Origin Acoustics DSP3 Series User manual

Installation Manual
DSP3-700
CAUTION! WARNING!
DO NOT INSTALL THIS SYSTEM UNTIL YOU HAVE SET UP YOUR DSP.
USE THIS MANUAL OR SCAN QR CODE TO CONSULT MANUAL ONLINE.
Please visit docs.originacoustics.com or scan the QR code using your smart device for the
most up to date installation, presets, safety & warranty information.

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide bladed
or the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
M. Unplug this apparatus during lightning
storms or when unused for long
periods of time.
N. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
O. The equipment shall be used at maximum 35o
C/ 95o F ambient temperature. To help maintain
ambient temperature, DO NOT mount in
locations with direct sunlight.
P. To reduce the risk of electrical shock, do not
open the equipment. For safety reasons it is
only allow to the opened by qualified service
personnel.
Q. WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture. Additionally, the apparatus shall not
be exposed to dripping or splashing and no
objects filled with liquids shall be placed on the
apparatus.
R. The mains plug is used as the disconnect
device and shall remain readily operable.
S. The product shall be used on open bench.
T. No naked flame sources, such as lighted
candles, should be placed on the apparatus.
U. The apparatus should be connected to a
mains socket outlet with a protective earthing
connection.
V. Ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
W. This apparatus is suitable for use in tropical
climates.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER OR BACK. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO AUTHORIZED
SERVICE PERSONNEL.
CAUTION: WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THE
APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR
SPLASHING. NO OBJECTS FILLED WITH LIQUIDS SHALL
BE PLACED ON THE APPLIANCE.

Table of Contents
Introduction 1
Amplifier Presets 2
Specifications 4
What’s Included 5
Wire Recommendations 5
About the DSP3-700 6
Startup 6
Loading a DSP preset 8
Adjusting the Volume 9
Troubleshooting 10
Technical Assistance 11
Warranty 12
Return Process 13

1
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
Thank you for purchasing the DSP3-700 amplifier. At Origin Acoustics, we take pride in
providing you with a high quality product. All of Origin Acoustics’ products are designed to
have excellent sound quality, longevity, and a simple installation process.
This instruction booklet covers the necessary information for a smooth installation,
including: the tools you will need, step-by-step instructions for installation, troubleshooting
tips for any errors that may occur, and all warranty information. If for any reason you
experience problems or if you have installation questions please call us at [phone].
Hours of operation are 8:00am to 5:00pm (Pacific Time), Monday through Friday.
Introduction

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
2
Amplifier Presets
LIST DSP PROFILE
1 FLAT
2 0 LS44
3 0 LS64
4 0 OS55
5 0 OS57
6 0 OS65
7 0 OS67
8 8 LS44
9 8 LS64
10 8 SAT0
11 10 LS44
12 10 LS64
13 10 SAT0
14 12 LS44
15 12 LS64
16 12 SAT0
17 P LS44
18 P LS64
19 P OS55
20 P OS57
21 P OS65
22 P OS67
23 P SAT0
24 OSR65
25 0SR685
26 LSB64 ROUND 180
27 LSB64 ROUND 360
28 LSB64 SQUARE 180
29 LSB64 SQUARE 360
30 0SUB12 LSR6

3
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
Amplifier Presets
LIST DSP PROFILE
31 OSUB12 6.5HD
32 12HDR SBR42-55
33 10HDR LSR6
34 10HDR 6.5HD
35 11BP-IG LSR6
36 12HDR LSR6
37 12HDR 6.5HD
38 12HDR 26.5HD
39 12BP-IG LSR6
40 12BP-IG 6.5HD
41 LSR6
42 6.5HD
43 10HDR6
44 10HDR65
45 11BP-IG6
46 12HDR6
47 12HDR65
48 12BP-IG6
49 12BP-IG65
50 6.5HDRFR
51 ALSB106 Round 180
52 ALSB106 Round 360
53 ALSB106 Square 180
54 ALSB106 Square 360
55 EMPTY
56 EMPTY
CAUTION! WARNING!
DO NOT INSTALL THIS SYSTEM UNTIL YOU HAVE SET UP YOUR DSP.

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
4
Power & Amplifier Sections
*All product specifications are subject to change. Please refer to the dealer portal for the latest information.
MODEL DSP3-700
PART AMPD03X7000
# of Channels 3 Powered Out (L/R/S)
Analog Input 4 x RCA A/B Unbalanced Max Input 12dBu
Digital Input 1 Stereo Coaxial, 1 Stereo Optical
Dynamic Power 700 Watts RMS / Channel, All Channels Driven into 4 Ohm / 70 V, 500 Watts
RMS/ Channel Driven into 8 Ohm x 3, Dynamic Power (Peak) 1 kW / Channel x 3
Frequency Response 
Power Supplies 1 Independent Switch Mode Power Supply
Output Circuitry Class D - Self-Oscillating PWM Topology;
400kHz Supplied by Independent SMPS
THD @ Rated Power
4 ohm (1kHz 0.02% (1W), 0.05% (60W), 0.08% (100W)
Dynamic Range 118dB (A-Weighted, AES-17 Filter)
Feature 1 USB program interface
Feature 2 DSP 24/96 Sampling/Resolution
Presets Built in 64
Rack Space 2U
Protection Clip Limiting, Temperature, Over Current, DC, HF on outputs
Dimensions 


5
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
What’s Included
Wire Recommendations
For this setup, use a direct burial, multi-stranded wire designed for amplifier to
speakers connections. 70V systems greatly minimize the eect of speaker wire
(resistance) which allows you to use a lighter gauge wire. Refer to this chart to
select the minimum wire gauge ---Heavier gauge wire is always OK.
Wire Length
(Feet)
8 Ohm 70V
0-100 14 16
100+ 12 14
5
FOUNDATION COLLECTION™ USER MANUAL
Amplifier USB Cord AC Cord
What’s Included
Wire Recommendations
For this setup, use a direct burial, multi-stranded wire designed for amplifier to
speakers connections. 70V systems greatly minimize the eect of speaker wire
(resistance) which allows you to use a lighter gauge wire. Refer to this chart to
select the minimum wire gauge ---Heavier gauge wire is always OK.
Wire Length
(Feet)
8 Ohm 70V
0-100 14 16
100+ 12 14
Recommended Gauge
Recommended Gauge

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
6
About the DSP3-700
Startup
Aer the installation of the device is complete you will see the startup page on the
display. If the amplifier is in Standby mode, press and hold the Standby button for
a few seconds to exit the Standby Mode to the main page.
We have simplified set-up by limiting front panel adjustments to that of
loading internal presets and setting channel levels. All other DSP adjustments
require the use of the dedicated soware program. To download the dedicated
soware program refer to the DSP3-700 section under the electronics tab
at www.originacoustics.com
This amplifier is a highly flexible and intelligent digital audio 3 Channel Class D
power amplifier. The DSP3-700 delivers up to a total of 2,100W @4Ω or is able
to drive 70/100V constant voltage lines. All setup parameters for input/output
processes and DSP features are accessible by using the remote PC soware. Each
DSP3-700 has space for 56 profiles and comes preloaded with 54 DSP presets
optimized for Origin Acoustics’ speakers/subwoofers, assuring peak performance.
FOUNDATION COLLECTION™ USER MANUAL
6
About the DSP3-700
Startup
DSP3-700
Power Amplifier
Aer the installation of the device is complete you will see the startup page on the
display. If the amplifier is in Standby mode, press and hold the Standby button for
a few seconds to exit the Standby Mode to the main page.
We have simplified set-up by limiting front panel adjustments to that of
loading internal presets and setting channel levels. All other DSP adjustments
require the use of the dedicated soware program. To download the dedicated
soware program refer to the DSP3-700 section under the electronics tab
at www.originacoustics.com
DSP3 amplifiers are highly flexible and intelligent digital audio 3 Channels Class D
power amplifiers. The DSP3-700 amplifier delivers up to a total of 2,100W@4Ω or
able to drive 70/100V constant voltage lines. All setup parameters for input/output
processes and DSP features are accessible by using the remote PC soware. Each
DSP3-700 comes preloaded with up to 64 DSP presets to optimize it for use with
all of Origin Acoustics’ speakers and subwoofers assuring peak performance.

7
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
In order to access the menu, press the dial. Rotate the dial to select either “Load
Program,” “Change Volume” or “Exit Menu”
7
FOUNDATION COLLECTION™ USER MANUAL
In order to access the menu, press the dial. Rotate the dial to select either “Load
Program,” “Change Volume” or “Exit Menu”
DSP3-700
Load Program
DSP3-700
Change Volume
DSP3-700
Exit Menu

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
8
To change a program select the page “Load Program” and press the dial. The IP
address and the name of the preset of the device will appear on the display.
Loading a DSP Preset
Turn the dial to select your desired preset to match your Origin Acoustics Speakers.
If you are not sure which preset to use, refer to the “Amplifier Preset” section of this
manual. Once you have found the desired program number it will be blinking.
Press the dial to select the desired program to load, at which time it will stop
blinking. If the number is not blinking while selecting, the display will return to the
“Load Program” menu and you will need to restart the process.
The DSP3-700 features a third channel to provide an easy way to control the low-
end output of passive subwoofers. With a selection of preloaded DSP presets,
to match every outdoor speaker in our arsenal, set-up is as easy as selecting the
one that’s right for your design configuration. Or you can customize and store
settings for each specific project should you choose. Independent settings can be
assigned to each of the three channels, which can also independently drive 4Ω or
70V signals.
It is essential to configure before installing the system
FOUNDATION COLLECTION™ USER MANUAL
8
To change a program select the page “Load Program” and press the dial. The IP
address and the name of the preset of the device will appear on the display.
Loading a DSP Preset
IP 192.168.0.100
Preset: “Program Name”
Turn the dial to select your desired preset to match your Origin Acoustics Speakers.
If you are not sure which preset to use, refer to the “Amplifier Preset” section of this
manual. Once you have found the desired program number it will be blinking.
Press the dial to select the desired program to load, at which time it will stop
blinking. If the number is not blinking while selecting, the display will return to the
“Load Program” menu and you will need to restart the process.

9
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
To change the volume, select the “Change Volume” page from the main page and
press the dial to select.
Adjusting the Volume
Once selected the volume level will appear on the display. Use the dial to change
the volume level (from -60dB to +12dB) and press the dial once again to confirm
the volume level selection. The display will start with the Le Output, then to the
Right Output, and lastly to the Sub Output. To return to the “Change Volume”
page, press the dial again. To exit the menu, select “Exit Menu” and press the dial.
CAUTION! WARNING!
DO NOT INSTALL THIS SYSTEM UNTIL YOU HAVE SET UP YOUR DSP.
9
FOUNDATION COLLECTION™ USER MANUAL
To change the volume, select the “Change Volume” page from the main page and
press the dial to select.
Adjusting the Volume
Output Left:
Level = 0.0dB
Once selected the volume level will appear on the display. Use the dial to change
the volume level (from -60dB to +12dB) and press the dial once again to confirm
the volume level selection. The display will start with the Le Output, then to the
Right Output, and lastly to the Sub Output. To return to the “Change Volume”
page, press the dial again. To exit the menu, select “Exit Menu” and press the dial.

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
10
If you have a problem, try isolating it first. For example, if you’re playing a DVD
and there is no sound, try replacing the DVD with an MP3 player to see if you get
sound. If it does work, then the problem is with the television, DVD player, or the
cables connecting them. If it doesn’t work, the problem will be with the amplifier,
speakers, or those cables.
Troubleshooting
Problem Possible Cause
No Sound
The volume may be turned down or muted. Check the volume
settings on both the amplifier and the television/computer/CD
player/etc.
No Sound Make sure the proper source is selected on the amplifier or re-
ceiver.
No Sound
Check the cord connecting the amplifier with the source. The
cord may be damaged or plugged into the wrong input or out-
put.
No Sound
Check the wires connecting the amplifier with the speakers.
Make sure they’re connected properly and not damaged in any
way.
Poor Sound
Quality
If you hear something like static, or the sound is cutting in and
out, check the audio cables. If the problem increases when a
cable is being moved, then the cable is most likely faulty or not
connected properly.
Poor Sound
Quality
Today’s audio systems may have several places to adjust the
volume, for example your MP3 player may have a volume
control, and your amplifier may also have one. Check to be
certain that the volume isn’t turned up past 80% on any device.
Poor Sound
Quality
Try changing sources to be certain that the selection you’ve
chosen is a good quality recording.

11
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
If you have any questions or concerns about installing or using this product, you
can reach us through one of the following methods:
Phone: [phone]
Hours of operation: 8:00am - 5:00pm (Pacific Time), Mon - Fri
Email: [e-mail]
If you are having technical trouble, please include the model number and
briefly explain what steps you took to resolve the problem in your email, or
be prepared to answer these questions over the phone. If you are considering
returning the product, it’s required that you contact Origin Acoustics prior to any
return attempts. This way we can determine if the issue can be resolved without
returning the product, or if needed we can provide instructions and support for
the return process.
Technical Assistance

DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
12
Origin Acoustics warrants to the original retail purchaser only that this Origin
Acoustics product will be free from defects in materials and workmanship,
provided the speaker was purchased from an Origin Acoustics authorized dealer.
If the product is determined to be defective, it will be repaired or replaced at
Origin Acoustics’ discretion. If the product must be replaced yet it is no longer
manufactured, it will be replaced with a model of equal to or greater value that is
the most similar to the original. If this is the case, installing the replacement model
may require mounting modifications; Origin Acoustics will not be responsible for
any such related costs.
2 Year Limited Warranty
This warranty may not be valid if the product was purchased through an
unauthorized dealer. This warranty only applies to the individual that made the
original purchase, and it cannot be applied to other purchases. The purchaser
must be prepared to provide proof of purchase (receipt). This warranty will not
be valid if the identifying number or serial number has been removed, defaced,
or altered.
Requirements & Warranty Coverage
*All warranties and warranty conditions are subject to change. Please refer to
www.originacoustics.com for the latest information.

13
DSP3-700 AMPLIFIER INSTALLATION USER MANUAL
• Accidental damage
• Damage caused by abuse or misuse
• Damage caused by attempted repairs/modifications by anyone other than
Origin Acoustics or an authorized dealer
• Damage caused by improper installation
• Normal wear, maintenance, and environmental issues
• Damage caused by voltage inputs in excess of the rated maximum of the unit
• Damage inflicted during the return shipment
Not Covered by Warranty
Before making any return attempts, it is required that you first contact Origin
Acoustics. Return product to Origin Acoustics or your dealer, either in person or by
mail. It’s preferable if the product is returned in the original packaging. If this isn’t
possible, the customer is responsible for insuring the shipment for the full value
of the product.
This warranty is in lieu of all other expressed or implied warranties. Some states
do not allow limitations on implied warranties, so this may not apply depending
on the customer’s location. (For more information, see Magnuson-Moss Warranty
Act.)
Return Process




