TX-NR414
5.1-Channel Network A/V Receiver
Cloud-Based Audio Streaming and Internet Radio
Over the Home Network
Connecting to the internet and your home PC via a local
network, the TX-NR414 makes streaming audio and internet
radio easy.You can also play MP3,WMA,WMA Lossless,
FLAC, WAV, Ogg Vorbis, AAC, and LPCM audio files stored
on your PC through your Onkyo system with stunning
power and fidelity.The receiver offers access to internet
radio channels from Last.fm and vTuner, plus cloud-based
music streaming from Spotify, AUPEO!, and MP3tunes*.
Internet connectivity has the added benefit of making
firmware updates simpler than ever.
*Availability of services depends on region. Some services may require a firmware
update.
Audio Return Channel and 3D Video via HDMI®
Six HDMI inputs on the TX-NR414 allow seamless
integration of high-definition devices such as Blu-ray
players, cable/satellite tuners, and gaming consoles. HDMI
implementation on this receiver also supports an Audio
Return Channel, allowing TV audio to be sent upstream
to the A/V receiver.That means you can enjoy television
programs in magnificent Onkyo sound. HDMI also supports
3D video and other popular high-resolution formats.
InstaPrevue™Technology Makes Switching
Sources Easy
The TX-NR414 incorporates InstaPrevue visual port
management technology, making input source selection
much easier. InstaPrevue technology provides a live
video thumbnail of the available content on your devices
connected via HDMI.You no longer have to remember that
your gaming console is connected to Port 3, or your BD
player to Port 1, for example—you can see what’s playing
and choose accordingly.
Onkyo Remote Apps for iPod touch/iPhone and
Android
The Onkyo Remote App 2 for iPod touch/iPhone*1and
Onkyo Remote for Android*2both provide an intuitive
way to operate Onkyo network A/V receivers. Control
input sources, adjust settings, and play audio stored in a
smartphone wirelessly (Android only) using the application’s
interactive graphical display.The two Remote Apps are
available separately as free downloads.
*1 Compatible with iPod touch (3rd generation or later) and iPhone 3GS or later. All
models require iOS 4.2 or later. *2 Requires Android OS 2.1 or later.
Save Power with Hybrid Standby
Hybrid Standby provides ‘HDMI through’ functionality while
the receiver sleeps, so you don’t have to fully power up to
watch a Blu-ray or play a game using just yourTV’s sound.
The receiver also maintains a local network connection
when on Hybrid Standby mode, so you can switch the unit
on at any time using the Onkyo remote apps for
iPod touch/iPhone and Android.
WRAT (Wide Range Amplier Technology)
Delivers Higher Fidelity
WRAT is a suite of proprietary technologies Onkyo
developed to improve signal-to-noise ratios, and enhance the
fidelity of amplified audio.The technologies work to reduce
noise across the frequency range, guaranteeing a clear, well-
balanced performance. It does this by employing a low
negative-feedback amplifier design; using “closed” ground-
loop circuitry to cancel noise from individual circuits; and
by ensuring high instantaneous-current capability to cancel
reflex energy and impedance fluctuations from the speakers.
Overlaid On-Screen Display with Quick
Set-Up Menu
The receiver’s HDMI-linked On-Screen Display (OSD)
makes initial set-up and in-program calibration very easy.
The ‘Q’ button on your remote overlays a transparent
‘Quick Setup’ menu on the program you’re watching.This
handy shortcut includes the most frequently used settings,
and helps you optimize your home cinema’s performance
with the minimum of disruption.The ‘Home’ button accesses
standard set-up menus for more detailed adjustment.
Enjoy Lossless High-Denition Movie Soundtracks
The TX-NR414 can decode Dolby®TrueHD and DTS-
HD Master Audio™—two “lossless” Blu-ray formats that
deliver a soundtrack identical to the studio master.The
TX-NR414 also handles Dolby®Digital Plus and DTS-HD
High Resolution Audio™. Dolby Digital Plus is designed to
accompany HD video delivered via disc media, television
broadcasts, and online content. DTS-HD High Resolution
Audio, meanwhile, offers a higher bit and sampling rate than
the core DTS technology.
Direct Digital iPod/iPhone Connection for Cleaner
Sound
The TX-NR414’s front-panel USB port lets you play MP3
and AAC stored on an iPod/iPhone, and MP3, WMA, AAC,
and FLAC audio files stored on a flash-memory device using
the system’s own remote for track selection and playback.
Your music will also sound much cleaner and clearer, as
the audio signal is transported in digital form (rather than
analog) via the direct digital connection.
Top-Quality DACs Deliver Clearer Sound
Digital-to-Analog converters are of particular importance
to audio fans seeking excellent sound reproduction, and the
TX-NR414 features reliable, high-performance 192 kHz/
24-bit chips from Burr-Brown. As well as optimizing analog
performance, these DACs are highly resistant to “clock jitter”,
a subtle form of digital distortion.
Playback of Different Audio Sources in Two Zones
Zone 2 line-outs on the TX-NR414 allow you to enjoy
surround-sound entertainment in the main room, while
playing back a different stereo source in a second zone
equipped with an amplifier and a pair of speakers.
SPECIFICATIONS
Amplifier Section
Power Output
Front L/R 130 W/Ch (6 Ω, 1 kHz, 1% THD,
1 Channel Driven, IEC)
160 W/Ch
(6 Ω, 1 kHz, 1 Channel Driven, JEITA)
Center 130 W (6 Ω, 1 kHz, 1% THD,
1 Channel Driven, IEC)
160 W
(6 Ω, 1 kHz, 1 Channel Driven, JEITA)
Surround L/R 130 W/Ch (6 Ω, 1 kHz, 1% THD,
1 Channel Driven, IEC)
160 W/Ch
(6 Ω, 1 kHz, 1 Channel Driven, JEITA)
Dynamic Power 180 W (3 Ω, Front)
165 W (4 Ω, Front)
100 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half Power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 Ω(Line)
Rated RCA Output Level and Impedance
200 mV/2.2 kΩ(Rec Out)
Maximum RCA Output Level and Impedance
2.0 V/2.2 kΩ(Rec Out)
Frequency Response 5 Hz–100 kHz/+1 dB, -3 dB (DSP Bypass)
Tone Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker Impedance 6 Ω – 16 Ω
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 Ω(Component Y)
0.7 Vp–p/75 Ω(Component PB/CB, PR/CR)
1.0 Vp–p/75 Ω(Composite)
Component Video Frequency Response
5 Hz–100 MHz/+0 dB, -3 dB
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
530 kHz–1,710 kHz
FM/AM Preset Memory 40 Stations
General
Power Supply AC 230 V~, 50 Hz
(Asian Model: AC 220−240V~, 50/60 Hz)
Power Consumption 400 W (Asian Model: 450 W)
Standby Power Consumption
0.2 W
Dimensions (W x H x D) 435 x 173.5 x 328 mm
Weight 9.0 kg (Asian Model: 9.4 kg)
CARTON
Dimensions (W x H x D) 570 x 297 x 423 mm
Weight 11.5 kg (Asian Model: 12.0 kg)
Supplied Accessories
• Indoor FM antenna • AM loop antenna • Speaker cable labels
• Instruction manual • Quick start guide • Remote controller
• AA (R6) batteries* x 2
*Not included with Chinese model.
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories. DTS,
DTS-HD, the Symbol, & DTS or DTS-HD and the Symbol together are registered trademarks of DTS, Inc. © DTS, Inc. All Rights Reser ved. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries. iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. "Made for iPod" and "Made for iPhone" mean that an electronic device has been designed to connect specifically to
iPod or iPhone, respectively, and has been certified by the developer to meet Apple performance standards.Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this device with iPod or iPhone
may affect wireless performance. Android is a trademark of Google Inc. InstaPrevue and the InstaPrevue logo are trademarks or registered trademarks of Silicon Image, Inc. in the United States and other countries. x.v.Color is a trademark of Sony Corporation.Windows 7 and the
Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. WRAT, Music Optimizer, CinemaFILTER, and Theater-Dimensional are trademarks of Onkyo Corporation. All other trademarks and registered trademarks
are the property of their respective holders.
NPR No. 12N04 12/11
Text on receiver may vary with region.
