S316 Bright projection
Bright projection – 3200 ANSI Lumens
SVGA resolution, 15,000:1 contrast ratio, HDMI input
Low ownership costs - up to 10,000 hours² lamp life
Lightweight and portable, carry bag included

S316
Simple to connect to with HDMI connectivity the S316 is ideal for use in a meeting room or classroom. The bright 3200L with 15,000:1 contrast
allows you to project bright, crystal clear images with superb colours using DLP®, BrilliantColor™ and Dynamic Eco+ technology.
The S316 also provides you with energy and cost saving features with an incredible lamp life of up to 10,000 hours. It also incorporates a built in
speaker, Full 3D technology and optional wireless capabilities allowing you to present wirelessly from a PC or mobile device with ease. Installed or
on the move with the included carry bag, the versatile S316 is the perfect projector for all your display needs.
Eco+ technology from Optoma increases our
commitment to reducing the impact we all
make on the environment
Eco AV mute off
100% power consumption
Eco AV mute on
25% power consumption
Green Solutions
Dynamic Mode
Saving energy saves money! Dynamic Mode reduces the power
consumption to as little as 30%. This intelligent feature can more than
double your expected lamp life, lowering the total cost of ownership
and reducing maintenance.
Eco AV Mute
Stay in control of your presentation with the Eco AV mute feature.
Direct your audience's attention away from the screen by blanking the
image when no longer needed. This also instantly reduces the power
consumption to 25%, further prolonging the life of your lamp.
Power Consumption
100% Bright mode
80%
Dynamic mode
Eco
30%
Quick Resume On
Rapid Off
It takes less than 10 seconds for the projector to power up and
shutdown, saving both time and energy.
Quick Resume
Save time by not waiting for the projector to cool down before it can
power up again. If the projector is accidentally turned off, this feature
allows the projector to be instantly powered on again, if selected
within a period of 100 seconds.
Full 3D
Using the inherent speed of DLP technology, The Optoma S316. Full
3D projector can display true 3D content form any 3D display device,
such as 3D Blu-ray, PS3, Xbox and Sky3D.
Audio Performance
Built-in 2W speaker offers excellent audio support. The S316 is easy
to set up without the need for costly external speakers
Brightness Where It Matters
Room lighting can be unpredictable for the business traveller; you
never know what to expect. The S316 has a powerful lamp producing
3000 ANSI Lumens, so you can be sure your presentation will be
bright and clear.
instant on (within
100s)

2000:1 Contrast Ratio 15,000:1 Contrast Ratio
Cost Saving – Long Lamp Life
Reduce the number of lamp changes with lamp life of up to 10,000
hours² using the Education Cycle.
Clear, Focused Images
Produce a stunning 15,000:1 contrast ratio for pin sharp graphics and
crystal clear text using the unique Dynamic mode feature.
Combined with DarkChip3 technology for Texas Instruments,
Dynamic mode automatically adjusts the lamp output, based on the
brightness information of each frame; to create a stunning high
contrast ratio. Bright scenes are crisp and clear, while dark scenes
remain detailed with deep blacks which gives exceptional light and
shade detail.
Lamp Mode
Bright
Eco
Dynamic
Education Cycle
Lamp Life (Hours)
Simple and easy – connect using a HDMI cable for
a digital audio and video connection to your
projector giving you a clear projected image with
sound.
We know that improving our products is
the best way to reduce our impact on the
environment. That's why at Optoma we
design our products to have a long usable
life, use fewer materials, ship with the
minimum packaging and be free of all
possible toxic substances. Naturally,
energy efficiency and being recyclable are
built in at the design stage. With each new
product, we strive towards minimising our
environmental impact.
Digital Connectivity
Wireless Presenting (optional extra)
Making presentations couldn't be easier using the optional wireless
features of the S316. Using the Wireless Adapter you can connect
and display presentations and video material wirelessly from a laptop,
PC or mobile device. (Additional power required)

S316 Specification
Display Technology Single 0.55” SVGA DC3 DMD chip DLP® Technology by Texas Instruments
Native Resolution SVGA 800 x 600
Brightness1 (Bright Mode) 3200 ANSI Lumens
Contrast 15,000:1
Noise Level (Eco mode) 29dB
Weight (kg) 2.35
I/O Connectors Inputs: HDMI (v1.4a 3D), 2 x VGA (YPbPr/RGB/Wireless), S-Video, Composite, 2 x Audio In 3.5mm
Outputs: VGA Out, Audio Out 3.5mm
Control: RS232 - 9 Pin
Maximum Resolution UXGA 1600 x 1200
Computer Compatibility UXGA, SXGA, XGA, SVGA, VGA, Mac
Video Compatibility PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25,MHz, 4.4MHz, 480i/p,
576i/p, 720p(50/60Hz), 1080i(50/60Hz) 1080p(24/50/60Hz)
Displayable Colours 1073.4 Million
Projection Lens F/2.41~2.55; f=21.8~23.98mm, 1.1x Manual Zoom
Throw Ratio 1.95 - 2.15:1
Projection Screen Size 0.70 - 7.62m (22.9" - 300") Diagonal 4:3
Projection Distance 1.2 - 12 metres
Zoom Type 1.1x Manual
Aspect Ratio 4:3 Native, 16:9 Compatible
Offset 115%
Horizontal Scan Rate 15.3 - 91.1kHz
Vertical Scan Rate 24 - 85Hz
Lamp Type 190W
Keystone Correction ± 40° Vertical
Audio 2W
Dimensions (W x D x H) 314.6 x 222.6 x 101.7
Remote Control Card style remote with direct source selecting
Power Supply 100-240V, 50-60Hz
Power Consumption 225W BRIGHT mode < 0.5W Standby mode, 191W Eco mode < 0.5W Standby mode
Operating Conditions 5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m
Uniformity 80%
Security Security Bar, Kensington Lock, Password Protection
Standard Accessories Carry Bag, AC Power Cord, VGA Cable, Infra Red Remote Control with Batteries, Quick Start Card, CD User Manual, Warranty
Card
Optional Accessories Ceiling Mount Kit, WPS
RoHS Compliant
3D Support The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D
educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games
from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification.
3D Viewing Requires the Optoma DLP-Link shutterglasses - available separately.
3D Compatibility Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60
On Screen Display 19 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek,
Norwegian/Danish, Hungarian, Czech, Turkish, Romanian, Farsi and Arabic.
Optional Wireless Yes
Features Eco+, Up to 10,000 hours lamp life - Education Cycle

S316 Remote Control
1. Power
2. Source
3. VGA 1 / VGA 2
4. HDMI
5. Format
6. Up / Keystone +
7. Right / Volume +
8. Enter
9. Zoom
10. Down / Keystone -
11. Lamp Mode
12. Mute
13. AV Mute
14. Menu
15. Left / Volume -
16. 3D
17. Video / S-Video
18. ReSync
Easy To Use Remote
S316 Connections
1. S-Video
2. VGA Out
3. VGA 1
4. VGA 2
5. Video
6. Audio2 In
7. Security Bar
8. Audio Out
9. Audio1 In
10. RS232 9 Pin
11. USB (Service / Mouse)
12. HDMI
13. Power
14. Kensington Lock
Exceptional Connectivity / Multiple Terminals
S316 distance Table aspect ratio 4:3
Projection
Distance (m)
Max. Horizontal Image
Size (m)
Min. Horizontal Image
Size (m)
Max. Vertical Image
Size (m)
Min. Vertical Image
Size (m)
Max Diagonal Image
Size (m)
Max Diagonal Image
Size (inch)
Max. Image
Offset (m)
1.20 0.62 0.56 0.46 0.42 0.77 30.31 0.07
2.00 1.03 0.93 0.77 0.70 1.28 50.52 0.12
2.50 1.28 1.16 0.96 0.87 1.60 63.15 0.14
3.00 1.54 1.40 1.16 1.05 1.92 75.78 0.17
4.00 2.05 1.86 1.54 1.40 2.57 101.04 0.23
5.00 2.56 2.33 1.93 1.75 3.21 126.30 0.29
6.00 3.08 2.79 2.31 2.10 3.85 151.56 0.35
7.00 3.59 3.26 2.70 2.45 4.49 176.82 0.40
8.00 4.10 3.72 3.08 2.80 5.13 202.08 0.46
9.00 4.62 4.19 3.47 3.15 5.77 227.34 0.52
10.00 5.13 4.65 3.86 3.50 6.42 252.60 0.58
11.00 5.64 5.12 4.24 3.85 7.06 277.86 0.64
12.00 6.15 5.58 4.63 4.20 7.70 303.12 0.69
For guide purposes only
S316 is capable of 16:9 aspect ratio projection. When projecting a 16:9 image the image sizes, screen height and offset information will differ from the above.
