Optimus SCP-84 User manual

Cat. No. 14-1225
OWNER’S MANUAL
Please read before using this equipment.
SCP-84
Auto-Reverse
AM²FM Stereo
Cassette Player
14-1225.fm Page 1 Friday, July 2, 1999 9:00 AM

2
FEATURES
Your Optimus SCP-84 Auto-Reverse AM/FM Stereo Cas-
sette Player delivers excellent sound from its built-in ra-
dio or your favorite cassette tapes through your speakers
or stereo headphones. You can set the time on the cas-
sette player’s display, set an alarm to sound, and store
up to 20 radio stations in memory. The tuner’s PLL
(Phase-Locked Loop) circuitry gives you precise tuning
and drift-free reception.
Its features include:
Auto-Reverse Cassette Deck — lets you continuously
play a cassette tape.
AM/FM Radio with 20-Station Memor
y
— lets you store
up to 20 radio stations (10 FM and 10 AM) in memory so
you can quickly tune to your favorite stations.
LCD with Clock and Alarm — displays the current time
and lets you set the SCP-84 to sound an alarm at the
time you select.
Seek Tunin
g
— searches forward or backward to the
next strong station in the selected band so you can quick-
ly find new stations.
©1996 Tandy Corporation.
All Rights Reserved.
RadioShack is a trademark used by Tandy Corporation.
14-1225.fm Page 2 Friday, July 2, 1999 9:00 AM

3
E-BASS IN/OUT Switch — lets you increase bass
sounds to suit your listening preferences.
9 kHz/10kHz Switch — lets you set the frequency tuning
increments between stations for tuning in the United
States as well as abroad.
PHONES Jack — lets you connect headphones for pri-
vate listening, or speakers to share the sound with oth-
ers.
Three Power Options — let you power the SCP-84 from
internal batteries, standard AC power (with an optional
AC adapter), or your vehicle’s cigarette-lighter socket
(with an optional DC adapter).
Removable Belt Clip — lets you attach the SCP-84 to
your belt for hands-free carrying when you are on the go.
Lock Switch — lets you lock the currently tuned station
to prevent accidentally changing it.
Note: You need a pair of headphones or amplified
speakers (neither supplied), with a 1/8-inch plug, to oper-
ate your SCP-84. Your local RadioShack store sells a
wide variety of headphones and speakers.
14-1225.fm Page 3 Friday, July 2, 1999 9:00 AM

4
CONTENTS
Preparation .................................................................. 5
Attaching the Belt Clip ............................................ 5
Powering the SCP-84 ............................................. 6
Using Batteries ................................................... 6
Using AC Power ................................................. 8
Using Your Vehicle’s Cigarette-Lighter Socket . 10
Setting the Clock .................................................. 12
Setting the 9kHz/10kHz Switch ............................ 14
Connecting Headphones or Amplified Speakers .. 15
Listening Safely ................................................ 16
Traffic Safety ..................................................... 16
Usin
g
the Radio ......................................................... 17
Listening to the Radio ........................................... 17
Storing Radio Stations in Memory ........................ 20
Using Lock ............................................................ 22
Usin
g
the Cassette Pla
y
er ........................................ 23
Playing a Cassette Tape ....................................... 23
Usin
g
the Alarm ........................................................ 27
Setting the Alarm Time ......................................... 27
Turning the Alarm On/Off ...................................... 28
Care and Maintenance .............................................. 29
The FCC Wants You to Know ............................... 30
Cleaning the Tape-Handling Parts ........................ 31
Restoring Tape Tension and Sound Quality ......... 32
Specifications ............................................................ 33
14-1225.fm Page 4 Friday, July 2, 1999 9:00 AM

5
PREPARATION
ATTACHING THE BELT CLIP
To attach the belt clip to the SCP-84, press the clip’s
three latches into the corresponding holes on the back of
the SCP-84. Then push the clip upward until it locks into
place.
To remove the belt clip, press down at the point where
the clip attaches to the SCP-84, then slide off the clip.
(illus)
(illus)
14-1225.fm Page 5 Friday, July 2, 1999 9:00 AM

6
POWERING THE SCP-84
You can power your SCP-84 from any of three power
sources:
• Internal batteries (not supplied)
• Standard AC power (with an optional AC adapter)
• Your vehicle’s cigarette-lighter socket (with an
optional DC adapter)
Note: Connecting an optional adapter disconnects inter-
nal batteries.
Using Batteries
You can power your SCP-84 from two AA batteries. We
recommend alkaline batteries, such as RadioShack Cat.
No. 23-557, not supplied. You can also use rechargeable
nickel-cadmium batteries (such as Cat. No. 23-125, not
supplied). If you use rechargeable batteries, you also
need a battery charger (such as Cat. No. 23-133, not
supplied).
14-1225.fm Page 6 Friday, July 2, 1999 9:00 AM

7
Cautions:
• Do not mix old and new batteries, different types of
batteries (standard, alkaline, and nickel-cadmium), or
rechargeable batteries of different capacities in the
SCP-84.
• Use only fresh batteries of the required size and type.
Follow these steps to install batteries.
1. Press down on the battery compartment cover and
slide it in the direction of the arrow to remove it.
2. Install the batteries over the ribbon inside the com-
partment as indicated by the positive (+) polarity sym-
bols marked inside.
3. Replace the cover.
(illus)
14-1225.fm Page 7 Friday, July 2, 1999 9:00 AM

8
Cautions:
• Never leave dead or weak batteries in the SCP-84.
• If you do not plan to use the SCP-84 for a month or
more, or if you plan to use only AC or vehicle battery
power, remove the batteries.
• Dispose of batteries promptly and properly; do not
bury or burn them.
Note: If your SCP-84 locks up, simply remove one of the
batteries then reinstall it.
Important: Your SCP-84 is capable of using recharge-
able nickel-cadmium batteries. At the end of the batteries’
useful life, they must be recycled or disposed of properly.
Contact your local, county, or state hazardous waste
management authorities for information on recycling or
disposal programs in your area. Some options that might
be available are: municipal curbside collection, drop-off
boxes at retailers, recycling collection centers, and mail-
back programs.
Using AC Power
You can power the SCP-84 from a standard AC outlet us-
ing an AC adapter (such as Cat. No. 273-1654, not sup-
plied).
14-1225.fm Page 8 Friday, July 2, 1999 9:00 AM

9
Cautions:
• The recommended AC adapter supplies 3 volts and
delivers at least 300 milliamps. Its center tip is set to
negative, and its plug correctly fits the DC 3V jack on
the bottom of the SCP-84. Using an adapter that
does not meet these specifications could damage the
SCP-84 or the adapter.
• Always plug the AC adapter’s barrel plug into the
SCP-84 before you plug its power module into the
AC outlet, and unplug its power module from the AC
outlet before you unplug its barrel plug from the SCP-
84.
Follow these steps to connect an AC adapter to the SCP-
84.
1. Set the adapter’s voltage switch to 3V.
2. Insert the 3.4 mm outer diameter/1.3 mm inner diam-
eter barrel plug into the AC adapter’s socket. Line up
TIP on the plug with –NEG on the socket.
(illus)
14-1225.fm Page 9 Friday, July 2, 1999 9:00 AM

10
3. Insert the barrel plug into the SCP-84’s DC 3V jack.
4. Plug the AC adapter into a standard AC outlet.
Using Your Vehicle’s Cigarette-Lighter
Socket
To power the SCP-84 from your vehicle’s cigarette-lighter
socket, you need a DC adapter, such as Cat. No. 270-
1560.
Cautions:
• The recommended DC cigarette-lighter adapter sup-
plies 3 volts and delivers at least 300 milliamps. Its
center tip is set to negative, and its plug correctly fits
the DC 3V jack on the bottom of the SCP-84. Using
an adapter that does not meet these specifications
could damage the SCP-84 or the adapter.
• Unplug the adapter from your vehicle’s cigarette-
lighter socket when you turn off the ignition. This pre-
vents your vehicle’s battery from being drained if you
leave the SCP-84 on when you turn off the ignition.
14-1225.fm Page 10 Friday, July 2, 1999 9:00 AM

11
• Always plug the DC adapter’s barrel plug into the
SCP-84 before you plug its power module into your
vehicle’s cigarette-lighter socket, and unplug its
power module from your vehicle’s cigarette-lighter’s
socket before you unplug its barrel plug from the
SCP-84.
Follow these steps to power the SCP-84 from your vehi-
cles’s cigarette-lighter socket.
1. Set the adapter’s voltage switch to 3V.
2. Insert the 3.4 mm outer diameter/1.3 mm inner diam-
eter barrel plug into the DC adapter’s socket. Line up
negative (–) on the plug with TIP on the socket.
3. Insert the plug into the SCP-84’s DC 3V jack.
4. Plug the adapter into the vehicle’s cigarette-lighter
socket.
(illus)
14-1225.fm Page 11 Friday, July 2, 1999 9:00 AM

12
Note: If the SCP-84 does not operate when you turn it
on, remove the DC adapter from your vehicle’s cigarette-
lighter socket and check the socket for debris. Also,
check the fuse in the adapter and your vehicle’s fuse
block.
SETTING THE CLOCK
1. Set RADIO STEREO/MONO/TAPE to TAPE. The dis-
play shows the currently set time.
2. Press MODE twice. The currently set time flashes.
(illus)
(illus)
14-1225.fm Page 12 Friday, July 2, 1999 9:00 AM

13
Note: If you do not press HR. or MIN. within 10
seconds, the currently set time stops flashing. If this
happens, simply repeat this step.
3. Repeatedly press HR. until the display shows the
correct hour. To rapidly advance the hours, press and
hold down HR.
4. Repeatedly press MIN. until the display shows the
correct minute. To rapidly advance the minutes,
press and hold down MIN.
5. When the display shows the correct time, either
press
MODE or wait until the display stops flashing.
(illus)
(illus)
14-1225.fm Page 13 Friday, July 2, 1999 9:00 AM

14
SETTING THE 9KHZ/10KHZ SWITCH
The 9kHz/10kHz switch on the back of the cassette com-
partment door is preset to 10kHz.
In the 10kHz setting, the SCP-84 tunes frequencies in in-
crements of 10 kHz (AM) and 0.1 MHz (FM), which is
standard in the United States.
However, in Europe and some other parts of the world,
AM frequencies are broadcast in increments of 9 KHz. If
you use the SCP-84 in these countries, use a pointed ob-
ject, such as a straightened paper clip, to set 9kHz/10kHz
to 9kHz.
(illus)
(illus)
14-1225.fm Page 14 Friday, July 2, 1999 9:00 AM

15
CONNECTING HEADPHONES OR
AMPLIFIED SPEAKERS
To listen to the SCP-84, you need a pair of headphones
or amplified speakers with a 1/8-inch plug. Your local Ra-
dioShack store carries a wide selection of headphones
and amplified speakers.
Insert the headphones’ or speakers’ 1/8-inch plug into the
SCP-84’s PHONES jack.
(illus)
14-1225.fm Page 15 Friday, July 2, 1999 9:00 AM

16
Listening Safely
To protect your hearing, follow these guidelines when
you use headphones.
• Set the volume to the lowest setting before you begin
listening. After you begin listening, adjust the volume
to a comfortable level.
• Do not listen at extremely high volume levels.
Extended high-volume listening can lead to perma-
nent hearing loss.
• Once you set the volume, do not increase it. Over
time, your ears adapt to the volume level, so a vol-
ume level that does not cause discomfort might still
damage your hearing.
Traffic Safety
Do not wear headphones while operating a motor vehicle
or riding a bicycle. This can create a traffic hazard and
can be illegal in some areas.
Even though some headphones let you hear some out-
side sounds when listening at normal volume levels, they
still can present a traffic hazard.
14-1225.fm Page 16 Friday, July 2, 1999 9:00 AM

17
USING THE RADIO
LISTENING TO THE RADIO
Important: Make sure you have connected headphones
or speakers to the SCP-84. See “Connecting Head-
phones or Amplified Speakers” on Page 15.
1. Set RADIO STEREO/MONO/TAPE to STEREO for ste-
reo sound on FM stations. STEREO appears when
you receive an FM broadcast in stereo. Set RADIO
STEREO/MONO/TAPE to MONO for monaural recep-
tion.
2. Adjust VOLUME to a comfortable listening level.
(illus)
(illus)
14-1225.fm Page 17 Friday, July 2, 1999 9:00 AM

18
3. Press AM/FM until the display shows the desired
band (AM or FM).
4. Tune to the desired station.
Manual Tunin
g
:Repeatedly press TUNING or to
tune up or down the selected band. To rapidly tune
the band, press and hold down TUNING or .
Seek Tunin
g
: Press and hold down TUNING or
for about 1 second. The SCP-84 tunes up or down
the selected band, then stops at the next higher or
lower station with a strong signal.
(illus)
(illus)
14-1225.fm Page 18 Friday, July 2, 1999 9:00 AM

19
Notes:
• The SCP-84 has a built-in AM antenna, and the
headphones’ or speakers’ cord serves as an FM
antenna. For the best AM reception, rotate the
SCP-84. For the best FM reception, fully uncoil the
headphones’ or speakers’ cord.
• If FM stereo reception is poor or noisy, set RADIO
STEREO/MONO/TAPE to MONO. The sound is not in
stereo, but reception should improve.
5. Set E-BASS IN/OUT to IN for extra bass effect, or to
OUT to leave the bass sound unchanged.
6. To turn off the radio, set RADIO STEREO/MONO/TAPE
to TAPE.
(illus)
14-1225.fm Page 19 Friday, July 2, 1999 9:00 AM

20
STORING RADIO STATIONS IN
MEMORY
You can store up to 20 radio stations (10 FM and 10 AM)
in memory. Then you can quickly tune to the stored sta-
tion by pressing a memory button (or +5 and a memory
button).
Follow these steps to store stations in memory.
1. Set RADIO STEREO/MONO/TAPE to STEREO or
MONO.
2. Press AM/FM until the display shows the desired AM
or FM band.
3. Tune to the first station you want to store. The display
shows the frequency.
4. Press STORE. Mflashes on the display for about 10
seconds.
(illus)
14-1225.fm Page 20 Friday, July 2, 1999 9:00 AM
