Optimus CTR-107 User manual

Cat. No. 14-1112
OWNER’S MANUAL
Please read before using this equipment.
CTR-107
Portable Cassette
Tape Recorder
14-1112.fm Page 1 Thursday, July 1, 1999 1:05 PM

2
FEATURES
Your Optimus CTR-107 Portable Cassette Tape Re-
corder has a lightweight, portable design that makes
it perfect for recording lectures, interviews, business
meetings, and speeches.
The recorder’s voice activation feature lets you set
the recorder to automatically record only when itpicks
up sound. This saves room on your cassette tape,
conserves battery power, and lets you record without
manually stopping the recorder whenever a long
pause or break occurs.
The recorder also includes these features:
Built-In Condenser Microphone — provides good
quality recordings.
Built-In Speaker — lets you listen to your recordings
without connecting an earphone.
Cue/Review — lets you listen to recordings at a high
speed to help you find a particular section.
© 1997 Tandy Corporation.
All Rights Reserved.
Optimus is a registered trademark
used by Tandy Corporation.
RadioShack is a trademark used by
Tandy Corporation.
14-1112.fm Page 2 Thursday, July 1, 1999 1:05 PM

3
Tape Counter — helps you quickly locate a specific
section on the tape.
Automatic Level Control (ALC) Circuit — automat-
ically adjusts to the proper recording level.
Auto Stop — automatically stops the recorder when
the tape reaches the end during playback or record-
ing.
Pause Control — lets you edit as you record.
Three Power Sources — let you power the recorder
using four AA batteries, a standard AC outlet (with an
optional AC adapter), or your vehicle’s cigarette-
lighter socket (with an optional DC adapter).
Built-In Carrying Strap — lets you easily carry the
cassette recorder anywhere you go.
Supplied Earphone — lets you listen in privacy.
Erase Plug — lets you erase a tape without record-
ing any sound over it.
MIC Jack — lets you connect an optional external mi-
crophone.
14-1112.fm Page 3 Thursday, July 1, 1999 1:05 PM

4
CONTENTS
Preparation ........................................................... 5
Connecting Power ........................................... 5
Using Internal Batteries ............................ 5
Using AC Power ....................................... 8
Using Vehicle Battery Power .................. 10
Using the Earphone ...................................... 12
Listening Safely ...................................... 12
Traffic Safety .......................................... 13
Operation ............................................................ 14
Loading a Cassette Tape .............................. 14
Playing a Cassette Tape ............................... 16
Using Fast-Forward/Rewind ................... 18
Using the Tape Counter ......................... 19
Recording ...................................................... 20
Using an External Microphone ............... 22
Tape Tips ....................................................... 24
Recommended Tapes ............................ 24
Erasing a Cassette Tape ........................ 24
Preventing Accidental Erasure ............... 25
Restoring Tape Tension and
Sound Quality ........................................ 27
Maintenance ........................................................ 28
Cleaning the Tape-Handling Parts ................ 30
Specifications ..................................................... 33
14-1112.fm Page 4 Thursday, July 1, 1999 1:05 PM

5
PREPARATION
CONNECTING POWER
You can power the CTR-107 from any of three power
sources:
• Internal batteries
• Standard AC power (with an optional AC
adapter)
• Your vehicle’s cigarette-lighter socket (with an
optional DC adapter)
Note: Connecting an adapter disconnects internal
batteries.
Using Internal Batteries
You can power the CTR-107 from four AA batteries
(not supplied). For the best performance, we recom-
mend alkaline batteries, such as RadioShack Cat.
No. 23-557.
You can also use rechargeable nickel-cadmium bat-
teries (Cat. No. 23-125) with a battery charger (Cat.
No. 23-133).
14-1112.fm Page 5 Thursday, July 1, 1999 1:05 PM

6
Follow these steps to install batteries:
1. Press down on the battery compartment cover
and slide it off in the direction of the arrows.
2. Install the batteries as indicated by the polarity
symbols (+ and –) marked outside the compart-
ment.
Cautions:
• Use only fresh batteries of the required size
and type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or re-
chargeable), or rechargeable batteries of dif-
ferent capacities.
• Always dispose of old batteries promptly and
properly.
14-1112.fm Page 6 Thursday, July 1, 1999 1:05 PM

7
• Never leave dead, old or weak batteries in the
CTR-107. Batteries can leak chemicals and
corrode or damage electronic circuits.
3. Replace the cover.
Notes:
• If you plan not to use the CTR-107 for a week or
more, or you plan to use an AC or DC adapter,
remove the batteries to protect the CTR-107
from possible battery leakage.
• When the RECORD/BATT indicator becomes
dim during operation or does not light when you
turn on the recorder, replace the batteries.
14-1112.fm Page 7 Thursday, July 1, 1999 1:05 PM

8
Important: Your recorder is capable of using re-
chargeable nickel-cadmium batteries. At the end of
the batteries’ life, they must be recycled or disposed
of properly. Contact your local, county, or state haz-
ardous waste management authorities for information
on recycling or disposal programs in your area. Some
options that might be available are: municipal curb-
side collection, drop-off boxes at retailers such as
your local RadioShack store, recycling collection cen-
ters, and mail-back programs.
Using AC Power
To power the CTR-107 from an AC outlet, you need
an AC adapter (not supplied), such as Cat. No. 273-
1663 or 273-1664.
Cautions:
• The recommended AC adapter supplies 6 volts
and delivers at least 300 millliamps. Its center tip
is set to negative, and its plug correctly fits the
DC 6V jack on the CTR-107. Using an adaper
that does not meet these specifications could
seriously damage the CTR-107 or the adapter.
14-1112.fm Page 8 Thursday, July 1, 1999 1:05 PM

9
• Always plug the AC adapter into the CTR-107
before you plug it into the AC outlet, and unplug
the AC adapter from the AC outlet before you
unplug its barrel plug from the CTR-107.
Follow these steps to connect the CTR-107 to AC
power.
1. Set the adapter’s voltage switch to 6V.
2. Insert the adapter’s 5.5 mm outer diameter/2.1
mm inner diameter barrel plug into the adapter’s
cord so it reads –TIP.
3. Insert the AC adapter’s barrel plug into the DC 6V
jack on the CTR-107.
4. Plug the AC adapter into a standard AC outlet.
14-1112.fm Page 9 Thursday, July 1, 1999 1:05 PM

10
Using Vehicle Battery Power
You can power the CTR-107 from your vehicle’s ciga-
rette-lighter socket using a DC adapter (not supplied),
such as Cat. No. 273-1802.
Cautions:
• The recommended DC adapter supplies 6 volts
and delivers at least 300 milliamps. Its center tip
is set to negative, and its plug correctly fits the
CTR-107’s DC 6V jack. Using an adapter that
does not meet these specifications could dam-
age the CTR-107 or the adapter.
• Always plug the DC adapter into the CTR-107
before you plug it into the cigarette-lighter
socket, and always unplug the adapter from the
cigarette-lighter socket before you unplug it from
the CTR-107.
14-1112.fm Page 10 Thursday, July 1, 1999 1:05 PM

11
Follow these steps to connect the CTR-107 to vehicle
battery power.
1. Set the DC adapter’s voltage switch to 6V.
2. Insert the adapter’s barrel plug into the CTR-
107’s
DC 6V jack.
3. Plug the adapter’s larger plug into the vehicle’s
cigarette-lighter socket.
14-1112.fm Page 11 Thursday, July 1, 1999 1:05 PM

12
USING THE EARPHONE
To listen in privacy, insert the supplied earphone’s 1/8-
inch plug into the EAR jack.
Note: Connecting the earphone automatically discon-
nects the built-in speaker.
Listening Safely
To protect your hearing, follow these guidelines when
you use the earphone.
• Set the volume to the lowest setting before you
begin listening. After you begin listening, adjust
the volume to a comfortable level.
• Do not listen at extremely high volume levels.
Extended high volume listening can lead to per-
manent hearing loss.
14-1112.fm Page 12 Thursday, July 1, 1999 1:05 PM

13
• Once you set the volume, do not increase it.
Over time, your ears adapt to the volume level,
so a volume level that does not cause discomfort
might still damage your hearing.
Traffic Safety
Do not wear the earphone while operating a motor
vehicle or riding a bicycle. This can create a traffic
hazard and is illegal in some areas.
Even though some earphones are designed to let you
hear some outside sounds when listening at normal
volume levels, they still present a traffic hazard.
14-1112.fm Page 13 Thursday, July 1, 1999 1:05 PM

14
OPERATION
LOADING A CASSETTE TAPE
Note: Metal tapes are not recommended for use with
this cassette player.
1. Take up any slack in the tape by turning one of
the cassette’s hubs with a pencil. Do not touch
the tape.
Caution: If you do not remove the excess slack,
the tape might become tangled in the record/
playback mechanism.
14-1112.fm Page 14 Thursday, July 1, 1999 1:05 PM

15
2. Press STOP/EJECT to open the cassette com-
partment door.
3. Load the cassette with its open edge out, the
side you want to play facing up, and its full reel to
the left.
4. Close the door.
14-1112.fm Page 15 Thursday, July 1, 1999 1:05 PM

16
PLAYING A CASSETTE TAPE
1. Load the cassette tape.
2. Press PLAY. The cassette plays until it reaches
the end of the side, then it automatically stops.
Note: Press PAUSE to temporarily stop playback.
Press PAUSE again to resume playback.
14-1112.fm Page 16 Thursday, July 1, 1999 1:05 PM

17
3. Adjust VOLUME as desired.
4. Press STOP/EJECT to completely stop playback
before it automatically stops. Press STOP/EJECT
again to open the cassette compartment and
remove the cassette tape.
14-1112.fm Page 17 Thursday, July 1, 1999 1:05 PM

18
Using Fast-Forward/Rewind
While the tape is stopped, press REVIEW/REWIND or
CUE/FAST-F to rapidly wind the tape backward or for-
ward. Press STOP/EJECT, then PLAY again to resume
playback.
If you press and hold down REVIEW/REWIND or CUE/
FAST-F while the tape is playing, you can hear the
tape as it moves at a faster speed. This makes it easy
to locate a specific part of a recording (such as the
space between tracks). When you release REVIEW/
REWIND or CUE/FAST-F, the tape plays at its normal
speed.
14-1112.fm Page 18 Thursday, July 1, 1999 1:05 PM

19
Using the Tape Counter
You can use the tape counter to help you find specific
locations on the tape.
At the beginning of a tape, press the reset button to
reset the tape counter to 000. Then note the
counter’s reading at the beginnng of each selection.
To return to a selection, fast-forward or rewind the
tape until the counter shows the noted reading.
14-1112.fm Page 19 Thursday, July 1, 1999 1:05 PM

20
RECORDING
Notes:
• Before you load a cassette tape for recording, be
sure its erase-protection tabs are in place (see
“Preventing Accidental Erasure” on Page 25).
• The recorder’s Automatic Level Control (ALC)
circuit automatically adjusts the recording level.
VOLUME has no effect on recording.
1. Load a blank cassette tape, or one you want to
record over, into the cassette compartment.
2. Set VOICE ACTIVATION to the desired sensitivity.
HIGH — begins recording from soft, low sounds
as well as loud sounds.
LOW — requires a normal to loud sound to begin
recording.
14-1112.fm Page 20 Thursday, July 1, 1999 1:05 PM
