Optocore X6r User manual

X6R/V3R-TP– A/D D/A Converter with SANE and Ethernet

Operating Manual

Rev. 2.4

Operating Manual for OPTOCORE X6R/V3R-TP Devices

A/D and D/A Converter with SANE and Ethernet

OPTOCORE GmbH

Lohenstr. 8

82166 Munich-Gräfelfing

Germany

Page intentionally left blank

X6R/V3R-TP

3 / 27

rev. 2.4

Important Safety Instructions

•Please read this manual carefully.

•Please keep this operating manual in a safe place.

•Heed all warnings.

•Follow all instructions.

•This device may only be used in accordance to the information provided in this operating

manual. Ensure that all recommendations detailed in this operating manual, especially the

safety recommendations, are followed before and during use of the device.

•Do not use this device near water and liquids, for example, in humid or damp rooms.

•Clean only with a dry cloth.

•Do not block or cover any ventilation openings. Install the device in accordance with the

operating manual.

•Do not install or place the device near a source of heat. Such as: radiators, power-amplifiers,

or any other heat emitting devices.

•Protect the power cord from being stepped on, crushed, pinched or damaged in any other way

or form. Pay special attention to the condition of the AC mains sockets on the device.

•Do not place this device on an unstable table, tripod, cart, etc. The device may fall, causing

serious damage to the device.

•The device can be disconnected from the power supply by unplugging the power cord. The

power cords must be freely accessible at all times. The device should be disconnected during

lightning storms or when the device is unused for a long period of time.

•The device must be grounded. Disconnecting the ground is strictly prohibited.

•The internal components of the switched-mode power supplies operate at very high voltages.

Coming into contact with the power supplies can lead to considerable electric shock, which

may result in death.

•Only use attachments and accessories that are specified by the manufacturer of the device.

•This device contains no user serviceable parts. Please consult with authorised service

personnel before attempting to carry out any repair or modification of the device.

•Your warranty will be voided if you tamper with the internal components of the device.

X6R/V3R-TP

4 / 27

rev. 2.4

Purchaser Information

•Operating Manual

Please read this manual. If you call for technical support, we will assume that you have already done

so. Study the operating manual carefully in order to familiarise yourself with the device and its

operation. The operating manual contains important information on proper use of the device.

It cannot be guaranteed that this operating manual will not contain typographical mistakes or

misprints. The operating manual is regularly revised and updated.

Modifications, which serve the purpose of technical improvement of the device, may be carried out

without prior notification.

•Transport and Shipping

Always ensure careful handling of the device. The device should be transported and shipped in

shock-absorbing transport cases. If these are not available, we recommend well-padded packaging

such as the coated carton in which the device was delivered.

We strongly advise against the use of light weight flight-cases without shock-absorbing rack-in-rack

mounting.

•Environments

This device can be used in E1, E2, E3, E4, or E5 environments (as listed below) according to the

harmonised European standards EN55103-1 and EN55103-2 “Electromagnetic compatibility –

Product family standard for audio, video and audio-visual and entertainment lighting control apparatus

for professional use”

E1-Residental

E2-Commercial and light industrial

E3-Urban outdoors

E4-Controlled EMC environment e.g. broadcast and TV-studio

E5-Heavy industry

The product is intended for the use in moderate climate.

•Ventilation

Do not block or cover any ventilation openings. Install the device in accordance with the operating

manual. Allow for sufficient space around the units (at least 200 mm ≡7,87" free space behind the

rear-panel of the device) and make sure to allow for air circulation near the ventilation openings on

both sides of the device. Keep the rear of the rack open during operation. Do not operate the device

close to heat emitting equipment, such as power-amplifiers. Leave sufficient space (minimum ½ RU)

between the device and any heat emitting devices housed in the same rack.

An X6R/V3R device may be placed on top or beneath other Optocore products, except DD32E,

without additional space.

•Water and Moisture etc.

To prevent fire or shock hazard, do not expose the device to direct sunlight, dust, water, or rain during

operation or storage.

Please note:

Do not populate more than 4 adjacent rack spaces with Optocore devices.

Maintain 1RU of empty space between each 4 RU of Optocore devices.

Keep the equipment rack open during operation.

Ensure air circulation around the devices.

Maintain at least 200mm (~8”) clearance behind the rear panel of the devices.

X6R/V3R-TP

5 / 27

rev. 2.4

•Cleaning

Only use a dry linen cloth to clean the device. If the unit is very dirty, moisten a cloth using a little

water and a small amount of household detergent. Never use cleansing agents containing solvents to

clean the device.

•Operating and Storage Temperature

Operating temperature: -20

C …50

C ≡-4

F … 122

F; ensure proper ventilation

Storage temperature: -20

C …60

C ≡-4

F … 140

•Power Supply

The device can be disconnected from the power supply by unplugging the power cord. The power

cords must be freely accessible at all times. The device should be disconnected during lightning

storms or when the device is unused for a long period of time

Never disconnect the main plug by pulling the cable, always pull the plug itself.

Power-supply cords should be routed in such a way that they are not likely to be walked on, crushed,

pinched, or damaged in any other way. Pay special attention to the plugs and the sockets of the

device.

•Fuse

There is no fuse in the device. The power supplies contain circuitry that protects the device from

overload.

•Lightning

For additional protection of this device during lightning storms, or when it is left unattended and

unused for a long period of time, disconnect the power cord. This will prevent damage to the device

due to lightning and power line surges. Disconnection from the mains power supply is only possible

by disconnecting the power plug from the mains socket.

•External objects and/or liquids

Never push objects of any kind into the device through openings in the casing. They may come into

contact with dangerous voltage points or short out parts that could result in a fire or electric shock.

Never spill liquid of any kind on the device.

Important:

The switched-mode power supplies operate at very high voltages.

Coming into contact with the power supplies can lead to considerable electric shock,

which may result in death.

Important:

A damaged power cable must be replaced immediately.

The device must be grounded. Disconnecting the ground is strictly prohibited. Ensure

that the device is always grounded using the power connector.

Do not cover the ground connection of the power connector with any kind of insulation

material!

X6R/V3R-TP

6 / 27

rev. 2.4

•Cables and Accessories

Only use attachments that are specified by the manufacturer of the device.

Use high quality, properly terminated, cables to connect the device. The device should only be used

with optical fibre cables that are specified for use with the devices optical transceivers and within the

specified power budget of the optical transceivers. When not in use, ensure that the optical

connectors on the device and the optical fibre cables are covered with the provided caps.

Do not place this device on an unstable table, tripod, cart, etc. The device may fall, which can cause

injury and serious damage to the device. Any mounting of the device should follow the

manufacturer’s instructions, and should use mounting accessories recommended by the

manufacturer of the device.

•Servicing

Do not attempt to service this device yourself.

The device contains no user serviceable parts, components or controls. The operation of an opened

device is not permitted. Such operation can lead to damage of the device’s components due to lack

of air flow through the device.

The device may not be serviced, altered or modified without authorisation from Optocore or an

Optocore authorised distributor / dealer. Only qualified service personnel may carry out repair and

maintenance work on the device. The warranty of the device will be voided if any unauthorized

maintenance or repair work has been carried out.

X6R/V3R-TP

7 / 27

rev. 2.4

CE/FCC-Conformity

This document confirms that the X6R/V3R-TP bearing the CE (Communauté Européenne)label meets all

requirements in the EMC directive 2004/108/EG laid down by the Member States Council for adjustment of legal

requirements. Furthermore the product complies with the rules and regulations of the low-voltage directive

2006/95/EG and the Restriction of Hazardous Substances Recast Directive 2011/65/EU (RoHS 2). This product

bearing the CE label complies with the following standards, ratified by CENELEC (Comité Européen de

Normalisation Electrotechnique):

Electromagnetic compatibility – Product family standard for audio, video, audio-visual and

entertainment lighting control apparatus for professional use

EN 55103-1, Emission

EN 55103-2, Immunity

EN 60065, Safety requirements

FCC notice

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communication. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case you will be required to correct the interference at his own expense.

Changes or modifications not expressly approved by Optocore GmbH could void the user’s authority to operate

this equipment.

Industry Canada Compliance Statement

This Class[A] digital device complies with Canadian ICES-003.

Avis de conformité à la réglementation d'Industrie Canada

Cet appareil numérique de la class[A] est conforme à la norme NMB-003 du Canada

The authorised declaration and compatibility certification lies with the manufacturer and can be viewed on

request. Responsible as manufacturer is:

OPTOCORE GmbH, Lohenstr. 8, 82166 Munich-Gräfelfing, Germany

represented by Marc Brunke, Managing Director

N.B. The awarding of the CE label confirms the compliance with legal directives issued for the manufacturer and

marketing of electronic and electrical devices. As such the CE label is not a "seal of quality" but rather proof that

the device bearing the CE label conforms with the electromagnetic compatibility standards laid down in the above

named testing regulations.

Munich, 11.12.2013

Marc Brunke

Page intentionally left blank

X6R/V3R-TP

9 / 27

rev. 2.4

X6R/V3R-TP - A/D and D/A Converter for SANE

Table of Contents

Important Safety Instructions...................................................................................................................................3

Purchaser Information..............................................................................................................................................4

CE-Conformity .........................................................................................................................................................7

Device Description.................................................................................................................................................11

Card Types ............................................................................................................................................................12

Front Panel............................................................................................................................................................13

X6R-TP.......................................................................................................................................................13

V3R-TP.......................................................................................................................................................13

Rear Panel.............................................................................................................................................................15

X6R-TP with Analogue Input- and Output Cards........................................................................................15

V3R-TP or X6R-TP with Dual Microphone..................................................................................................15

Device Details........................................................................................................................................................16

SANE Ports ................................................................................................................................................16

A/D and D/A Converter...............................................................................................................................16

Analog Inputs..............................................................................................................................................16

Analog Outputs...........................................................................................................................................16

AES Ports...................................................................................................................................................16

Word Clock.................................................................................................................................................16

Power Supply .............................................................................................................................................16

Control...................................................................................................................................................................17

X6R-TP with DD32R(E)..............................................................................................................................17

X6R/V3R-TP in SANE Network Applications..............................................................................................17

Third Party Control......................................................................................................................................17

SANE bandwidth allocation....................................................................................................................................18

Connectors and Cables .........................................................................................................................................19

SANE Ports ................................................................................................................................................19

AES Ports...................................................................................................................................................19

RS232-Connection .....................................................................................................................................19

Connector Hood Quality .............................................................................................................................19

USB-Connection.........................................................................................................................................19

LAN-Connection .........................................................................................................................................19

Word Clock-Connection..............................................................................................................................19

Mains-Connection.......................................................................................................................................19

Hardware Connection............................................................................................................................................20

Example 1...................................................................................................................................................20

Example 2...................................................................................................................................................21

Connection Tables.................................................................................................................................................22

BI-B Cable..................................................................................................................................................23

Technical Specifications ........................................................................................................................................24

Dimensions and Weight.........................................................................................................................................25

X6R/V3R-TP

10 / 27

rev. 2.4

Warranty and Liability.............................................................................................................................................26

Shipping Contents..................................................................................................................................................27

Company Information.............................................................................................................................................27
