oqan QLS-6 Street Partner User manual

USER MANUAL
QLS-6 Street Partner

-Every person involved with the installation, operation and maintenance of this device has to be qualified.
-Follow the instructions of this manual.
-Consider this manual to be part of the total product.
-Keep this manual for the entire service life of the product.
-Pass this manual on to every further owner or user of the product.
-Download the latest version of the user manual from the In ternet.
For your own safety, please read this user manual carefully before your initial start-up.
>>
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning
notes written in this user manual.
DANGER OF BURNING!
The materials used in this speaker system are norma
lly flammable. If B1 is required at the
installation place, the surface must be treated witan appropriate fire retardant in regular
intervals.
CAUTION!
Keep this device away from rain and moisture!
DANGER TO LIFE!
This speaker system must never be suspended.
This speaker system must never be stacked.
DANGER TO LIFE!
A crashing speaker system can cause deadly accidents. All safety instructions given in this
manual must be observed.
CAUTION!
Be careful with your operations. With a dangerous v o ltage you can suffer a dangerous electric
shock when touching the wires!
WARNING!
Speaker systems must only be operated by trained persons. Danger of Life due to crashing
speaker systems or hearing loss due to excessive sound pressure levels! The different local
conditions have to be considered in terms of safety rules.
1

Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not
accept liability for any resulting defects or problems.
Unpacking
Please make sure that there are no obvious transpor t
damages. Should you notice any damages on the
connection panel or on the casing, do not take the
speaker system into operation and immediately consu lt
your local dealer.
Protection Class
This device falls under protection class I. The power
plug must only be plugged into a protection class I
outlet. The voltage and frequency must exactly be the
same as stated on the device. Wrong voltages or power
outlets can lead to the destruction of the device and to
mortal electrical shock.
Power Cord
Always plug in the power plug least. The power plug
must always be inserted without force. Make sure that
the plug is tightly connected with the outlet. Never let
the power cord come into contact with other cables!
Handle the power cord and all connections with the
mains with particular caution! Never touch them with
wet hands, as this could lead to mortal electrical shock.
Never modify, bend, strain mechanically, put pressure
on, pull or heat up the power cord. Never operate next
to sources of heat or cold. Disregard can lead to power
cord damages, fire or mortal electrical shock. The cable
insert or the female part in the device must never be
strained. There must always be sufficient cable to the
device. Otherwise, the cable may be damaged which
may lead to mortal damage. Make sure that the power
cord is never crimped or damaged by sharp edges.
Check the device and the power cord from time to time.
If extension cords are used, make sure that the core
diameter is sufficient for the required power
consumption of the device. All warnings concerning the
power cords are also valid for possible extension cords.
Always disconnect from the mains, when the device is
not in use or before cleaning it. Only handle the power
cord by the plug. Never pull out the plug by tugging the
power cord. Otherwise, the cable or plug can be
damaged leading to mortal electrical shock. If the power
plug or the power switch is not accessible, the device
must be disconnected via the mains.
If the power plug or the device is dusty, the device must
be taken out of operation, disconnected and then be
cleaned with a dry cloth. Dust can reduce the insulation
which may lead to mortal electrical shock. More severe
dirt in and at the device should only be removed by a
specialist.
Liquids
There must never enter any liquid into power outlets,
extension cords or any holes in the housing of the
device. If you suppose that also a minimal amount of
liquid may have entered the device, it must immediately
be disconnected. This is also valid, if the device was
exposed to high humidity. Also if the device is still
running, the device must be checked by a specialist if
the liquid has reduced any insulation. Reduced
insulation can cause mortal electrical shock.
Foreign Objects
There must never be any objects entering into the
device. This is especially valid for metal parts. If any
metal parts like staples or coarse metal chips enter into
the device, the device must be taken out of operation
and disconnected immediately. Malfunction or short-
circuits caused by metal parts may cause mortal
injuries.
Secure Setup
Please note that speaker systems could move due to
bass beats and vibrations. Furthermore, unintended
pushes from DJs, musicians or the audience present
further risk. This is why the speaker system must
always be secured against moving or the respective
area has to be blocked.
Prior to Switching on
Before the speaker system is switched on all faders and
volume controls have to be set to zero or minimum
position.
Children and Amateurs
Keep away children and amateurs!
Maintenance and Service
There are no serviceable parts inside the speaker
system. Maintenance and service operations are only to
be carried out by authorized dealers!
2

Controls and functions

Model:
Product type:
Low/mid driver dimensions :
Type:
RMS:
Amplifier:
P powereak :
Woofer magnet:
SPL(1W/1m):
Frequency response:
Max SPL. :
Protection circuits:
Controls:
I :ndicators
Supported media(opioion):
Media player display elements:
Line inputs:
Line input connectors:
Mix i nputs:
6.5"
portable PA Speaker
Ferrite
25W
100W
80Hz-20kHz
110dB
short circuit overcurrent
93dB
Master, Voice priority on/off, Line Gain, Bass Treble, Power, Mic Gain
Charge/battery status,Power
Bluetooth, USB, SD
Lighted multifunctional lc display
3
RCA, 6.5min/XLR, 3.5mm Jack
XLR/ 6.3mm Jack
active
Class D
QLS-6 Street Partner
Mix outputs:
Line output connectors:
Frequency Response :
Radio Frequency Range:
Operating Voltage:
RF Transmitter Power Output:
Rechargeable batteries:
lndicators:
Cabinet construction:
Cabinet material:
Dimensions(WxHxD):
Weight:
Other features:
Indicators:
50-17.000Hz
6.3mm Jack
RF(LED),AF(LED)
External 100-240V AC switch mode power supply, 19V DC, 3A
12V/2.6 AH
polypropylene
220X320X205mm
6kg
vented
35mm stand mount, transport handle
Charge/battery status,Power
865MHz
10 mW
1
