Oreck CC1400A Guide

©2011 Oreck Holdings, LLC. All rights reserved. All word marks, logos, product configurations, and registered trademarks are owned and used under the authority of Oreck Holdings, LLC.
73115-01 REV D 12/11
ECN# 10824

Part Number Listing: CC1400A, CC1400B
# Item Order # Qty. Pk.
1CC1400A: Upper Housing Assembly 87610+008+4610 1 1
Does not include motor or PCBA
CC1400B: Upper Housing Assembly 87609+008+4610 1 1
Does not include motor or PCBA
2CC1400A: Lower Assembly (Dust Bin) 87610+008+4600 1 1
CC1400B: Lower Assembly (Dust Bin) 87609+008+4600 1 1
3 Powered Hose 49009-01 1 1
4 Tool Caddy 49004-01 1 1
5 Shoulder Strap 49005-01 1 1
6 Floor Tool 73028-01-0327 1 1
7 Standard Slinky Hose 49008-01 1 1
8 Motor Kit (includes motor, motor mount, 2-spacers) 87610+008+4250 1 1
9 HEPA Filter 49003-01 1 1
10 Main PCBA 87610+008+4260 1 1
11 Dust bags 12 pack (item not shown) PKCC12DW 1 1
12 Ratcheting Wand 73081-01-0327 1 1
13 Dusting Brush 73027-01-0327 1 1
16 Crevice Tool 72031-01-0327 1 1
17 Inlet Adapter 49027-01 1 1
5
Part Number Listing: CC1500B
# Item Order # Qty. Pk.
1CC1500B: Upper Housing Assembly 87611+008+4050 1 1
Does not include motor or PCBA
2CC1500B: Lower Assembly (Dust Bin) 87609+008+4600 1 1
3 Powered Hose 49009-01 1 1
4 Tool Caddy 49004-01 1 1
5 Shoulder Strap 49005-01 1 1
6 Floor Tool 73028-01-0327 1 1
7 Standard Slinky Hose 49008-01 1 1
8 Motor Kit (includes motor, motor mount, 2-spacers) 87611+008+4030 1 1
10 Main PCBA DC Unit 87611+008+4040 1 1
11 Dust bags 12 pack (item not shown) PKCC12DW 1 1
12 Ratcheting Wand 73081-01-0327 1 1
13 Dusting Brush 73027-01-0327 1 1
14 DC Battery 49019-01 1 1
15 DC Charger 49018-01 1 1
16 Crevice Tool 72031-01-0327 1 1

Part Diagram
Diagram is for representation purposes only.
4
Accessories
73
6
13
4
12
8
10
9
5
14
15
16

Diagram is for representation purposes only.
3
Part Diagram
Upper Housing Assembly
1
Lower Dust Bin Assembly
2

Service Information
• Component configuration on exploded view may differ in
case of specific versions. However, the actual
components are distinguished by means of item and
part numbers.
• If a repair has been made, make sure that all functions
of the appliance are working correctly.
• Spare parts have been standardized as much as
possible and the part may not be the exact replacement
part.
• Do not use unit for prolonged periods w/full bag..
2
Type Code: Represents product service
revision number.
Julian Date Code:
Represents date of manufacture.
10 Represents the year.
036 Represents the day in that year.
FOR HOUSEHOLD USE ONLY.
CONCU UNIQUEMENT POU TYPE MENAGER.
Manufactured for Oreck Manufacturing Company.
Cookeville,TN USA. Please read Owner’s Safety and
Operation Manual for safety and functional
information. Call USA 1-800-989-3535 Canada
1-888-676-7325 or go to www.oreck.com for help
or more information.
Patents Pending.
HALO is a trademark owned by, and used with
permission from, Oreck Holdings LLC.
Made in China
Conforms to UL Standard 1017
Certied to CSA C22.2 No. 243-01
COOKEVILLE, TN 38506 U.S.A.
3167504
®
MODEL: CC1400A
TYPE 1
120 VOLTS 60 HZ 7.5 AMP CANISTER
120 VOLTS 60 HZ 8.1 AMP W/FLASH
DATE: 10036
W: 3 YR Can
5 YR Flash
Data Label

SIMPLY AMAZING
®
Oreck Flash/Edge
Compact Canister
CC1400A
CC1400B
CC1500B
Service Parts List
REV D.
73115-01
