Paradyne 6310 User manual

1
Hotwire®ReachDSL™v1 (MVL®) Modem,
Model 6310-A4, with Inline Phone Filter
Installation Instructions
Document Number 6310-A2-GN12-00
September 2001
Contents
Hotwire 6310 ReachDSL v1 (MVL) Modem Overview .................................. 1
Getting Started .............................................................................................. 4
Installing the Hotwire 6310 ReachDSL v1 Modem ....................................... 5
Power-On ...................................................................................................... 8
Troubleshooting ............................................................................................. 9
HomeLink (for ReachDSL v1 Modems Only) ................................................ 10
Increasing the Number of End-User Systems .............................................. 10
Cables & Connectors .................................................................................... 11
Optional ReachDSL Modem Wall Placement ............................................... 13
Technical Specifications for Hotwire 6310 ReachDSL v1 Modem ................ 15
Important Safety Instructions ........................................................................ 16
Warranty, Sales, Service, and Training Information ...................................... 21
Hotwire 6310 ReachDSL v1 (MVL) Modem Overview
The Hotwire®6310 ReachDSL™version 1 (formerly MVL®) Modem is a component in
the Hotwire ReachDSL System and interoperates with the Hotwire 8310 MVL, or
Hotwire 8312/8314 ReachDSL Card in the DSLAM (Digital Subscriber Line Access
Multiplexer) system. This system provides high-speed Internet or corporate LAN access
over traditional twisted-pair copper telephone wiring.
The ReachDSL technology:

Utilizes an inline phone filter on the ReachDSL modem’s PHONE jack.

Operates over existing copper wire with existing telephone jacks.

Includes a second line pass-through from the ReachDSL modem’s LINE jack to
PHONE jack to accommodate an attached 2-line telephone.

Provides rate adaptive data rates to dynamically adapt and allocate bandwidth to
optimize applications.

2
In addition, the ReachDSL v1 technology:
 Transforms a single copper pair into multiple virtual lines to support multiple
services simultaneously.
 Supports simultaneous multiple access of four ReachDSL v1 modems with up to
254 end-user systems sharing one common WAN interface.
 Features HomeLink, which provides peer-to-peer communications, including print
and file sharing applications (see
HomeLink (for ReachDSL v1 Modems Only) on
page 10).
Hotwire ReachDSL System
Copper pairs run from the central office (CO) to the customer premises (CP) to create
the local loop. The local loop terminates on the customer premises at the demarcation
point.
NOTES:
In this document:
—A telephone is used to represent any equipment that plugs into a phone jack
and uses the POTS line, such as a phone, modem, or fax machine.
—End-user system is used to represent any PC with an Ethernet connection and
ReachDSL-based service.
—RJ11 wall jack is used to represent either an RJ11 or an RJ14 wall jack. The
RJ14 wall jack is used for a phone with two lines.
—Service provider is used to represent any Internet Service Provider (ISP) or
remote LAN access provider.
01-17005
Customer Premises (CP)
DSL/POTS
Ethernet
Crossover
Cable Ethernet
Cable
or
Central
Office
(CO)
Local Loop
Hub
DSL –Digital Subscriber Lines
POTS –Plain Old Telephone Service
End-user
Systems
(up to 32)
Network
Service
Provider
(NSP)
Demarcation
Point
ReachDSL
Modem

3
Phone Filter
Depending on the type of phone handset and the quality of the home or business wiring,
a phone filter is recommended to minimize background noise during a phone
conversation. An internal phone filter is included with the Hotwire 6310 ReachDSL v1
Modem. If additional telephones are used on the same phone line as the ReachDSL
modem, install one phone filter on each telephone.
There are two Hotwire phone filters:
 Hotwire 6035 Universal Phone Filter is designed for use with a tabletop phone.
 Hotwire 6040 Universal Wall Jack Phone Filter is designed for use with a wall
phone.
Product-Related Documents
To install a phone filter, refer to the appropriate document:
Contact your sales or service representative to order additional product documentation.
Paradyne documents are available on the World Wide Web at www.paradyne.com.
Select
Library → Technical Manuals → Hotwire DSL Systems.
Document
Number Document Title
6035-A2-GN11 Hotwire 6035 Universal Phone Filter Installation Instructions
6040-A2-GN11 Hotwire 6040 Universal Wall Jack Phone Filter Installation
Instructions
PHONELINE
ETHERNET
POWER
PHONELINE
ETHERNET
POWER
01-17006
RJ11
Wall Jack
RJ11
Wall
Jack
ReachDSL Modem
Customer
Premises (CP)
FAX
ReachDSL
Modem
6035
Phone Filter
6040
Wall Jack
Phone
Filter

4
Getting Started
Before beginning your modem’s installation, make sure that you have all the equipment
that you need.
Package Checklist
Verify that your package contains the following:
❑Hotwire 6310 ReachDSL v1 Modem
❑DSL interface cable with RJ11 connectors
❑Power cord with power transformer
Be sure to register your warranty at www.paradyne.com/warranty.
Wiring and Cables You Need
The following wiring and standard connectors are used with this product:
❑Standard RJ11 (or RJ14) wall jack for the ReachDSL modem cabling.
❑Standard Ethernet 8-pin, non-keyed modular plug for a PC or workstation. An
Ethernet straight-through or crossover cable is used.
—Refer to Installing the Hotwire 6310 ReachDSL v1 Modem on page 5 for
Ethernet installation details.
—Refer to Cables & Connectors on page 11 for ReachDSL modem and Ethernet
cable pin assignments.

5
Installing the Hotwire 6310 ReachDSL v1 Modem
Place the ReachDSL modem on a flat surface with clearance for the rear connectors.
Procedure
1. If a telephone is connected at the RJ11
wall jack where the modem will be installed,
unplug the telephone line from the wall jack.
2. Connect a telephone to the modem.
(Optional –go to Step 3 if you are not
connecting a telephone to the ReachDSL
modem.)
Plug the existing telephone interface cable
that was unplugged in Step 1 into the jack
labeled PHONE.
3. Use the supplied RJ11 6-pin interface cable for theLINE connection. Insert one end
of the cable into the jack labeled LINE. Insert the other end of the cable into the
RJ11 wall jack.
NOTE:
If you are installing a POTS splitter with another telephone, connect the
telephone to the jack labeled PHONE, then connect the jack labeled LINE to a
wall jack. Do NOT plug any cable into the POTS splitter jack labeled either
MODEM or DSL. In particular, make NO connections between a POTS splitter
and the modem.
01-17015a
RJ11
Wall Jack
01-17015
RJ11
Wall Jack
PHONE LINE
ETHERNET
POWER
RJ11
6-pin
Interface Cable
PHONE LINE

6
4. Use an 8-pin Ethernet cable for the Ethernet connection. Insert one end of the cable
into the jack labeled ETHERNET.
—Use a straight-through cable and connect the other end to an Ethernet hub.
(To connect to a hub’s Uplink connection, use an Ethernet crossover cable).
–or–
—Use an Ethernet crossover cable and connect the other end to a PC with an
Ethernet Network Interface Card (NIC) installed.
PHONE LINE
ETHERNET
POWER
01-17008
Ethernet
Line
Ethernet
Hub
87654321
Ethernet
Straight-Through
Cable
01-17009
Ethernet
Line
PC with Ethernet
Network Interface
Card
Ethernet
Crossover
Cable
PHONE LINE
ETHERNET
POWER

7
5. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the
transformer into an AC outlet.
The ReachDSL modem hardware installation is now complete. When the power cord is
installed, the ReachDSL modem goes through a power-on self-test.
PHONE LINE
ETHERNET
POWER
01-17010
Power
Jack
Transformer
or

8
Power-On
When power is applied, the ReachDSL modem performs self-diagnostics and the PWR
LED is on. The self-diagnostics includes a power-on self-test and all of the LEDs turn on
for one second.
Status LEDs
All of the LEDs turn on and off during the power-on self-test. After a successful self-test,
the LEDs should appear as indicated in BOLD in the Condition column below.
Refer to
Troubleshooting on page 9 for LED indications requiring action.
LED Condition Status
PWR ON ReachDSL modem has power.
ALM OFF
ON
No active alarms.
An alarm condition exists.
TST OFF
ON
No active tests.
The TST LED is on during the power-on self-test and
during a test initiated by the service provider.
LINE ON
OFF
The DSL link is active and ready to transmit and receive
data.
The DSL link has not been established.
TX/RX ON
OFF
Data transmission is in progress on the DSL line.
The modem is not transmitting or receiving data.
ETHERNET ON
OFF
The Ethernet connection to the Ethernet hub or PC is
active.
No Ethernet 10BaseT device is detected.
ReachDSL
TST LINE ETHERNET ALMPWR TX/RX
01-17003
Power –green
Alarm –red
Test –yellow
Transmit/Receive –green
Ethernet Link –green
DSL Line –green

9
Troubleshooting
LED Symptom Action
All LEDs are on. If LEDs remain on after ten minutes, the modem is not
functional. Contact the service provider.
ALM LED remains
on. The power-on self-test may have failed. Unplug the unit and reapply power. If the alarm LED is still on, contact the service
provider.
ALM and TST LEDs
are blinking. Firmware download may be in progress. If firmware download is not in progress or the LEDs continue blinking after ten minutes,
contact the service provider.
Ethernet LED is off. Verify that the Ethernet cable is securely installed at both ends,
and at least one PC is connected and powered on.
Verify that the correct straight-through or crossover cable is
installed. Refer to
Installing the Hotwire 6310 ReachDSL v1
Modem
on page 5.
LINE LED is off. Verify that the LINE cable is securely installed on both ends. If
the problem continues, contact the service provider.
Verify that the line has dial tone. If there is no dial tone, contact
the service provider.
LINE LED is on and
there is no data
transmission.
The DSL link has been established but there is no data
transmission. Verify the Ethernet connection. If the problem
persists, contact the service provider.
LINE and Ethernet
LEDs are on and
there is no data
transmission.
The DSL line and Ethernet links have been established but
there is no data transmission. If the problem continues, contact
the service provider.
PWR LED is off. Check that the power cord is securely installed on both ends.
If no LEDs are on, the power supply may be defective. Test the
outlet to verify power. If the problem persists, contact the
service provider.
If other LEDs are on, the PWR LED may be burned out. Unplug
the unit and reapply power; watch all LEDs during the power-on
self-test to verify if the PWR LED is functioning.
TST LED is on. A test initiated by the service provider may be active. Wait five
minutes. If the TST LED does not go off, contact the service
provider.

10
To improve data transmission throughput and minimize background noise during a
telephone conversation, make sure that:
 The Hotwire 6310 ReachDSL v1 Modem is always powered on, even when not in
use, and
 A Hotwire phone filter is installed on every telephone on the same line as the
Hotwire 6310 ReachDSL v1 Modem (see Phone Filter on page 3).
HomeLink (for ReachDSL v1 Modems Only)
HomeLink is a feature that provides peer-to-peer communications for PCs attached to
different Hotwire 6310 ReachDSL v1 modems at the customer premises.
For example, PCs that are not connected to the same physical Ethernet LAN can now
take advantage of the resources of the primary office computer. With the Microsoft
Windows operating system, multiple end-user systems can share resources, including:
 File sharing
 Print sharing
 Secondary computer backup
To enable the sharing of resources and review security considerations, see Microsoft’s
Web site at www.microsoft.com.
In this example of HomeLink, the PC in the family room could use the office printer.
Increasing the Number of End-User Systems
A single end-user system is attached to the Hotwire 6310 ReachDSL v1 Modem by
using an Ethernet crossover cable. To increase the number of end-user systems,
connect all the PCs to an Ethernet hub using a straight-through cable.
On one line, the ReachDSL v1 system provides the capability to use up to four Hotwire
6310 ReachDSL v1 modems and 32 end-user systems in any combination.
PHONELINE
ETHERNET
POWER
PHONELINE
ETHERNET
POWER
01-17012
RJ11
Wall
Jack
ReachDSL v1
Modem
Office
Hub
FAX
Ethernet
Cable Printer
RJ11
Wall
Jack
ReachDSL v1
Modem
Family Room
