Optoma EW766 User manual

www.optoma.co.uk
EW766
DLP®Projector
Versatile Widescreen
Installation...
5
5
PureShift (V&H Shift) & 1.5x Zoom
16:10
16
16
16
16
6
6
6
:1
:1
:1
:1
:1
:1
:1
1
1
0
0
0
0
0
0
0
0
0
0
Widescreen presentations and
HD entertainment
Bright projection – 4000 ANSI Lumens
Digital and Analogue connectivity includes:
HDMI, DVI-D, dual VGA
Low ownership costs – up to 4000hrs lamp life
Networking – RJ45 control and monitoring
Environmentally friendly design <1W standby mode
�
DLP® filter-free design – Virtually no maintenance

TRUE WXGA RESOLUTION
The EW766 is the perfect companion for widescreen laptops. Your
presentations will appear as sharp and detailed as they do on your
widescreen laptop in WXGA (1280 x 800). WXGA resolution gives
30% more pixels than XGA.
XGA WXGA
PROJECTOR CONTROL AND MANAGEMENT
Projectors can be controlled and monitored over a network (LAN)
using a web browser.
Manage up to 99 projectors at the same time (via master PC)•
Control and alter the projector settings using a simple web•
browser page
Instant onscreen display of messages to projectors
•
Set up email alerts for warning messages•
Ideal for large installations both in the educational and business•
environments
1 2 3
1 3
2 4
CONTROL
The extensive RS232 command structure makes it simple and easy
to control the EW766 with any control system.
AMX Compatibility – Dynamic Discovery
Protocol is incorporated into the EW766.
This feature allows for easy installation with
AMX control systems.
1.5X ZOOM AND PURESHIFT - EASY INSTALLATION
The EW766 can project a 100” diagonal image from any distance
between 3.4m and 5.2m. The PureShift system provides a lens shift
function that can be used to adjust the position of the projected
image either horizontally or vertically within the range detailed in the
diagrams below.
When replacing existing projectors, the 1.5x zoom and PureShift
system will greatly increase your installation flexibility.
25%
Max
30%
Max
30%
Max
5.2m
3.4m
100”
Screen
Above diagrams for guide purposes only
Powerful installation projector
Widescreen, HD Ready. The high performance EW766 with a brightness of 4000 ANSI Lumens is ideally partnered
with a widescreen notebook and HD sources to deliver bright widescreen images from a great distance.
The introduction of PureShift technology gives your projector outstanding flexibility and with a 1.5x zoom makes the
EW766 an ideal replacement for existing ceiling mounted systems.
The environmentally friendly EW766 has energy saving features including <1W standby mode and auto power
off saving you both time and money. Long lamp-life of 4000hrs combined with our unique Optoma Colour guarantee
ensures hassle-free, long-lasting projection.
EW766

EXTENSIVE CONNECTIVITY
This native WXGA projector accepts a wide variety of computer and
video input signals. Connectivity includes: HDMI, dual VGA–SCART
and Component, S-Video, Composite, RS232 and RJ45.
Three audio inputs for individual PC and video connections enable
the EW766 to function as an audio switcher and volume controller,
thereby eliminating complicated and costly additional audio
hardware and cabling.
CLEAR, FOCUSED IMAGES
Technology from Texas Instruments produces a stunning 2500:1
contrast ratio for pin sharp graphics and crystal clear text. Crisper
whites, ultra-rich blacks make images come alive and text easier
to read - ideal for business and education presentations.
o read
500:1 contrast ratio 2500:1 contrast ratio
‡Simulated Image
AMAZING COLOURS
The EW766 incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
COLOUR GUARANTEE
We are so confident that the EW766 image colour quality will remain
as good as the day you bought it that Optoma will guarantee it for
five years.
5
MAINTENANCE FREE = LOWER TOTAL COST
OF OWNERSHIP (TCO)
DLP® technology ensures lower cost of ownership, longer life and
improved reliability compared to other technologies.
The filter-free projector design means no more regular filter cleaning
or replacements, saving you time and money.
ENVIRONMENTALLY FRIENDLY
The EW766 incorporates energy saving features to reduce power
consumption and extend the lamp life.
The timer control functions can automatically switch the projector
off to standby mode <1W, conserving power and extending the
lamp life to an astonishing 4000hrs**.
FEATURES
Preset display modes
Easy to use remote with laser pointer, mouse control
and direct source selection
Direct power on and Auto power off
Customised start-up logo
EW766

Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.co.uk
*Optoma guarantees that in normal use, Optoma DLP®colour quality will be indistinguishable from when new. Exclusions: (a) Guarantee is voided if the projector is subject to damage through misuse. (b) Guarantee may be void in industrial or commercial
entertainment environments where dust or smoke is excessive (c) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working due to other faults. (d) Over time worn lamps within all projector types will show a slight colour
variance.**Typical lamp life achieved through testing.Will vary according to operational use and environment conditions. Copyright © 2012, Optoma Europe Ltd.All other product names and company names used herein are for identifications purposes only and
may be trademarks or registered trademarks of their respective owners. Errors and omissions excepted, all specifications are subject to change without notice. DLP®, BrilliantColor™ and the DLP logo are registered trademarks of Texas Instruments. All images of
products are for representation purposes only.Whilst every care is taken to provide accurate images of our products, actual products may differ slightly. Some product images may have been digitally altered by us to add an Optoma logo to the front panel. Optoma
reserves the right to amend or alter actual product or product images without notice. Some images may be simulated.
EW766
EW766 Remote Control
1Laser
2Remote Mouse
3Page Up/Down Control
4Help/Enter
5Vertical Keystone Correction
6Volume Control
7AV Mute
8Digital Zoom Control
9Direct Input Source Selection
EW766 Connections
10 USB (Remote Mouse)
11 HDMI (audio supported)
12 DVI-D
13 VGA 1 - SCART & Component
14 VGA 2
15 VGA Out
16 S-Video
17 Composite Video
18 RS232 - 3 Pin
19 RJ45
20 Audio In (DVI-D)
21 Audio In (VGA 1 & 2)
22 Audio Out
23 Audio In L&R (S-Video & Composite)
24 +12v Trigger
25 Kensington™ Lock
EASY TO USE REMOTE CONTROL
EW766 Projection Distance 1.2 - 10m (16:10 Aspect Ratio)
Projection Distance (m) Max. Horizontal
Image Size (m)
Min. Horizontal
Image Size (m) Max. Screen Height (m) Min. Screen Height (m) Max Diagonal Image Size (m)
Min Diagonal
Image Size (inch)
Max Diagonal
Image Size (inch)
1.20
2.00
2.50
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
0.76
1.27
1.59
1.91
2.55
3.18
3.82
4.46
5.10
5.73
6.37
0.50
0.84
1.05
1.26
1.67
2.09
2.51
2.93
3.35
3.77
4.18
0.48
0.80
1.00
1.19
1.59
1.99
2.39
2.79
3.18
3.58
3.98
0.31
0.52
0.65
0.78
1.05
1.31
1.57
1.83
2.09
2.35
2.62
0.90
1.50
1.88
2.25
3.00
3.76
4.51
5.26
6.01
6.76
7.51
23.31
38.85
48.56
58.28
77.70
97.13
116.55
135.98
155.40
174.83
194.26
35.49
59.14
73.93
88.71
118.29
147.86
177.43
207.00
236.57
266.14
295.71
For guide purposes only
EW766 is also capable of 16:9 & 4:3 aspect ratio projection. When projecting a 16:9 & 4:3 image the image sizes, screen height and offset information
will differ from the above.
Easy to use remote
with buttons to
change the input
sources
EW766 SPECIFICATIONS
Brightness - BRIGHT mode 4000 ANSI Lumens
Contrast 2500:1
Native Resolution WXGA 1280 x 800
Compressed Resolution UXGA (1600 x 1200)
Noise Level 28dB
Keystone Correction ± 40° Vertical
PureShift Movement +25% Vertical, ±30% Horizontal (Max Movement)
Before installation please read EW766 install guide
Projection Lens F/2.45 ~ 2.9; f=22.18 ~ 33.27mm, 1.5x Manual Zoom
Throw Ratio 1.57 - 2.39:1 (Projection Distance:Image Width)
Projection Distance 1.2 - 10m
Image Size 0.59 – 7.51m (23.32” - 295.71”) Diagonal 16:10
Display Technology Single 0.65” WXGA DMD chip DLP® Technology
by Texas Instruments
Aspect Ratio 16:10 Native, 16:9, 4:3 Compatible
Lamp Life** 4000/3000 (STD/BRIGHT mode)
Weight 4.6 kg
Dimensions (W x D x H) 364 x 283 x 127 mm
Remote Control Full function remote with mouse control, laser pointer
and direct source selecting
INPUTS HDMI (HDCP) - audio supported
DVI-D (HDCP)
2 x 15 Pin D-Sub VGA (SCART & Component via adaptor)
S-Video 4 Pin Mini Din
Composite RCA
3 x 3.5mm Audio Mini Jack
USB (remote mouse)
CONTROL RS232 - 3 Pin D-sub & RJ45 - Network Control
OUTPUT 15 Pin D-Sub VGA (monitor loop-through)
3.5mm Audio Mini Jack
+12v Trigger
Audio 4W Speaker
On Screen Display 18 Languages: English, German, French, Italian, Spanish,
Portuguese, Polish, Dutch, Russian, Finnish, Swedish,
Greek, Norwegian, Danish, Hungarian, Czech,
Turkish & Arabic
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 134.2 Million
Horizontal Scan Rate 15 - 91.1kHz
Vertical Scan Rate 50 - 85Hz
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 233W BRIGHT mode < 1W Standby mode
207W STD mode < 1W Standby mode
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max),
3000m Altitude (Max)
Security Kensington Lock Port, Password Protection
Standard Accessories Lens Cover, AC Power Cord, VGA Cable, RS232 Cable,
USB Cable, Full Function Remote, Batteries x 2, Quick
Start Guide, CD User Manual, Warranty Card, WEEE Card
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country. Please see
www.optomaeurope.com or ask your local
supplier for details
Colour Guarantee* 5 Years
5 6
78
9
1
2
3
4
Exceptional Connectivity / Multiple Terminals
10 12 1513 14 16 1811 19
20 21 22 23 24
17
25
