Onkyo HT-S8409 Specification sheet

TX-NR609
7.1-Channel Network A/V Receiver
•130 Watts per Channel at 6 Ohms, 1 kHz, .07%,
2 Channels Driven, FTC
•HDMI®Support for 3D,Audio Return Channel,
DeepColor™, x.v.Color™, LipSync, Dolby®TrueHD, DTS-HD
Master Audio™, DVD-Audio, Super Audio CD, Multichannel
PCM, and CEC
•6 HDMI Inputs and 1 Output
•HDMI Video Upscaling to 4K with Qdeo™Technology by
Marvell
•Direct Digital Connection of iPod®/iPhone®via Front-Panel
USB Port
•Compatible with UWF-1 Wireless LAN Adapter (via USB)
•Supports Onkyo Remote App for Control of A/V Receiver
via iPod/iPhone*1
•Dolby®TrueHD, DTS-HD Master Audio™, Dolby®Digital
Plus, DTS-HD High-Resolution Audio™Decoding
•TI Burr-Brown 192 kHz/24-Bit DACs for All Channels
•PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology
for S/PDIF Audio
•Dolby®Pro Logic®IIz for Expanded Surround Channels
•Playback of Audio Files Through Local Network (MP3,
WMA,WMA Lossless, FLAC,WAV, Ogg Vorbis,AAC, LPCM)
•Internet Radio and Music Streaming Service Connectivity
(vTuner, SIRIUS XM Internet Radio®, Mediafly,
Pandora®, Slacker™, Napster, Rhapsody®)*2
•Certified with Windows®7 and DLNA Version 1.5
•Firmware Updates via Ethernet and USB
•Universal Port for Onkyo Peripheral Devices Such as UP-
A1 Dock for iPod/iPhone, UP-HT1 HD Radio™Tuner,
or UP-TR1 Wireless Audio Module
•Powered Zone2 and Zone 2 Line-Out for Distributed
Audio Playback in Another Room
•Audyssey 2EQ®for Room Acoustic Correction
•Audyssey Dynamic EQ®for Loudness Correction
•Audyssey Dynamic Volume®to Maintain Optimal Listening
Level and Dynamic Range
•Overlaid On-Screen Display (OSD) via HDMI
•H.C.P.S. (High Current Power Supply) Massive High Power
Transformer
•Optimum Gain Volume Circuitry
•Advanced 32-Bit Processing DSP Chip
•4 DSP Modes for Gaming: Rock, Sports,Action, and RPG
•Advanced Music Optimizer for Compressed Digital
Music Files
•Theater-Dimensional Virtual Surround Function
•Direct Mode
•Double Bass Function
•Non-Scaling Configuration
•A-Form Listening Mode Memory
•2 Component Video Inputs and 1 Output
•5 Composite Video Inputs (1 Front/4 Rear) and 2 Outputs
•4 Digital Audio Inputs (2 Optical and 2 Coaxial)
•6 Analog Audio Inputs (1 Front/5 Rear) and 1 Output
•Analog RGB Video Input (D-sub, 15 pin) for PC
•Subwoofer Pre Out
•Crossover Adjustment (40/50/60/70/80/90/100/120/150/
200 Hz)
•A/V Sync Control (Up to 800 ms at 48 kHz)
•3-Mode Display Dimmer (Normal/Dim/Dimmer)
•40 FM/AM Random Presets
•RIHD (Remote Interactive over HDMI) for System Control
•Full-Function RI Remote Control
*1 Compatible iPod/iPhone models: Pod touch 3rd generation or later; iPhone 3GS or
later (All models requ re iOS 4 2 or later) *2 Availabilty of services depends on region
HTP-890
7.1-Channel Home Theater Speaker
System
SKF-780 2-Way Bass Reflex
Front Speakers
•3 1/˝(8 cm) Cone Woofer x 2
•1˝(2.5 cm) Balanced-Dome Tweeter
•Max. Input Power: 130 W
•Gloss Finished Top Panel
SKC-780 2-Way Bass Reflex
Center Speaker
•3 1/˝(8 cm) Cone Woofer x 2
•1˝(2.5 cm) Balanced-Dome Tweeter
•Max. Input Power: 130 W
•Gloss Finished Side Panels
SKR-780/SKB-780 Full-Range Acoustic
Suspension Surround/Surround
Back Speakers
•3 1/˝(8 cm) Cone
•Max. Input Power: 130 W
•Gloss Finished
Note: All speakers feature an impedance of 6 ohms and color-coded speaker terminals
and cable And all except the front speakers are wall-mountable
SKW-780 Bass Reflex Powered Subwoofer
•10˝(25 cm) Cone
•Rated Output Power: 120 W (Minimum Continuous Power,
4 Ohms, 100 Hz, 1%, FTC)
•Down-Firing
•Gloss Finished
•Output Level Control
Sleek Receiver-and-Speaker Package Is Built to Thrill
With its two mighty tower speakers, the HT-S8409 stands apart from other home theater package systems. These two-way tall-boys work
in concert with the other high-quality speakers to express the full scope and power of your music and other entertainment. No matter
whether it’s a song, a game, or a movie, the receiver’s Dolby®Pro Logic®IIz decoding creates an enveloping 7.1-channel soundstage with
superb ambience. Once you’ve set the system up and calibrated the speakers—a breeze, thanks to Audyssey 2EQ®—you can browse your
content seamlessly via the intuitive on-screen menus. The receiver accepts a wide range of playback devices and formats, including PC
video via RGB and digital audio from iPod®/iPhone®via USB. In addition, six HDMI®inputs handle 3D video, lossless audio from DTS and
Dolby, and video upscaling to 4K via Qdeo™technology.The system’s network capability supports streaming audio from your PC or media
server, as well as the infinite variety of internet radio.The HT-S8409 from Onkyo—prepare to be entertained.
HT-S8409
7.1 CHANNEL NETWORK A/V RECEIVER/SPEAKER PACKAGE
2011 NEW PRODUCT RELEASE
Microphone for
Audyssey

HT-S8409 7.1 CHANNEL NETWORK A/V RECEIVER/SPEAKER PACKAGE
HDMI®Support for 3D Video and Audio
Return Channel
The six HDMI inputs on the HT-S8409’s A/V receiver let
you simultaneously connect high-def sources such as a Blu-
ray player, a gaming console, and a cable/satellite tuner. A
single output then sends a pristine signal to your connected
high-resolution display.The HDMI implementation on this
receiver supports both 3D video and an Audio Return
Channel, along with numerous high-resolution formats. 3D
video brings exciting possibilities to home entertainment,
with movie, game, and broadcast content on the increase
and 3D-compatible TVs now on the market. Meanwhile, the
Audio Return Channel allows audio content received
directly by your HDTV’s tuner to be sent “upstream” via
HDMI to your A/V receiver, without the need for a
separate S/PDIF audio cable.
Network Capability Delivers Internet Radio and
Network Audio Streaming via Ethernet
As one of Onkyo’s new breed of receivers that can link
directly to the internet or to your home PC via a local
network, the HT-S8409’s A/V receiver takes streaming
audio and internet radio to a whole new level. MP3, WMA,
WMA Lossless, FLAC, WAV, Ogg Vorbis, AAC, and LPCM
audio files can now be played back through your main
system with unprecedented power and fidelity.The receiver
also brings to life a huge array of internet radio channels
from vTuner, Last.fm, SIRIUS XM Internet Radio®, Mediafly,
Pandora®, and Slacker™, plus on-demand music streaming
from Napster and Rhapsody*. As well as being compatible
with earlier platforms, the receiver is compatible with
Microsoft’s Windows®7 platform, which includes the
DLNA 1.5-specified “Play To” media-streaming feature.The
receiver’s internet connectivity has the added benefit of
making firmware updates simpler than ever.
* Availability of internet radio and music streaming services depends on region
Direct Digital Connection of iPod®/iPhone®via
Front-Panel USB Port
The front-panel USB port on the HT-S8409’s A/V receiver
lets you access MP3, WMA, FLAC, and AAC audio files
stored on a USB flash drive or iPod/iPhone. As the audio
signals are transported in digital form, rather than analog,
there is much less chance for signal degradation. End result:
your music sounds cleaner and more faithful to the original.
A further benefit of the USB input is that it lets you use the
system’s remote controller to play back audio files on the
connected device.
4K Video Upscaling and Processing via Qdeo™
Technology
The HT-S8409 offers full 4K (3840 x 2160) upscaling of
standard video sources such as 480i/p, 720p, and 1080i/p.
Interlaced-to-progressive conversion and scaling are
performed by high-quality Qdeo technology from Marvell.
Qdeo is a versatile video processor that uses algorithms
designed to erase video noise and artifacts such as jaggies
and feathering. Played back on a compatible wide-screen
display, your Blu-ray Discs and DVDs will look more
detailed and cinematic than ever.
Onkyo Remote App for iPod/iPhone*
Available as a free download, this app lets you use your
iPod touch or iPhone as a remote controller to control a
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–107.9 MHz
AM 530 kHz–1,710 kHz
FM/AM Preset Memory 40 stations
General
Power Supply AC 120 V~, 60 Hz
Power Consumption 6.2 A
Dimensions (W x H x D) 17 1/8˝x 6 3/6˝x 12 5/6˝
(435 x 173.5 x 328 mm)
Weight 24.7 lbs (11.2 kg)
SPEAKER SYSTEM
Speaker Type
Front 2-way, Bass reflex
Center 2-way, Bass reflex
Surround Full-range, Acoustic suspension
Surround Back Full-range, Acoustic suspension
Subwoofer Bass reflex, Powered
Drivers
Front 3 1/4˝(8 cm) cone woofer x 2
1˝(2.5 cm) balanced-dome tweeter
Center 3 1/4˝(8 cm) cone woofer x 2
1˝(2.5 cm) balanced-dome tweeter
Surround 3 1/4˝(8 cm) cone
Surround Back 3 1/4˝(8 cm) cone
Subwoofer 10˝(25 cm) cone
Frequency Response
Front 55 Hz–50 kHz
Center 60 Hz–50 kHz
Surround 80 Hz–20 kHz
Surround Back 80 Hz–20 kHz
Subwoofer 25 Hz–150 Hz
Output Sound Pressure Level
Front 79.5 dB/W/m
Center 79 dB/W/m
Surround 81 dB/W/m
Surround Back 81 dB/W/m
Max. Input Power
Front/Center/Surround/Surround Back
130 W
Rated Output Power
Subwoofer 120 W (Minimum continuous power,
4 ohms, 100 Hz, 1%, FTC)
Nominal Impedance
Front/Center/Surround/Surround Back
6 ohms
Input Sensitivity/Impedance
Subwoofer 550 mV/20 k-ohms
General
Dimensions (W x H x D)
Front 10 5/16˝x 41 1/8˝x 10 5/6˝
(262 x 1045 x 262 mm)
Center 16 9/16˝x 4 1/2˝x 4 3/4˝
(420 x 115 x 121 mm)
Surround 4 1/2˝x 9 1/6˝x 3 3/4˝
(115 x 230 x 96 mm)
Surround Back 4 1/2˝x 9 1/6˝x 3 3/4˝
(115 x 230 x 96 mm)
Subwoofer 10 13/6˝x 19 15/6˝x 16 3/16˝
(275 x 507 x 411 mm)
Weight
Front 11.5 lbs. (5 2 kg)
Center 4.9 lbs. (2.2 kg)
Surround 2.2 lbs. (1.0 kg)
Surround Back 2.2 lbs. (1.0 kg)
Subwoofer 25.6 lbs. (11.6 kg)
CARTON
Dimensions (W x H x D) 27 1/16˝x 45 1/4˝x 21 15/16˝
(688 x 1150 x 558 mm)
Weight 106.9 lbs (48.5 kg)
UPC CODE
(B) 751398010460
Supplied Accessories
•Indoor FM antenna •AM loop antenna •Color-coded speaker cable
•Subwoofer cable •Speaker set-up microphone •Instruction manual
•Quick set-up guide •Remote controller •AA (R6) batteries x 2
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. Manufactured under icense from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories. DTS,
DTS-HD, and the DTS symbol are registered trademarks and the DTS logo is a trademark of DTS, Inc. Manufactured under license from Audyssey Laboratories, Inc. U.S. and foreign patents pending. Audyssey 2EQ,Audyssey Dynamic EQ, and Audyssey Dynamic Volume are
registered trademarks of Audyssey Laboratories, Inc. HDMI, the HDMI logo, and High-Definition Mu timedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Phone, Pod, iPod classic, Pod nano, iPod shuffle, and
Pod touch are trademarks of Apple Inc., registered in the U.S. and other countries. “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or Phone, respectively, and has been certified by the developer to meet
Apple performance standards. Apple is not responsible for the operation of this device or its comp iance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. x.v Color is a trademark of Sony
Corporation. Windows 7 and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Qdeo and QuietVideo are trademarks of Marvell or ts affi iates. SIRIUS, XM and all related marks and logos are
trademarks of SIRIUS XM Radio Inc. and its subsidiaries. HD Radio and the HD Radio logo are trademarks of Biquity Digital Corp. Music Optimizer and Theater-Dimensional are trademarks of Onkyo Corporation. All other trademarks and registered trademarks are the property
of their respective holders.
N PR No . 11N 4 2 03 / 1 1
SPECIFICATIONS
A/V RECEIVER
Amplifier Section
Power Output
Front L/R
Center
Surround L/R
Surround Back L/R or Front High L/R
Dynamic Power 180 W (3 ohms, Front)
160 W (4 ohms, Front)
100 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half power)
Damping Factor 60 (Front, 1 kHz, 8 ohms)
Input Sensitivity and Impedance
200 mV/47 k-ohms (Line)
Rated RCA Output Level and Impedance
200 mV/2.2 k-ohms (Rec out)
Maximum RCA Output Level and Impedance
2.0 V/2.2 k-ohms (Rec out)
Frequency Response 20 Hz–50 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker Impedance 6 ohms–16 ohms
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 ohms (Component Y)
0.7 Vp–p/75 ohms (Component PB/CB, PR/CR)
1.0 Vp–p/75 ohms (Composite)
Component Video Frequency Response
5 Hz–100 MHz/0 dB, -3 dB
Front View Rear View
range of functions on the HT-S8409. As well as letting you
select internet radio stations, it also lets you select
streaming audio input from a DLNA-compatible server.The
Remote App also enables you to perform basic playback
operations and control the receiver’s volume with an
interface that uses the iPod/iPhone’s built-in accelerometer.
* Compatible iPod/iPhone models: iPod touch 3rd generation or later; iPhone 3GS
or later (All models requ re OS 4 2 or later )
A Suite of Audyssey Technologies for the Ideal
Listening Environment
The HT-S8409 comes equipped with three sound-
enhancing Audyssey technologies.
(1) Audyssey 2EQ®tailors multi-channel audio for your home theater
speaker set-up by measuring three room positions and applying a
resolution filter to the satellite speakers to correct for room
acoustics.
(2) Audyssey Dynamic EQ®maintains a consistent bass response,
tonal balance, and surround-sound effect at different volume levels,
so you can enjoy the natural dynamics of your content regardless of
the volume.
(3) Audyssey Dynamic Volume®automatically compensates for
volume fluctuations in different audio content—for example, during
commercial breaks—while optimizing the dynamic range.
TX-NR609
130 W/Ch
(6 ohms, 1 kHz, .07%, 2 channels driven, FTC)
100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%,
2 channels driven, FTC)
130 W/Ch
(6 ohms, 1 kHz, .07%, 2 channels driven, FTC)
100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%,
2 channels driven, FTC)
130 W/Ch
(6 ohms, 1 kHz, .07%, 2 channels driven, FTC)
100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%,
2 channels driven, FTC)
130 W/Ch
(6 ohms, 1 kHz, .07%, 2 channels driven, FTC)
100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%,
2 channels driven, FTC)
