Oral-B iO 6 User manual

91451398 _iO6_EE_75x155.indd 191451398 _iO6_EE_75x155.indd 1 23.11.20 10:0923.11.20 10:09
Stapled booklet, 75 x 155 mm, 162 pages (incl. 6 pages
cover), Cover 4c, Inhalt = black + PMS 288 C

6
4
5
3
2
1
91451398 _iO6_EE_75x155.indd 291451398 _iO6_EE_75x155.indd 2 23.11.20 10:0923.11.20 10:09

8
7
18
222119 20
23
262524 27
15 1614 17
9
11 12 1310
91451398 _iO6_EE_75x155.indd 391451398 _iO6_EE_75x155.indd 3 23.11.20 10:0923.11.20 10:09

ab
ec d
fg
91451398 _iO6_EE_75x155.indd 491451398 _iO6_EE_75x155.indd 4 23.11.20 10:0923.11.20 10:09

5
Description
1 Brush head
2 Brush head identification symbol
3 Smart Pressure Sensor (Light Ring)
4 Interactive Display
5 Handle
6 Charger
7 On/off button
8 Mode button
9 Interactive Display features
10 «Daily Clean» mode
11 «Sensitive» mode
12 «Whiten» mode
13 «Gum Care» mode
14 «Intense» mode
15 «Super Sensitive» mode
16 «Tongue Clean» mode
17 Settings menu
18 Settings menu features
19 Manage Bluetooth
®
settings
20 Select/Change colour of Light Ring
21 Select/Change language
22 Perform factory reset
23 Feedback features
24 Timer
25 Battery status
26 Exchange reminder
27 Brush feedback
Accessories (depending on model) and features:
a Smart Pressure Sensor features
b Customize colour of Light Ring via Oral-B App
c Brush head «Ultimate Clean»
d Brush head «Gentle Care»
e Brush head holder with cap
f Brush head holder stand
g Travel case
h Download Oral-B App and connect to Bluetooth
®
(see back page)
Note: Content may vary based on the model purchased.
91451398 _iO6_EE_75x155.indd 591451398 _iO6_EE_75x155.indd 5 23.11.20 10:0923.11.20 10:09

6
English
Welcome to Oral-B!
Before operating this toothbrush, please read these
instructions and save this manual for future reference.
IMPORTANT
• Periodically check the entire product/
cords for damage. A damaged or
non-functioning unit should no longer
be used. If the product/cords are
damaged, take it to an Oral-B Service
Centre. Do not modify or repair the
product. This may cause fire, electric
shock or injury. Never insert any
object into any opening of the
appliance.
• Usage by children under age 3 is not
recommended. Toothbrushes can be
used by children and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge, if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and maintenance shall not be
performed by children.
• Children shall not play with the
appliance.
• Use this product only for its intended
use as described in this manual. Do not
use attachments which are not
recommended by the manufacturer.
Only use the charger provided with
your appliance.
91451398 _iO6_EE_75x155.indd 691451398 _iO6_EE_75x155.indd 6 23.11.20 10:0923.11.20 10:09

7
WARNING
•Do not place the charger in water or liquid or store where it
can fall or be pulled into a tub or sink. Do not reach for it
when fallen into water. Unplug immediately.
•Avoid sharp bending, jamming or squeezing of the cord.
•This appliance contains batteries that are non-replaceable.
Do not open and disassemble device. For battery recycling
please dispose whole device according to local environ-
mental regulations. Opening the handle will destroy the
appliance and invalidate the warranty.
•When unplugging, always pull the power plug instead of the
cord. Do not touch the power plug with wet hands. This can
cause an electric shock.
•If you are undergoing treatment for any oral care condition,
consult your dental professional prior to use.
•This toothbrush is a personal care device and is not intended
for use on multiple patients in a dental practice or institution.
For hygienic reasons we recommend the use of individual
brush handles and brush heads for each family member.
•Small parts may come off, keep out of reach of children.
To avoid brush head breakage which may generate a small
parts choking hazard or damage teeth:
•Prior to each use, ensure the brush head fits well. Discon-
tinue use of the toothbrush, if brush head no longer fit prop-
erly. Never use without a brush head.
•If the toothbrush handle is dropped, the brush head should
be replaced before the next use even if no damage is visible
•Replace brush head every 3 months or sooner if brush head
becomes worn.
•Clean brush head properly after each use
(see «Cleaning
recommendations» paragraph).
Proper cleaning ensures the
safe use and functional life of the toothbrush.
Important Information
•This toothbrush and pouch (accessory) contains NdFeB
magnets and generate magnetic fields. If you use a medical
device or have an implanted medical device, consult with
the medical device manufacturer or a physician, if you have
questions about safely using your Oral-B iO toothbrush.
•Your Oral-B toothbrush can be used with your smartphone
(find details under «Connecting your toothbrush to your
Smartphone»). To avoid electromagnetic interference and/
or compatibility conflicts, disable Bluetooth® on your tooth-
brush handle (5) before using it in restricted surroundings,
such as aircrafts or specially marked areas in hospitals.
•Disable Bluetooth by entering the «Settings» menu on the
interactive display (4) -> Bluetooth -> disable. Follow the
same procedure to enable Bluetooth again.
•Persons with pacemakers should always keep the tooth-
brush more than 15 centimeters (six inches) from the pace-
91451398 _iO6_EE_75x155.indd 791451398 _iO6_EE_75x155.indd 7 23.11.20 10:0923.11.20 10:09

8
maker while turned on. Anytime you suspect interference is
taking place disable Bluetooth.
Specifications
For voltage specifications refer to the bottom of the charging
unit.
Noise level: 64 dB (A)
First use
Please wake up your toothbrush by pressing the on/off button
(7) and follow the instructions on the interactive display (4) to
get started for first time setup.
If not further instructed on the display, you may toggle with the
mode button (8) and select with the on/off button (7).
You may change the settings via the «Settings» menu (17) at any
time.
Charging and Operating
•To charge the battery place the toothbrush on the
plugged-in charger (6).
•The charge level is indicated on the interactive display (4).
Once it is fully charged the display turns off. A full charge
typically takes 12 hours.
•If the battery is running low the motor reduces its speed and
the Smart Pressure Sensor (3) shortly blinks in red. Once
the battery is empty, the motor stops; it will need at least a
30-minutes charge for one usage.
Note: In case the battery is empty (display off), charge for at
least 30 minutes.
•You can always store the handle on the plugged-in charger
to maintain it at full charge; a battery overcharge is pre-
vented by the device.
Note: Store handle at room temperature for optimal battery
maintenance.
Caution: Do not expose handle to temperatures higher than
50°C / 122°F.
Using your toothbrush
Start Brushing
Place the brush head on the handle. A small gap should remain
between handle and brush head.
Lift the handle off the plugged-in charger or simply pick it up to
wake up the handle (display turns on). Wet brush head and
apply toothpaste. To avoid splashing, guide the brush head to
your teeth before switching the handle on by pressing the on/
off button.
91451398 _iO6_EE_75x155.indd 891451398 _iO6_EE_75x155.indd 8 23.11.20 10:0923.11.20 10:09

9
Note: Display turns off after some time. You may press the on/
off button to activate display again.
Guide the brush head from tooth to tooth. Brush the outsides,
the insides and the chewing surfaces. Brush all four quadrants
of your mouth equally. You may also consult your dentist or
dental hygienist about the right technique for you.
After Brushing, the display gives you feedback based on your
brushing time.
In the first days of using any electric toothbrush, your gums
may bleed slightly. In general, bleeding should stop after a few
days. Should it persist after 2 weeks, please consult your den-
tist or dental hygienist. If you have sensitive teeth and/or gums,
Oral-B recommends using the «Sensitive» or «Super Sensitive»
modes (optional in combination with an Oral-B «Gentle Care»
brush head (d)).
Availability of modes are depending on model purchased.
Timer
The timer signals with a short stuttering sound at 30-seconds
intervals to move to the next quadrant of your mouth. A long
stuttering sound indicates the end of the professionally recom-
mended 2-minute brushing time.
The timer memorizes the elapsed brushing time, even when
the handle is briefly switched off during brushing. The timer
resets if pausing longer than 30 seconds or placing the handle
on the plugged-in charger.
Note: During the use of the Oral-B App, the timer may be deac-
tivated for some features.
Note: You may also customize the timer settings via Oral-B
App.
Smart Pressure Sensor features (a)
Your toothbrush is equipped with a Smart Pressure Sensor (3)
that has various functionalities indicated via different colours of
light:
White (default) = Operating indicator (choose individual colour
via Oral-B App (b)) / Low pressure indicator
Red = high pressure indicator / low battery indicator
Green = recommended pressure indicator
Blue = Bluetooth pairing indicator
Orange = Error indicator (follow display messages)
Brush with the right pressure indicated with a green light. If too
much pressure is applied, it lights up in red reminding you to
reduce pressure. If the Smart Pressure Sensor illuminates in
white (or your pre-selected colour), we recommend applying
more pressure.
91451398 _iO6_EE_75x155.indd 991451398 _iO6_EE_75x155.indd 9 23.11.20 10:0923.11.20 10:09

10
During high pressure the brush head movement will be
reduced (in «Daily Clean», «Intense» and «Sensitive»
modes).
Periodically check the operation of the Smart Pressure Sensor
by pressing moderately on the brush head during use.
Note: During the use of the Oral-B App, the Smart Pressure
Sensor feedback may be inactive for some features.
Note: Smart Pressure Sensor is deactivated during «Tongue
Clean» mode (depending on model).
Brushing modes (depending on model)
Your toothbrush offers different brushing modes indicated on
the display:
«Daily Clean» – Standard mode for daily cleaning
«Sensitive» – Gentle, yet thorough cleaning for sensitive areas
«Whiten» – Polishing for occasional or everyday use
«Gum Care» – Gentle massage of gums
«Intense» – For an extraordinary clean feeling
(operated with a higher speed)
«Super Sensitive» – Super gentle cleaning for extra sensitive
areas
«Tongue Clean» – Tongue cleaning for occasional or everyday
use
Note: The sequence and availability of brushing modes may
vary depending on model purchased.
When operating the «Tongue Clean» mode, we recommend
using a «Gentle Care» brush head (d). You can brush your
tongue either with or without toothpaste. Brush the whole area
of your tongue systematically in gentle movements. The rec-
ommended brushing time
is 30 seconds; the motor stops after
30 seconds.
Mode setting:
You may first choose your default mode by pressing the mode
button (8) successively once the handle is awake (display
turned on). Select a mode by pressing the on/off button (7).
Your toothbrush starts in the selected default mode. You may
also change modes during brushing.
Note: You may also customize mode settings via Oral-B App.
Interactive Display
Turn on the interactive display (4) by pressing the on/off button
(7). If not further instructed on the display, you may toggle with
the mode button and select with the on/off button.
(10-16) «Mode selection» – toggle by pressing
the mode but-
ton and select default start mode
with on/off button.
91451398 _iO6_EE_75x155.indd 1091451398 _iO6_EE_75x155.indd 10 23.11.20 10:0923.11.20 10:09

11
(17) «Settings» – toggle through all modes until you reach the
option «Settings»; to enter press the on/off button:
-> (19) manage Bluetooth settings (enable, disable)
-> (20) select/change colour of Light Ring
-> (21) select/change language
-> (22) perform factory reset
(24) «Timer» – displays brushing time.
(25) «Battery status» – shows battery status
after use, when
charging or when battery is low.
(26) «Exchange reminder» – reminds you when to replace your
brush head.
(27) «Brush feedback »– brushing feedback is indicated with a
smiley face.
«Brush waking» when handle is picked up, lifted off the
plugged-in charger or when you press the on/off button the
handle indicates its readiness.
«Error messages» – «outside operating limits»: you are operat-
ing or charging outside standard temperatures and/or above
standard battery current.
Brush heads
Oral-B offers you a variety of different Oral-B iO brush heads
(c/d) that only fit your Oral-B iO toothbrush handle and can be
used for tooth-by-tooth precision cleaning.
Most iO Oral-B brush heads feature INDICATOR® bristles to
help you monitor brush head replacement need. With thorough
brushing, twice a day for two minutes, the colour will fade half-
way approximately within 3 months, indicating the need to
exchange your brush head. If the bristles splay before the col-
our recedes, you may exert too much pressure on teeth and
gums.
In general, we recommend replacing the brush head every
3 months.
Connecting your toothbrush to your
Smartphone
The Oral-B App is available for smartphones running iOS or
Android™ operating systems. It can be downloaded for free
from App Store
(SM)
/ Google Play™ or you may scan the QR
code on the back page of this manual (h).
•Launch the Oral-B App. It will guide you through the entire
Bluetooth pairing procedure. You may also find it under the
App´s settings (More -> Your brush).
Note: Oral-B App functionality is limited if Bluetooth is deacti-
vated on your smartphone (for directions please refer to your
smartphone’s user manual).
91451398 _iO6_EE_75x155.indd 1191451398 _iO6_EE_75x155.indd 11 23.11.20 10:0923.11.20 10:09

12
•Pairing is indicated via the Smart Pressure Sensor light. Any
App instructions will be displayed on your smartphone.
•You may change Bluetooth settings at any time on your han-
dle via the display -> Settings -> Bluetooth enable/disable.
•Keep your smartphone in close proximity (within 5m dis-
tance) when using it with the handle. Make sure the smart-
phone is safely positioned in a dry place.
Note: Your smartphone must support Bluetooth 4.2 (or
higher)/Bluetooth Smart in order to pair your handle. Check
app.oralb.com for compatible smartphones and country avail-
ability of the Oral-B App.
Caution: Follow your smartphone’s user manual to ensure your
phone/charger is designed for use in a bathroom environment.
Cleaning recommendations
After brushing, rinse your brush head under running water with
the handle switched on. Remove the brush head and clean the
handle and brush head separately. Make sure water runs inside
the top of the handle as well as inside the brush head. Wipe all
parts dry and let them air-dry before reassembling your tooth-
brush again.
Unplug the charger before cleaning. Clean the charger regu-
larly with a damp cloth.
Please check individual cleaning instructions for each acces-
sory in its «Accessories» paragraph.
Accessories
(depending on model)
Travel Case (g)
Store the clean and dry toothbrush/brush heads in the travel
case (g).
The outer and inner case should be cleaned with a damp cloth
only.
91451398 _iO6_EE_75x155.indd 1291451398 _iO6_EE_75x155.indd 12 23.11.20 10:0923.11.20 10:09

13
Note: Clean stains on travel case surface immediately. Store
travel case in a clean and dry place.
Brush head holder stand (f) / Brush head holder
with cap (e)
You may store your cleaned brush heads on the pins of the
brush head holders. Make sure brush heads are dried before
placing them in the holder and/or closing the cap. Brush head
holders and cap are dishwasher-safe.
Zipper Pouch / Magnetic Pouch
Store the clean and dry toothbrush/brush heads in the zipper
pouch.
The outer and inner case can be cleaned under running water.
Store the clean and dry toothbrush along with the brush head
holder (e) in the magnetic pouch. Make sure brush heads are
dried before placing them into the holder and/or closing the
cap. The outer and inner surfaces can be cleaned under
running water. Store pouches in a clean and dry place.
Note: Clean stains on pouch surfaces immediately.
Subject to change without notice.
Environmental Notice
Product contains batteries and/or recyclable
electric waste. For environment protection do not
dispose in household waste, but for recycling
take to electric waste collection points
provided in your country.
Guarantee
We grant 2 years guarantee on the product commencing on the
date of purchase.
Within the guarantee period we will eliminate, free of charge,
any defects in the appliance resulting from faults in materials or
workmanship, either by repairing or replacing the complete
appliance as we may choose. Depending on availability
replacement of a unit might
result in a different colour or an
equivalent model.
This guarantee extends to every country where this appliance
is supplied by Braun/Oral-B or its appointed distributor. This
guarantee does not cover: damage due to improper use, nor-
mal wear or use, especially regarding the brush heads, as well
as defects that have a negligible effect on the value or opera-
tion of the appliance.
91451398 _iO6_EE_75x155.indd 1391451398 _iO6_EE_75x155.indd 13 23.11.20 10:0923.11.20 10:09

14
The guarantee becomes void if repairs are undertaken by
unauthorized persons and if original Braun/Oral-B parts are not
used.
This appliance is equipped with a Bluetooth Smart approved
radio interface. Failure to establish a Bluetooth Smart connec-
tion to specific smartphones is not covered under the device
guarantee, unless the malfunction of the Bluetooth interface is
referable to Oral-B. The Bluetooth devices are warranted by
their own manufacturers and not by Oral-B. Oral-B does not
influence or make any recommendations to device manufac-
turers, and therefore Oral-B does not assume any responsibility
for the number of compatible devices with our Bluetooth inter-
face.
Oral-B reserves the right, without any prior notice, to make any
technical modifications or changes to system implementation
of device features, interface, and menu structure changes that
are deemed necessary to ensure that Oral-B systems function
reliably.
To obtain service within the guarantee period, hand in or send
the complete appliance with your sales receipt to an authorized
Oral-B Braun Customer Service Centre.
Information
Bluetooth
®
radio module
Although all indicated functions on the Bluetooth device are
supported, Oral-B does not ensure 100% reliability in connec-
tion, and feature operation consistency.
Operation performance and connection reliability are direct
consequences of each individual Bluetooth device, software
version, as well as the operating system of those Bluetooth
devices and company security regulations implemented on the
device.
Oral-B adheres to and strictly implements the Bluetooth stand-
ard by which Bluetooth devices can communicate and function
in Oral-B toothbrushes.
However, if device manufacturers fail to implement this stand-
ard, Bluetooth compatibility and features will be further com-
promised and the user may experience functional and fea-
ture-related issues. Please note that the software on the
Bluetooth device can significantly affect compatibility and
operation.
Warranty – Exclusions and Limitations
This limited warranty applies only to the new products manu-
factured by or for The Procter & Gamble Company, its Affiliates
or Subsidiaries («P&G») that can be identified by the Braun /
Oral-B trademark, trade name, or logo affixed thereto. This lim-
ited warranty does not apply to any non-P&G product including
91451398 _iO6_EE_75x155.indd 1491451398 _iO6_EE_75x155.indd 14 23.11.20 10:0923.11.20 10:09

15
hardware and software. P&G is not liable for any damage to or
loss of any programs, data, or other information stored on any
media contained within the product, or any non-P&G product
or part not covered by this limited warranty. Recovery or rein-
stallation of programs, data or other information is not covered
under this limited warranty. This limited warranty does not apply
to (i) damage caused by accident, abuse, misuse, neglect,
misapplication, or non-P&G product; (ii) damage caused by
service performed by anyone other than Braun or authorized
Braun service location; (iii) a product or part that has been
modified without the written permission of P&G, and (iv) dam-
age arising out of the use of or inability to use the Oral-B
Smartphone stand/puck, Smartphone mirror holder, or charg-
ing travel case («Accessories»).
LIMITATION OF LIABILITY
TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO
EVENT SHALL P&G ITS DISTRIBUTORS OR SUPPLIERS BE
LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDI-
RECT, INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY
OR PUNITIVE DAMAGES, OF ANY NATURE WHATSOEVER,
ARISING OUT OF THE USE OF OR INABILITY TO USE THE
ORAL-B ACCESSORIES, INCLUDING, WITHOUT LIMITATION,
INJURY TO PERSONS, PROPERTY DAMAGE, LOSS OF VALUE
OF ANY THIRD PARTY PRODUCTS THAT ARE USED IN OR
WITH THE ORAL-B ACCESSORIES, OR LOSS OF USE OF THE
ORAL-B ACCESSORIES OR ANY THIRD PARTY PRODUCTS
THAT ARE USED IN OR WITH THE ORAL-B ACCESSORIES,
EVEN IF P&G HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. WITHOUT LIMITING THE FOREGOING,
YOU UNDERSTAND AND AGREE THAT P&G HAS NO LIABILITY
FOR ANY DAMAGE OR DESTRUCTION TO CONSUMER ELEC-
TRONICS DEVICES OR OTHER PERSONAL PROPERTY THAT
ARE CONTAINED ON OR EXTERIOR TO THE ORAL-B ACCES-
SORIES, OR ANY LOSS OF DATA CONTAINED IN THE FORE-
GOING DEVICES. IN NO EVENT SHALL ANY RECOVERY
AGAINST ORAL-B EXCEED THE ACTUAL PRICE PAID FOR THE
PURCHASE OF THE PRODUCT.
Warranty replacement brush heads
Oral-B warranty will be voided if electric rechargeable handle
damage is found to be attributed to the use of non-Oral-B
replacement brush heads.
Oral-B does not recommend the use of non-Oral-B replace-
ment brush heads.
•Oral-B has no control over the quality of non-Oral-B
replacement brush heads. Therefore, we cannot ensure the
cleaning performance of non-Oral-B replacement brush
heads, as communicated with the electric rechargeable
handle at time of initial purchase.
91451398 _iO6_EE_75x155.indd 1591451398 _iO6_EE_75x155.indd 15 23.11.20 10:0923.11.20 10:09

16
•Oral-B cannot ensure a good fit of non-Oral-B replacement
brush heads.
•Oral-B cannot predict the long-term effect of non-Oral-B
replacement brush heads on handle wear.
All Oral-B replacement brush heads carry the Oral-B logo and
meet Oral-B’s high quality standards. Oral-B does not sell
replacement brush heads or handle parts under any other
brand name.
Trouble Shooting
Problem Possible reason Remedy
APP
Handle does
not operate
(properly)
with Oral-B
App.
1. Oral-B App is
closed.
2. Bluetooth is not
activated on smart-
phone.
3. Bluetooth is disa-
bled on handle.
4. Bluetooth connec-
tion to smartphone
has been lost.
5. Your smartphone
does not support
Bluetooth 4.2 (or
higher)/
Bluetooth Smart.
6. Outdated Oral-B
App.
1. Launch Oral-B
App.
2. Activate
Bluetooth on
smartphone
(described in its
user manual).
3. Enable
Bluetooth via
display Settings
-> Bluetooth
enable.
4. Pair handle and
smartphone again
via App settings.
Keep your smart-
phone in close
proximity when
using it with
handle.
5. Your smartphone
must support
Bluetooth 4.2
(or higher)/
Bluetooth Smart in
order to pair han-
dle. Check
app.oralb.com for
compatible smart-
phones and coun-
try availability of
the Oral-B App.
6. Download latest
Oral-B App.
91451398 _iO6_EE_75x155.indd 1691451398 _iO6_EE_75x155.indd 16 23.11.20 10:0923.11.20 10:09

17
Reset to fac-
tory settings. Original functionality wanted. Enter via display Settings -> Factory
Reset (22). Press
on/off button to
confirm.
TOOTHBRUSH
Handle is not
operating
(during first
use).
1. Battery has a very
low charge level;
handle does not
operate.
2. Operating outside
standard tempera-
ture (message on
display and/or alter-
nating lights of
Smart Pressure
Sensor)
1. Charge at least for
30 min.
2. Always operate in
standard operating
temperatures
(> 0 °C and
< 40 °C).
Short stutter-
ing sounds
after 2 min-
utes or
handle
does not
operate any
timer.
Timer has been
modified/deactivated
via App.
Use App to change
timer settings or per-
form factory reset
(see App Trouble
Shootings).
Handle does
not charge. 1. Battery is at a very low charger level
(0%); it may take
up to 10-15min
until display turns
on.
2. Ambient tem-
perature for
charging is out
of valid range
(< 0 °C and
> 40 °C).
3. Charger may not
be (properly) con-
nected.
1. Charge at least for
30 min.
2. Recommended
ambient tempera-
ture for charging is
5 °C to 35 °C.
3. Ensure charger is
connected to
mains voltage.
Rattling/loud
noise during
brushing or
turning on.
1. Brush head may not
be placed correctly
onto the brush han-
dle.
2. Brush head may be
worn.
1. Check proper fit of
brush head
on handle. Small
gap remains in
between.
2. Replace brush
head.
91451398 _iO6_EE_75x155.indd 1791451398 _iO6_EE_75x155.indd 17 23.11.20 10:0923.11.20 10:09

18
The rechargeable toothbrush contains a radio module which
operates in the 2.4 to 2.48 GHz band with a maximum power of
1mW.
Hereby, Braun GmbH declares that the radio equipment types
3753, 3758, 3771, 3765, 3754, 3764,
3762 and 3767 are in
compliance with Directive
2014/53/EU. The full text of the EU
declaration
of conformity is available at the following internet
address: www.oralb.com/ce.
APPROVED
TA-2019/617
319
91451398 _iO6_EE_75x155.indd 1891451398 _iO6_EE_75x155.indd 18 23.11.20 10:0923.11.20 10:09

19
Opis
1 Glava četkice
2 Identifikacioni simbol na glavi četkice
3 Pametan senzor pritiska (lampica na prstenu)
4 Interaktivni displej
5 Drška
6 Punjač
7 Prekidač napajanja
8 Dugme za promenu režima
9 Funkcije interaktivnog displeja
10 Režim za «Svakodnevno Čišćenje»
11 Režim za «Osetljive Desni»
12 Režim za «Izbeljivanje»
13 Režim za «Negu Desni»
14 Režim za «Intenzivno»
15 Režim za «Superosetljivo Pranje»
16 Režim za «Čišćenje Jezika»
17 Meni sa podešavanjima
18 Funkcije menija sa podešavanjima
19 Upravljanje Bluetooth
®
podešavanjima
20 Izaberite/promenite boju lampice na prstenu
21 Izaberite/promenite jezik
22 Vratite na fabrička podešavanja
23 Funkcije povratnih informacija
24 Tajmer
25 Nivo napunjenosti baterije
26 Podsetnik za zamenu glave četkice
27 Povratne informacije o pranju
Dodatna oprema (u zavisnosti od modela) i funkcije:
a Funkcije pametnog senzora pritiska
b Podesite boju lampice na prstenu preko aplikacije Oral-B
c Glava četkice u režimu «Besprekorna čistoća»
d Glava četkice u režimu «Nežna nega»
e Držač glave četkice sa poklopcem
f Stalak za držač glave četkice
g Putna torbica
h Preuzmite aplikaciju Oral-B i povežite se putem Bluetooth
®
veze (vidite poslednju stranu)
Napomena: Sadržaj može da se razlikuje u zavisnosti od
kupljenog modela.
91451398 _iO6_EE_75x155.indd 1991451398 _iO6_EE_75x155.indd 19 23.11.20 10:0923.11.20 10:09

20
Srpski
Dobro došli u Oral-B!
Pre prve upotrebe četkice za zube obavezno pročitajte ovo
uputstvo. Sačuvajte uputstvo. Možda ćete želeti ponovo da ga
pročitate.
VAŽNO
• Povremeno proverite da li su proizvod/
kablovi oprema oštećeni. Uređaj koji je
oštećen ili ne radi ne treba koristiti. Ako
su proizvod/kablovi oprema oštećeni,
odnesite ih u servis kompanije Oral-B
na popravku. Ne prepravljajte i ne
popravljajte proizvod. To može dovesti
do požara, strujnog udara ili povrede.
Nikada ne stavljajte bilo kakve
predmete u otvore aparata.
• Ne preporučuje se upotreba deci
mlađoj od 3 godine. Četkice za zube
mogu koristiti deca i osobe sa
smanjenim fizičkim, čulnim ili
mentalnim sposobnostima ili osobe
koje nemaju potrebno iskustvo ili
znanje, ali su pod nadzorom ili im je
objašnjeno kako da bezbedno koriste
proizvod i razumeju do kakvih
opasnosti njegovo korišćenje može da
dovede.
• Čišćenje i održavanje ne treba
prepustiti deci.
• Nije dozvoljeno davati deci da se igraju
sa aparatom.
• Koristite ovaj proizvod shodno njegovoj
nameni opisanoj u ovom uputstvu. Nije
dozvoljeno koristiti dodatne delove
91451398 _iO6_EE_75x155.indd 2091451398 _iO6_EE_75x155.indd 20 23.11.20 10:0923.11.20 10:09
