Open Technologies NeWay User manual

User Manual
201 7

Neway 1
Neway
This wiki will describe both the settings available to the end user and the ones only accessible by inserting a
password, known only by our dealers, that will enable some features normally hidden from the end users.
The password is: CrE2u=eP
To login as a dealer, launch the software, click on the OEM button in the welcome page and insert the password.
This mode allows to change some advanced options and use the toolbox.
Index
User Manual
1.1. EC marking and Conformity declaration
2.2. Introduction
1.1. Presentation of the machine
2.2. User's Precautionary measures
3.3. Transportation and Storage
4.4. Machine Specification
5.5. Operation
6.6. Emergency Situations
7.7. Decommissioning
8.8. Residual Risk Relating to the machine
ScanWay 1.0
1.1. System Set Up
1.1. PC Minimum Requirements
2.2. Before Installing
3.3. Master License Dongle
4.4. Software Installation
5.5. Software Configuration
6.6. Manual connection to Exocad
2.2. Options Window
1.1. General Options
2.2. CAD Options
3.3. Service Mode
1.1. Scanner's Calibration
4.4. External Software Integrations
1.1. Dental Database and Orthodontic Cad Integration (VDDS)
2.2. Onyx Ceph Integration
Exocad
1.1. Updating the Exocad License and Adding Modules
2.2. Exoscan
3.3. Importing Intraoral Scan Data
1.1. iTero Importer
2.2. 3M Importer
3.3. Trios Importer

Neway 2
4.4. Planmeca Planscan Importer
Advanced Tech Support
1.1. Profile Editor
2.2. OpenToolBox
3.3. Troubleshooting
Maintenance
1.1. Ordinary Maintenance
2.2. Components Replacement
EC CE
WARNING: Article could not be rendered - ouputting plain text.
Potential causes of the problem are: (a) a bug in the pdf-writer software (b) problematic Mediawiki markup (c) table
is too wide
Position of the label on the machine The product label attesting the Ec marking and the serial number of the product
is on the back of the scanner, near the back switch. Conformity Declaration All of our scanners are EC certified.

Intro 3
Intro
This manual refers to the 3D scanner and addresses the users, who, before performing any operation, use or
maintenance, must read and acquaint themselves with the material in the following pages in order to use the
machine correctly, avoiding the improper uses listed later on, before turning the machine on make sure the user is
suitable for the job.
The manufacturer refuses any responsibility for consequences deriving from:
•• Use or installation not contemplated in this manual
•• Disassembly, modifications or replacement of original parts or components with parts or components of different
origin without written agreements with the manufacturer
•• Unsuitable power supply
•• Serious inadequacy of the required maintenance
This manual reflects the technical standing at the time the machine was manufactured and it should not be
considered inadequate because based on new experiences it can be updated. The features and design of this machine
may be modified without any notice, for a constant improvement of the product.
Open Technologies S.r.l. reserve all their rights on this manual, no whole or partial reproduction is allowed
without their written authorization.
Norm References
In drafting this document, we have referred to what is reported in attachment I of Law n. 17 of 27/01/2010,
implementation of the 2006/42/EC Directive. In the planning, construction and realization of the machine a set of
technical norms have been used as reference to meet the requirements of the laws in force on the subject of safety on
the job.

Presentation 4
Presentation
NeWay is a sophisticated 3D optical scanner for the no contact acquisition of three-dimensional shapes.
The technology it uses is called active stereo vision: structured light patterns are projected on the surface of the
object and acquired by two video cameras. As the image belows shows, an object (on the right) is hit by the
projection of light patterns for 3D reconstruction.
Advanced image processing algorithms retrieve depth data of the acquired surface. This approach guarantees high
performances, flexibility and fast execution.
NeWay was specifically created to operate successfully in the dental field. The whole scanning phase is
computerized and is performed with the aid of a rotating table that allows the acquisition of different views of the
object.
Thanks to this system, you can digitize model, dies, impressions, articulators etc, very quickly.
Glossary
•3D scanner – a machine created to acquire 3D images of opaque, solid objects;
•Bedplate – lower supporting structure, composed of screwed on steel plates;
•Rotating table – a support for the objects to be scanned located inside the equipment and having an intermittent,
rotating and tilting movement.
•Optical head – the component housing the optoelectronic components (2 cameras and a DMD projector) which
allow the acquisition of the object surface;
•Electric motor – actuator which rotates the rotating table;
•Electric panel – power device with a sectioning switch;
•Exposed person – any person within the whole or part of the danger zone;
•Operator – those people who have to install, operate, adjust, perform maintenance, clean, repair and transport
correctly the machine having received all the relative instructions and read this manual.
Technical Data

Presentation 5
General Data Standard of Measurement Value
Width mm 500
Depth mm 610
Height mm 540
Weight (empty) kg 18
Elettrical Supply Standard of Measurement Value
Single phase voltage V 230 c.a.
Control voltage V 12 c.c.
Power usage W 58,5
Mains frequency Hz 50
Max amps A 4,72
Phases - 2P+T
Precautions
WARNING: Article could not be rendered - ouputting plain text.
Potential causes of the problem are: (a) a bug in the pdf-writer software (b) problematic Mediawiki markup (c) table
is too wide
The user must: Keep all the fixed, moving protections, in their place, Avoid placing any liquids on the external
structure or nearby, Avoid moving, removing or modifying manually the rotating table; Check the electric switch
periodically, Use properly mounted sockets and do not use damaged or worn cables; Make sure the machine is
unplugged before moving it; Avoid inserting any metal objects, like clips, metal cables or flammable objects like
matches or pieces of paper inside the 3D scanner through the vents; Avoid touching the plug with wet hands; Avoid
connecting to the electric system more devices using just one socket; Avoid placing heavy objects on the electric
cable, bending it, pulling it or twisting it; Insert the plug all the way in; Connect to the scanner only grounded
devices; Put back in their place all the danger, warning and requirement signs that might come off. The manufacturer
declines any responsibility arising from accidents caused by the partial or total removal of these protection devices.

Trasport 6
Trasport
The buyer’s personnel can install the 3D scanner in the operating area after reading this manual.
As soon as the buyer receives the machine, he/she will have to check that the components have not suffered any
damages during transport, if any are noticed he will have to notify the carrier and the manufacturer immediately.
The scanner is in a protective cover made of a foam polystyrene shell placed inside a cardboard box.
When using the machine for the first time special attention must be paid to anything that might seem to have an
irregular operation and, if the case, contact Open Technologies S.r.l. immediately, reporting the anomaly.
Storage Conditions
If the 3D scanner is not installed inside the buyer’s premises but it is stored:
•• outdoors - suitable covers and precautions must be arranged to protect the components of the machine from
weather conditions (rain, snow, fog, humidity etc.).Check periodically for any damages that might take place in
the course of time.
•• indoors - no special precautions are required but just periodically check that the machine is stored correctly and
the environmental conditions below are respected:
TEMPERATURE
( -20 ÷ +45 )°C
HUMIDITY
( 5 ÷ 85 )%
Moving Instructions
Moving can be carried out with the help of trans pallet, trolleys or by hand.
Lifting
We advise the operator to lift the machine holding it by its opposite sides. The operator must pay attention when
lowering the machine onto a surface to avoid injures at the upper limbs.

Specs 7
Specs
Detailed Description of the Machine
The 3D scanner has a solid external structure. All the covers are integral part of the tool and must not be removed or
tampered with in any way so not to compromise the correct functioning of the apparatus.
The power connection and the power switch are on the back of the scanner. The frontal part of the scanner is the
access point to the scanning area framed by the optical head.
The optical head lodges the opto-electronic components for the acquisition of the object surface.
NeWay's optical head comprises two black-white video cameras and a DMD projector. The set up of these three
components allows one single scanning field.
Any other application not present here has not been contemplated by the manufacturer and, therefore, cannot
be performed.
Repairs and/or Safety Devices
The 3D scanner is fitted with external metal panels and plastic covers, which keep electrical parts (feeders) out of
reach.
The electrical motors for the movement system and the projector electric supply work on low voltage (24V).
The manufacturer declines any responsibility arising from accidents deriving from partial or total removal of
the protective panels.
Unauthorized uses of the machine
•• Using the 3D scanner with damaged wires or plugs
•• Using the 3D scanner with open or removed panels
•• The 3D scanner has been designed to work in a controlled light condition. If the scanner is placed under a
strong source of light (like the direct sun) or anyways more intense than the internal light, the best
scanning performances are not guaranteed
•• Do not expose the 3D scanner to the rain nor place it in places where water is present (bathtub, basin, sink
or washtub, wet floor, near a swimming pool or any similar situation).
Noise emission
The noise the machine produces, intended as the level of sound pressure in the workplace, is <80 dB (A).
Vibration, radiations fine particles emitted by the machine
The unit does not emit any vibrations, fine particles and radiation when operating.
Gasses and fumes emitted by the machine
The unit does not emit any gasses and fumes when operating.
Electrical System
See electrical diagram attached.

Operation 8
Operation
Loading
The loading operation of the objects to scan includes:
•• Placing the objects inside the 3D scanner by laying them on the chosen model support, consequently attaching the
support to the magnetic joint at the base of the scanner's opening.
•• Make sure the object is placed inside the scanning area of 120 x 100 mm. The scanning area is placed at a height
of 90 mm from the base of the scanning opening. The model holders and accessories are supplied to reach the
critical scanning height. Take care in using the correct support for each item.
•• Scanning operations start using the management software installed on the computer connected to the 3D scanner.
Do not load the objects when the model holder is mounted on the joint, as to do so the reductor could suffer
damages from the pressure
Do not place objects on the model holders weighing more than 3kg.
The scanner does not work with transparent, light reflecting objects and with black objects.
Controls
Please read the Software Manual [1]] for the controls that the 3D scanner operational software can perform.
Unloading the object
The unloading operation of the object includes:
•• Manually removing the object from the chosen support and consequentially the support from the magnetic joint at
the base of the scanner's opening.
Stopping Measures
You stop the machine by:
•• Switching off the power supply at the mains.
During maintenance operations, it is advisable, for safety purposes, to unplug the machine as well as switching it off.
Unautorized uses of the machine
IT IS FORBIDDEN
•• To operate the 3D scanner if the safety devices supplied with the installation are not present or working.
•• To use the machine outdoors in the rain.
•• To modify or tamper with the machine.
•• To clean during scanning.
•• To carry out ordinary maintenance without unplugging the machine.

ER 9
ER
Fire-fighting equipment
The parts of the machine, which can catch fire, are the electric components (electromotor, projector, cables, feeders).
In all these cases, the best extinguisher is carbon dioxide (CO2) or the ABC powder, keeping in mind that by using
the ABC powder you can permanently damage the electric and electronic components.
Using water is forbidden and it is only allowed when the electricity has been turned off in the whole building.
Using water to extinguish fires is forbidden and it is possible only with the electricity turned off.
Harmful emissions/ dispersions warnings
The only harmful emissions the scanner might produce are:
•• toxic fumes in case of a fire.
Waste
For Ordinary deommisioning, the scanner does not produce any waste.
The disposal of the machine's material, for scrappage purpose, must be performed according to current legislation.
Ordinary
At the end of the work activity, the operator will:
•• remove the objects from the scanning area,
•• press the electric switch,
Scrapping disposal
During scrapping, separate the machine parts according to their material: steel, plastic, electric (cables, connectors)
electronic.
Scrapping operations must start with the disassembly of the plastic covers and then of the components (electromotor,
feeders, video cameras, electronic card drivers).

Risk 10
Risk
RISKS DANGEROUS
AREA
DANGEROUS SITUATION DEALING WITH RISKS
Mechanical hazards caused by:
Crushing Machine's base. Transport and moving. Placing the
equipment on the work surface.
Warnings are in the instruction manual.
Loss of stability/ toppling over of
the machine
Work Station Collaps of the surface supporting
the machine during its positioning
limitation instructions in the instruction manual
Electrical hazards
People coming in contact with
live elements (direct electric
contact).
Electric cables,
metallic base.
Installation, adjustment,
calibration. Testing, maintenance,
cleaning. Event of Cable breakage
Warnings are in the instruction manual.
People coming in contact with
elements that become live in case
of fault (Indirect electric contact).
Metal structure of the
apparatus.
Testing, maintenance, cleaning.
Event of Cable breakage
Test periodically that the grounding system is
efficient and in compliance with the regulatory
guidelines. Test periodically the efficiency of the
safety switches.
Thermal hazards
Burns caused by flames or
explosions and by heat radiation.
Internal Projector or
electronic components
Testing, maintenance, cleaning.
Event of components over-heating.
Follow the indications in the instruction manual.
Radiation hazards
Infrared rays, visible light and
ultraviolet.
Internal Scanning
Area
Normal Use. Event of beamer
projecting unexpected amounts of
light intensity.
Follow the indications in the instruction manual.
Hazards deriving from power
faults or breakage of parts.
Restoring power after an
interruption
Electric Circuit. Accidental Starting, short circuit,
power interruption.
Switch the machine off and on again,
unauthorized use instructions in the manual
External influences on the electric
devices
Electric Circuit. Environmental conditions limitation instructions in the instruction manual

Pc Min Requirements 11
Pc Min Requirements
Recommended Systems
The Computers connected to our scanners have to meet specific requirements.
In order to simplify the choice, we recommend this reference system:
1.1. Dell XPS (with Intel i7)
Minimum Requirements
Software
These are the minimum requirements our software needs:
Component Requirement
Operating System Windows 7/8/8.1/10 (64 bit)
CPU Intel® Quad Core ™ or Better
RAM 8Gb RAM or Better
Minimun required Video Card NVIDIA GeForce GTX 560 Ti or Better
*
NVIDIA GeForce GTX 660 or Better *
NVIDIA GeForce GTX 745 or Better *
Suggested Video Card NVIDIA GeForce GTX 950 or Better *
NVIDIA GeForce GTX 1050 or Better *
The Video Card has important additional requirements:
•• Only NVIDIA GeForce cards are supported by the system
•• The NVIDIA QUADRO line is not supported
• The name scheme for the NVIDIA cards is complex, as specified in this page [1]. To check if a card is better than
another, check the 'Core Config' column of the table. A card with less than 300:40:30 cores is not supported.
Particular attention has to be given to the appendix of the card name. E.g. the GTX 560 Ti is good enough but the
GTX 560M is not.
Scanner Connection
In order to work properly, the scanner needs to be correctly connected to the PC. Make sure to check here-below the
necessary connections for your scanning system.
NeWay scanning system can be connected to a Computer through only 2 cables:
•1 USB 3.0 Port that has to be directly connected to the Computer's motherboard. Only Intel C220 or Better and
Rensas USB 3.0 are supported. Other USB chipsets could not properly work.
•• 1 HDMI Port

Before SW1 12
Before SW1
Before Installing
The scanner's set up procedure is very straightforward. This paragraph describes the operations that need to be
carried out before installing the software.
They are enlisted in an ideal order and, even though it is not strictly necessary to follow such order, it is advisable to
do so:
1.1. Check the Graphic Card's (NVIDIA) drivers
2.2. Check the Windows Updates
3.3. Connect the Scanner
4.4. Configure the screen resolution.
Check the Graphic Card's (NVIDIA) drivers
It is very important to always have the graphic card's drivers up to date to fix possible bugs of the previous version or
to solve compatibility issues. To check if the NVIDIA drivers need to be updated just right click on your desktop and
select NVIDIA control panel.
This window will open:
Here it is possible to gather all the information one needs to know about the NVIDIA graphic card currently mounted
in the computer: the version of the drivers, here 347.52, and the product name, here GeForce GTX 980M.
WARNING! Not all NVIDIA Graphic Cards are supported. We have very specific Computer requirements that have
to be respected
for the software to function.
The list of supported Graphic Cards can be found in the Final User's Wiki at the page [PC Minimum Requirements [1]]”.

Before SW1 13
There are two ways one can update the NVIDIA drivers: the first is to download them directly from the NVIDIA
website and the other is to use the GeForce Experience App.
Update NVIDIA drivers downloading them from the NVIDIA website
Go to the NVIDIA web site and look for the driver's download page (http://www.nvidia.com/Download/index.
aspx?lang=en-us).Insert in the fields the required information about the graphic card, in this case it would be:
Once the new drivers have been downloaded to the computer, install them and reboot the system.
Update NVIDIA drivers from GeForce Experience
Not all costumers already have this app pre-installed, it usually comes with newer NVIDIA drivers and can be found
in the Program List of the Windows Start menu. GeForce Experience is divided into tabs, so the only thing one has
to do to search for new drivers is to open the “Drivers” tab and click on “check for updates”. Once the drivers have
been downloaded, install them and then reboot the system.
Check the Windows Updates
Before installing the software, it is important to check that Windows is fully updated. It would also be convenient to
set Windows' Automatic Updates, just to be sure that the system is updated at any time.
To check if windows needs to be updated just open the start menu and find the Control Panel, then select Windows
Update.
In case there were updates to be installed, the window will present itself as in the following picture:

Before SW1 14
If the number of updates to install is not significant, it is possible to simply click on “Change Settings” in the left list
and set the automatic updates, as in this picture:
In this way, those few updates can be automatically installed when shutting down the system.
However, if there were many updates to install, after setting the automatic updates it still would be necessary to

Before SW1 15
install them and reboot the system before installing the software.
Create your Workstation
Before the installation the 3D scanner must be taken out of the cardboard box and the shock resistant, foam
polystyrene protective shell. Please keep it for the whole guarantee term.
All packing material must be disposed of acording to the law in force.
Clamping/anchorage and vibration damping instructions
The 3D scanner supports must rest on a perfectly horizontal flat surface (leveling the machine). The supporting
surface must be at a certain height from the ground so that the scanning internal surface is between 800 and 1000
mm.
The supporting surface must guarantee the maximum planarity and be able to bear the weight of the machine and of
the scanned objects (18 kg, total mass (daN).
The scanned pieces are:
•• Small plaster elements, representing palate or dental arches impressions;
• Steel “articulator”, dental instrument that simulates jaw movement (2 kg. max weight)
The supporting surface of the 3D scanner must not lodge equipment and machinery that may produce vibrations.
Rest the 3D scanner only on worktops that are stable, resistant and with a surface greater than the base.
Required Space for use and maintenance
The use of the scanner requires the presence of an operator in the following position:
•• Front to place and remove the objects to scan.
•• The adjustments of the working parameters, the start command and processing of the scanned images take place
in a video terminal station located nearby.
The posts for the maintenance of the machine are:
•• Front to clean the work top, bed and outer frame.
Keep at least 100 cm of space around, in all directions, around the machine, in order to be able to perform the
cleaning, maintenance and all the necessary adjustments in total safety and with all the space required.
The 3D scanner has a back opening to release the internal heat, do not obstruct the opening with curtains, paper or by
placing the 3D scanner directly in contact with panels, walls and shelves.
Allowed environment conditions
Environment conditions for a correct functioning of the machine are:
•• temperature 0° between +40°C;
•• humidity between 20% and 80%.
Where the 3D scanner is installed, the room must be free of dust and suspended aerosol.Keep the scanner away from
heat sources, direct sunlight or radiators.< br /> If the 3D scanner has been in a colder place (outdoors or a
warehouse) wait at least two hours before installing the machine in a warmer place – otherwise, condensation can
form which compromises the scanner correct operation.
The 3D scanner must operate away from sources that generate a powerful electromagnetic interference (e.g.: electric
welders, high frequency devices, high voltage cables).< br /> Even though in compliance with all the laws regulating
electromagnetic immunity and that Open Technologies have done everything in their power to immunize the unit
from electromagnetic interference, the scanner is after all a precision electronic device therefore powerful radio
waves may interfere with the scans.

Before SW1 16
Connect the Scanner
As you can see in the following pictures, on the back of the scanner there are, from left to right, the USB port, the
power switch, the power cable port and the HDMI port:
The 3D scanner will be connected to a power supply with these specifications:
•• 1 phase+neutral+ground supply;
•• Voltage 230 V;
•• Frequency 50 Hz;
Moreover, the power line will have to be suitably protected from overloads and short-circuits coming from the mains
mounted on the wall. A line will also be supplied to ground the machine.
The sockets to be used for the machine must be able to bear the electrical intensity required during operation.
The HDMI cable must be connected to the Computer, in the Graphic Card's HDMI port. The location of this port in
the computer may vary according to the Computer's brand and model.
This is the position of the HDMI port in the computers we provide:

Before SW1 17
The Usb cable must be connected directly to the Computer's Motherboard to a USB 3.0 port. The Usb ports are
usually color-coded, and generally the Usb 3.0 ports are marked in blue.
Once everything is connected it is possible to check if the computer recognised the components correctly by opening
windows Device Manager. The Device manager can be easily found using the Windows Search tool.
As displayed here-below, in the section Universal Serial Bus Controllers there is a list of all the USB devices and
image acquisition devices recognised by the Computer:
The devices labelled as NET ICube_cam are the two cameras and the Usb Serial Converter is the control board.

Before SW1 18
Configure the screen resolution
After connecting the scanner it is important to check that the screen resolution has configured in the correct way.
This is necessary because sometimes Windows is not able to properly recognise the configuration of the projector.
First of all it is very important that the projector is connected to the HDMI slot of the graphic card. When the
projector is properly connected right click in the desktop and select “Screen Resolution”. There should be two
monitors: one with a higher resolution, that has to be on the left and has to be the primary monitor, and the other with
a resolution of 1280x800 and on the upper right. Both monitors need to be extended.
The right configuration of the monitors is properly described in the following pictures:

Before SW1 19
