OPN-3102i Bluetooth Quick Start Guide
OPN-3102i
Function Key
Status LED
USB Connector (Data/Charging)
Feedback Buzzer
Scan Key
2D Imager
USB Data
Enabled
Disabled
SPP
(Serial Port Profile)
HID (Most Common)
(Human Interface Device)
Bluetooth Mode
MFi
(Made for iDevice)
Note: Apple MFi mode requires the OPNTerm application which is available for download from the Apple App Store.

Bluetooth Options
• Bluetooth-HID - This connection mode is the most common and is normally supported by host devices
(computers, tablets and smartphones). Bluetooth-HID mode works as if a Bluetooth keyboard were
attached to the host device. This means that all data scanned will be as if typed. It is important that
there is a blinking cursor ready to accept your scanned data. Any text field is a valid place to scan a
barcode.
• Bluetooth-SPP - This connection mode can be complicated and is only recommended for advanced
users or users who have a dedicated application that manages connections to the scanner. It may also
be necessary when pairing with older host devices that do not support Bluetooth-HID mode.
• Apple MFi - This Bluetooth mode is a serial connection mode similar to Bluetooth-SPP though in
a proprietary format devised by Apple. It allows two-way communication with the scanner from
an iOS application that implements Opticon’s iOS SDKs (an example of which is called OPNTerm
which can be downloaded from the Apple App Store). The associated APIs allow iOS developers to
create their own OPN-3102i applications or integrate the OPN-3102i into their existing application.
Please contact support@opticonusa for the SDK
• Feedback Options
• Vibrate Only - The OPN-3102i will only vibrate to alert the operator of a successful scan.
• Buzzer Only - The OPN-3102i will only beep to alert the operator of a successful scan.
• Buzzer & Vibrate - The OPN-3102i will both beep and vibrate to alert the operator of a successful scan.
Bluetooth Disconnect / Reconnect
• When connected, a Bluetooth connection can be broken by holding the trigger key for 5 seconds. This
will prolong battery life in some situations.
• When disconnected, a Bluetooth connection can be reestablished by holding the trigger key for 3
seconds. Barcode data stored when disconnected will be automatically transmitted.

Step 1 - Scan Bluetooth-HID(Keyboard)
Step 2 - Turn on Bluetooth and NFC in your mobile device
settings
Step 3 - NFC Symbol
Tap the NFC symbol on the back of the scanner to the NFC symbol on
the back of the device (location of the NFC chip) When the connection
is initiated, you will hear a chirp and the scanner’s LED will start flashing
blue.
• If you do not have an NFC symbol, simply rub the scanner over
the back of the scanner until a chirpping sound is made and the
scanner LED starts flashing blue.
Step 4 - Connection
If the connection is new, you will receive a pair request, tap yes. On newer Android
8.0 device, you are done. if you have an older OS verrsion, see step 5.
Step 5 -Devices 6.0.1 or earlier
For devices running 6.0.1 or earlier, you will likely receive “failure to connect” The
scanner is currently paired, but the connections need to be finished manually.
• While the scanner is still flashing blue, navigate to your Bluetooth settings.
• Tap the name of the scanner under “Paired Devices”
Step 6 - Connected
At this point your OPN3102i should be connected to your mobile device in
Bluetooth-HID (keyboard) and is ready to start scanning
NFC Pairing to Android
Bluetooth-HID (Keyboard)

Feedback
Beeper Only
Vibrate Only
Beeper & Vibrate
USB Data Options
• Enabled (Default) - This feature allows the data stored on the OPN-
3102i to be transferred to an attached computer. Data is stored when
the Bluetooth connection goes out of range or is otherwise interrupted.
Stored data is automatically transmitted to the host device upon
reestablishing the Bluetooth connection. The Bluetooth connection mode
also determines the USB connection mode. Bluetooth-SPP and Apple MFi
modes will connect as USB-VCP (serial port) devices while Bluetooth-HID
mode will result in an USB-HID (keyboard) connection.
• Disabled - In this mode, the USB connector is used only to charge the
OPN-3102i.
iOS Keyboard
• iOS On - This feature is a companion feature to Bluetooth-HID and is
intended for use with any Apple iDevice (iPhone, iPad and iPod) that has
an on-screen keyboard. With this feature, the on-screen keyboard can
be toggled on and off by use of the function key on the OPN-3102i. The
typical behavior for an iDevice is to hide the on-screen keyboard when a
Bluetooth keyboard is paired (as the OPN-3102i effectively is). Note that
this feature is not used in Apple MFi mode.
Defaults
Reset App Web Address
OPNTerm
None

0
1
2
3
4
5
6
7
8
9
PINE
Quick Start Instructions
Step 1 - Scan Bluetooth Mode
Scan the Bluetooth Default barcode that matches the connection
method you wish to use, HID (recommended), SPP or Apple MFi.
If you are pairing on an Apple iDevice, the on-screen keyboard can be
toggled with the OPN-3102i’s function key.
Step 2 - Hold the Function Key for 3 Seconds
Hold the OPN-3102i’s function key for 3 seconds until it makes a
short buzzer sound and begins to flash blue. The OPN-3102i is now
discoverable by your host device. This can be cancelled at any time by
holding the function key for another 3 seconds.
Step 3 - Perform Bluetooth Search on Host
Use the Bluetooth interface on your host device to search for and select
the OPN-3102i. The OPN-3102i will beep to indicate success or failure.
If you are pairing in Bluetooth-SPP or Apple MFi mode, the OPN-3102i
will complete the pairing process as soon as you launch an appropriate
application (i.e. OPNTerm for iDevices) and open the serial port created
by your Bluetooth software. If your host device does not support Simple
Pairing, then you may use the barcodes at left to input a PIN code.
SPP PIN code: input 1234 into host device
HID PIN code: Scan “PINE” from the “PIN code input” menu
For information about your OPN-3102i, including detailed setup
instructions, downloads and more, visit us at:
www.opticonusa.com/start/opn
