Oregon Scientific WMH90 User manual

4-Day Weather Forecaster
Model: WMH90
USER MANUAL
WMH90_COVER.indd 1 11-7-27 下午5:07
P/N: 300100781-00004-10 REV 1
1/86

EN
1
4-Day Weather Forecaster
Model: WMH90
USER MANUAL
CONTENTS
Introduction .............................................................. 2
Overview ................................................................... 2
Front View.............................................................. 2
Back View .............................................................. 3
Remote Sensor...................................................... 4
Getting Started ......................................................... 4
Set Up Remote Sensor.......................................... 4
Sensor Data Transmission..................................... 4
Set Up Main Unit.................................................... 5
Weather Information Display................................... 5
Regional Weather Information ............................... 5
Local Temperature And Humidity........................... 7
Weather Warning Message.................................... 7
Clock.......................................................................... 7
To Manually Set Clock ........................................... 7
Alarm ......................................................................... 8
To Set Alarm........................................................... 8
To Activate / Deactivate Alarm ............................... 8
To Silence Alarm .................................................... 8
Display Contrast....................................................... 8
Backlight ................................................................... 8
Reset.......................................................................... 8
Specifications........................................................... 9
Main Unit................................................................ 9
Remote Thermo Sensor (THN132NS)................... 9
Precautions............................................................... 9
About Oregon Scientific ........................................ 10
EU-Declaration Of Conformity .............................. 10
WMH90_M_EU_EN_R5.indd 1 11-7-27 下午4:55
P/N: 300100781-00004-10 REV 1
2/86

EN
2
INTRODUCTION
Thank you for selecting the Oregon Scientific™ 4-Day
Weather Forecaster (WMH90).
This wireless, plug and play weather station is capable of
receiving weather information from the whole of Europe.
European countries and cities are user-selectable,
allowing users to display the weather information of the
selected European city on the main unit.
NOTE Please keep this manual handy as you use
your new product. It contains practical step-by-step
instructions, as well as technical specifications and
warnings you should know about.
OVERVIEW
FRONT VIEW
6
7
9
10
11
13
15
17
18
14
16
12
8
5
4
3
2
1
1. MD / DM: calendar format (month-day or day-
month)
2. : main unit batteries low
3. : indicate daily alarm is On
WMH90_M_EU_EN_R5.indd 2 11-7-27 下午4:55
P/N: 300100781-00004-10 REV 1
3/86

EN
3
1
3
2
4. : indicate in Alarm mode
5. : indicate AM / PM
6. : clock signal reception indicator
7. : weather information signal reception indicator
8. Country name / City name / Clock / Daily alarm /
Calendar / Message
9. Today’s regional weather forecast / Day and night
temperature / Amount of precipitation / Wind speed
and direction (user selected city)
10. : sensor batteries low
11. : indicate outdoor sensor reception status
12. Local indoor and outdoor temperature and indoor
humidity
13. Next 3-day regional weather forecast with day /
night temperature and amount of precipitation (user
selected city)
14. ALARM: activate / deactivate alarm; set alarm
15. MODE: toggle between time / calendar and
message display; set clock
16. SNOOZE / LIGHT: activate snooze function; turn on
backlight
17. : increase value of the setting; display next
country / city; initiate sensor search with
18. : decrease value of the setting; display previous
country / city; initiate sensor search with
BACK VIEW
1. Wall mount hole
2. RESET: reset unit to default settings
3. ºC / ºF: select temperature unit
WMH90_M_EU_EN_R5.indd 3 11-7-27 下午4:56
P/N: 300100781-00004-10 REV 1
4/86

EN
4
REMOTE SENSOR
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET hole
NOTE The sensor included in this package
(THN132NS) does not measure humidity.
GETTING STARTED
SET UP REMOTE SENSOR
1. Slide open the battery door.
2. Insert battery, matching the polarities (+ / -).
3. Press RESET.
4. Close the battery door.
TIP Use alkaline batteries for longer usage and
consumer grade lithium batteries in temperatures below
freezing.
SENSOR DATA TRANSMISSION
To search for a sensor:
Press and hold and .
For best results:
• Place the sensor within 100 m (300 ft) of the main
unit.
• Position the sensor so that it faces the main unit,
minimizing obstructions such as doors, walls and
furniture.
• Place the sensor out of direct sunlight and
moisture.
• Place the sensor in a location with a clear view to
the sky, away from metallic / electronic objects.
• Position the sensor close to the main unit during cold
winter months as below-freezing temperatures may
affect battery performance and signal transmission.
1
2
3
4
