SERVICE MANUAL
SERVICE MANUAL
SUB WOOFER SYSTEM
SL-105 / HTP-2
MPP 230-240V AC, 50Hz
MDT 120V AC, 60Hz
MGT 220-230V AC, 50/60Hz
Black color :MPP model
Yellow color :MDT, MGT models
SL-105
POWERED SUBWOOFER
D-L5 x 5
SATELLITE SPEAKERS

SL-105
SERVICE NOTE
1. Replacing the fuses
This symbol located near the fuses indicates that the fuse used is
fast operating type. For continued protection against fire hazard, re-
place with same type fuse. For fuse rating refer to the marking adja-
cent to the symbol.
Ce symbole indique que le fusible utlise est a rapide. Pour une pro-
tection permanente, n'untiliser que fusibles de meme type. Ce darni-
er est la qu le present symbol est appse.
CIRCUIT NO. PART NO. DESCRIPTION
CIRCUIT NO. PART NO. DESCRIPTION
F901,F903 252069 or 0.8A-SE-EAK or
252236 800MA-SE-TL250V <MPP,MGT>
F902 252159 or 2A-UL/T-237 or
252253 2A-T/UL-ST2 <MDT>
2. Safety-check out
After correcting the original service problem, perform the following
safety check before releasing the set to the customer. Connect the in-
sulating-resistance tester between the plug of power supply cord and
screw on the back panel.
Specifications: 3.3MohmrCV8

SL-105
PANEL VIEW
Front panel
A Low-level input jacks (LINE INPUT)
Connect these jacks to the LINE OUT jacks of the
amplifier etc.
B Auto standby switch (AUTO STANDBY)
This switch is used to turn on and off the auto standby
function.
ON: This activates the auto standby function.
If a constant level signal is not received from the
amplifier (or receiver) over a period of a few minutes,
the SL-105 automatically enters the standby state. If a
constant level signal is later received from the amplifier
(or receiver), the power is automatically turned back on.
OFF: Deactivates the auto standby function.
Notes:
The auto standby function operates on the existence
or absence of a constant level input signal. If the auto
standby function does not operate properly, try
slightly increasing (or decreasing) the output level of
the amplifier or receiver. (Note that output levels of
some amplifiers and receivers cannot be adjusted.
For more details regarding your components, refer to
the instruction manual supplied with them.)
If noise from peripheral components causes the
incorrect operation of the auto standby function, or if
outputting low volumes (i.e., during the nighttime)
causes the auto standby function to activate, turn off
the auto standby function.
The auto standby function only operates while the
power switch for the SL-105 is turned on.
C Speaker-level input terminals
(INPUT FROM AMP/RECEIVER)
Connect these input terminals to the speaker output
terminals of your amplifier or receiver.
D Speaker-level output terminals
(OUTPUT TO SPEAKERS)
The speaker-level signal to the front speakers is output
from these terminals.
1 Power switch (POWER) and indicator
Pressing this button turns the power on (the indicator
lights). Pressing the button again turns the power off
(the indicator goes out).
Red: Unit is in standby mode
Green: Unit is in operation
2 Frequency adjusting knob (FREQUENCY)
Use this knob to select the high-frequency range at
which you wish to cut off the signal to the subwoofer.
You can select any frequency between 50 Hz and 200
Hz depending on the characteristics of the speaker
system being used with the SL-105.
3 Output level adjusting knob (OUTPUT LEVEL)
Use this knob to adjust the output level of the
subwoofer.
Rear panel
R
SPEAKER LEVEL
INPUT
FROM
AMP/RECEIVER
AUTO STANDBY
LINE
INPUT
L
R
OFF ON
OUTPUT
TO SPEAKERS
(MONO)
+_ L +
_
R +_ L +
_
SL-105 C
DAB
To AC outlet
FREQUENCY OUTPUT
LEVEL
MIN MAX
50Hz 200Hz
POWER
POWERED SUBWOOFER
SL-105
1
23
Subwoofer SL-105
*
*
*

SL-105
P535
E901
S7
S7
S7
S7
S4
S4
S4
S4
S8
S8
S8
S8 S2
S1
EXPLODEDVIEW
(CABINET SECTION)
S10
S3
Indicated in the exploded view of
an amplifier section.
S9

SL-105
A1
A2
A2
A4
A5
A5
A5
A5
A2
A8
A15
A18
A18
A20
A30
A41
A42
A49
A4
8
Q515
R602
Q515A
Q516B
Q516
Q541
Q951
Q952
T901
U1
U4
U5
U6
S7
A4 A42
A4
A42
A43
A43
A52
A55
E811
F901
P901
U2
U3
U8
U7
S7
S7
S7
S7
S7
S7
S7
S6
S5
S3
CHASSIS EXPLODEDVIEW
(AMPLIFIER SECTION)

SL-105
EXPLODED VIEW PARTS LIST
<AMPLIFIER ASSEMBLY PARTS LIST>
REF. NO. PART NO. DESCRIPTION
A1 27160467 Heat sink, SKW-205AMP
A2 801433 3SMS8W.SW+14B(BC), Self tapping screw
A4
27130745 Bracket
A5 838130088 3TTB+8B, Self tapping screw
A8
27141661 Retainer
A15
28184777 Cover
A18 82143010 3P+10FN(BC), PAN head screw
A20 28141322A Cushion
A21 28141417 Cushion, P t1x5x160
A22 28141418 Cushion, Q t1x5x80
A30
27100412 Chassis
A41 27122929 Rear panel <MPP>
27122930 Rear panel <MDT>
27122931 Rear panel <MGT>
A42 838430088 3TTB+8B(BC), Self tapping screw
A43 830440109 4TTC+10C(BC), Self tapping screw
A48
28141479 Cushion, t1X5X335
A49 28141416 Cushion, O t1x5x195
A52 28141334 Insulation sheet
A55 27301941 Cord bushing, KF-41
E811,E814
27255004 Clip
E901
260208 Wire tie
F901 252069 0.8A-SE-EAK or
252236 800MA-SE-TL250V, Fuse <MPP.MGT>
252159 2A-UL/T-237 or
252253 2A-T/UL-ST2, Fuse <MDT>
P535 2009990611UL NSAS-2P0833, Socket assy
P901 253175 AS-CEE ZA, Power cord <MPP,MGT>
253272HIT AS-UC-6#18, Power cord <MDT>
Q515 *2203063 2SC5198-O or
*2202523 2SC4468-O or
*2202524 2SC4468-Y or
*2202526 2SC4468-P or
*2203062 2SC5198-R, Transistor
Q515A,Q516A 223021 TBM-51W 9043, Isolation plate
Q516 *2203053 2SA1941-O or
*2202513 2SA1695-O or
*2202514 2SA1695-Y or
*2202516 2SA1695-P or
*2203052 2SA1941-R, Transistor
Q541
2202104 2SC3423-Y or
2202103 2SC3423-O, Transistor
Q951
2202754 2SD1266-P, Transistor
Q952
2202764 2SB941-P, Transistor
R602
4000144 PTH9M04-2.2K, Thermistor
T901 2301460 NPT-1396P, Power transformer <MPP>
2301487 NPT-1396D, Power transformer <MDT>
2301562 NPT-1396G, Power transformer <MGT>
NOTE:THE COMPONENTS IDENTIFIED BY MARK
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION:
Replacement of the transistor of mark , if necessary
must be made from the same beta group (HFE) as the
original type. *
NOTE: <MPP> European model
<MDT> Taiwanese model only
<MGT> Asian model only
<Y> Yellow color model
<B> Black color model MPP only
