Congratulations on choosing our company product! We thank you for your custom.
◆ Please keep in mind that this product, like other products of the company, adheres to the concept of
people-oriented design and manufacture, and takes product quality as the foundation.
◆ We put the interests of customers first, and do our best to meet customer requirements.
◆ Please read this instruction manual carefully and keep it for future reference. In the case of fully
understanding the product information, strictly abide by theUse the instruction manual to ensure that
the product is installed, used and serviced correctly and safely.
◆ Our company is not responsible for any damage to lamps or other performance due to personal failure
to follow the instructions during installation, use and maintenance.responsibility.
◆ Our company reserves the right to modify the manual at any time and without prior notice.
1. Safety Instructions....................................................................................................2
2. Technical Specifications ...........................................................................................5
2.1. Attachment And Size ........................................................................................8
3. Color/Effect/Gobo/Prism...........................................................................................9
3.1.Replacing Rotating Gobos....................................................................................10
4. Connection and control ..........................................................................................13
4.1. Power supply connection...............................................................................13
4.2. DMX 512 Connection......................................................................................14
4.3. Control Panel..................................................................................................15
5. How To Set The Unit ...............................................................................................16
5.1. Main Function.................................................................................................16
5.2. Channel Setting..............................................................................................22
5.3. Address Setting..............................................................................................22
5.4. DMX 512 Configuration ..................................................................................23
6. Electrical Connection Diagram ...............................................................................29
7. Troubleshooting......................................................................................................30
8. Fixture Cleaning......................................................................................................37
9. Duty exonerative And Copyright Protectio .............................................................37

-2-
The following symbols are used to identify important safety information on the product
and in this manual:
WARNING
1.Safety Instructions
Important:
Damages caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any resulting defects or problems.
 Unpack and check carefully to ensure that there is no transportation damage before
using the unit.
 This product is for indoor use only. Use only in a dry location.
 Do install and operate by qualified operator.
 The light source in this luminaire should be replaced by the manufacturer or its service
agent or a similarly qualified person, always cut off the power supply before replacing
he light source.
 Do not allow children to operate the fixture.
 Use safety chain when fixing the unit. Handle the unit by carrying its base instead of
head only.
Please read the instruction carefully which includes important information about
the installation, usage and maintenance.
Please keep this User Manual for future consultation. If you sell the unit to another user,
be sure that they also receive this manual.

-3-
 The unit must be installed in a location with adequate ventilation, at least 20cm from
adjacent surfaces.
 Be sure that no ventilation slots is blocked, otherwise the unit will be overheated.
 Before operation, ensure that you are connecting this product to the proper voltage in
accordance with the specifications in this manual or on the product’s specification label.
 It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
 Minimum ambient temperature Ta: 0℃. Maximum ambient temperature Ta: 40℃.
Do not operate this product at a lower or higher temperature.
 Do not connect the device to any dimmer pack.
 When the lamp is running, do not place combustible objects next to it. The shortest
distance between the device and inflammable and explosive objects or materials is
0.5m.
 Make sure the power cord is not crimped or damaged; replace it immediately if
damaged.
 Unit’s surface temperature may reach up to 80℃. do not touch the housing
bare-handedduring its operation.
 Avoid any flammable liquids, water or metal from entering the unit. once it happens,
cut off the mains power immediately.
 Do not operate in a dirty or dusty environment. do clean the fixture regularly.
 Do not touch any wire during operation as there might be a hazard of electric shock.
 Avoid entanglement of the power cord with other wires.
 The minimum distance to objects/surface must be more than 12 meters.
 In the event of serious operating problem, stop using the unit immediately.
 Never turn on and off the unit time after time.
 The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
 Do not open the housing as there are no user serviceable parts inside.
 Do not attempt to operate this unit if it becomes damaged. do not attempt any repairs
yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center if needed.

-4-
 Disconnect this product from its power source before servicing.
 Do use the original packaging if the device is to be transported.
 Avoid direct eye exposure to the light source while the product is on.
 Do not operate this product if you see damage on the housing, shields, or cables.
Have the damaged parts replaced by an authorized technician at once.
Installation:
The fixture should be fixed on the clamp. Always ensure that the unit is firmly fixed to
avoid vibration and slipping off during operation. Ensure that the trussing or area of
installation must be able to hold 10 times the weight without any deformation. Always
install a safety cable that can hold at least 12 times the weight of the fixture when
installing.
Do install and operate by qualified operator. It must be installed in a place where there
is out of the reach of people.

-5-
2.Technical Specifications
OPTICAL
- Light source:
OSL5 Adopt special customized bulbs jointly developed by our company and Osram.
- Zoom range: Beam mode 2.3-12°, Spot mode 9-36°, Wash mode 15-53°
- Optical lens: diameter 138mm
- Color temperature: 6200K
- Color rendering index: Ra≥80
- Light degree: 346000 lux @10M
COLOR
- CTO color temperature linear adjustment (2700K-6200K)
- 13 color chips + white light, can realize two-way color rainbow, two-color step-by-step gradient
(linear movement), color wheel two-way rotation, random color mode.
PATTERN
- Rotating gobo wheel: 7 glass gobos + white light, pluggable and replaceable, the outer
diameter of the gobo is 22.9mm, and the inner diameter of the gobo is 17mm, which can realize
the effects of rotation, flowing water and shaking.
- Fixed gobo wheel: 11 gobos + white light + 1 uniform optical lens, which can realize the effects
of rotation, flowing water and shaking.
- Dynamic wheel: it can be used alone or combined with the gobo wheel, and the speed of
rotation in both directions can be adjusted.
EFFECT
- 8 prisms + 6 rows of prisms: can be rotated in both directions, can be switched independently,
and can be superimposed.
- Soft light Effect: adjustable independent soft light effect
- Focus: high-precision electric focus- Strobe: 0.5-12 times/second adjustable pulse strobe and
random strobe- Dimming: 0-100% linear adjustment
CONTROL AND PROGRAMMING
- Control channel: 21CH, 24CH
- Protocol: standard DMX512 protocol, RDM protocol
- Data connection: three-core or five-core signal input/output
- Display: LCD liquid crystal screen

-6-
SOFTWARE
- Upgrade software via USB or DMX interface
X/Y AXIS MOVEMENT ANGLE
- X-axis: 540° 8bit/16bit precision scanning
- Y axis: 270° 8bit/16bit precision scanning
POWER
- Input voltage: AC 100-240V 50/60Hz
- Maximum power: 550W
- Power factor: 0.987
SIZE & WEIGHT
- Product size: 380mm×300mm×646mm
- Net weight: 22.5 kg
- Carton packing (default): 450mm×390mm×745mm
- Gross weight: 26.2 kg
- Flycase (option-2 sets) :810mmx530mmx845mm
- N.W: 45.0 Kg G.W: 84.5Kg
OTHERS
- Protection class: IP20
- Working environment: 0℃ ~ 40℃
- Maximum surface temperature of the lamp body: 80℃
- Maximum lamp current: 5.5A/110V; 2.75A/220V
APPROVALS
- The product implementation standard: GB 7000.1-2015 GB7000. 217-2008
、- Approved certifications: CE RoHs
- The product complies with the following EU directives:
Low Voltage Directive 2014/35/EU . EMC Directive 2014/30/EU

-7-
illuminationdiagram
10 20 30 50
12°
2.3°
diameter(m)
diameter(m)
Distance(m)
0.41 0.82 1.23 2.05
2.12 4.24 6.36 10.6
2.3° Lux
12° Lux 12800 3200 1400
500
346000 86500 38000 13800
0.6
3.18
5700
154000
15

-8-
2.1.Attachment And Size
Attachment contents-Fig.1
Size-Fig.2
Certificate of conformity power cord
x2 x2

-9-
3.Color/ /Gobo/PrismEffect
Color、Effect
GOBO
6 Prism 8Prism
Prism
Linear CTO
1
2
3
4
5
6
7
Mag net
10
11
12
13
Dark red
628
Orange
1-588
Aquama rine
445/53 5
Dark gre en
507/54 8
Green
508/594
Light pu rple
438/467
Pink
480/589
Y
522
M
456/612
blue
498
CTO 2
(2500K)-560
CTO 1
(3 200 K)- 556
Dark blue
444
Reverse

-10-
3.1.Replacing Rotating Gobos
1.Use a screwdriver to unscrew the two screws at [A] to take out the pattern color module
assembly.
A
step 5：Remove the rotating gobo wheel
step 4：Disassemble the effect plate
step 3：Remove the fixed pattern plate
step 2：Disassemble the color plate
step 1：Remove pattern
color module light baffle
2.Turn the module upside down, remove the corresponding materials in the following order,
and then remove the rotating gobo wheel.

-11-
3.As shown in [B], gently lift the gobo driven wheel from the edge upwards from the back
of the gobo wheel and pull it out slowly to take out a single gobo.
B
4.Use tweezers or other small objects to take out the snap ring at [C] (if the pattern piece
is coated with glass glue for fixing, please use a professional Use the cleaning agent to
remove the glass glue and then take out the circlip, so as not to damage the pattern piece).
C
5. When assembling the gobo, avoid touching the gobo directly with your hands, and
as shown in [D], the coated surface of the gobo should face the light source.
D

-12-
6. Insert the gobo driven wheel into the driving wheel assembly, as shown in [E], the
concave point of the gobo driven wheel must face the center of the driving wheel when
positioning.
E
7. After the installation is complete, put the pattern plate assembly back on the lamp.

-13-
4.1.Power supply connection
- The bus connecting the power supply must be installed by a qualified professional technician.
- After completing all the above operations and ensuring that it is installed, you can power
on the lamp to operate.
4.Connection and control
The L terminal
is connected with
the brown line.
The N terminal
is connected with
the blue line.
L
N
The ground wire is
connected to the
yellow-green wire
POWER in
out
in POWER EN D

-14-
4.2.DMX 512 Connection
1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 1200hm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output
of the last unit.
2. Connect the unit together in a “daisy chain” by XLR plug cable from the output of the unit to
the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very
high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can easily
distort the signal and shut down the system.
3. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one
of the units’ power is disconnected.
4. Each lighting unit needs to have a DMX address to receive the data by the controller. The
address number is between 1-512.
5. The end of the DMX 512 system should be terminated to reduce signal errors.
6. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used.
DMX - output
1
- Shield
2 - Signal (-)
- Signal (+)
- Not connected
- Not connected
3
4
5
1
2
3
DMX-input
- Shield
- Signal (-)
- Signal (+)
- Not connected
- Not connected
4
5
DMX512 in
out out
in in SIG N A L EN D

-15-
OK confirmation key
UP
DOWN
To the left
To the right
4.3.Control Panel
1.Display: To show the various
menus and the selected function.
2.USB:Used to update software
versions
3.Button：
12 3

-16-
Main menu I menu II menu III menu
DMX Address → Address:001-512 1-512
ESC is -1, ENTER is +1
UP is + current channel number,
DOWN is - current channel number
→
Lamp hours Clear device time
Light source time Clear Light Time
Temperature light source/display panel/sensor 1/sensor 2 temperature
communication status
Motor information
fault status record
Device channel
Version
Manual control →
light bulb switch
→
ON /OFF
A confirmation dialog box will pop up, press
the confirm key to confirm the current operation,
and ESC/ENTER to exit. Turn on or off the light
bulb, the switch time interval is limited to 30S
Mode selection DMX/self-propelled/voice control/scene OK key to switch
Scene mode automatic /1~10 OK key to switch
Channel control
scene selection(1~10) OK key to switch
scene time （0s-25.5s） Press OK to enter the parameter modification interface
Channel parameter setting（0~255） Press OK to enter the parameter modification interface
Reset
X axis Yaxis Reset XY axis
colour reset color wheel
pattern Reset the gobo
Strobe reset strobe
Focusing and Prisms Reset focus and prism
whole reset all
Personal
Channel selection Select according to the number of existing channels in the program
Master-slave mode (effective when
not in DMX mode, select the data
output mode, the lamp automatically
detects the DMX state and
automatically switches the output to
prevent data conflict)
automatic The light fixture operates as built-in, if there is no
DMX signal, it will output data (synchronization),
otherwise it will not output data
Slave The lamps operate as built-in and do not output
data (do not synchronize with other lamps)
main engine If there is no DMX signal, the luminaire operates as built-in,
otherwise, the luminaire operates as the DMX signal
Xaxis reversal
Y
Optocoupler Correction
X axis offset 4~150
Y axis offset 4~48
Light-on mode (sets the way the
bulb is turned on for the first
time after it is powered on)
Power-on Turn on the bulb first when power on, reset the lamp after 30S
manual After the reset is completed, manually turn on the bulb
through the menu or console
after reset
Factory settings Restore to factory default parameter settings
display
setting
→
language
→
Chinese /English
→
screen protector
closure The screen is always on
model 1 Screen off after 20S
2The channel information is displayed after 20S,
and the screen backlight turns off after 30S
3The manufacturer's LOGO is displayed after 20S, and
the screen backlight turns off after 30S
screen rotation positive/reverse
pilot lamp
1On when there is a signal, off when there is no signal
2 Off when there is a signal, on when there is no signal
3Flashes when there is a signal, off when there is no signal
screen backlight 1~10
Parameter
calibration
Information
axis reversal
Display the communication status between the board and the motor board
Motor information in the device
Record the fault name and fault time
The current communication data of the device
Manufacturer/device name/model/display board version and
date/motherboard version and date
ON /OFF
ON /OFF
ON /OFF
model
model
model
model
model
Reset the lamp after 3 seconds of power-on, and turn on
the bulb after the reset is complete
After a period of inactivity, it will return to the
set brightness, and if it is operated, it will
return to full brightness
On the main interface, press and hold the exit button (the button on the left
side of the upright display) for 3 seconds, and a password box will pop up.
Enter the password 2222 to enter the parameter calibration interface.
The lamp is powered on. When the system initialization and lamp reset are completed, and the
standby interface is displayed on the display screen, press OK to enter the preset menu interface.
Use the up/down/left/right keys to select ① level menu: DMX address, basic information,
personality settings, manual control, service options, bulbs, language, screen rotation.
The main functions are as follows:
5.How To Set The Unit
5.1.Main Function

-17-
① DMX Address-
Enter the preset menu interface，select function，Press the OK key to enter the lower
menu, and use the up/down key to set the lamp address Code (001~497), the default address code
of the lamp is 001. After setting, press OK to confirm and return to the upper menu。
① Information -
Enter the preset menu interface，select function，Press the OK key to enter the lower menu,
and use the up/down keys to select the② level menu:Total running time, equipment time, equipment
temperature, RDM address, fan speed/voltage, equipment channel, software information, exit.
②Total Time
Select the Total Time function and press the OK key to enter the lower menu to view the
equipment: total power on (H) and total bright bulb (H). Press the OK key or the left/right key to return
to the previous menu.
②Totel time function
Select the Totel time function and press the OK key to enter the lower menu to view the equipment:
power on time (H) and light on time (H). Press OK key or left/right key to return to the upper menu.
②Equipment temperature
Select the Equipment temperature function, and press OK to enter the lower menu to view the
equipment: temperature measurement board temperature. Press the OK key or the left/right key to
return to the previous menu.
②RDM address
Select the RDM address function and press the OK key to enter the lower menu to view the device:
RDM address information. Press the OK key or the left/right key to return to the previous menu.
②Fan speed/voltage
Select the Fan speed/voltage function and press the OK key to enter the lower menu to view the
speed of the equipment: blower 1, blower 2, blower 1 and blower 2. Press the OK key or the
left/right key to return to the previous menu.

-18-
②DMX live
Select the DMX live function and press the OK key to enter the lower menu to view the channel
information of the equipment in the current channel mode. Press the OK key or the left/right key to
return to the previous menu.
②Version information
Select the Version information function and press the OK key to enter the lower menu to view the
version information of the equipment: XY board, effect board and display board. Press the OK key
or the left/right key to return to the previous menu.
① Personal-
Enter the preset menu interface，select function， press the OK key to enter the lower menu, and
use the Up/Down key to select the ② menu: channel mode, automatic light bulb opening, horizontal and
vertical inversion, display setting, exit, press the OK key to enter the lower menu, or press the left key to
return to the upper menu.。
②Channel Mode
Select the Channel Mode function and press OK to enter the lower menu. You can use up/down
keys to select: standard mode (24CH), simple mode (21CH). Press OK to confirm the selection
and return to the upper menu.
②Auto lamp on
Select the Auto lamp on function, press the OK key to enter the lower menu, press the Up/Down
key to select: On/Off(default), press the OK key to confirm the selection and return to the upper menu.
②P/T invert
Select the P/T invert function, and press OK to enter the lower menu. You can use up/down keys
to select: horizontal reverse and vertical reverse. Press OK to confirm the selection and return to
the upper menu.

-19-
②Display Settings
Select the Display Settings function, press the OK key to enter the lower menu, and use the
up/down keys to select the③menu: Language, backlight, screen rotation, backlight flashing, and
exit. Press the OK key to enter the lower menu, or press the left key to return to the upper menu.
③ Language
Select the Language function and press OK to enter the lower menu. You can use up/down keys
to select Chinese and English. Press OK to confirm the selection and return to the upper menu.
③ Back Light
Select the Back Light function, press the OK key to enter the lower menu, use the up/down key to
select: normally on, automatically off(15S), press the OK key to confirm and return to the upper menu.
③ Screen rotation
Select the Screen rotation function, press the OK key to enter the lower menu, and use the up/down
key to select: normal (default), 180 degree rotation, press the OK key to confirm and return to the
upper menu.
③ Backlight blink
Select the Backlight blink function, press the OK key to enter the lower menu, and use the up/down
key to select: open (default), close, press the OK key to confirm and return to the upper menu.
① Manual control-
Enter the preset menu interface，select function， press the OK key to enter the lower
menu, and use the up/down keys to select the ② menu: channel control, reset, test lamps, exit,
press the OK key to enter the lower menu, or press the left key to return to the upper menu.
②Channel control
Select the Channel control function, press the OK key to enter the lower menu, press the Up/Down
key to select each channel of the current channel mode, press the Left/Right key to manually adjust
the DMX value of each channel from 0 -255, and press the OK key to return to the upper menu.
