Onlogic NWK030 User manual

NWK030: Cat M1 / NB-IoT Modem
Revision Date 2019.09.06
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com

Cat M1 / NB-IoT Modem
NWK030
Revision Date 2019.09.06
NWK030 Product Manual
Revision Date 2019.05.02 .............................................................................................
Preface............................................................................................................2
Important Notices and Warnings .....................................................................................3
Important Notice .....................................................................................................3
Limitation of Liability ..................................................................................................3
Safety and Hazards ...................................................................................................3
Introduction .......................................................................................................4
System/Product Overview ...........................................................................................5
Specications ........................................................................................................5
Product Information ................................................................................................6
Dimensions ..........................................................................................................6
Pin Connectors .......................................................................................................6
Initial Setup........................................................................................................9
Firmware Update .....................................................................................................9
USB Update Application ...............................................................................................9
Firmware Update via AT Commands.....................................................................................10
Procedure for FOTA Over HTTP .........................................................................................10
Procedure for FOTA Upgrade via UFTP Method ...........................................................................11
Technical Functions.................................................................................................12
Connecting to Modem via PuTTY (Windows) ..............................................................................12
Connecting to Modem via Minicom (Ubuntu) .............................................................................12
AT Commands .....................................................................................................13
Code Examples & Other Useful Resources .............................................................................15
Troubleshooting....................................................................................................15
Known Limitations ....................................................................................................15
Check Internet Connectivity (TCP) .......................................................................................15
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
1

Cat M1 / NB-IoT Modem
NWK030
Title
Subtitle
Copy.
Preface
About OnLogic
OnLogic is powering innovation with highly congurable embedded and IoT computers engineered for
reliability. Businesses worldwide depend on our solutions to operate in the toughest environments while
tapping into the evolving Industrial Internet of Things.
This guide will introduce you to the NWK030 modem and walk you through setup and installation. For
technical questions or support, please reach out via our contact information below or visit our NWK030 Tech
Support site at: https://www.onlogic.com/support/documentation/getting-started-with-the-nwk030/ .
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
2

Cat M1 / NB-IoT Modem
NWK030
Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed,
corrupted (i.e., have errors) or be totally lost. Although signicant delays or losses of data are rare when wireless devices such as the
Extrovert family of products are used in a normal manner with a well constructed network, the Extrovert family of products should not
be used in situations where failure to transmit or receive data could result in damage of any kind to other equipment, the user or any
other party, including but not limited to personal injury, death or loss of property. OnLogic accepts no responsibility for damages of any
kind resulting from failures, delays or errors in data transmitted or received. The purchase and use of the Extrovert family of products
does not come with or constitute a wireless or data plan. A separate plan with your carrier is required.
Limitation of Liability
The information in this manual is subject to change without notice and does not represent a commitment on the part of OnLogic.
OnLogic AND ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL,
CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR
ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY OnLogic PRODUCT, EVEN IF OnLogic AND/OR
ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD
PARTY.
In no event shall OnLogic and/or its aliates aggregate liability arising under or in connection with the OnLogic product, regardless
of the number of events, occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the OnLogic
product.
Safety and Hazards
CAUTION: For your own safety and to ensure continued proper operation, Extrovert products should not be used where explosive
atmospheres may be present or where radio interference may cause damage to, or disruption in service from, other equipment.
IMPORTANT NOTE: Maintain at least 20 cm of separation between the LTE antenna and the user’s body while in regular operation. Do
not use Extrovert products in the vicinity of medical equipment as it may cause potentially disruptive interference.
Do not co-locate an Extrovert-enabled device with any other transmitting system.
To comply with FCC/IC regulations in North America that limit both maximum RF output power and human exposure to RF radiation
(SAR), the maximum antenna gain including cable loss in a mobile-only exposure condition must not exceed the limits outlined in the
table on the following page.
Important Notice
Important Notices and Warnings
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
3

Cat M1 / NB-IoT Modem
NWK030
Important Notices and Warnings (cont.)
Device Technology Bands Uplink Frequencies (MHz) Downlink Frequencies (MHz) Maximum Antenna gain (dBi)
NWK030 LTE 2 1850 - 1910 1930 - 1990 7
4 1710 - 1755 2110 - 2155 6.75
5 824 - 849 869 - 894 4.41
12 698 - 716 728 - 746 3.66
13 777 - 787 746 - 756 3.94
Introduction
The NWK030 is based on the SARA-R410M module and provides a single RF interface for connecting the external antenna.
“Cellular” represents the primary RF input/output for transmission and reception of LTE RF signals. The “Cellular” pin of NWK030 has a
nominal characteristic impedance of 50 Ω and must be connected to the primary Tx / Rx antenna through a 50 Ω transmission line to
allow proper RF transmission and reception.
When installed in a OnLogic computer, the “Cellular” interface is connected to an external antenna mount. The external mount uses an
SMA (female) connector. Our line of compatible cellular antennas all use a standard SMA (male) connector.
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
4

Cat M1 / NB-IoT Modem
NWK030
System/Product Overview
SKU NWK030
Carriers Verizon
Connectivity LTE, SMS, GSM, VoLTE
Bands LTE:
FDD Bands Ch 2, 3, 4, 5, 8, 12, 13, 20, 28
3GPP Release 13 LTE Cat M1
3GPP Release 13 LTE Cat NB1
Coverage Enhancement Mode A
Rel 12 LTE Power Save Mode, PSM
Rel 13 e-DRX
Cat M1 Half-duplex (375 kbit/s DL and UL)
Cat NB1 Half-duplex (27.2 kbit/s DL, 62.5 UL)
Cat NB1 Non-IP Data Delivery
GSM:
EGPRS Power class E2
SMS:
MT/MO PDU / Text mode
SMS over SG/NAS1
VoLTE:
Codec: AMR-WB
Data Rate
Cat M1 Half-duplex:
(300 kbit/s DL, 375 kbit/s UL)
NB-IoT:
(27.2 kbit/s DL, 62.5 kbit/s UL)
Interface Mini PCIe (Half and Full Height)
SIM Card Socket Size 3FF (Micro-SIM)
Signal Type USB 2.0 (on Mini PCIe)
Expansion Options SIM Card Socket
PCIe Mini Card (Half and Full Height)
Operating Temp. Range -40°C ~ 85°C
Drivers Supported Ubuntu
Windows 10
Regulatory Information GCF, PTCRB, CE Europe, FCC US, ISED Canada,
RoHS
Protocols Dual stack IPv4 and IPv6
Embedded TCP/IP, UDP/IP, FTP, HTTP
Embedded MQTT, CoAP
Embedded HTTPS, FTPS, TLS
Firmware Upgrade Via UART and USB
Via FOTA
Operating Voltage
Power Input VCC_3V3 Minimum: 3v Maximum: 5.5v
Serial 1 UART
1 USB 2.0 (high speed, 480 Mb/s)
Features Power Save Mode
Embedded TCP/UDP stack
eDRX
Embedded HTTP, FTP
Antenna Supervisor
Dual stack IPv4 / IPv6
Embedded HTTPS, FTPS, TLS
FW update over the air (FOTA)
U(SIM) Supports 1.8 and 3 V, SIM toolkit
Specications
The OnLogic NWK030 is based on the PCI Express Mini Card standard with a USB 2.0 interface.
The NWK030 is an available option within OnLogic’s full range of industrial PCs. See www.onlogic.com to select your PC platform. Add
Cat M1 / NB-IoT connectivity during the system conguration stage. The NWK030 is not available for individual sale as a component.
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
5

Cat M1 / NB-IoT Modem
NWK030
Product Information
Dimensions
Pin Connectors
Micro SIM card
Socket
Full/Half size
Cutting Line
Cat M1 / NB1 U.FL-R-
SMT-1 Socket
Pin 1 Pin 52
Pin 2
Pin 51
50.95 mm
30 mm
26.8 mm
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
6

Cat M1 / NB-IoT Modem
NWK030
Pin Connectors (cont.)
Product Information (cont.)
PIN Name Input/Output Description
1 GPIO2 Output Module status indication SARA-R4 pin23
2 VCC_3V3 Power Power Input
3 NC Not Connected
4 GND Power Ground
5 NC Not Connected
6 GNSS_TXD Output +1.8V UART GNSS data output EVA-M8M-0 pin16
7 PWR_ON Input Power-on / power-o input SARA-R4 pin15
8 SIM_VCC External SIM signal — Power supply for the SIM
9 GND Power Ground
10 SIM_IO Input/Output External SIM signal — Data I/O
11 V_INT Output +1.8V UART GNSS data output SARA-R4 pin4
12 SIM_CLK Output External SIM signal — Clock
13 UART_DSR Output UART data set ready SARA-R4 pin6
14 SIM_RST Input External SIM signal — Reset
15 GND Power Ground
16 NC Not Connected
17 GNSS_RXD Input +1.8V UART GNSS data output EVA-M8M-0 pin15
18 GND Power Ground
19 NC Not Connected
20 W_DISABLE_N Hi or Open: Enable the Power
Low: Disable the power
21 GND Power Ground
22 RESET_N Input SARA-R4 External reset input SARA-R4 pin18
23 UART_RXD Input +1.8V UART data output SARA-R4 pin12
24 VCC_3V3 Power Power Input
25 UART_RTS Output +1.8V UART clear to send SARA-R4 pin11
26 GND Power Ground
27 GND Power Ground
28 UART_CTS Input +1.8V UART ready to sent SARA-R4 pin10
29 GND Power Ground
30 UART_DCD Output +1.8V UART data carrier detect SARA-R4 pin8
31 UART_TXD Output +1.8V UART data output SARA-R4 pin13
32 NC Not Connected
33 GPIO1 RESERVED pin SARA-R4 pin16
34 GND Power Ground
35 GND Power Ground
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
7

Cat M1 / NB-IoT Modem
NWK030
Product Information (cont.)
Pin Connectors (cont.)
PIN Name Input/Output Description
36 USB_DN Input/Output USB Data Negative
37 GND Power Ground
38 USB_DP Input/Output USB Data Positive
39 VCC_3V3 Power Input
40 GND Power Ground
41 VCC_3V3 Power Input
42 LED_WWAN Output Default: high impedance;
LED setting ash via AT command port
AT+UGPIOC=16,2
43 GND Power Ground
44 GPIO5 Input SIM detection SARA-R4 pin42
45 NC Not Connected
46 UART_DTR Input +1.8V UART data terminal ready SARA-R4 pin9
47 NC Not Connected
48 V_BCKP Input Real Time Clock Backup supply EVA-M8M-0 pin21
49 NC Not Connected
50 GND Power Ground
51 NC Not Connected
52 VCC_3V3 Power Power Input
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
8

Cat M1 / NB-IoT Modem
NWK030
A SIM inserted into the Modem will automatically congure to the SIM’s respective network. The connection can be veried by checking
the APN using the command ‘AT+CGDCONT?’. The APN will be congured on Class 1 by default. Connectivity can be veried using a
data test of supported protocol tests outlined in the AT command section or by using the dierent connectivity AT commands outlined
in the AT manual.
Firmware Update
Customers can check for device rmware updates through OnLogic’s NWK030 product page. When rmware is available, end users
can perform Firmware Over The Air (FOTA) updates to download and ash rmware. Both methods can be aided with applications or
performed within a PuTTY session using the relevant AT commands.
When rmware is available, User can perform a FOTA update via HTTP. The rmware will be hosted at www.onlogic.com/nwk030/.
A FOTA upgrade package is delivered as two phases:
• fwA_to_fwB-Phase1.pkg
• fwA_to_fwB-Phase2.pkg
In the Phase 1 package, the FOTA Update Agent is updated from a full le to delta le Agent. In the Phase 2 package, the remaining
rmware changes are executed. This two package method substantially reduces the overall package size.
USB Update Application
1. Download the Easy Flash application and Firmware Image File.
2. Make sure the Easy Flash application and the .dof Firmware Image le are in the same directory.
Initial Setup
3. Launch the Easy Flash utility as Administrator
4. Select the following options:
Product: SARA-R4
Port: USB
Baud rate: 921600
5. Hit Start and follow instructions provided
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
9

Cat M1 / NB-IoT Modem
NWK030
Initial Setup (cont.)
Firmware Update via AT Commands
Procedure for FOTA Over HTTP
1. Verify existing / current rmware version via ATI command
2. Set up a HTTP connection:
AT+UHTTP=2,1,”www.websiteurl.com”
AT+UHTTP=2,5,<port number>
3. Get from the previously set HTTP connection
AT+UHTTPC=0,1,”/path/rmware_le.pkg”
4. After the download is nished (+UUFTPCR: 100, 1), start the FOTA update:
AT+UFWINSTALL
It should reboot after 15-20 minutes, do not remove the power from the device before it reboots.
5. Verify rmware version via the ATI command
The rmware should be dierent from the previous ATI command output
USB Update Application (cont.)
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
10

Cat M1 / NB-IoT Modem
NWK030
Procedure for FOTA Upgrade via UFTP Method
1. Verify existing / current rmware version via ATI command
2. Set up a FTP connection:
AT+UFTP=0,”<ip_address>”
AT+UFTP=7,<server_port_number>
AT+UFTP=2,”<username>”
AT+UFTP=3,”<password>”
AT+UFTP=4,”<account>”
AT+UFTP=5,<timeout_seconds>
AT+UFTP=6,<ftp_mode: 1-passive, 0-active>
AT+UFTPC=1
The +UUFTPCR: 1,1 URC is issued to conrm a successful connection.
3. Download the phase-1 le from the FTP server
AT+UFTPC=100,”<package_path>/fwA_to_fwB-Phase1.pkg”
4. After the download is nished (+UUFTPCR: 100, 1), start the FOTA update:
AT+UFWINSTALL
The page should reboot shortly after (< 2 minutes), do not remove the power from the device before it reboots.
5. Setup a FTP connection:
AT+UFTP=0,”<ip_address>”
AT+UFTP=7,<server_port_number>
AT+UFTP=2,”<username>”
AT+UFTP=3,”<password>”
AT+UFTP=4,”<account>”
AT+UFTP=5,<timeout_seconds>
AT+UFTP=6,<ftp_mode: 1-passive, 0-active>
AT+UFTPC=1
The +UUFTPCR: 1,1 URC is issued to conrm a successful connection.
6. Download the phase-2 le from the FTP server:
AT+UFTPC=100,”<package_path>/fwA_to_fwB-Phase2.pkg”
7. After the download is nished (+UUFTPCR: 100, 1), start the FOTA update:
AT+UFWINSTALL
It should reboot after 15-20 minutes, do not remove the power from the device before it reboots.
8. Verify rmware version via the ATI command
The rmware should be dierent from the previous ATI command output
Initial Setup (cont.)
For more information and details on the HTTP commands, see the U-blox manual by searching U-blox’s website for SARA-R4 or
following this link https://www.u-blox.com/en/product/sara-r4-series#tab-documentation-resources
Procedure for FOTA Over HTTP (cont.)
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
11

Cat M1 / NB-IoT Modem
NWK030
Technical Functions
• In the Device Manager, nd out which virtual COM the modem is attached to
»Open the ‘Modems’ category yout,
»Right click the Qualcomm modem entry
»Select properties.
• The port number [n] is listed at the top of main page.
• Open PuTTY
»Select the Serial radio button in the main window.
»In the <<connection>> box, replace COM1 with the COM[n] from the modem properties.
»Set the baud rate to 9600
»Click Open.
• Make the modem “echo” back the commandes.
»In the terminal window, type
• ATE1 and press Enter. It is possible that no text will be displayed until the command is executed.
Connecting to Modem via Minicom (Ubuntu)
• From the Ubuntu terminal:
• sudo minicom -s
• Serial port setup
»Press a - change name to ‘/dev/ttyUSB1’
»Press g to change software ow control to YES
»Exit (this will drop you to a new shell)
• Make the modem “echo” back the commandes. In the terminal window, type
• ATE1
• You can now send any AT commands necessary
Connecting to Modem via PuTTY (Windows)
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
12

Cat M1 / NB-IoT Modem
NWK030
AT Commands (partial)
The modem can be accessed through Minicom or PuTTY. The full list of AT commands and functionality of the SARA-R410M modem can
be found by searching U-blox’s website for SARA-R4 : https://www.u-blox.com/en/product/sara-r4-series#tab-documentation-resources
AT+CGDCONT?
Check Class, APN, and IP information
AT+CGDCONT=<1-6>, <IP,IPV4V6,IPV6>,<APN>
Set class, IP format, and APN
AT+CFUN?
Check power function
AT+CFUN=0
Set modem into airplane mode (o)
AT+CFUN=1
Turn modem on
AT+CFUN=15
Power cycle the modem
AT+CNUM
Verify Phone Number
AT+CSQ
Signal quality (99,99 means no signal)
AT+XSIMSWITCH
Switch SIM Slot in use, 0-1 (default is 0)
AT+USOCR =?
Creates a socket and associates it with the specied protocol (TCP or UDP), and returns a number identifying the socket. Such
command corresponds to the BSD socket routine. Up to 7 sockets can be created. It is possible to specify the local port to bind within
the socket in order to send data from a specic port. The bind functionality is supported for both TCP and UDP sockets.
AT+USOCO=?
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
13

Cat M1 / NB-IoT Modem
NWK030
AT Commands (partial) (cont.)
Establishes a peer-to-peer connection of the socket to the specied remote host on the given remote port, like the BSD connect
routine. If the socket is a TCP socket, the command will perform the TCP negotiation (3-way handshake) to open a connection. If the
socket is a UDP socket, this function will declare the remote host address and port for later use with other socket operations (e.g.
+USOWR, +USORD). This is important to note because if refers to a UDP socket, errors will not be reported prior to an attempt to write
or read data on the socket.
AT+USORD=?
Reads the specied amount of data from the specied socket, like the BSD read routine. This command can be used to know the total
amount of unread data.
AT+USOCL=?
Closes the specied socket, like the BSD close routine. In case of remote socket closure the user is notied via the URC.
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
14

Cat M1 / NB-IoT Modem
NWK030
Troubleshooting
U-blox provides a GUI program (https://www.u-blox.com/en/product/m-center) to send AT commands to the modem if using PuTTY
becomes too dicult.
For network Connectivity issues, a SIM swap using a known good SIM should suce in troubleshooting if the SIM or modem is at fault.
When putting in a new SIM, use the AT commands above to check APN, Number, ICCID, and do a connectivity test.
If a known good SIM doesn’t x the issue, loading the default values for the card may also aid in troubleshooting.
AT&V
Display the default values
AT&F
Load the default values
Using the above commands followed by a system reset should help with troubleshooting issues with the modem + SIM.
Check Internet Connectivity (TCP)
This test sends a TCP packet to u-blox’s test server and then reads the return followed by closing the socket.
• TCP - Create socket and then open it
• AT+USOCR=6
• AT+USOCO=0,”195.34.89.241” ,7
• AT+USORD=0,32
• AT+USOCL=0
Known Limitations
The NWK030 will not have a cellular network connection that the Operating System’s network managing application can use. This
means that you can not select the “Cellular” network option from the system tray and then open a browser and begin browsing the
web. An application must be developed by you to interface with the modem and transfer data.
NWK030 requires SIM cards specic to Cat M1 and NB-IoT networks. Standard 4G/LTE SIM cards, even the same form factor, may not
function in this cellular modem.
The NWK030 is intended to use applications developed by the user to interface with the modem and do data transfers. By
the nature of Cat M1 / NB-IoT operating systems will not be able use the connection directly (i.e. Network Managers).
Code Examples & Other Useful Resources
To learn more about how to congure the product for specic uses and advanced functionality, visit OnLogic’s technical support
website at: https://www.onlogic.com/support/.
US Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
EU Oce
Phone: [phone]
Email: [email protected]
www.onlogic.com
15
