Oregon Scientific BAR933HG User manual

Weather Station with Scrolling Message Alerts
Model: BAR933HG / BAR936HG
User Manual
BAR933HG Eng Cover R10 OP 11/23/04, 4:29 PM1
Black

EN
1
CONTENTS
Contents ................................................................... 1
Introduction .............................................................. 1
Product Overview .................................................... 2
Front View.............................................................. 2
Back View .............................................................. 2
LCD Display ........................................................... 3
Remote Sensor (R GR368N) ................................ 4
Getting Started ......................................................... 5
Batteries ................................................................. 5
AC Adaptor (Main Unit) .......................................... 5
Change Settings .................................................... 5
Remote Sensor ......................................................... 5
Set Up hermo / Hygro Sensor (R GR368N) ....... 5
Sensor Data ransmission .................................... 6
Search for Sensor .................................................. 6
Cloc and Calendar ................................................. 6
Radio-Controlled Clock .......................................... 6
urn Radio-Controlled Clock ON / OFF ................. 6
Set Clock ............................................................... 7
Switch Clock Display ............................................. 7
Alarms ....................................................................... 7
Alarm Sound .......................................................... 7
Set Daily Alarm ...................................................... 7
Set Pre-Alarm ........................................................ 7
Activate Alarm ........................................................ 8
Snooze .................................................................. 8
Barometer ................................................................. 8
View Barometer Area ............................................. 8
Select Measurement Unit ...................................... 8
View Barometer History ......................................... 8
Set Altitude ............................................................. 8
Weather Forecast ..................................................... 8
Weather Forecast Icons ......................................... 8
UV Measurement ...................................................... 8
New Additional UV Features .................................. 9
Temperature and Humidity ...................................... 9
View emperature and Humidity Area ................... 9
Select Measurement Unit ...................................... 9
Select Sensor Channel .......................................... 9
Minimum / Maximum Records ............................... 9
View emperature and Humidity History ................ 9
emperature and Humidity rend ........................ 10
Comfort Zone ....................................................... 10
Heat Index ........................................................... 10
Tal ing Cloc .......................................................... 10
Enable / Disable alk Function ............................ 10
Using the alk Function ....................................... 10
alk Volume ......................................................... 10
Message Display .................................................... 10
Bac light ................................................................. 11
Reset System ......................................................... 11
Safety and Care ...................................................... 11
Warnings ................................................................. 11
Troubleshooting ..................................................... 11
Specifications ......................................................... 12
About Oregon Scientific ........................................ 12
EC-Declaration of Conformity ............................... 13
INTRODUCTION
hank you for selecting the Oregon Scientific M
BAR933HG / BAR936HG Weather Station with Scrolling
Message Alerts. his powerful device bundles time
keeping, weather messaging and monitoring, indoor and
outdoor temperature and humidity readings, barometric
trends and altitude adjustment, into a single tool you can
use from the convenience of your home.
In this box, you will find:
• Main unit
• Remote sensor (R GR368N)
• Optional UV sensor (UVR138)
• 6V AC adapter
• Batteries
BAR933HG --- BAR933HG Main Unit + R GR368N
Remote Sensor
BAR936HG --- BAR933HG Main Unit + R GR368N
Remote Sensor + UVR138 UV Sensor
he HGR328N (5-Channel) and HGR228N
(3-Channel) remote sensors are also compatible with
this weather station. Additional sensors are sold
separately. Please contact your local stockist for more
information.
Keep this manual handy as you use your new product.
It contains practical step-by-step instructions, as well
as technical specifications and warnings you should
know.
NOTE
Weather Station with Scrolling
Message Alerts
Model: BAR933HG / BAR936HG
User Manual
BAR933HG Eng R7 OP 8/20/04, 11:03 PM1
Black

EN
2
1. LCD display
2. MODE: Change settings / display
3. MEMORY: View current, maximum and minimum
temperature / humidity / UV readings
4. HISTORY: View historical barometer / temperature /
humidity and UV readings
5. MESSAGE: View different messages
6. SNOOZE / LIGHT: Activate 8-minute snooze or
backlight
7. SELECT: Switch Areas
8. CHANNEL: Switch remote sensor display
9. UP: Increase setting / activate radio-controlled clock
10. DOWN: Decrease setting / deactivate radio-
controlled clock
11. ALARM / : View alarm status; set alarm
PRODUCT OVERVIEW
FRONT VIEW
8
9
10
11
7
3
5
6
4
2
1
BACK VIEW
1. Ventilation holes
2. Battery compartment (bottom)
3. AC adaptor socket
4. mb / inHg button (in battery compartment)
5. RESET hole (in battery compartment)
6. °C / °F button (in battery compartment)
You can adjust the angle of the clock display as shown
below:
3
4
5
2
1
6
BAR933HG Eng R7 OP 8/20/04, 11:03 PM2
Black

EN
3
2
1
3
4
5
1
3
4
5
2
6
7
8
9
10
1
2
4
5
3
6
7
8
9
10
13
11
12
LCD DISPLAY
1. Weather Forecast Area: Animated weather forecast
2. Cloc / Alarm / Calendar Area: Radio-controlled
clock; alarms; calendar
3. UVI / Barometer Area: UV Index and barometric
pressure readings
4. Message Display Area: Displays general weather
information and warnings
5. Temperature / Humidity / Comfort Zone Area:
Readings and trend lines; comfort zone; sensor
channel number
Cloc / Alarm / Calendar Area
1. RF clock reception
2. Channel number (1-5)
3. Selected area icon
4. ime / date / calendar
5. alking Alarm is set
6. Pre-Alarm is set
7. Beep Alarm is set
8. Pre-Alarm display / Pre-Alarm setting
9. Offset time zone
Barometer / UVI Area
1
2
4
3
5
6
7
8
9
1. UVI value is showing
2. UV is showing
3. Barometric pressure is showing
4. UV index level
5. Altitude / barometric pressure / UVI reading
6. SPF applied to user for UV exposure
7. User skin type for UV exposure
8. Appears when setting the altitude
9. MAX / MIN UVI
10. UV exposure time countdown has started
11. Low battery icon for UV sensor
12. UV exposure time for user
13. User no. (for UV Mode) or hour history for UVI /
Barometric pressure reading
Message Display Area
1. Message display
2. CAUTION: Appears when a warning message is
displayed
3. TEMPERATURE HISTORY
4. HUMIDITY HISTORY
5. alk function is ON
6. AC adaptor is disconnected
Temperature / Humidity / Comfort Zone Area
1. Heat Index
2. emperature trend
3. Channel number (1-5) / reception status
4. Low battery icon for remote sensor OR low battery
icon for main unit when indoor data is displayed
5. Humidity trend
6. MAX / MIN temperature
7. emperature - °C / °F
8. Comfort levels
9. MAX / MIN humidity
10. Humidity
5
6
1
2
3
4
BAR933HG Eng R7 OP 8/20/04, 11:03 PM3
Black

EN
4
REMOTE SENSOR (RTGR368N)
1
2
3
4
1. LCD display
2. LED status indicator
3. Ventilation duct
4. Fold-out stand
1. Signal reception
2. ime
3. Channel number
4. emp / humidity readings
5. Low battery icon
6. emp (°C or °F)
7. Humidity %
1
2
3
4
5
6
7
Made in PRC
R GR368 N
SEARCH RESE 12 3 4 5
CHANNEL
EU UK
C F
1
3
4
5
26
7
1. Wall mount
2. EU / UK radio signal format switch
3. SEARCH button
4. °C / °F button
5. RESET button
6. CHANNEL switch (1-5)
7. Battery compartment
BAR933HG Eng R7 OP 8/20/04, 11:03 PM4
Black

EN
5
GETTING STARTED
BATTERIES
Batteries are supplied with this product:
• Main unit 4 x UM-4 (AAA) 1.5V
• Remote unit 2 x UM-3 (AA) 1.5V
Insert batteries before first use, matching the polarity
as shown in the battery compartment. For best results,
install batteries in the remote sensor before the main
unit. Press RESET after each battery change.
o install the main unit batteries:
Do not use rechargeable batteries.
It is recommended that you use alkaline
batteries with this product for longer performance.
shows when batteries are low.
NOTE
NOTE
UNIT LOCATION
Main emperature / Humidity Area
(when indoor data is displayed)
Remote emperature / Humidity Area
UV Sensor
AC ADAPTOR (MAIN UNIT)
he batteries serve as a back-up power supply. For
continuous use, please install the AC adaptor at the base
of the unit:
shows in the Message Display Area when the AC
adapter is not plugged in.
CHANGE SETTINGS
1. Press SELECT to switch between Areas.
indicates the selected Area.
2. Most Areas have alternate display options (for
example, Clock / Alarm or Barometer / UVI). Press
MODE to switch options, or ALARM / to switch
between clock and alarm.
3. Press and hold MODE for 2 seconds to enter setting
mode.
4. Press UP or DOWN to change settings.
5. Press MODE to confirm.
REMOTE SENSOR
his product is shipped with the R GR368N hermo /
Hygro Sensor. he main unit can collect data from up to
6 sensors (5 hermo / Hygro Sensors and 1 UV Sensor).
he HGR328N and HGR228N sensors are also
compatible with this weather station. (Additional sensors
are sold separately. Contact your local stockist for more
information.)
he R GR368N sensor collects temperature and
humidity readings, and signals from official time-keeping
organizations for the radio-controlled clock.
SET UP THERMO / HYGRO SENSOR (RTGR368N)
1. Open the battery compartment with a small Phillips
screwdriver.
2. Insert the batteries.
3. Set the channel and radio signal format. he switches
are located in the battery compartment.
SWITCH OPTION
Channel If you are using more than one
sensor, select a different
channel for each sensor.
Radio Signal Format EU (DCF) / UK (MSF)
4. Press RESET. hen set the temperature unit.
SWITCH OPTION
emp °C / °F
5. Close the battery compartment.
UVI / Barometric Pressure Area
BAR933HG Eng R7 OP 8/20/04, 11:03 PM5
Black

EN
6
o fold out the stand: o use the wall mount:
For best results:
• Insert the batteries and select the unit, channel, and
radio signal format before you mount the sensor.
• Place the sensor out of direct sunlight and moisture.
• Do not place the sensor more than 70 metres
(230 feet) from the main (indoor) unit.
• Position the sensor so that it faces the main (indoor)
unit, minimizing obstructions such as doors, walls,
and furniture.
• Place the sensor in a location with a clear view to
the sky, away from metallic or electronic objects.
• Position the sensor close to the main unit during cold
winter months as below-freezing temperatures may
affect battery performance and signal transmission.
he transmission range may vary and is subject
to the receiving range of the main unit.
You may need to experiment with various locations to
get the best results.
SENSOR DATA TRANSMISSION
Data is sent from the sensor(s) every 60 Seconds. he
reception icon shown in the emperature / Humidity Area
indicates the status.
NOTE
SEARCH FOR SENSOR
o search for a hermo / Hygro sensor, press SELECT
to navigate to the emperature / Humidity Area. will
show next to the Area. hen, simultaneously press and
hold MEMORY and CHANNEL for 2 seconds.
o search for the UV sensor, press SELECT to navigate
to the UVI / Barometer Area. will show next to the
Area. hen, press and hold MEMORY and CHANNEL
for 2 seconds.
If the sensor is still not found, check the
batteries.
ICON DESCRIPTION
Main unit is searching for
sensors.
At least 1 channel has been
found.
Sensor 1 is sending data. ( he
number shows which sensor is
selected.)
he selected sensor cannot be
found. Search for the sensor or
check batteries.
--- shows in emp /
Humidity Area
NOTE
CLOCK AND CALENDAR
his product tracks the time and date based on radio-
controlled signals from the R GR368N remote sensor,
or manual settings that you enter.
RADIO-CONTROLLED CLOCK
he time and date are automatically updated by radio-
controlled clock signals from official time-keeping
organizations in Frankfurt (Germany) and Rugby
(England) unless you disable this feature. he signals
are collected by the remote sensor (R GR368N)
whenever it is within 1500 km (932 miles) of a signal.
Initial reception takes 2-10 minutes, and is initiated when
you first set up the unit, and whenever you press RESET.
Once complete, the reception icon will stop blinking.
he icon shown in the Clock Area indicates
2 factors:
• Connection between the main unit and the sensor
that collects RF signals ( )
• RF signal reception ( )
How these signals work together:
ICON MEANING
he unit has contact with the
sensor and has synchronized
the time.
he unit has contact with the
sensor but the time has not
been synchronized.
he unit has lost contact with
the remote sensor but the time
is synchronized.
he unit has lost contact with
the remote sensor and the time
is not synchronized.
he unit cannot reach the
remote sensor.
o force a manual search for RF clock reception,
press and hold SEARCH on the sensor (R GR368N)
for 2 seconds.
TURN RADIO-CONTROLLED CLOCK ON / OFF
If you wish to manually set the clock, you must first
disable the radio-controlled feature. o do this, navigate
to the Clock / Alarm Area. hen, press and hold DOWN
on the main unit for 2 seconds. o enable it, navigate to
the Clock / Alarm Area, then press and hold UP for
2 seconds.
NOTE
BAR933HG Eng R7 OP 8/20/04, 11:03 PM6
Black

EN
7
RF clock enabled:
RF clock disabled:
SET CLOCK
You only need to do this if you have disabled the radio-
controlled clock, or if you are too far from a RF signal.
1. Press SELECT to navigate to the Clock Area.
will show next to the Area.
2. Press and hold MODE for 2 seconds.
NOTE
NOTE
ALARM SOUND
he alarms can be set to sound either a beeping alarm or a
talking alarm. However, the sound you choose i.e. beeping
or talking will apply to both the Daily and Pre-Alarm.
he beeping alarm will beep for 2 minutes and get louder
and faster during this time.
he talking alarm will beep 4 times and then tell you the
time for 2 minutes in the selected language.
he talking alarm will only sound if the AC
adaptor is being used. If the adaptor is not plugged in,
the beeping alarm will sound.
SET DAILY ALARM
1. Press SELECT to navigate to the Clock Area.
will show next to the Area.
2. Press ALARM / to view the alarm. (AL will
show at the top.)
NOTE
NOTE
3. Select the time zone offset hour (+ / -23 hours),
12 / 24 hour format, hour, minute, year, date / month
format, month, date, and display language.
4. Press UP or DOWN to change the setting.
5. Press MODE to confirm.
he language options are (E) English, (F)
French, (D) German, (I) Italian, and (S) Spanish. he
language you select determines the weekday display,
talking function and message display.
If the talk function is enabled then the talk
settings will follow after the display language. Please
see the " alking Clock" section for further information.
SWITCH CLOCK DISPLAY
Press SELECT to navigate to the Clock Area. will
show next to the Area.
Press MODE to toggle between:
• Clock with seconds
• Clock with day
• Clock with time-zone offset
• Calendar
ALARMS
his product has 2 alarms: he Daily Alarm and a Pre-
Alarm for snowy weather. he Daily Alarm can be set to
go off at the same time every day. he Pre-Alarm sounds
only when the Daily Alarm is activated and the recorded
temperature from Channel 1 sensor falls to 2°C (35.6°F)
or below.
3. Press and hold ALARM / for 2 seconds.
4. Press UP or DOWN to select 15, 30, 45 or
60 minutes. his is the amount of time the Pre-Alarm
will sound BEFORE the Daily Alarm. he Pre-Alarm
is automatically activated when you select a time.
5. Press ALARM / to confirm.
6. shows when the Pre-Alarm is set.
he Daily Alarm will NO function until the next day
if the Pre-Alarm has been triggered. Also, if you deactivate
the Daily Alarm, the Pre-Alarm is automatically deactivated.
3. Press and hold ALARM / for 2 seconds.
4. Select the hour, minute, talking or beep alarm. Press
UP or DOWN to change settings.
5. Press ALARM / to confirm.
6. he Beep Alarm icon or the alk Alarm icon
icon will appear when the alarm is set.
SET PRE-ALARM
he Pre-Alarm can be set to sound 15, 30, 45, or 60
minutes before the Daily Alarm. It will sound whenever
the recorded temperature from Channel 1 sensor falls
to 2°C (35.6°F) or below.
For example, if you set the alarm to 7:00 AM, and the
Pre-Alarm to 45 minutes, the Pre-Alarm will sound at
6:15 AM provided the outdoor temperature at
Channel 1 sensor is 2°C or below.
1. Set up and activate the Daily Alarm.
2. Press ALARM / to switch to Pre-Alarm view.
(PRE-AL will show at the top.)
BAR933HG Eng R7 OP 8/20/04, 11:03 PM7
Black

EN
8
ACTIVATE ALARM
Navigate to the Clock Area, then press ALARM / to
switch to Daily Alarm or Pre-Alarm view. o activate or
deactivate the alarm, press UP or DOWN.
When the alarm time is reached, the backlight will be on
for 5 seconds and crescendo alarm will sound for
2 minutes. Press any key (except snooze) to silence
the alarm. It will sound at the same time the next day.
SNOOZE
Press SNOOZE / LIGHT to temporarily disable the alarm
for 8 minutes. or , or will blink while Snooze is
on.
BAROMETER
his product tracks fluctuations in barometric pressure
to provide the weather forecast, and the current and past
24 hours barometric pressure history measurements are
recorded by the main (indoor) unit.
VIEW BAROMETER AREA
Press SELECT to navigate to the Barometer Area.
If is NO shown, press MODE.
SELECT MEASUREMENT UNIT
Slide the mb / inHg switch (in the battery compartment),
to change the display unit.
VIEW BAROMETER HISTORY
o view the last 24 hours barometric history, navigate to
the Barometer Area. hen press HISTORY repeatedly
to scroll through the measurements. he number shown
in the HR box indicates how long ago each measurement
was taken (e.g. 2 hours ago, 3 hours ago, e.t.c.).
SET ALTITUDE
Set the altitude to match how far above or below sea
level you are living. his ensures that the barometric
pressure readings are accurate.
1. Navigate to the Barometer Area.
2. Press and hold HISTORY for 2 seconds.
3. Press UP or DOWN to set the altitude in 10-metre
increments (-100m to 2500m).
4. Press HISTORY to confirm.
ICON DESCRIPTION
Clear
Partly cloudy
Cloudy
Rainy
Snowy
Day / Night
Day / Night
he night time icon displays from 6 PM to 6 AM.
When the Channel 1 sensor records a temperature of
2°C (35.6°F) or lower, the RAINY icon becomes SNOWY.
UV MEASUREMENT
he UVR138 Ultra-Violet Radiation Sensor is included
with the BAR986HG and is available as an optional item
for the BAR933HG. he UV sensor gives you the
following information at your fingertips:
• 10-hour Ultra-Violet Index (UVI) record.
• Automatic calculation of acceptable UV exposure
times based on pre-set user profiles (4 users
maximum).
• UVI Danger Alert when UV Index reaches unsafe levels.
UV data is shown in the same area as the Barometer.
Press SELECT to navigate to the Barometer Area, then
press MODE to display the UV icon and data.
Refer to the UVR138 User Manual for more
information and see below to learn about the new
additional UV features.
NOTE
NOTE
WEATHER FORECAST
his product forecasts the next 12 to 24 hours of weather
within a 30-50 km (19-31 mile) radius. he forecast is
based on barometric pressure trend readings.
he top area shows an animated icon indicating the
forecasted weather.
WEATHER FORECAST ICONS
BAR933HG Eng R7 OP 8/20/04, 11:03 PM8
Black

EN
9
2. Press CHANNEL to select user 1-4.
3. Press and hold MODE for 2 seconds to enter the
Skin ype Setting Mode of the selected user.
4. Press UP or DOWN to choose 1 of the 4 skin type
settings. hen press MODE to confirm and enter the
SPF Set Up Mode.
5. Press UP or DOWN to increase or decrease the SPF
value. hen press MODE to confirm and enter the
UV Exposure ime Count Down Setting Mode.
6. Press UP or DOWN to enable or disable countdown.
Press MODE to exit the UV Exposure ime
Countdown Mode and start the exposure time
countdown. he remaining user UV exposure time
will display and the icon will flash.
7. When the countdown has reached "0", an alarm will
sound for 2 minutes. Press any button to turn the
alarm off. he icon will flash for 2 minutes even
if you have stopped the alarm sound.
MAXIMUM / MINIMUM MEMORY FOR UVI
o view the maximum and minimum memory for UVI:
1. Press SELECT to navigate to the Barometer Area.
2. Press MODE to select the UV display.
3. Press MEMORY to show maximum, minimum and
current UVI readings.
4. Press and hold MEMORY for 2 seconds to clear the
UVI memory.
he UV sensor must be activated before you
try and set the additional features. Please refer to the
UVR138 User Manual for more information.
TEMPERATURE AND HUMIDITY
he weather station can display the following information
from any of the 5 remote sensors:
• Current, minimum, and maximum temperatures and
relative humidity percentages.
• Comfort level indicator and trend line (rising, falling,
or steady).
Data is collected and displayed approximately every
60 seconds.
VIEW TEMPERATURE AND HUMIDITY AREA
Press SELECT to navigate to the emperature and
Humidity Area.
NOTE
NEW ADDITIONAL UV FEATURES
UV EXPOSURE TIME COUNTDOWN
o set the exposure time countdown you need to set
the Skin ype and Sun Protection Factor (SPF) as
follows:
1. Press SELECT to navigate to the Barometer Area,
then press MODE to select the UV display.
SELECT MEASUREMENT UNIT
Slide the °C / °F switch (inside the battery compartment),
to the setting you want.
SELECT SENSOR CHANNEL
Press CHANNEL to switch between outdoor sensors
1-5 and indoor temperature and humidity readings.
indicates outdoor remote sensor channel;
corresponding temperature and humidity readings are
displayed.
indicates indoor temperature and humidity
readings are displayed.
• o auto-scan between sensors, press and hold
CHANNEL for 2 seconds. Each sensor's data will
be displayed for 3 seconds.
• o end auto-scan, press CHANNEL or MEMORY
with the emperature / Humidity Area selected.
If you select a sensor that collects only
temperature data, the humidity will not be shown.
MINIMUM / MAXIMUM RECORDS
• Press MEMORY repeatedly to view current,
maximum and minimum records for the selected
sensor.
• o clear the records, press and hold MEMORY for
2 seconds. A beep will sound to confirm that the
memory has been cleared
VIEW TEMPERATURE AND HUMIDITY HISTORY
o view the last 24 hours temperature and humidity
history, navigate to the emperature or Humidity Area.
hen press HISTORY repeatedly to scroll through the
measurements. he number shown to the right of the
display indicates how long ago each measurement was
taken (e.g., 2 hours ago, 3 hours ago, etc.).
emperature history:
NOTE
Humidity history:
emperature data is given at the top, humidity is below.
BAR933HG Eng R7 OP 8/20/04, 11:03 PM9
Black

EN
10
ZONE
WET
COM
TEMPERATURE HUMIDITY
Any >70%
20-25°C
(68-77°F)
40-70%
DRY Any <40%
his information is shown in the Humidity Area
when the current measurement is displayed.
HEAT INDEX
he Heat Index advises 4 levels of warning if the
temperature is high.
NOTE
DANGER
CATEGORY
TEMPERATURE
°C°F
>54.5 >130
40.5-54.4 105-130
Extreme danger
Danger
32.2-40.5 90-105Extreme Caution
26.6-32.2 80-90Caution
o display the Heat Index:
1. Press SELECT to navigate to the emperature Area.
will show next to the Area.
2. Press MODE to reach the Heat Index display.
3. Press CHANNEL to select the desired channel.
If the temperature is below 26°C / 80°F, or the
desired channel is not working, the Heat Index will
display "NA".
TALKING CLOCK
Your clock can keep you informed of the time,
temperature, humidity and weather forecast by the press
of a button or at pre-set times.
o use any talking function, the AC adaptor must
be connected.
NOTE
NOTE
NOTE
ENABLE / DISABLE TALK FUNCTION
o enable or disable the talk function:
• Plug or unplug the adaptor.
OR
• Press and hold UP and DOWN for 3 seconds.
will appear in the bottom, right-hand corner of the
LCD display when the talk function is enabled.
If you are using the adaptor and want to turn
the talk function OFF, then press and hold UP and
DOWN for 3 seconds.
USING THE TALK FUNCTION
o instantly hear the current time, indoor temperature,
humidity and weather forecast, press and hold
SNOOZE / LIGHT for 3 seconds.
o hear the time, temperature, humidity and weather
forecast every hour for a set period of time i.e. 6pm to
10pm, or once every 24 hours:
1. Press SELECT to navigate to the Clock / Alarm Area.
2. Press and hold MODE for 2 seconds.
3. Press MODE to scroll through until you reach the
talk setting, (it appears immediately after display
language).
4. Select 1hr or 24hr broadcast, talk start-time, talk stop-
time and talk volume.
5. Press UP or DOWN to change the setting.
6. Press MODE to confirm.
If you select the 24-hour talk function, you do
not need to enter a talk stop-time.
TALK VOLUME
he talk function icon appears in the bottom, right-hand
corner of the LCD display.
NOTE
ICON VOLUME LEVEL
Low
Medium
High
See "Using the alk Function" section for how to adjust
the volume.
MESSAGE DISPLAY
Your clock can display messages and warnings in
5 languages. If a warning is being issued will
flash.
o display messages:
Press MESSAGE, the display box text will flash for
5 seconds and then the message will scroll across the
display.
TEMPERATURE AND HUMIDITY TREND
he trend lines are shown next to the temperature and
humidity readings.
TREND
TEMPERATURE
HUMIDITY
RISING STEADY FALLING
COMFORT ZONE
he Comfort Zone indicates how comfortable the
climate is, based on current temperature and humidity
measurements.
BAR933HG Eng R7 OP 8/20/04, 11:03 PM10
Black

EN
11
MESSAGE DEFINITION
Heat Index N / A
Possibility of
heat exhaustion
Strong heat: Possibility
of dehydration
Very strong heat: Heat
exhaustion likely
Intense heat: Strong
possibility of heat stroke
26.7°C to 32.2°C /
80°F to 90°F
32.2°C to 40.5°C /
90°F to 105°F
40.5°C to 54.4°C /
105°F to 130°F
54.4°C / 130°F
or greater
UV Index Messages (displays only when optional
UV sensor is connected):
MESSAGE DEFINITION
UV: Apply sunscreen 0-2
UV: Wear protective clothing 3-5
Low
Medium
UV: Wear sunglasses &
protective clothing
6-7 High
UV: Avoid the sun between
10AM to 4PM
8-10 Very high
UV: Very strong rays stay
indoors
UV: ime is up
>= 11 Extremely
high
Max. exposure
time to sun is up
Weather Forecast Messages:
Forecast: Sunny enjoy your day
Forecast: Partly cloudy
Forecast: Cloudy
Forecast: Rainy don't forget your umbrella
Forecast: Snowy
Weather Warnings (based on Channel 1 sensor's data):
MESSAGE DEFINITION
Freeze Alert: Wrap pipes
& cover your vegetation
Ice Alert: Possibility of
black ice when driving
Fog Alert: Possibility of
poor visibility when driving
Dew Point & Current
emperature <= 0°C / 32°F
-2 to 3°C
(28.4 to 37.4°F)
emperature - Dew Point
< 5°F / -15°C
o change the display language, see "Set Clock"
section.
BACKLIGHT
Press SNOOZE / LIGHT to illuminate the backlight for
5 seconds.
RESET SYSTEM
he RESET button is located at the bottom of the unit.
Press RESET when you change the batteries and
whenever performance is not behaving as expected (for
example, you are unable to establish radio frequency
link with remote unit or radio-controlled clock).
NOTE
When you press RESET, all settings will return
to default value, and you will lose all stored information.
SAFETY AND CARE
Clean the product with a slightly damp cloth and alcohol-
free, mild detergent. Avoid dropping the product or
placing it in a high-traffic location.
WARNINGS
his product is designed to give you years of service if
handled properly. Oregon Scientific will not be
responsible for any deviations in the usage of the device
from those specified in the user instructions or any
unapproved alterations or repairs of the product.
Observe the following guidelines:
• Never immerse the product in water. his can cause
electrical shock and damage the product.
• Do not subject the main unit to extreme force, shock,
or fluctuations in temperature or humidity.
• Do not tamper with the internal components.
• Do not mix new and old batteries or batteries of
different types.
• Do not use rechargeable batteries with this product.
• Remove the batteries if storing this product for a long
period of time.
• Do not scratch the LCD display.
he technical specification of this product and
contents of this user guide are subject to change without
notice. Images not drawn to scale.
TROUBLESHOOTING
NOTE
PROBLEM SYMPTOM
Barometer
REMEDY
Strange readings Set altitude / unit (→ 8)
Calendar Strange date /
month
Change language
(→ 7)
Clock Cannot adjust
clock
Disable radio-
controlled clock (→ 6)
Cannot auto-
synch
1. Adjust batteries (→ 5)
2. Press RESET (→ 11)
3. Manually activate
radio-controlled
clock (→ 6)
emp Shows "LLL" or
"HHH"
emperature is out-
of-range
alk
function
No talking
function
Connect to AC
adaptor (→ 5)
Remote
sensor
Cannot locate
remote sensor
Check batteries
(→ 5)
Heat Index Messages: NOTE
BAR933HG Eng R7 OP 8/20/04, 11:03 PM11
Black

EN
12
SPECIFICATIONS
Main Unit Dimensions
L x W x H 295 x 86 x 110 mm
(11.61 x 3.39 x 4.33 inches)
Weight 386 grams (0.85 lbs)
without battery
Remote Unit Dimensions
L x W x H 70 x 24.5 x 116 mm
(2.76 x 0.96 x 4.57 inches)
Weight 114 grams (0.25 lbs)
without battery
Temperature Unit °C or °F
Indoor Range -5°C to 50°C
(23°F to 122°F)
Outdoor Range -20°C to 60°C
(-4°F to 140°F)
Resolution 0.1°C (0.2°F)
Comfort 20°C to 25°C
(68°F to 77°F)
Memory Min / Max
Relative Humidity
Indoor Range 25% to 95%
Outdoor Range 25% to 100%
Resolution 1%
Comfort 40% to 70%
Memory Min / max
Barometer Unit mb / hPa or inHg
Resolution 1 mb (0.03 inHg)
Altitude -100 to 2500 metres
(-328 to 2734 feet)
Weather Display Sunny (day / night),
partly cloudy (day /
night), cloudy, rainy,
snowy
Remote Unit (RTGR368N)
RF frequency 433 MHz
Range Up to 70 metres (230 feet)
with no obstructions
ransmission Approx. every 1 minute
Channel No. 1, 2, 3, 4 or 5
Unit °C or °F
Radio-Controlled Cloc
Synchronization Auto or disabled
Clock Display HH:MM:SS
Hour Format 12hr AM / PM (MSF format)
24hr (DCF format)
Calendar DD / MM or MM / DD;
Day of the Week in
1 of 5 Languages (E, G, F, I, S)
Alarm Daily & Pre-Alarm;
2-minute crescendo
beep or talk alarm
Snooze 8-minute snooze
Power
Main Unit
Power adapter 6V AC adapter
Batteries 4 x UM-4 (AAA) 1.5V
Thermo / Hygro Remote Unit
Batteries 2 x UM-3 (AA) 1.5V
It is recommended that you use alkaline
batteries with this product for longer performance.
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn
more about Oregon Scientific products such as digital
cameras; MP3 players; children's electronic learning
products and games; projection clocks; health and
fitness gear; weather stations; and digital and conference
phones. he website also includes contact information
for our customer care department in case you need to
reach us, as well as frequently asked questions and
customer downloads.
We hope you will find all the information you need on
our website, however if you'd like to contact the Oregon
Scientific Customer Care department directly, please
visit: www2.oregonscientific.com/service/support
OR
Call 949-608-2848 in the US.
For international enquiries, please visit:
www2.oregonscientific.com/about/international/
default.asp
NOTE
BAR933HG Eng R7 OP 8/20/04, 11:03 PM12
Black

EN
13
EC-DECLARATION OF CONFORMITY
his product contains the approved transmitter module
that complies with the essential requirements of
Article 3 of the R& E 1999 / 5 / EC Directive, if used as
intended and the following standards have been applied:
Safety of information technology equipment
(Article 3.1.a of the R& E Directive)
Applied Standard EN 60950-1 : 2000
Electromagnetic compatibility
(Article 3.1.b of the R& E Directive)
Applied Standards
ETSI EN 301 489-1-3 (Ver.1.4.1) : 2002-08
Efficient use of radio frequency spectrum
(Article 3.2 of the R& E Directive)
Applied Standards
ETSI EN 300 220-3 (Ver1.1.1) : 2000-09
Additional information:
he product herewith complies with the requirements of
the Low Voltage Directive 73 / 23 / EC, the EMC Directive
89 / 336 / EC and carries the CE marking accordingly.
Carmelo Cubito
Agrate Brianza (MI) / Italy January 2004
Manufacturer's EU R& E Representative
COUNTRIES RTTE APPROVAL COMPLIED
All EC countries, Switzerland CH
and Norway N
BAR933HG Eng R7 OP 8/20/04, 11:03 PM13
Black

© 2004 Oregon Scientific. All Rights Reserved.
P/N.: 086-00 589-019
BAR933HG Eng Back R7 OP 8/20/04, 11:03 PM1
Black

DE
1
INHALT
Inhalt ......................................................................... 1
Einleitung .................................................................. 1
Produktübersicht ..................................................... 2
Vorderansicht ......................................................... 2
Rückansicht ........................................................... 2
LCD-Anzeige ......................................................... 3
Funksendeeinheit (R GR368N) ............................ 4
Vorbereitung zu Einsatz ....................................... 5
Batterien ................................................................ 5
Netzadapter (Basiseinheit) .................................... 5
Änderung der Einstellungen .................................. 5
Funksendeeinheit .................................................... 5
Einrichtung der hermo- / Hygro
-Funksendeeinheit (R GR368N) ........................... 5
Datenübertragung .................................................. 6
Suche nach einer Funksendeeinheit ..................... 6
Uhr und Kalender ..................................................... 6
Funkuhr ................................................................. 6
Funkuhr ein- und ausschalten ............................... 7
Uhr einstellen ......................................................... 7
Zeitanzeige umschalten ......................................... 7
Weckalar e .............................................................. 7
Weckalarmton ........................................................ 7
äglichen Weckalarm einstellen ............................ 8
Weck-Voralarm einstellen ...................................... 8
Weckalarm aktivieren ............................................ 8
Schlummerfunktion ................................................ 8
Baro eter ................................................................. 8
Barometer-Anzeigefeld .......................................... 8
Messeinheit auswählen ......................................... 8
Luftdruckverlauf anzeigen ..................................... 8
Höhenlage einstellen ............................................. 8
Wettervorhersage ..................................................... 9
Wettervorhersagesymbole ..................................... 9
UV-Messungen ......................................................... 9
Neue zusätzliche UV-Funktionen .......................... 9
Te peratur und Luftfeuchtigkeit .......................... 10
emperatur und Luftfeuchtigkeit anzeigen ........... 10
Messeinheit auswählen ....................................... 10
Funksendeeinheitskanal auswählen .................... 10
Minimal- und Maximalaufzeichnungen ................ 10
emperatur- und Luftfeuchtigkeits-Verlauf
anzeigen .............................................................. 10
emperatur- und Luftfeuchtigkeits- rend ............. 10
Komfortzone ........................................................ 10
Hitzeindex ............................................................ 10
Sprechende Uhr ..................................................... 11
Ansagefunktion aktivieren / deaktivieren ............. 11
Benutzung der Ansagefunktion ............................ 11
Ansagelautstärke ................................................. 11
Meldungsanzeige ................................................... 11
Hintergrundbeleuchtung ....................................... 12
Syste -Rückstellung ............................................ 12
Sicherheit und Pflege ............................................ 12
Warnungen ............................................................. 12
Fehlersuche und Abhilfe ....................................... 12
Technische Daten ................................................... 13
Über Oregon Scientific .......................................... 13
EU-Konfor itätserklärung .................................... 14
EINLEITUNG
Wir danken Ihnen, dass Sie sich für die sprechende
Wetterstation mit Informationsdienst (BAR933HG /
BAR936HG) von Oregon Scientific M entschieden haben.
Dieses leistungsstarke Gerät vereint die Beibehaltung
einer präzisen Zeitanzeige, eine Wettervorhersage, die
Messung der Innen- und Außentemperaturen und der
Luftfeuchtigkeit sowie die Anzeige des Luftdrucktrends
mit Höhenlageneinstellung in einem Instrument, das Sie
bequem in Ihrem Haus benutzen können.
In dieser Box befinden sich:
• Basiseinheit
• Funksendeeinheit (R GR368N)
• Optionale UV-Funksendeeinheit (UVR138) - nur bei
BAR936HG inklusive.
• 6 V Netzadapter
• Batterien
BAR933HG --- BAR933HG Basiseinheit + R GR368N
Funksendeeinheit
BAR936HG --- BAR936HG Basiseinheit + R GR368N
Funksendeeinheit + UVR138 UV-Funksendeeinheit
Auch die Funksendeeinheiten HGR328N
(5-Kanal) and HGR228N (3-Kanal) sind mit dieser
Wetterstation kompatibel. Zusätzliche Funksendeeinheiten
werden separat verkauft. Weitere Information hierzu
erhalten Sie bei Ihrem lokalen Händler.
Halten Sie dieses Handbuch bereit, wenn Sie Ihr neues
Gerät benutzen. Es enthält praktische schrittweise
Anleitungen, sowie technische Daten und Warnhinweise,
die Sie wissen sollten.
HINWEIS
Wetterstation it Mitteilungsdienst
Modell: BAR933HG / BAR936HG
Bedienungshandbuch
BAR933HG German R2 OP 8/27/04, 6:59 PM1
Black

DE
2
1. LCD-Anzeige
2. MODE: Änderung der Einstellungen / Anzeige
3. MEMORY: Messungen der aktuellen, maximalen
und minimalen emperatur / Luftfeuchtigkeit /
UV-Werte anzeigen.
4. HISTORY: Anzeige historischer Daten zu Luftdruck,
emperatur, Feuchtigkeit, UV
5. MESSAGE: Ansicht verschiedener Meldungen
6. SNOOZE / LIGHT: 8 Minuten Schlummerfunktion
oder Hintergrundbeleuchtung aktivieren
7. SELECT: Anzeigefelder umschalten
8. CHANNEL: Umschaltung der Funksende-
einheitenanzeige
9. UP: Erhöhung von Einstellungen / Funkuhr aktivieren
10. DOWN: Reduzieren von Einstellungen / Funkuhr
deaktivieren
11. ALARM / : Weckalarmstatus anzeigen;
Weckalarm einstellen
PRODUKTÜBERSICHT
VORDERANSICHT
8
9
10
11
7
3
5
6
4
2
1
RÜCKANSICHT
1. Belüftungsschlitze
2. Batteriefach (unten)
3. Netzadapterbuchse
4. aste b / inHg (im Batteriefach)
5. RESET-Loch (im Batteriefach)
6. aste °C / °F (im Batteriefach)
Sie können den Winkel der Uhranzeige wie unten gezeigt
einstellen:
3
4
5
2
1
6
BAR933HG German R2 OP 8/27/04, 6:59 PM2
Black

DE
3
1
3
4
5
2
6
7
8
9
10
1
2
4
3
5
6
7
8
9
2
1
3
4
5
1
2
4
5
3
6
7
8
9
10
13
11
12
LCD-ANZEIGE
1. Wettervorhersagen-Anzeigefeld: Animierte
Wettervorhersage
2. Uhr- / Weckalar - / Kalender-Anzeigefeld:
Funkuhr; Weckalarme; Kalender
3. UVI- / Baro eter-Anzeigefeld: UV-Index- und
Luftdruckmessungen
4. Meldungs-Anzeigefeld: Zeigt allgemeine
Wetterdaten und Warnungen an
5. Te peratur- / Luftfeuchtigkeit- / Ko fortzonen-
Anzeigefeld: Messungen und rendlinien;
Komfortzone; Funksendeeinheits-Kanalnummer
Uhr- / Weckalar - / Kalender-Anzeigefeld
1. Funkuhrempfang
2. Kanalnummer (1-5)
3. Symbol des ausgewählten Bereiches
4. Zeit / Datum / Kalender
5. Sprechender Weckalarm ist eingerichtet
6. Weck-Voralarm ist eingerichtet
7. Wecktonalarm ist eingerichtet
8. Weck-Voralarm-Anzeige / Einstellung
9. Zweite Zeitzone
Baro eter- / UVI-Anzeigefeld:
1. UVI-Wert wird angezeigt
2. UV wird angezeigt
3. Luftdruck wird angezeigt
4. UV-Indexpegel
5. Höhenlage / Luftdruck- / UVI-Messung
6. SPF, angewandter Schutzfakor des Benutzers für
UV-Belichtung
7. Benutzer-Hautyp für UV-Belichtung
8. Erscheint bei der Einrichtung der Höhenlage.
9. MAX / MIN UVI
10. UV-Belichtungszeitkontrolle wurde gestartet
11. Anzeige für schwache UV-Sensor-Batterie
12. UV-Expositionszeit für den Benutzer
13. Benutzernr. (für UV-Modus) oder zeitliche
Entwicklung für UVI- / Luftdruckmessungen.
Meldungs-Anzeigefeld
1. Meldungsanzeige
2. CAUTION: Erscheint, wenn eine Warnmeldung
angezeigt wird.
3. TEMPERATURENTWICKLUNG
4. LUFTFEUCHTIGKEITSENTWICKLUNG
5. Sprachmeldung ist eingeschaltet (ON)
6. Netzadapter ist getrennt.
Te peratur- / Luftfeuchtigkeits- / Ko fortzonen-
Anzeigefeld:
1. Hitzeindex
2. emperaturtrend
3. Kanalnummer (1-5) / Empfangsstatus
4. Symbol für schwache Funksendeeinheits-Batterie
ODER schwache Basiseinheits-Batterie, wenn die
Innentemperatur angezeigt wird.
5. Luftfeuchtigkeitstrend
6. MAX / MIN emperaturen
7. emperatur - °C / °F
8. Komfortpegel
9. MAX / MIN Luftfeuchtigkeit
10. Luftfeuchtigkeit
5
6
1
2
3
4
BAR933HG German R2 OP 8/27/04, 6:59 PM3
Black

DE
4
FUNKSENDEEINHEIT (RTGR368N)
1
2
3
4
1. LCD-Anzeige
2. LED-Statusanzeige
3. Belüftungsöffnung
4. Ausklappbarer ischständer
1. Signalempfang
2. Zeit
3. Kanalnummer
4. emperatur- / Luftfeuchtigkeitsmessungen
5. Batteriewechselanzeige
6. emperatur (°C oder °F)
7. Luftfeuchtigkeit %
1
2
3
4
5
6
7
Made in PRC
R GR368 N
SEARCH RESE 12 3 4 5
CHANNEL
EU UK
C F
1
3
4
5
26
7
1. Wandmontageöse
2. EU / UK Funksignalformat-Umschalter
3. SEARCH- aste
4. °C / °F aste
5. RESET- aste
6. CHANNEL-Umschalter (1-5)
7. Batteriefach
BAR933HG German R2 OP 8/27/04, 6:59 PM4
Black

DE
5
VORBEREITUNG ZUM EINSATZ
BATTERIEN
Batterien sind im Lieferumfang dieses Gerätes enthalten:
• Basiseinheit 4 x 1,5 V Micro (AAA, LR03)
• Funksendeeinheit 2 x 1,5 V Mignon (AA, LR6)
Legen Sie die Batterien vor der ersten Benutzung ein
und beachten Sie dabei die im Batteriefach abgebildeten
Polaritäten. Installieren Sie für optimale Ergebnisse die
Batterien zuerst in der Funksendeeinheit und dann in der
Basiseinheit. Drücken Sie nach jedem Batteriewechsel
auf RESET.
Installation der Batterien in der Basiseinheit:
Verwenden Sie keine wiederaufladbaren
Akkus.
Um eine längere Lebensdauer zu erzielen,
wird für dieses Gerät die Verwendung von Alkaline-
Batterien empfohlen.
zum Schutz unserer Umwelt / Batterieentsorgung
Batterien gehören nicht in den Hausmüll. Als
Verbraucher sind Sie gesetzlich verpflichtet, gebrauchte
Batterien zurückzugeben. Sie können Ihre alten
Batterien bei den öffentlichen Sammelstellen in Ihrer
Gemeinde oder überall dort abgeben, wo Batterien der
betreffenden Art verkauft werden.
zeigt an, wenn die Batterien schwach sind.
HINWEIS
HINWEIS
EINHEIT POSITION
Basiseinheit emperatur- / Luftfeuchtigkeits-
Anzeigefeld (wenn die
Innenraumdaten angezeigt werden)
Funksende-
einheit
emperatur- / Luftfeuchtigkeits-
Anzeigefeld
UV-Sensor
NETZADAPTER (BASISEINHEIT)
Die Batterien dienen als Ersatzstromversorgung. Für
kontinuierlichen Gebrauch schließen Sie bitte den
Netzadapter am Sockel der Basiseinheit an:
UVI- / Barometer-Anzeigefeld
HINWEIS
Wird im Meldungs-Anzeigefeld angezeigt, wenn
der Netzadapter nicht eingesteckt ist.
ÄNDERUNG DER EINSTELLUNGEN
1. Drücken Sie SELECT, um zwischen den
Anzeigebereichen umzuschalten. zeigt den
ausgewählten Bereich an.
2. Die meisten Anzeigefelder haben alternative
Anzeigeoptionen (z. B. Uhr / Weckalarm oder
Luftdruck / UVI). Drücken Sie MODE, um zwischen
den Optionen oder ALARM / , um zwischen Uhr
und Alarm umzuschalten.
3. Halten Sie 2 Sekunden lang MODE gedrückt, um
den Einstellmodus zu starten.
4. Drücken Sie die UP oder DOWN, um die Einstellungen
zu ändern.
5. Drücken Sie zur Bestätigung auf MODE.
FUNKSENDEEINHEIT
Dieses Gerät wird mit der hermo-/Hygro-
Funksendeeinheit R GR368N geliefert. Die Basiseinheit
kann Daten von bis zu 6 Sensoren (5 emperatur- /
Luftfeuchtigkeitssensoren und 1 UV-Sensor erfassen).
Auch die Funksendeeinheiten HGR328N und
HGR228N sind mit dieser Wetterstation kompatibel.
(Zusätzliche Funksendeeinheiten werden separat
verkauft. Weitere Information hierzu erhalten Sie bei
Ihrem lokalen Händler.)
Die Funksendeeinheit R GR368N erfasst emperatur-
und Luftfeuchtigkeitsmessungen und Signale von
offiziellen Normalzeitorganisationen für die Funkuhr.
EINRICHTUNG DER THERMO- / HYGRO -
FUNKSENDEEINHEIT (RTGR368N)
1. Öffnen Sie das Batteriefach mit einem kleinen
Kreuzschlitzschraubendreher.
2. Legen Sie die Batterien ein.
3. Stellen Sie den Kanal und das Funksignalformat ein.
Die Schalter befinden sich im Batteriefach.
BAR933HG German R2 OP 8/27/04, 6:59 PM5
Black
