Congratulations on your purchase of a quality
Orion accessory. Your new Orion Dual Finder
Scope Mounting Bracket is a terric accessory
that enables two aiming devices to be used at
the same time on one telescope.
Included Items:
• Bracket
• dovetail mounting shoe for nder scopes
(x2)
• Philips head screws (x4)
Assembly
• Attach each of the dovetail mounting
shoes to the bracket using the included
screws and a Philips head screwdriver (not
included) making sure that both the bases
are oriented in the same direction as the
base of the bracket (Figure 1).
Figure 1. Rear view of bracket showing orientation of
bracket and dovetail mounting shoes to x to bracket
using screws.

2
Attaching the Bracket to a
Telescope
Once assembled simply slide the bracket into
the telescope’s dovetail mounting shoe (Figure
2) and tighten the thumbscrew on the shoe to
secure the bracket.
Attaching Aiming Devices to
the Dual Mounting Bracket
Many combinations of accessories can now
be used at the same time (Figure 3). To attach
each device simply slide each device into either
of the dovetail mounting shoes and tighten the
thumbscrew to secure the device.
Warning: Never look directly at the Sun with the naked eye or with a telescope
– unless you have a proper solar lter installed over the front of the telescope!
Otherwise, permanent, irreversible eye damage may result.
