY SHIELDED NOT MAGNETICALLY SHIELDED
<Notes>
USA and Canadian models : inch nut.
Other models : mm nut.
<Note>
Cannot remove the speaker grill.

1/2 PAGE
HTP-350
EXPLODED VIEWS PARTS LIS
T
<Notes>
(B) : Black model
(S) : Silver model
<MD> : USA model
<MC> : Canadian model
<MA> : Australian model
<MK> : Korean model
<MO> : World wide model
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
SKW-350 : PASSIVE SUBWOOFER
EXPLODED
SP01a SUBWOOFER ASS'Y SKW-350 BLACK 1 ANW8W600B-BM10 (B)
EXPLODED
SP01b SUBWOOFER ASS'Y SKW-350 SILVER 1 ANW8W600S-BM10 (S)
EXPLODED
SP03 WOOD SCREW 4 x 20 BIND HEAD (FOR SP UNIT) 8 NST8550518201
EXPLODED
SP05 WOOFER SPEAKER 20cm 8ohm 50W RoHS 1 W20178D
EXPLODED
SP09 BACK LABEL BLACK / E2 GRADE 1 YLB8100010106
EXPLODED
SKF-350F : FRONT SPEAKERS (L)/(R)
EXPLODED
SP10a COMPLETE UNIT "SKF-350F (B) L & R" / (Inch nut) 1 ASL5M0503-BM04 (B) <MD>
EXPLODED
SP10b COMPLETE UNIT "SKF-350F (S) L & R" / (Inch nut) 1 ASL5M0503-BM01 (S) <MC>
EXPLODED
SP10c COMPLETE UNIT "SKF-350F (S) L & R" / (mm nut) 1 ASL5M0503-BM02 (S) <MA>
EXPLODED
SP10c COMPLETE UNIT "SKF-350F (S) L & R" / (mm nut) 1 ASL5M0503-BM02 (S) <MK>
EXPLODED
SP10c COMPLETE UNIT "SKF-350F (S) L & R" / (mm nut) 1 ASL5M0503-BM02 (S) <MO>
EXPLODED
SP11a BACK LABEL (L) BLACK 1 YLB5101690441 <MD>
EXPLODED
SP11a BACK LABEL (L) BLACK 1 YLB5101690441 <MC>
EXPLODED
SP11b BACK LABEL (L) GRAY 1 YLB5101690446 <MA>
EXPLODED
SP11b BACK LABEL (L) GRAY 1 YLB5101690446 <MK>
EXPLODED
SP11b BACK LABEL (L) GRAY 1 YLB5101690446 <MO>
EXPLODED
SP12a BACK LABEL (R) BLACK 1 YLB5101690442 <MD>
EXPLODED
SP12a BACK LABEL (R) BLACK 1 YLB5101690442 <MC>
EXPLODED
SP12b BACK LABEL (R) GRAY 1 YLB5101690447 <MA>
EXPLODED
SP12b BACK LABEL (R) GRAY 1 YLB5101690447 <MK>
EXPLODED
SP12b BACK LABEL (R) GRAY 1 YLB5101690447 <MO>
EXPLODED
SKC-350C : CENTER SPEAKER
EXPLODED
SP13a COMPLETE UNIT "SKC-350C (B)" / (Inch nut) 1 ASL5C0503-BM04 (B) <MD>
EXPLODED
SP13b COMPLETE UNIT "SKC-350C (S)" / (Inch nut) 1 ASL5C0503-BM01 (S) <MC>
EXPLODED
SP13c COMPLETE UNIT "SKC-350C (S)" / (mm nut) 1 ASL5C0503-BM02 (S) <MA>
EXPLODED
SP13c COMPLETE UNIT "SKC-350C (S)" / (mm nut) 1 ASL5C0503-BM02 (S) <MK>
EXPLODED
SP13c COMPLETE UNIT "SKC-350C (S)" / (mm nut) 1 ASL5C0503-BM02 (S) <MO>
EXPLODED
SP14a BACK LABEL BLACK 1 YLB5101690443 <MD>
EXPLODED
SP14a BACK LABEL BLACK 1 YLB5101690443 <MC>
EXPLODED
SP14b BACK LABEL GRAY 1 YLB5101690448 <MA>
EXPLODED
SP14b BACK LABEL GRAY 1 YLB5101690448 <MK>
EXPLODED
SP14b BACK LABEL GRAY 1 YLB5101690448 <MO>
EXPLODED
SKM-350S : SURROUND SPEAKERS (L)/(R)
EXPLODED
SP15a COMPLETE UNIT "SKM-350S (B) L & R" / (Inch nut) 1 ASL5U0503-BM04 (B) <MD>
EXPLODED
SP15b COMPLETE UNIT "SKM-350S (S) L & R" / (Inch nut) 1 ASL5U0503-BM01 (S) <MC>
EXPLODED
SP15c COMPLETE UNIT "SKM-350S (S) L & R" / (mm nut) 1 ASL5U0503-BM02 (S) <MA>
EXPLODED
SP15c COMPLETE UNIT "SKM-350S (S) L & R" / (mm nut) 1 ASL5U0503-BM02 (S) <MK>

2/2 PAGE
EXPLODED
SP15c COMPLETE UNIT "SKM-350S (S) L & R" / (mm nut) 1 ASL5U0503-BM02 (S) <MO>
EXPLODED
SP16a BACK LABEL (L) BLACK 1 YLB510169-0444 <MD>
EXPLODED
SP16a BACK LABEL (L) BLACK 1 YLB510169-0444 <MC>
EXPLODED
SP16b BACK LABEL (L) GRAY 1 YLB5101690449 <MA>
EXPLODED
SP16b BACK LABEL (L) GRAY 1 YLB5101690449 <MK>
EXPLODED
SP16b BACK LABEL (L) GRAY 1 YLB5101690449 <MO>
EXPLODED
SP17a BACK LABEL (R) BLACK 1 YLB5101690445 <MD>
EXPLODED
SP17a BACK LABEL (R) BLACK 1 YLB5101690445 <MC>
EXPLODED
SP17b BACK LABEL (R) GRAY 1 YLB5101690450 <MA>
EXPLODED
SP17b BACK LABEL (R) GRAY 1 YLB5101690450 <MK>
EXPLODED
SP17b BACK LABEL (R) GRAY 1 YLB5101690450 <MO>
EXPLODED
SATELLITE PACKAGE
EXPLODED
--- SATELLITE PACKAGE (B) --- 1 ANB5NS503-BM04 <MD>
EXPLODED
--- SATELLITE PACKAGE (S) --- 1 ANB5NS503BM01 <MC>
EXPLODED
--- SATELLITE PACKAGE (S) --- 1 ANB5NS503BM02 <MA>
EXPLODED
--- SATELLITE PACKAGE (S) --- 1 ANB5NS503BM02 <MK>
EXPLODED
--- SATELLITE PACKAGE (S) --- 1 ANB5NS503BM02 <MO>
