Opti-Med JM032-HA Series User manual

Horizontal Cylindrical Pressure Steam Sterilizer
JM032-HA Series
Model
USER MANUAL
Warning: please read the user’s manual carefully before using the machine.
Hangzhou Jupiter Medical Equipment Co., Ltd
1116, Gudun Road, West Lake District, Hangzhou, China
Tel: [phone] Web: www.opti-med.net
Email: [email protected]
Opti-Med ®

1
Horizontal Cylindrical Pressure Steam Sterilizer
(Autoclave Machine)
General
Saturated pressure steam is used to sterilize article, for it will liberate a great amount of heat
when condensing. To make the articles (need to be sterilized) hot and wet for a certain time,
most resistant bacterial spores will be killed, and then sterilization aim is reached. The method
is reliable, economical, and easy to be controlled, so it has been used for more than one
hundred years.
This unit is ideal equipment for clinics, scientific research institutes and other organizations to
sterilize surgical instruments, fabric glassed, culture media etc.
Features
Capacity: JM032-HA280: 280L (ф600*1000mm)
JM032-HA150: 150L (ф440*1000mm)
Max.work pressure: 0.22MPa
Max.work temperature: 134℃
Temp.range: 105~134℃
Timer range: 0~60min
Heat evenness: ≤1℃
Power consumption: 380V, 50Hz.
Interlock device for safety:
the steam can’t go through to chamber when the door haven’t close, and the pilot off
to inform. You can processing dry operate.
when the pressure inner over 0.027Mpa, the door be lock and not be open.
if you mistake open the door in the course of start, the jacket valve auto off and open
the chamber valve.
if you not choose the sterile time and start the machine, buzzer sound.
lack water the pilot on, heating and sterile pilot off, the buzzer sound and auto release
steam.
overload and leakage protection, when leakage or over current occur, it auto cut off
the power.
temperature controller not work and the inner pressure over 0.165 Mpa, the safety
valve auto start open.
Specifications
The main body is composed of a chamber and steam-jacket with closed double jacket.
The chamber wall will be pre-heated as steam enters and fills the jacket up. A main valve
is connected between the chamber and the jacket, which is turned to “sterilize” position
Opti-Med ®
www.opti-med.net

2
and admit steam from jacket to chamber to make articles moist and heated. The
above-mentioned method ensures requirements for pre-heating, sterilizing, drying and
following operations.
The vaporizer, gauge in front above easy watch, the thermometer on the side, all the
pilots and display in front lower part control box for easy operating. (fig.1)
Fig1
Each letter mark for the role:
pilot display
power------- power start, pilot on.
close door--- pilot on.
start-------pilot on
water in----auto fill the water,the pilot on to high level the pilot off.
heating-----pilot on to sterile temperature the pilot off.
sterilizing-----pilot on to sterilize end the pilot off.
overheat----after heating water lack the pilot on, press emergency stop button or turn
off dealing the error, restart the machine the pilot off.
power switch
turn on the breaker, the machine enter the state of standby.
the knob for setting auto program select.
OVER
TEMP.CONTROL
5050
40
30
20
min 600
40
0 60
min
20
30
1010
TIMER
ENT STOP
POWER
ENTPOWER STERILIZING
HEATINGWATER
DOOR LAMP HEATING
Opti-Med ®
www.opti-med.net

3
sterilizing temperature ( range 105℃~134℃)
sterilizing time (range 1~60min.)
key start
press key start, the auto program sterilizing or dry begin, repeat press useless.
key emergency stop
press the key emergency stop recovered to connect power, vaporizer, and electric
valve open all and release, pilot start, heat, sterilize off, repeat press useless.
The jacket is coated with a cover, in which insulated liner of glass fabric is filled, for the
sake of saving energy, as well as preventing ambient temperature from rising excessively
The door opening mechanism adopts a dial of radial-bar with self-lock and two grade
inter-lock safety devices, first move safety closing handle when you close the door, the
angle 45°with the radial-bar connection center, the radial-bar enter the close position
complete, then turn the handle again, the dial go in axle direction, the center dial be
locked by pin.when the inner pressure over 0.027Mpa, the interlock auto enter to prevent
mistake operation, until the inner pressure lower than 0.027Mpa, interlock device turn
back but the dial keep lock by pin, the handle can be rotate counter clockwise,the center
dial back out in axle way, the seal became useless, the spare steam be release to zero, that
is release the pressure first then open the door,until the handle returned to outer can you
move closing handle and returned radial-bar to open the door.
With program function, it’ll auto release the air and condense to balance the
temperature in chamber.
With the device to stabilizing the steam pressure in the course of heating, the range
0.05~0.15Mpa, related temperature 105~134℃,
With timer device, the range 1~60min. the knob on the panel of the control box.
With high water level device, you push the key start, the pilot water in on, the water auto
enters to the high level of the tank (about 26L)and heating right way, meanwhile the pilot
off.
auto control problem
the steam can’t go through to chamber when the door haven’t close, and the pilot off
to inform. You can processing dry operate.
if you mistake open the door in the course of start, the jacket valve auto off and open
the chamber valve. with mechanic interlock pressure ≥0.027MPa
if you not choose the sterile time and start the machine, buzzer sound.
with lower level protection device, when lack water the pilot on,auto cut off the
power, heating and sterile pilot off, the buzzer sound and auto release steam.
overload and leakage protection, when leakage or over current occur, it auto cut off
the power.the pilot off on panel.
An ordinary lift safety valve connected to the jacket is installed at the
top of the sterilizer. It cannot open to release overpressure steam until
the steam in jacket overpasses set pressure of safety valve. When steam
pressure falls to the normal value, it automatically closes. The set
pressure for safety valve is 0.165 MPa~0.17 MPa (See Fig2)
manual emergency switch valve
lug
Fig2
Opti-Med ®
www.opti-med.net

4
when the unit suddenly break the power and you need take the objects be sterilize
urgent, you can manually turn on the bulb valve on the rear release the pressure,
until the gauge back to zero you can take the objects.
manual maintenance switch valve
When you need clean the vaporizer, you can open the manual valve
at the bottom and release the dirty water.
magnetic valve function:
water-in valve: press key start, it auto fill the water to high level then turn off.
condensation valve: power connect and press key start auto release,heating and
temperature ≤108℃ auto turn on, ≥108℃ auto turn off, press emergency key
release valve: power connect and press key start auto release, after the auto water in
to high level then turn off. Sterilize end, press emergency key auto release on.
sterilize valve: power connect and press key start auto air-in, after the auto water in to
high level,the door haven’t closed turn off, otherwise turn on.sterilize end press
emergency key auto release on.
Installation
for installation. More floor space around the sterilizer is set aside for operating and
repairing. The Min. Installation size for single door 200×93×182cm, for double doors
200×93×182cm.(see fig.3)
Fig3
electric type single door installation
Opti-Med ®
www.opti-med.net

5
Connect inlet with tap water supply and outlet with drain pipelines so as to make daily
operation simpler.
Extend exhaust pipe outside to avoid vapor throughout inside, so as to affect operation
inside.
During sterilizing, condense will be discharged through the condense ejector. It is
suggested that a cone-shaped funnel is supplied to join the exhaust pipe and drain pipe.
Thus the drainage of condense may be easily observed, as well as prevent drain flowing
back, in case of drain line clogged.
The unit has been fully inspected before leaving the factory, but after installation by users,
training should be performed according to manual instructions. In case that anything
abnormal occurs, it should be resolved until the unit is in operation.
Operation
Operation procedures:
manual operation
connection water----- trun on the water source
connection the power-----pilot display
Pile --------The articles (to sterilize) should be well packed and separated certain
distance from each other in chamber, so as to leave free passage for steam. Dressing
package cannot be close to chamber door, otherwise condense drops along door into
dressing and prolongs drying time. In general dressing package should be no more
than 20×20×10cm, otherwise the period of sterilizing time would be prolonged .If
sterilize solution, pour it into a rigid heat-resistant flask, do not exceed 3/4
containment of the flask. Stuff mouth with cotton and gauze, and bind it with yarn.
Be sure not to use a non-perforated rubber stopper or cork, or the flask will be broken.
Put the flask onto a larger enamelware or metal tray, in case the explosion of the
bottle occurs, the liquid won't flow away to pollute and damage the inside of the
sterilizer.
Close the door, turn the safety handle clockwise to the center position, to make radial
arms into the door ring, then turn the octagonal hand wheel clockwise along axis, till
the door is steam-tight (Avoid over-tightening or it will shorten the life of the door
gasket). Then the door close indicator lights. Solenoid valve is closed so that steam
pipelines admit the steam into chamber. For the double-doors unit, till both the front
and the back doors are all closed, then the door close indicator lights.
Preset Sterilizing Time:
The customer can preset the required sterilizing time (see form 1) according to
following table. Turn the timer knob on the time line you wanted clockwise. When it
reached the preset temperature, the pilot of time light, the timer start to count
automatically.
Reference table to sterilization time and temperature ( form I)
1. Sterling temperature（105℃~134℃）
2. Sterling time (1~60min)
Rotate of counter clockwise,
the pressure and temperature high
in the sterilizing room
Fig4
Opti-Med ®
www.opti-med.net

6
Objects
Required heat
preservation time
(min)
Steam Pressure
Mpa
Relative steam
Temperature ℃
Rubber goods
15
0.1 – 0.11
121
Surgical dressings
15 - 20
0.1 – 0.22
121– 134
Utensils
8
0.1 – 0.22
121– 134
Instruments
10
0.1 – 0.22
121– 134
Solution in flasks
20 - 40
0.1 – 0.145
121– 126
setting fulfill---- press key SET. Pilot door,start, water-in on. Auto water-in to high
level and the pilot off, and heating pilot on, this time you press start the buzzer sound
to inform you setting temperature and time.
Press key start----- sterilizing begin.
End---- buzzer sound, when the inner gauge show zero, open the door the buzzer
stop.
At the end of the sterilization period, in case of rapid decrease in pressure of chamber,
solution or culture media in flasks would boil over or be spoiled. Therefore, turn the
main valve knob to “slow exhaust” position to release the steam in the chamber
slowly. Also cut off steam supply, let pressure and temperature in chamber drop
naturally. Another way is provided to turn pressure adjustment switch to
“close ”position till chamber pressure gauge is reduced to “0”. Wait a few minutes
after main valve is turned to “slow exhaust”, door can be opened.
By reaching the rating pressure, the sterilizing lamp will be on, and the timer would s
tart to count down. After counting to the zero, the buzzer would go off to remind the
end of the sterilizing. The unit would automatically exhaust the air, and pay attention
that don’t open the door till the needle of the pressure gauge point to zero. Open the d
oor a little for about 5~10 cm, and the objects can be fetched in 20~30 mins.( the po
wer could be shut off when the door is open)
auto program control
auto water-in,( from tap to main tank)-----heating ( auto release the
condense)-----sterilizing(timing)------exhaust steam-----end
auto display pilot indicator in sterilizing processing
power pilot on----door pilot on----start pilot on----water in pilot on(high level
off)----heating pilot on----sterilizing pilot on (heating pilot
flash)----heating,sterilizing pilot off,buzzer sound---- open the door the pilot off,
buzzer stop.
dry fully auto program
after sterilize time, according different demand , be drying by the jacket,and
meanwhile open the door around 40~50mm for cooling.
manual operation ( setting program select)
1. Sterilizing temperature 134℃
2. Sterilizing time 1~60min.
dry auto program control
Opti-Med ®
www.opti-med.net

7
heating(auto release the condense)----drying(timing)----end
auto display pilot indicator in drying processing
power pilot on---- start pilot on---- heating pilot on---- sterilizing pilot on (heating
pilot flash)---- heating,sterilizing pilot off
Notice
Do not sterilize different articles at the same time, such as dressing and solution or the
same article but has different sterilization requirements
Check the water level indicator before using the unit, see whether it has sufficient water
in tank, if not, add more water when the water level below water line, adding water must
in no pressure state.
if alarm pilot for the water level on, it’ll auto exhaust the steam, press emergency key
or turn off the power then restart the power,the adding water going on, this time the
pilot off, then press key start to going on the heating.
If you want adding water in the standby,press emergency key, the machine recover to
the state of connect power, vaporize & magnet valve open to release, pilot
start,heating and sterilize off, press repeat useless. Thus it auto adding the water and
going on heating.
The handle of safety valve draw up 1-2times per week,make it smoothly.
Electric connector should tighten often to prevent loose and overheat.
Keep the sterilizer clean and dry, particularly if not used for a certain period of time,
please clean up for the purpose of no rust. And lubricate the active parts regularly.
The unit should be operated in normal conditions, as well as periodically checked and
maintained by professional personnel.
Operating regulations should be set up beside the unit, for the convenience of reference
and conformance.
Protective earth should be provide to ensure safety.
In the course of sterilizing, if the safety gauge release,means the jacket pressure over the
working pressure, you should inspect the pressure controller gauge and safety valve.
Maintenance
Gasket:
The door gasket of rubber should be replaced timely, if steam leakage occurs.
Pressure gauge:
If pressure gauge pointer doesn’t return to “0” or reading isn’t accurate, repairs should be
made and then see if it up to standard pressure gauge. If not, replace it with new one.
Thermometer:
There are one thermometer, equipped in condenser outlet at the bottom of chamber, for test
the temperature between condensate and chamber ,If temperature difference of them is large
and the mercurial thermometer is in good order, the dial one should be repaired and checked.
Pressure controller:
It is equipped with temperature pressure controller preset: 0.05MPa,~0.15Mpa, after be using
Opti-Med ®
www.opti-med.net

8
for a period and large difference please replace.
(form 2）
Electric-thermal tube
There are three U-shape electric-thermal tubes at the bottom of water tank. each 3KW for
AC380V three phase /AC110V(single phases).The unit input of power supply should conform
to nameplate.
Breakdown
Possible cause
Removes method
Required temperature in the
chamber can’t be reached
Dirt accumulated
between the seats of
the valve
Unscrew the cover, clean the
ejector
The front part to the
elector blocked
Dredge it
The temperature in chamber
rises too slowly, A great
quantity of steam leaks out
Distance between top
and seat of the valve
is wide
Fine adjust the temperature
controller on the bottom of
control box
Opti-Med ®
www.opti-med.net
