ORIUM 23660 User manual

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
PORTABLE INDOOR AIR QUALITY TESTER
User manual
Please read the instructions below carefully before use and keep this manual for future reference
The portable air quality tester (product reference 23660) has been designed for indoor use only.
The tester continuously measures the level of various pollutants and provides a practical, ever-ready,
alternative prevention solution to comply with national regulations (e.g., French decree 2015-1000 of
17th August, 2015: 2012-14) on the measurement of pollutants in the indoor air of public buildings and
venues.
Its primary purpose is to indicate air quality in enclosed atmospheres. The tester cannot be considered
a substitute for the indoor air quality monitoring methods described in your relevant legislation.
Technical features:
- Measures concentrations of airborne pollutant: formaldehyde (HCHO), particulates (PM1.0,
PM2.5, PM10), and total volatile organic compounds (TVOC) in a room and displays them on
the LCD display
- Measures and displays the room’s relative humidity and ambient temperature.
- Power supply: lithium battery 1200 mAh rechargeable via USB cable (included).
- Storage and carrying pouch.
Detection and
measurement range Formaldehyde (HCHO) level 0.001 to 1.999 mg/m³
Total volatile organic
compounds (TVOC) 0.001 to 9.999 mg/m³
PM1.0, PM2.5, PM10 levels 0 to 999 µg/m³.
Temperature –10°C to +50°C
Humidity 20% to 85% RH.
Accuracy Formaldehyde (HCHO). ± 20%
TVOC ± 20%
Particulates ± 15%
Temperature ± 1°C
Humidity ± 5%
Granularity: Formaldehyde (HCHO) 0.001 mg/m³
TVOC 0.001 mg/m³
Particulates 1 µg/m³
Temperature 1°C
Humidity 1% RH
Operating conditions: temperature –10°C to +45°C, humidity 20% to 85%, avoid condensation.
Storage conditions: temperature –10°C to 60°C, humidity 20% to 85%, avoid condensation.
Sensor technology: electrochemical for formaldehyde, semiconductor for TVOC, laser for particulates.

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
 Date, time, and battery charge level.
 Fine particle (PM2.5) level
 Formaldehyde (HCHO) level
 TVOC level
 Temperature and Humidity
 Colour coded rating.
 ON/OFF and settings button.
 UP button “+”
 DOWN button
 Return button
Set-up and Installation:
Unpack the device and make sure all the accessories are present, then follow these instructions.
Step 1: Charging the battery. Plug the micro-USB end of the charging cable into the micro-USB port
on the side of the device then connect the other end to the USB port of a power source (computer,
mains adapter, etc.).
The display lights up and the battery charge level bar shows charging progress (1). A red power-on
LED comes on at the top of the tester. Once the battery is completely charged, the charge level
indicator stops blinking and the power-on LED turns green. Disconnect the cable. The battery charge
life is 4 hours.
The device needs 200 seconds to warm up and adapt to the atmosphere. A countdown of this time in
seconds is shown on the TVOC display line (4). To recover from the effects of packaging and
shipping, the device must be placed outdoors in a dry, protected area for 30 minutes in order to clear
the sensors before first use.
Important: Do not make any adjustments during the warm-up period.
Unfold the stand and position the air quality tester in a convenient place in the room, office,
warehouse, etc. Choose a location where the sensor air vents on the front and back of the device are
completely unobstructed; this will ensure the device functions properly. Keep the device well away
from any direct source of pollution as well as any liquids, heat sources, flammable products, and
magnetic fields. The measurements made are shown on the display.
The tester makes a slight noise during use. This is normal and is caused by the sensor cooling fan.
The noise stops when the tester is turned off.
Important: if the screen becomes dim and/or the battery charge level bar (1) starts blinking,
it means the charge is running low. Recharge the battery fully.
To turn the tester on or off, press and hold in button (7).












Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
Step 2: Displaying the interfaces
While the screen is in the default display mode, press buttons (8) and (9) to step through the different
interfaces.
Step 3: Settings (SYSTEM SET)
Press button (7) → System Set is highlighted → press button (7) to confirm.
Press buttons (8) and (9) to step through the settings to reach the one you want to adjust → the
setting is highlighted → Press button (7) to open that setting for editing.
Adjust the value up or down with buttons (8) and (9) then press button (7) to confirm your choice.
Press button (10) to return to the previous list of selections.
Selection of temperature units (Temp Unit): Celsius (°C) or Fahrenheit (°F).
HCHO alarm (Alarm HTL): to set one of three alarm thresholds for the formaldehyde level
(0.100, 0.300, or 0.600 mg/m³).
Delete stored data readings (Clear Log): to delete the measured data points on the graphs
(select “Clean”).
Power saving mode (Off Time): to adjust the delay before the screen switches to standby
mode:
Never or after 30, 60, or 90 minutes.
If a set time is chosen, the tester switches off automatically if that amount of time
elapses without a button being pressed. Press button (7) to exit standby mode: the
countdown begins again.
Interface colours (Style): to set the background colour of certain specific displays.
Language: to select either English or Chinese as the display language.
Brightness: to adjust the screen’s backlight level.
Alarm (Buzzer Set): to activate (Open) / deactivate (Close) the HCHO threshold alarm.
Press button (10) to return to the previous list of selections → Press button (9) to select Time Set →
press button (7) to open that setting.
Clock and calendar adjustment (TIME SET):
Press button (7). Step through the items with buttons (8) and (9).
Y: for changing the highlighted year (with buttons (8) and (9)) → Press button (7) to confirm
and advance to the next setting
Interface 1
Default display
Interface 2 Interface 3 Interface 4

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
M: for changing the highlighted month → Press button (7) to confirm
D: for changing the day number → Press button (7) to confirm
H: for changing the hour (24-hour clock) → Press button (7) to confirm
Min: for changing the minutes → Press button (7) to confirm
Sec: to change the seconds → Press button (10) then either press button (7) to accept and
save these settings (OK) or press button (10) to cancel the changes and return to the previous
screen
Graphs display (HISTORY):
In the settings menu, press button (9) to select History (highlighted) → press button (7) to confirm.
The screen displays the last 10 readings for HCHO, PM2.5, temperature, and humidity measurements.
Select a pollutant (HCHO, PM2.5) or the temperature or humidity readings with buttons (8) and (9).
The relevant pollutant is highlighted and the corresponding graph displayed. With this graph you can
visualize the trend of the automatically measured readings. The tester lets you display ten readings
every ten minutes. The maximum observed value of the pollutant is shown at the top of the screen.
Important: Readings can only take place when the air quality tester is switched on. If no readings are
displayed, make sure the (Clear Log) option is not activated (Clean).
Step 4: Measurements and comfort ratings
1. Particulates are airborne particles resulting from wood burning, farming activities, general
dust, etc.
Three sizes of “particulate matter” (PM) are defined: PM1.0, PM2.5, and PM10, representing particle
diameters of less than 1µm, 2.5μm, and 10µm respectively. PM2.5—“fine particles”—are the most
common in indoor air.
The measured level of PM2.5 fine particles is displayed by default on line (2) of the interface.
Colour band
Range of PM2.5 values
Rating
Green 0–75 µg/m³ Good
Yellow 76–300 µg/m³ Modest
Red 301–999 µg/m³ Bad (danger)
Important: Different counties stipulate different legal or recommended thresholds for fine particles.
These thresholds focus mainly on PM2.5. The World Health Organization has defined exposure
thresholds for PM2.5 and PM10 particulates, but PM1.0 is generally overlooked when it comes to
exposure thresholds and guide values. Nonetheless, PM1.0 is the most harmful category of the three,
their extreme smallness allowing them to penetrate the human anatomy. That’s why the Quaelis
indoor air quality tester includes this category in its measurements, especially for the more sensitive
among us. We therefore recommend that PM1.0 measurements be monitored to ensure they remain
lower than those of PM2.5.

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
2. Formaldehyde is a polluting gas with multiple sources (construction materials, furniture, glues,
cleaning products, etc.).
The measured formaldehyde level is displayed by default on line (3) of the interface.
Colour
code
HCHO level Rating RECOMMENDATIONS
Green 0–0.100 mg/m³ Good Continue airing the room regularly to renew the
air.
Yellow 0.101–0.500 mg/m³ Modest Ventilate the room.
Leave the room
Limit heating during winter
Red 0.501–1.999 mg/m³ Bad
(danger)
Indoor air quality guide
values (French)
Exposure
threshold Short-term actions recommended
0,03 mg/m³ for a long
exposure period (1)
100 µg/m³ =
0.10 mg/m³
for a 30-minute
exposure period (2)
Move away from the source of pollution.
Leave the room.
Ventilate.
(1) Guide values for Formaldehyde and Benzene based on French decree No. 2015-1000 of the 17 August 2015: 2012-14
Long exposure throughout the year.
Exposure
threshold
Short-term actions
recommended Long-term actions recommended
PM2.5
25 µg/m³ (1)
average
exposure in a 24-
hour period
10 µg/m³ (1)
average year-
round exposure
Continue airing the
room (unless the
outdoor air is
experiencing a fine-
particle pollution
peak).
Limit heating during
winter.
Wear a mask.
Install a permanent ventilation system.
Keep some ambient air detoxifying plants (azalea,
ficus, palm): 1 plant per 10m² of room area.
Identify and reduce all sources of possible pollution
(moulds, allergens, mites, etc.).
Regularly remove dust from floors and furniture with
a vacuum cleaner.
PM10
50 µg/m³ (2)
average
exposure in a 24-
hour period
20 µg/m³ (2)
average year-
round exposure

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
Source: Indoor air quality monitoring in places frequented by children, published by the French ministry of environment,
energy, and the sea, 2016. Practical guide to improving air quality in places frequented by children, published by the
French ministry of ecology and solidarity changes, 2017.
(2) Source: Update of guide values for indoor air quality, Anses, February 2018.
Source: Benchmark values for the management of airborne particles in enclosed spaces: published by French Public
Health Commission, 2013.
3. The cumulative total of various volatile organic compounds (TVOC) is shown on line (4). This
measurement corresponds to the total detected values of multiple pollutants.
Volatile organic compounds, including benzene, are pollutants derived from hydrocarbons, solvents,
exhaust fumes, etc.
Colour
code
TVOC Rating RECOMMENDATIONS
Green 0–0.600 mg/m³ Good Continue airing the room regularly to renew the
air.
Yellow 0.601–1.000 mg/m³ Modest Air the room; leave the room for now.
Limit heating during winter.
Red 1.001–5.0 mg/m³ Bad
(danger)
Air the room and leave it.
Install a permanent ventilation system.
Identify and reduce all sources of possible
pollution (furniture, ceiling, floor and wall
coverings, home improvement work, painting,
etc.).
The values detected by the tester at a given moment can often be higher than the exposure threshold.
That’s why each threshold is coupled to a specific exposure time. If the measured values regularly
exceed these limits, a professional diagnosis is advisable to identify the source of the pollutants.
The AQI (Air Quality Index) uses coloured bands for easy interpretation of the air quality:
Green: 0-75 The air quality is good (Good)
Yellow: 76-150 The air quality is tolerable (Slight)
Red: 151-300 The air quality is poor (Moderate)
Purple: 301-500 The air quality is critical (Serious).
Reminder:
Pollutant-related risks vary with exposure levels (mild to extreme).
Formaldehyde: Tiredness, headaches, sleeplessness, skin and eye irritation, allergies, eczema,
breathing difficulties, etc.
Fine particles PM2.5: Breathing discomfort, nasal and bronchial irritation, other signs of irritation, etc.
That’s why it’s important to measure indoor airborne concentrations, which are important criteria when
drawing up room air-change regulations.
Important: the short-term actions above are intended only as a guide. They cannot be considered a
substitute for legislative or regulatory provisions or any other obligation that may exist. More specific
actions may need implementing. The values detected by the tester at a given moment can often be
higher than the exposure threshold. That’s why each threshold is coupled to a specific exposure time.
If the measured values regularly exceed these limits, a professional diagnosis is advisable to identify
the source of the pollutants. In the case of public buildings and venues, seek expert advice from the
relevant authorities, e.g., Regional Health Board or equivalent, Regional Environmental Office, etc.

Imported by
AIC International, 44980 Ste-Luce-sur-Loire, France
Power saving mode.
The portable tester features a power saving mode: the backlight switches to screen-saver mode after
15 minutes go by without a button being pressed (the values remain on display). Press any button to
revert to full display mode.
The tester shuts down automatically if two hours go by without a button being pressed. Press any
button to exit standby mode: the three-minute countdown begins again.
Important: If the values displayed on the screen seem stuck or if the tester has not been used for
quite some time, take the tester outdoors and leave it in a dry, protected place for 30 minutes to clear
the sensors.
Conditions of use and safety considerations:
Use the indoor air quality tester only for its intended purpose.
Do not alter the structure of the product or repair it yourself.
Use only the cables and connectors supplied with the product.
The manufacturer cannot be held liable for damages arising from improper use or maintenance of the
product.
Keep the appliance out of children’s reach.
Troubleshooting guide:
Fault symptoms Checks/solutions
The tester does not turn on.
Make sure the battery is charged.
Make sure the charger is properly connected.
Make sure the USB port of the power source
(computer, mains adapter, etc.) is receiving current.
Check whether the mains outlet socket has an on/off
switch. If so, switch it on.
Press and hold in button (7) until the screen comes
on.
The alarm doesn’t go off.
Make sure the alarm has not been cancelled.
The visual alarm is set only for formaldehyde (HCHO)
and goes off when the user-set threshold is
exceeded.
The stored readings interface does not show
any measurements.
The screen should display the last ten readings of
HCHO, PM2.5, temperature, and humidity
measurements.
Make sure this option has not been disabled.
The tester display keeps switching off.
The tester has a power saving mode.
Press any button to exit power saving mode.
Disable power saving mode in the settings (“Never”).
Two settings affect battery charge life: the screen
backlight level and the power saver delay.
