ORIGO CD-S1238UV User manual

UV殺菌乾衣機
: CD-S1238UV
: 220-240伏特~, 50/60赫茲
: 1000瓦特
型號
電壓
功率
保用
本機可獲自購買或領取日起1年免費保用(商業用途享有三個月
免費保用)。此保用只包含生產所導致的品質問題；並不包外罩
及其他附件，因誤用或不依說明書指示使用而導致的損壞。
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號
匯城集團大廈21樓H室(近華星街12號)
電話：2156 8238
辦公時間
上午10:30 -下午12:30 (星期一至五)
下午02:30 -下午05:30 (星期一至五)
上午10:30 -下午12:30 (星期六)
(星期日及公眾假期休息)
源澤地圖
安全注意事項
1) 使用本產品前，請小心閱讀說明書並保留給將來翻閱。
2) 使用本產品前，請確定規格標貼上標示的額定電壓與當地供
電電壓相同。如有疑問可向服務中心查詢。
3) 本機不是為體質、感覺或智力有障礙人士(包括小孩)或缺乏
經驗及知識者使用，除非他們曾經接受負責安全人士的監督
或指示。大人應指導小孩不可把玩電器。
4) 本產品只可以用附設的電源線使用。
5) 使用前請先拆除所有包裝物料。
6) 本產品不可放於潮濕或有積水的地方使用。
7) 本產品應放在平穩的地面上使用，及遠離發熱源頭。
8) 本產品不可於室外使用。
9) 本產品設計只適合家居使用。
10) 當作為暖風機功能使用時，切勿開啟UV殺菌燈管，以免對
人體做成傷害。
11) 乾衣前，務必先將衣物脫水，避免出現水珠下滴，弄濕機
身或地面而造成危險，同時亦可縮短乾衣時間。
12) 使用本產品時，切勿觸摸出風口的金屬部份，以免燙傷。
13) 本乾衣機僅供乾燥用水洗滌的衣物使用。
14) 乾衣前，應注意衣物上的標籤，認清該衣物是否可使用乾
衣機及使用溫度限制。
15) 使用乾衣機時，憑保持室內空氣流通，乾衣機與牆壁最少
保持150毫米距離。
16) 本乾衣機僅供耐溫攝氏75度以上的布料，每次乾衣總重量
不可超出10千克。
17) 經常檢查本產品。如發現有任何損壞，例如電源線損毀，
應立即停止使用，並交由指定維修服務中心檢查及修理。
清潔保養
1) 清潔前必須拔除電源插頭，切斷電源。
2) 清理時切勿將主機體浸於水或其他液體中。
3) 可使用濕布加入少許溫和的清潔劑擦淨。
費延長保用期3個月，即15個月免費保用(商業用途除外)。請即登
入網站 : www.origo.hk
注意：保用時，須帶同收據及請先致電服務中心。
使用方式
1) 將插頭插入電壓220-240 伏特的獨立插座。
2) 將控制旋鈕以順時針方向旋轉，乾衣機進入工作狀態及電源指
示燈亮起。
3) 將控制旋鈕旋轉，設置自動關機時間。
- 本乾衣機可選擇0-180分鐘定時自動關機。
- 當旋鈕指向"殺菌"(UV)位置，UV燈管亮起並進行〸五至二〸
分鐘紫外線殺菌。
- 當作為暖風機功能使用時，切勿使用"殺菌"(UV)功能，避免紫
外線對人體做成傷害。
4) 中間位置為關機(OFF)。
5) 控制旋鈕以逆時針方向旋轉至(ON)位置為連續開機。
各部名稱
儲存：連同使用說明書，把乾衣機存放於清涼及乾爽地方。
安裝步驟
***額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免
外罩
圓管
固定桿
防水蓋
電源線
主機體
滑輪
主機體支架
2) 將圓管插進固定桿相應位置
內。
1) 將滑輪向上插進固定桿相應
位置內。
3) 將圓管向下插進固定桿相應
位置內。
4) 將外罩套進4支圓管上。
5) 重複步驟(2)製作頂部支架。 6) 使用螺絲把防水蓋鎖緊於主機
體出風口上，並將主機體出風
口從外罩底部圓孔插入外罩內
。
向上插入
滑輪
固定桿
向下插入
將外罩向上拉，並將整個支
架覆蓋。
Paper weight: 120 gram or above
Printing Color: Black
www.origo.hk

Clothes Dryer
with UV Sterilization
: CD-S1238UV
: 220-240V~, 50/60Hz
: 1000W
Model
Voltage
Power
Maintance and Care
1) Unplug the power cord before cleaning.
2) Do not immerse the main body in water, it may cause electric
shocks.
3) Clean the Dryer with a soft cloth. To remove presistent dirt,
wipe down with a cloth that has been dampened with warm
soapy water.
Origin Map
Warranty
This product is guaranteed for 1 year (commercial use for 3
months)from the date of receipt against manufacturing defect.
The warranty does not cover the stand, clothes cover and other
accessories, damage or defect caused by negligence or use not
according to this instruction manual.
1) Plug the power cord into a 220-240V~ electrical outlet.
2. Turn the control knob clockwise, the Dryer switch on and the
power indicator light will be on.
3. Turn the control knob to set desired auto power off time.
- The range of the timer is from 0 to 180 minutes.
- When the control knob pointed at "UV" position, UV tube will
light on and process 15 to 20 minutes sterilization.
- Do not switch on the UV light when the dryer is working as
a heater.
4) To turn the Dryer off, rotate the control knob to "OFF" position.
5) Turn the control knob anti-clockwise to "ON" position for
drying without time limit.
Remark: For repair service, please contact and bring alone the
invoice or receipt to the Service Centre.
***Extra 3 months warranty: just complete Online Warranty
Registration within 10 days from the date of receipt, free
warranty will be extended to 15 months (not applicable to
commercial use). Please enter our website: www.origo.hk
Caution
1) Read all instructions carefully before using the Clothes Dryer.
Appropriately keep it for furture reference when necessary.
2) Before using the Dryer, check if the volatage marked on
the rating label corresponds to the mains in your home.
3) This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
4) Only the provided power cord can be used.
5) Remove all the package before using the Dryer.
6) The Dryer is not intended for use in wet or damp locations.
7) Place the Dryer on a stable surface and keep away from heat
source.
8) Do not use the Dryer in outdoor location.
9) The Dryer is designed for domestic use only.
10) Do not switch on the UV light when the dryer is working as
a heater.
11) Ensure spin-drying completely before using the Dryer.
12) To avoid being scalded, never touch the metal parts on the
wind outlet during drying process.
13) This Dryer is intended only for drying textiles washed in
water.
14) Check the clothing care label before drying, Make sure they
can be dried using the drying machine, pay special attention
to its temperature limits.
15) Keep a distance of at least 150mm between Dryer and the
wall.
16) Clothes to be dried should be able to endure 75 degree
above, and maximum weight is 10 kgs.
17) Always check the Dryer, if the power cord is damaged, it must
be replaced and repaired by authorized service agent.
Operation
Main Parts STORAGE: Store the Dryer with these instructions in the original
box in a cool and dry place.
Clothes Cover
Water Proof
Plate Caster
Power Cord
Main Body
Main Body
Support Rack
Installation
2) Insert the round tubes into
correspond holes at the
locating rod.
1) Up insert the casters into
locating rod.
3) Insert the round tubes into
into the plastic holes of the
locating rod.
4) Put the clothes cover through
the round tube.
5) Repeat step (2), insert the
round tubes into correspond
holes at the upper locating
rod. Let the clothes cover up
to cover the whole stand.
Up insert
Caster
Locating Rod
Down
insert
6) Screw and fix the water proof
cover on the wind outlet of
the main body, then insert the
air outlet of the main body
into the clothes cover from the
round hole at the bottom of
the clothes cover.
Round Tube
Locating Rod
Service CentreService Centre
ORIGIN MARKETING LIMITED
Unit H,21/F, Reason Group Tower
(nearby 12 Wah Sing Street), 403 Castle Peak Road,
Kwai Chung, N.T., Hong Kong.
Tel: [phone]
OOfffice Hoursfice Hours
10.30am - 12:30pm (Mon ~ Fri)
02:30pm - 05:30pm (Mon ~ Fri)
10:30am - 12:30pm (Sat)
(Closed on Sunday and Holiday)
Paper weight: 120 gram or above
Printing Color: Black
白底黑字, 中英各一面, 風琴
摺, A4 SIZE, 120g紙或以上
www.origo.hk
