IntelliScope®-to-PC
Interface Cable
#5222
The IntelliScope Object Locator can “talk” to a computer with the
addition of the IntelliScope-to-PC Interface Cable. The interface
cable allows use of the object locator with optional astronomy soft-
ware. The cable is also needed to download updates or changes
into the object locator’s internal memory.
Plug one end of the cable into the RS-232 jack in the top end of
the object locator. Plug the other end of the cable into the included
serial port adapter. Then connect the serial port adapter to the
serial port of your personal computer. If your computer has only
USB ports, then you will need to purchase a USB-to-serial adapter
from a local electronics or computer store.
Currently, the IntelliScope system is compatible with two commer-
cially available software programs, TheSky6 and Starry Night Pro.
Compatibility with TheSky6
TheSky6 astronomy software from Software Bisque is now fully
compatible with the IntelliScope Computerized Object Locator;
all commands and functions can now be performed through The
Sky6 software. This provides a larger and more graphical interface
for the IntelliScope system.
In addition to TheSky6 Software (Orion part #17154 for Serious
Edition, #17155 for Professional Edition) and the IntelliScope-to-
PC cable, you will need to download TheSky6 “Hot Fixes” found
on the following webpage:
http://www.bisque.com/hotfixes/
Download the files “TheSky6, all editions” and the help files
“TheSkyVersion6.chm” and “Telescope.chm”. Double click on
the downloaded TheSky6Update file, and the software will auto-
matically update itself. The help files must manually be placed
in TheSky6’s help folder (located in C:\Program Files\Software
Bisque\TheSky6\Help if you have chosen the default file locations
during installation).
Next, run TheSky6 software, and select “Contents and Index” from
the Help menu on the toolbar at the top of the screen. When the
TheSky6 Help page pops up, type in the word “IntelliScope” as the
search keyword, and select “IntelliScope (Orion Telescopes and
Binoculars)” from the displayed topics. Then follow the directions
on how to set up and use the software through the IntelliScope
Object Locator.
TheSky6 is one of the most advanced astronomy programs avail-
able and has many features, so be sure to carefully read the
manual that comes with the software. TheSky6 literally opens up
new worlds to explore with your IntelliScope!
Compatibility with Starry Night Pro
Version 5.0 of Starry Night Pro (Orion part #17171) from Space.
com is also fully compatible with the IntelliScope Object Locator.
It too allows performing all IntelliScope commands and functions
through the PC, and provides a larger and more graphical inter-
face for the IntelliScope system.
The details on how to set up and use the Starry Night Pro with
the object locator are included in the manual and/or help files that
come with the software.
IntelliScope Object Locator Updates
The interface cable is needed for downloading software updates
or changes into the object locator’s operating system. These
downloads are located on the IntelliScope support page at www.
telescope.com. Check the website for currently available down-
loads, and for the procedure for actual downloading.
Cable
Serial port adapter
IN 253 Rev B 02/09
