AS-1E –Assembly Instruction Manual–
•Have a Phillips screw driver (large or medium) avail-
able.
• Assemble the product on a carpet or mat so that the
floor and/or the stand will not become scratched or
damaged.
•Before starting assembly, make sure that you have all
the parts by referred to in the parts list and assembly
diagram.
•Be careful not to scratch the speaker when you install
the speaker on the speaker stand.
Product weight: 15.9 lbs (per unit)
Static live load capacity: 44 lbs or less;
* Do not exceed this limit.
* This illustration shows a single unit.
Thank you for purchasing an Onkyo product!
• This instruction manual describes how to assemble and use the speaker stand and provides precautionary infor-
mation.
• Be sure to read this manual BEFORE you assemble the stand to ensure proper use of the product.
• Store this manual in a safe place for future reference to help extend the useful life of the product.
• Onkyo cannot guarantee product quality unless you follow the instructions in the manual to assemble the stand.
Precautions before unit assembly
Dimensions
4-15/16"
11-5/16" 16-1/4"
23" 22"
Package contents
Finished assembly
• Spike • Screws for additional
top panel
• Speaker affixing screw • Teflon washer
