Optimus CTR-106 User manual

Cat. No. 14-1111
OWNER’S MANUAL
Please read before using this equipment.
CTR-106
Voice-Activated
Cassette Tape Recorder
14-1111.fm Page 1 Thursday, July 1, 1999 12:55 PM

2
FEATURES
Your Optimus CTR-106 Voice-Activated Cassette Tape
Recorder gives you a convenient and reliable way to
record live audio. You can manually start recording or set
the CTR-106 to automatically start recording when the re-
corder picks up sound.
Because the CTR-106 does not record long periods of si-
lence, you not only save tape space and battery power,
you also save time when you try to find a certain section
on the tape. Your recorder is small enough to fit in a brief-
case or purse, so you can take it almost anywhere —
meetings, lectures, and so on.
The cassette recorder includes these special features:
Voice-Activated Circuit — automatically starts record-
ing when the recorder picks up sound and stops record-
ing within 5 seconds after the sound falls below a set
level.
Built-In Condenser Microphone — helps provide quali-
ty recordings.
Di
g
ital Tape Counter — helps you quickly return to a
specific section on the tape.
©1997 Tandy Corporation.
All Rights Reserved.
Optimus and RadioShack are registered trademarks
used by Tandy Corporation.
14-1111.fm Page 2 Thursday, July 1, 1999 12:55 PM

3
Automatic Level Control (ALC) Circuit — automatically
adjusts to the proper recording level.
Auto Stop — during playback and recording, stops the
recorder and releases the tape mechanism when the
tape reaches the end, to save battery power and protect
your cassette tape.
Three-Way Power — lets you operate your cassette re-
corder using internal batteries, an AC outlet (using an op-
tional adapter), or your vehicle’s cigarette-lighter socket
(using an optional adapter).
Earphone — lets you listen without disturbing others.
You can also use the earphone to monitor a recording
and check the microphone’s sensitivity.
Built-In Speaker — lets you listen to your recorder with-
out an earphone.
14-1111.fm Page 3 Thursday, July 1, 1999 12:55 PM

4
CONTENTS
Preparation .................................................................. 5
Powering the Recorder ........................................... 5
Using Internal Battery Power ........................... 5
Using AC Power ............................................... 7
Using DC Power .............................................. 9
Using the Earphone .............................................. 11
Listening Safely .............................................. 12
Traffic Safety .................................................. 12
Operation ................................................................... 13
Loading a Cassette Tape ...................................... 13
Playing a Tape ...................................................... 14
Using Fast-F and Rewind ..................................... 15
Using the Tape Counter ........................................ 15
Recording ............................................................. 16
Using Voice Activation (VOX) ........................ 16
Manual Recording .......................................... 17
Tape Tips .............................................................. 18
Restoring Tape Tension and Sound Quality ... 18
Preventing Accidental Erasure ....................... 18
Erasing a Cassette Tape ................................ 19
Maintenance .............................................................. 20
Cleaning the Tape-Handling Parts ........................ 21
Specifications ............................................................ 23
14-1111.fm Page 4 Thursday, July 1, 1999 12:55 PM

5
PREPARATION
POWERING THE RECORDER
For portable use, you can power the recorder from inter-
nal batteries. You can also power it from a standard AC
outlet or your vehicle’s cigarette-lighter socket.
Using Internal Battery Power
The recorder uses two AA batteries. For the best results,
we recommend alkaline batteries, such as RadioShack
Cat. No. 23-552. Or, you can use rechargeable nickel-
cadmium batteries, such as Cat. No. 23-125, with a bat-
tery charger (Cat. No. 23-133).
Cautions:
• Use only fresh batteries of the recommended size
and type.
• Do not mix old and new batteries, different types of
batteries (standard, alkaline, or rechargeable), or
rechargeable batteries of different capacities.
14-1111.fm Page 5 Thursday, July 1, 1999 12:55 PM

6
Follow these steps to install batteries.
1. Slide the battery compartment cover in the direction
shown by the arrow on the cover.
2. Install two AA batteries as indicated by the polarity
symbols (+ and –) marked on the back of the
recorder.
3. Replace the cover.
Cautions:
• If you do not plan to use the recorder for a week or
more, or you plan to use only another power source,
remove the batteries.
• Always dispose of old batteries promptly and prop-
erly.
Illust.
14-1111.fm Page 6 Thursday, July 1, 1999 12:55 PM

7
Important: Your recorder is capable of using recharge-
able nickel-cadmium batteries. At the end of the batteries’
useful life, they must be recycled or disposed of properly.
Contact your local, county, or state hazardous waste
management authorities for information on recycling or
disposal programs in your area. Some options that might
be available are: municipal curbside collection, drop-off
boxes at retailers, recycling collection centers, and mail-
back programs.
Using AC Power
To power the recorder from an AC outlet, you need an
AC adapter (not supplied), such as Cat. No. 273-1654.
Cautions:
• You must use an adapter that supplies 3 volts and
delivers at least 300 milliamps. Its center tip must be
set to negative, and it must have a plug that properly
fits the CTR-106’s DC 3V jack. The recommended
adapter meets these specifications. Using an adapter
that does not meet these specifications could dam-
age the CTR-106 or the adapter.
• Connecting an AC adapter automatically disconnects
internal batteries.
14-1111.fm Page 7 Thursday, July 1, 1999 12:55 PM

8
• Always plug the adapter into the recorder before you
plug it into the AC outlet. Always unplug the adapter
from the AC outlet before you unplug it from the
recorder.
1. Set the adapter’s voltage switch to 3V.
2. Attach the 3.4 mm outer diameter/1.3 mm inner
diameter barrel plug to the AC adapter’s cord with the
tip set to negative (–).
3. Insert the plug into the recorder’s DC 3V jack.
4. Plug the adapter into a standard AC outlet.
Illust.
14-1111.fm Page 8 Thursday, July 1, 1999 12:55 PM

9
Using DC Power
To power the recorder from your vehicle’s cigarette-lighter
socket, you need a DC adapter (not supplied), such as
Cat. No. 270-1560.
Cautions:
• You must use an adapter that supplies 3 volts and
delivers at least 300 milliamps. Its center tip must be
set to negative, and it must have a plug that properly
fits the CTR-106’s DC 3V jack. The recommended
adapter meets these specifications. Using an adapter
that does not meet these specifications could dam-
age the CTR-106 or the adapter.
• Connecting a DC adapter automatically disconnects
internal batteries.
• Always plug the adapter into the recorder before you
plug it into the cigarette-lighter socket. Always unplug
the adapter from the cigarette-lighter socket before
you unplug it from the recorder.
14-1111.fm Page 9 Thursday, July 1, 1999 12:55 PM

10
Follow these steps to power the recorder from your vehi-
cle’s cigarette-lighter socket.
1. Set the adapter’s voltage switch to 3V.
2. Attach the 3.4 mm outer diameter/1.3 mm inner
diameter barrel plug to the DC adapter’s cord with
the tip set to negative (–).
3. Insert the plug into the recorder’s DC 3V jack.
4. Plug the adapter into the vehicle’s cigarette-lighter
socket.
Note: If the recorder does not operate properly when
powered from your vehicle’s battery, unplug the adapter
from the cigarette-lighter socket and clean the socket to
remove any ashes or other debris.
Illust.
14-1111.fm Page 10 Thursday, July 1, 1999 12:55 PM

11
USING THE EARPHONE
You can use the earphone for private listening. You can
also monitor a recording and check the microphone’s
sensitivity (see “Using Voice Activation (VOX)” on
Page 16).
Insert the earphone’s 1/8-inch plug into the EAR jack.
Note: Connecting the earphone disconnects the record-
er’s built-in speaker.
Illust.
14-1111.fm Page 11 Thursday, July 1, 1999 12:55 PM

12
Listening Safely
To protect your hearing, follow these guidelines when
you use an earphone.
• Do not listen at extremely high volume levels.
Extended high-volume listening can lead to perma-
nent hearing loss.
• Set the volume to its lowest level before you begin
listening. After you put on the earphone, adjust the
volume to a comfortable listening level.
• Do not increase the volume once you have estab-
lished a comfortable listening level. Over time, your
ears adapt to the volume level, so a volume level that
does not cause discomfort might still damage your
hearing.
Traffic Safety
Do not wear an earphone while operating a motor vehicle
or riding a bicycle. This can cause a traffic hazard and
could be illegal in some areas.
Even though some earphones let you hear outside
sounds when listening at normal volume levels, they still
can present a traffic hazard.
14-1111.fm Page 12 Thursday, July 1, 1999 12:55 PM

13
OPERATION
LOADING A CASSETTE TAPE
1. Take up any slack in the cassette tape by turning the
hub with a pencil to prevent the tape from becoming
tangled in the tape mechanism. Do not touch the
tape.
2. Open the cassette compartment door by lifting it at
the notch. Insert a cassette tape into the door guides
so the cassette’s open edge faces out, the side you
want to play or record on faces the compartment win-
dow, and the full reel is to the left.
3. Close the cassette compartment door.
Illust.
Illust.
14-1111.fm Page 13 Thursday, July 1, 1999 12:55 PM

14
PLAYING A TAPE
1. Load a cassette.
2. Press
PLAY.
3. Adjust VOLUME to the desired level.
4. To stop the tape, press STOP or let the tape auto-
matically stop when it reaches the end.
Illust.
Illust.
14-1111.fm Page 14 Thursday, July 1, 1999 12:55 PM

15
USING FAST-F AND REWIND
To rapidly advance or rewind the tape, press FAST-F
or
REWIND. The button locks, and the tape fast-for-
wards or rewinds to the end or until you press STOP.
When the tape reaches the end, press STOP to re-
lease the button and the tape-handling parts.
USING THE TAPE COUNTER
The tape counter shows you the tape’s current playing
position, making it easier to locate a particular segment.
Before you play a tape, press the reset button to reset the
counter to 000. As the tape plays, note the position you
want to return to later.
Illust.
Illust.
14-1111.fm Page 15 Thursday, July 1, 1999 12:55 PM

16
RECORDING
Notes:
• We recommend you use normal bias (Type I) cas-
sette tapes, such as RadioShack LN and XR tape.
• We recommend regular length (60- or 90-minute)
cassette tapes. We do not recommend long-play cas-
sette tapes, such as C-120s, because they are thin
and can easily tangle.
• The ALC (automatic level control) circuit automati-
cally sets the recording level. VOLUME has no effect.
Caution: Never try to force down RECORD after you
remove an erase protection tab (see “Preventing Acci-
dental Erasure” on Page 18). You might damage the re-
corder.
Using Voice Activation (VOX)
1. Load a blank cassette (or one you want to record
over) into the tape compartment.
2. Set VOICE ACTIVATION to IN.
Illust.
14-1111.fm Page 16 Thursday, July 1, 1999 12:55 PM

17
3. Press
RECORD. Recording begins when the voice-
activation mechanism detects a sound.
4. To cause soft sound levels to activate recording,
rotate
VOLUME/VOX SENS toward MAX. To automati-
cally record only louder sounds, rotate VOLUME/VOX
SENS toward MIN. (This does not change the volume
of the recording.)
The RECORD BATTERY indicator lights during
recording. The louder the sound, the brighter the indi-
cator glows.
Manual Recording
Set VOICE ACTIVATION to OUT, then press RECORD to
record continuously. For the best quality recordings,
place the recorder 1 to 5 feet from the sound source.
Recording automatically stops when the recorder
reaches the end of the tape side. To manually stop
recording, press STOP.
Illust.
14-1111.fm Page 17 Thursday, July 1, 1999 12:55 PM

18
TAPE TIPS
Restoring Tape Tension and Sound Quality
After you play a cassette tape several times, the tape
might become tightly wound on the reels. This can cause
playback sound quality to deteriorate.
To restore the sound quality, fast-forward the tape from
the beginning to the end of one side, then completely re-
wind it. Then loosen the tape reels by gently tapping each
side of the cassette’s outer shell on a flat surface.
Caution: Be careful not to damage the cassette when
tapping it. Do not touch the exposed tape or allow any
sharp objects near the cassette.
Preventing Accidental Erasure
Cassette tapes have two erase-
protection tabs — one for each
side. When a tab is in place, you
can record on that side. To pro-
tect a recording from being acci-
dentally recorded over or
erased, use a screwdriver to re-
move one or both of the cassette
tape’s erase-protection tabs.
Illust.
14-1111.fm Page 18 Thursday, July 1, 1999 12:55 PM

19
If you later decide to record on a tape side after you have
removed the erase-protection tab, place a piece of strong
plastic tape over that side’s erase-protection hole. Be
sure you cover only the hole originally covered by the
erase-protection tab.
Caution: Removing the erase-protection tabs does not
prevent a bulk eraser from erasing a cassette tape.
Erasing a Cassette Tape
To record over a cassette tape, simply record as usual.
The cassette deck records over the previous recording.
You can quickly erase both sides of a cassette tape using
a bulk tape eraser, such as Cat. No. 44-232.
Illust.
14-1111.fm Page 19 Thursday, July 1, 1999 12:55 PM

20
MAINTENANCE
Your CTR-106 Voice-Activated Cassette Tape Recorder
is an example of superior design and craftsmanship. The
following suggestions will help you care for your recorder
so you can enjoy it for years.
Keep the recorder dry. If it gets wet, wipe it
dry immediately. Liquids might contain
minerals that can corrode the electronic cir-
cuits.
Use and store the recorder only in normal
temperature environments. Temperature
extremes can shorten the life of electronic
devices and distort or melt plastic parts.
Keep the recorder away from dust and dirt,
which can cause premature wear of parts.
Handle the recorder gently and carefully.
Dropping it can damage circuit boards and
cases and can cause the recorder to work
improperly.
14-1111.fm Page 20 Thursday, July 1, 1999 12:55 PM
