Orionstar Bluetooth Speaker
User Manual
Model A10 (Version 2.1)
Thank you for purchasing the Orionstar Bluetooth speaker. Please read this
manual carefully and keep it for future reference.
Features of the speaker:
1. New Bluetooth Technology supports wireless control through a Bluetooth device
2. Large Screen display of Time and date, Alarm, Temperature, Battery level and
Mode
3. Built-in FM radio with automatic channel searching
4. Plays MP3, WAV, WMA, APE, FLAC format audio files from a Micro SD card/TF
card and USB. Shuffle function when playing from a USB or Micro SD/TF card
5. 3.5mm line-in jack for wired devices
6. Built-in 5000mAh rechargeable battery
7. Two 52MM speaker drivers deliver 12W deep and rich sound
8. Built-in Microphone for phone Calls
9. Alarm setting for FM radio and Music from a USB/Micro SD card. Repeat alarm
and snooze function.

2
Operating Instructions:
1. Charging
Connect the Micro-USB connector of the charging cable to the DC5V input socket
at the rear side of the speaker, and plug the USB connector of the charging cable
to an external USB power supply socket with a minimum supply current of 1A
(recommended charge current is 2A). The external USB power supply can be the
USB socket in your computer/laptop, the USB adaptor of most cell phone USB
chargers with DC5V output, or the 5V USB port of a power socket etc. When
charging, the charge indicator on the charge port will be on and it will turn off when
charging is complete.
2. On/Off
Slide the On/Off switch at the rear side to turn on/off the speaker. The speaker will
enter Time Mode after turning on.
3. Bluetooth
Press the “ ” button to enter Bluetooth mode, press the “ ” button again
will exit to Time mode.
Paring –When the speaker is in Bluetooth mode, turn on your Bluetooth device
and search for Bluetooth equipment “A10”, and then pair up with the speaker.
Bluetooth phone call - When paired to your phone, press the “” button to
answer incoming calls, press “” again to end the call. Hold the “”button to
reject the call. Pressing the “ ” button twice will call the last incoming call
number.
Note: Microphone is on top of the speaker, please talk into the microphone
when making phone calls.
Track selection –When playing music in Bluetooth mode, press the
”button to jump to the previous track or next track. Track selection can also
be done from your Bluetooth device.

3
4.FM radio
Press the “ ” button to enter FM mode. Press the “ ” button again will exit
to Time mode.
FM Channel Search –When in FM mode, press and hold the “ ” button to
start automatic channel searching. The speaker will save the channels it finds
and automatically assign channel number.
Channel Selection –After channels have been saved, press the / button
tomovetothenextorpreviouschannel.
Delete Channel –Press and hold the “ ” button while the radio is playing the
channel you want to delete.
5.USB / Micro SD Card
The speaker supports a USB/Micro SD card. Just plug your USB Flash Drive or
Micro SD Card into the speaker’s USB port or Card slot and the speaker will play
the music files automatically.
Note: USB/Micro SD card is not supported when in FM mode. If the speaker is in
FM mode, press the “ ” or “ ” button to exit FM mode and insert the
USB/Micro SD card.
Shuffle –When playing music from a USB/Micro SD card, press and hold the
button to switch between shuffle and sequence playing. “-R-”on the screen
means Random play.
6.Setting the Time & Date
Press and hold the “ ” button and the month number will start flashing, press “+”
or “-“to adjust the month. Press “ ” again to confirm the month setting, and the
date number will start flashing. Press “+”or “-“to adjust the date, press “ ”
again to set, and then follow the same process to adjust the hour and minute.

4
Pressing “ ” in time mode will switch between 12H and 24H display format.
7.Alarm
1.) Alarm can only be set in Time mode, press “ ” button to enter Time mode
before setting alarm.
2.) Press and hold the button to start alarm setting:
- Press the “+”/”-“button to set the hour and press the button to confirm,
and then press the “+”/”-“button to set the minute and then press the button
to move to “repeat alarm”setting
- Press the “ ” button to turn on or off repeat alarm, when repeat alarm is on,
the repeat symbol will be displayed on the screen.
- press the button to confirm and move to alarm ring setting. Select from
the 3 default rings and press “ ” to confirm.
Note: In Time mode, press the button to turn the alarm on or off. When
the alarm is on, the alarm indicator will be displayed on the screen.
3) Setting Radio or music in USB/Micro SD as alarm: when the alarm is turned
on, play the radio station or music from a USB/Micro SD which you want to set
as the alarm, and press the button. The screen will display” -AL-”, and the
radio station or music playing will be set as the alarm ring. Please note that the
USB/Micro SD alarm ring setting will change to a default ring when the USB or
TF card is removed from the speaker.
4) The alarm will sound for 10 minutes, press any buttons except the “+”/ “-”to

5
turn off the alarm.
5) Snooze - When the alarm is ringing, press the”+”or “-“button and the alarm
will ring again after 5 minutes.
6) To set the alarm volume, press “ ”to go to time mode fist and then press
“+”or “-”button to set alarm volume.
8. Screen and display
1) Press the “ ” button to select from the 3 brightness level of the screen.
2) In time mode, press the “ ” button to switch between 12H and 24H time
display format.
3) Press the C/F button on the rear side of the speaker to switch the
temperature display between Degrees Celsius and Fahrenheit.
4) When speaker is switched to Bluetooth, FM radio, USB/Micro SD card or
AUX, the screen will display time after 10 seconds.
5) If battery is exhausted completely, the user setting will be cleared.
9. Reset –If the speaker is not working normally, insert a thin wire into the “R”
hole on the rear side to reset.
10. Technical Data
Power
Built-in high capacity Lithium Ion battery
External USB 5V supply
Power input: 1A~2A
Technical
Frequency
80HZ-18KHZ
FM radio
87.5-108MHz
SNR
≥85db (line out)
Sensitivity Rate
80db
THD
0.3% (line out)
Output power
6W*2

6
Speaker
Φ52mm 4Ω6w *2
Music format
MP3、WMA、WAV、APE、FLAC
Speaker size
230 x96x 68mm (9.1x3.1x2.7inch)
11. Trouble shooting:
⚫Can’t turn the speaker on:
Check if the battery is low. Charge the speaker and turn on again.
⚫Can’t charge the speaker:
Check the power supply is working and that the output of the power supply to the
charging cable is 5V and 1~2A.
Check that the charging cable and connectors of the cable are not damaged.
⚫Buttons not working
Reset the speaker by inserting a thin wire into the “R”hole on the rear side.
⚫No FM radio
Check if any electronic equipment is interfering with the signal.
Adjust the direction or position of the speaker or move to an open area for a
better signal reception.
12. Warning:
1. Do not use the product in high temperatures. Always keep the product away
from fire. For your own safety, never throw the product into a fire, as this may
cause an explosion and personal injury.
2. Do not use the product close to high-voltage wires or electronic equipment.
3. Keep the speaker away from water, and avoid using the speaker in
high-humidity environments.
4. Keep the speaker away from any strong magnetic fields.
5. Charge the speaker regularly to avoid damage of battery result from low battery
level. It’s recommended to charge the speaker from 5V 2A USB input.

7
13. Support:
If you have any questions or problems in using the speaker, please feel free to write
to: [e-mail]
