ORACLE LIGHTING OWP-FC-211-LED User manual
OWP-FC-211-LED INSTRUCTIONS
LED Full Cut-OffWall Pack
SAFETY INSTRUCTIONS
1. Equipment should be mounted securely in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel. 2. Do not mount near gas or electric heaters. 3. Cap unused wires with enclosed wire nuts or other approved
method. 4. Do not use this equipment for anything other than its intended use. 5. The use of accessory equipment not recommended
by the manufacturer will void product listing and warranty and may cause an unsafe condition. 6. Use caution when servicing batteries. 7. Any
service on this equipment should be performed by qualified personnel only. 8. Make sure wire terminations are secure and leads are properly
tucked in appropriate wire channels. CONSULT A QUALIFIED ELECTRICIAN BEFORE INSTALLING
1.
Conduit Installation
Loosen screws and remove the front lens set carefully from the back
plate.
2.
Remove the knockout cap (A) from where you intend to feed conduit.
Attach the back plate on the wall, use the supplied gaskets for a
weather tight seal.
3.
Connect the wiring.
4.
Replace the lens set on the hinges, make connections and close the lens
set then tighten the screws.
Replace the lens set on the hinges, make connections and close the lens
set then tighten the screws.
PAGE 1 OF 2
O.R.-Revision A: 3/13/20
Caution:
Disconnect AC power before servicing and installation.
All electrical connections must be in accordance with
NEC/CEC or your local code.
3.
Connect the wiring.
A: 1/2" NPS tapped holes
B: 1/2" dia. knockout
C: 5/16" dia. Screw hole
4.
1.
2.
Remove/drill the knockout cap (B) for wiring. Attach the back plate on
the wall, use the supplied gaskets for a weather tight seal. Use
water proof caulk for covering screws (C).
Junction Box Mounting
Loosen screws and remove the front lens set carefully from the back
plate.
OWP-FC-211-LED INSTRUCTIONS
LED Full Cut-OffWall Pack
1.
Troubleshooting
Check that the line voltage at the fixture is correct. Refer to wiri
ng
directions.
2.
Is the fixture grounded properly?.
3.
Be sure the photocell, if used, is functioning properly. To check bypass it.
Use photocell rated for your supply voltage.
PAGE 2 OF 2
O.R.-Revision A: 3/13/20
Wiring Diagram
For 0-10V dimming version, please check wiring diagram below..
Photocell Installation (Optional)
1.
Install photocell and wire as per diagram.
2.
Elite Part#:PC120-277
Wiring Diagram
