Fluke 5080A User manual

July 2012
© 2012 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
5080A
Calibrator
Operators Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment.
Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the
original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses,
disposable batteries, or to any product which, in Fluke's opinion, has been misused, altered,
neglected, contaminated, or damaged by accident or abnormal conditions of operation or
handling. Fluke warrants that software will operate substantially in accordance with its functional
specifications for 90 days and that it has been properly recorded on non-defective media. Fluke
does not warrant that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user
customers only but have no authority to extend a greater or different warranty on behalf of Fluke.
Warranty support is available only if product is purchased through a Fluke authorized sales outlet
or Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for
importation costs of repair/replacement parts when product purchased in one country is submitted
for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of
charge repair, or replacement of a defective product which is returned to a Fluke authorized
service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return
authorization information, then send the product to that service center, with a description of the
difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in
transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid
(FOB Destination). If Fluke determines that failure was caused by neglect, misuse, contamination,
alteration, accident, or abnormal condition of operation or handling, including overvoltage failures
caused by use outside the product’s specified rating, or normal wear and tear of mechanical
components, Fluke will provide an estimate of repair costs and obtain authorization before
commencing the work. Following repair, the product will be returned to the Buyer transportation
prepaid and the Buyer will be billed for the repair and return transportation charges (FOB
Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM
ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or
exclusion or limitation of incidental or consequential damages, the limitations and exclusions of
this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or
unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not
affect the validity or enforceability of any other provision.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99

OPERATOR SAFETY
SUMMARY
WARNING

HIGH VOLTAGE
is used in the operation of this equipment
LETHAL VOLTAGE
may be present on the terminals, observe all safety precautions!
To avoid electrical shock hazard, the operator should not electrically contact
the output HI or sense HI terminals or circuits connected to these terminals.
During operation, lethal voltages of up to 1020 V ac or dc may be present on
these terminals.
Whenever the nature of the operation permits, keep one hand away from
equipment to reduce the hazard of current flowing through vital organs of
the body.

i
Table of Contents
Chapter Title Page
1 Introduction and Specifications......................................................... 1-1
Introduction........................................................................................................ 1-3
Safety Information............................................................................................. 1-3
Operation Overview........................................................................................... 1-5
Where to Go from Here ..................................................................................... 1-5
Instruction Manuals ........................................................................................... 1-6
5080A Operators Manual .............................................................................. 1-6
5080A Getting Started Manual...................................................................... 1-6
How to Contact Fluke........................................................................................ 1-6
General Specifications....................................................................................... 1-7
Detailed Specifications ...................................................................................... 1-8
DC Voltage.................................................................................................... 1-8
DC Current .................................................................................................... 1-8
Resistance...................................................................................................... 1-9
AC Voltage (Sine Wave)............................................................................... 1-10
AC Current (Sine Wave) ............................................................................... 1-11
DC Power Summary...................................................................................... 1-12
AC Power Summary...................................................................................... 1-12
Power and Dual Output Limits...................................................................... 1-12
Phase.............................................................................................................. 1-13
Calculating Power Specifications.................................................................. 1-13
Frequency...................................................................................................... 1-14
2 Operation Preparation ........................................................................ 2-1
Introduction........................................................................................................ 2-3
Unpacking and Inspection.................................................................................. 2-3
Replacing the Fuse............................................................................................. 2-3
Selecting Line Voltage....................................................................................... 2-4
Connecting to Line Power ................................................................................. 2-4
Selecting Line Frequency .................................................................................. 2-4
Service Information ........................................................................................... 2-6
Cooling Considerations...................................................................................... 2-7
Accessories and Options.................................................................................... 2-8
Rack Mount Considerations............................................................................... 2-8

5080A
Operators Manual
ii
3 Features ............................................................................................... 3-1
Introduction........................................................................................................ 3-3
Front-Panel Features.......................................................................................... 3-3
Rear-Panel Features........................................................................................... 3-3
Softkey Menu Trees........................................................................................... 3-3
4 Front-Panel Operations....................................................................... 4-1
Introduction........................................................................................................ 4-3
Turning on the Calibrator................................................................................... 4-3
Warming up the Calibrator ................................................................................ 4-4
Using the Softkeys............................................................................................. 4-4
Using the Setup Menu........................................................................................ 4-4
Using the Instrument Setup Menu................................................................. 4-5
Utility Functions Menu.................................................................................. 4-5
Using the Format NV Memory Menu ........................................................... 4-6
Resetting the Calibrator ..................................................................................... 4-6
Zeroing the Calibrator........................................................................................ 4-6
Using the Operate and Standby Modes.............................................................. 4-7
Connecting the Calibrator to a UUT.................................................................. 4-8
Recommended Cable and Connector Types.................................................. 4-8
When to Use EARTH.................................................................................... 4-9
Four-Wire versus Two-Wire Connections .................................................... 4-9
Cable Connection Instructions....................................................................... 4-10
Auto Range Versus Locked Range.................................................................... 4-12
Setting the Output.............................................................................................. 4-13
Setting DC Voltage Output ........................................................................... 4-13
Setting AC Voltage Output ........................................................................... 4-14
Setting DC Current Output............................................................................ 4-16
Setting AC Current Output............................................................................ 4-17
Setting DC Power Output.............................................................................. 4-18
Setting AC Power Output.............................................................................. 4-20
Setting a Dual DC Voltage Output................................................................ 4-22
Setting a Dual AC Voltage Output................................................................ 4-24
Setting Resistance Output.............................................................................. 4-27
Sine Wave Output.............................................................................................. 4-28
Adjusting the Phase ........................................................................................... 4-29
Entering a Phase Angle ................................................................................. 4-30
Entering a Power Factor................................................................................ 4-31
Editing and Error Output Settings...................................................................... 4-31
Editing the Output Setting............................................................................. 4-32
Displaying the UUT Error: AC and DC Voltage and Current Output........... 4-32
Displaying the UUT Error: Resistance Output.............................................. 4-33
Using Multiply and Divide............................................................................ 4-33
Setting Voltage and Current Limits................................................................... 4-33
5 Remote Operations ............................................................................. 5-1
Introduction........................................................................................................ 5-3
Setting up the RS-232 Host Port for Remote Control........................................ 5-4
Configuring the Ethernet (LAN) Port................................................................ 5-5
Setting the IP Address ................................................................................... 5-6
Selecting Dynamic Host Configuration Protocol (DHCP)........................ 5-6
Setting a Static Internet Address............................................................... 5-7
Setting the LAN Subnet Mask....................................................................... 5-7
Reading the Domain Name ........................................................................... 5-7

Contents (continued)
iii
Configuring the Host Name........................................................................... 5-7
Reading the MAC Address............................................................................ 5-8
Configuring the LAN Default Gateway ........................................................ 5-8
Configuring the General Network Socket Port.............................................. 5-8
Establishing an Ethernet Connection................................................................. 5-9
Terminating an Ethernet Connection................................................................. 5-9
Changing Between Remote and Local Operation.............................................. 5-10
Local State..................................................................................................... 5-10
Local and Lockout State................................................................................ 5-10
Remote State.................................................................................................. 5-10
Remote with Lockout State ........................................................................... 5-10
RS-232 Interface Overview ............................................................................... 5-11
Using Commands............................................................................................... 5-11
Types of Commands...................................................................................... 5-11
Device-Dependent Commands.................................................................. 5-11
Common Commands................................................................................. 5-12
Query Commands...................................................................................... 5-12
Compound Commands.............................................................................. 5-12
Coupled Commands.................................................................................. 5-12
Overlapped Commands............................................................................. 5-12
Sequential Commands............................................................................... 5-13
Commands that Require the Calibration Switch....................................... 5-13
Command Syntax .......................................................................................... 5-13
Parameter Syntax Rules ............................................................................ 5-13
Extra Space or Tab Characters.................................................................. 5-15
Terminators............................................................................................... 5-15
Incoming Character Processing................................................................. 5-15
Response Message Syntax ........................................................................ 5-15
Checking 5080A Status ..................................................................................... 5-17
Serial Poll Status Byte (STB)........................................................................ 5-17
Master Summary Status ............................................................................ 5-19
Service Request Enable Register (SRE).................................................... 5-19
Programming the STB and SRE................................................................ 5-19
Event Status Register (ESR) ..................................................................... 5-19
Event Status Enable (ESE) Register.......................................................... 5-19
Bit Assignments for the ESR and ESE...................................................... 5-20
Programming the ESR and ESE................................................................ 5-20
Instrument Status Register (ISR)................................................................... 5-20
Instrument Status Change Registers.......................................................... 5-20
Instrument Status Change Enable Registers.............................................. 5-21
Bit Assignments for the ISR, ISCR, and ISCE ......................................... 5-21
Programming the ISR, ISCR, and ISCE ................................................... 5-22
Output Queue................................................................................................. 5-22
Error Queue ................................................................................................... 5-22
Input Buffer Operation .................................................................................. 5-22
6 Remote Commands............................................................................. 6-1
Introduction........................................................................................................ 6-3
Command Summary by Function ...................................................................... 6-3
Command Details .............................................................................................. 6-7
7 Maintenance......................................................................................... 7-1
Introduction........................................................................................................ 7-3
How to Replace the Line Fuse........................................................................... 7-3

5080A
Operators Manual
iv
How to Replace the Current Fuses..................................................................... 7-5
How to Clean the Air Filter ............................................................................... 7-7
General Cleaning ............................................................................................... 7-8
Performance Tests.............................................................................................. 7-9
Appendices
A Glossary....................................................................................................... A-1
B RS-232 Cabling and Connector................................................................... B-1
C Error Messages............................................................................................ C-1

v
List of Tables
Table Title Page
1-1. Symbols.................................................................................................................. 1-4
2-1. Standard Equipment............................................................................................... 2-3
2-2. Line Power Cord Types Available from Fluke ...................................................... 2-6
2-3. Accessories and Options ........................................................................................ 2-8
3-1. Front-Panel Features .............................................................................................. 3-4
3-2. Rear-Panel Features ............................................................................................... 3-9
3-3. Factory Defaults for SETUP Menus Power-Up Defaults ...................................... 3-20
4-1. UUT connections ................................................................................................... 4-10
4-2. Standard Calibrator Resistances............................................................................. 4-27
4-3. Keys That Exit Error Mode.................................................................................... 4-32
5-1. Operating State Transitions.................................................................................... 5-11
5-2. Units Accepted in Parameters and Used in Responses .......................................... 5-14
5-3. Terminator Characters............................................................................................ 5-15
5-4. Response Data Types............................................................................................. 5-16
5-5. Status Register Summary ....................................................................................... 5-17
6-1. Common Command Summary............................................................................... 6-3
6-2. Error Mode Command Summary........................................................................... 6-4
6-3. External Connection Command Summary............................................................. 6-4
6-4. Output Command Summary................................................................................... 6-4
6-5. RS-232 Host Port Command Summary ................................................................. 6-5
6-6. Setup and Utility Command Summary .................................................................. 6-6
6-7. Status Command Summary.................................................................................... 6-7
6-8. Overlapped and Coupled Commands..................................................................... 6-8
6-9. Default Setup Values.............................................................................................. 6-13
7-1. Replacement Fuses................................................................................................. 7-3
7-2. Current Fuses ......................................................................................................... 7-6
7-3. Verification Tests for DC Voltage (Normal) ......................................................... 7-9
7-4. Verification Tests for DC Voltage (AUX)............................................................. 7-10
7-5. Verification Tests for DC Current.......................................................................... 7-10
7-6. Verification Tests for 2-Wire Resistance............................................................... 7-11
7-7. Verification Tests for 4-Wire Resistance............................................................... 7-11
7-8. Verification Tests for AC Voltage (Normal) ......................................................... 7-12
7-9. Verification Tests for AC Current.......................................................................... 7-13
7-10. Verification Tests for Phase................................................................................... 7-14
7-11. Verification Tests for Distortion ............................................................................ 7-15

5080A
Operators Manual
vi
7-12. Verification Tests for Frequency............................................................................ 7-15

vii
List of Figures
Figure Title Page
2-1. Fuse Access and Line Voltage Selection ............................................................... 2-5
2-2. Line Power Cord Types Available from Fluke ...................................................... 2-6
3-1. Front-Panel View ................................................................................................... 3-4
3-2. Rear-Panel View .................................................................................................... 3-9
3-3. SETUP Softkey Menu Tree.................................................................................... 3-11
4-1. UUT Connection: Resistance (4-Wire Compensation).......................................... 4-10
4-2. UUT Connection: Resistance (2-Wire Compensation).......................................... 4-11
4-3. UUT Connection: Resistance (Compensation Off)................................................ 4-11
4-4. UUT Connection: DC Voltage/AC Voltage........................................................... 4-12
4-5. UUT Connection: DC Current/AC Current ........................................................... 4-12
4-6. Sine Wave .............................................................................................................. 4-29
5-1. Typical RS-232 Remote Control Connections....................................................... 5-3
5-2. Menus to Set LAN Parameters............................................................................... 5-6
5-3. Status Register Overview....................................................................................... 5-18
5-4. Serial Poll Status Byte (STB) and Service Request Enable (SRE) ........................ 5-19
5-5. Event Status Register (ESR) and Event Status Enable (ESE)................................ 5-20
5-6. Bit Assignments for the ISR, ISCEs, and ISCRs ................................................... 5-21
7-1. Accessing the Fuse................................................................................................. 7-4
7-2. Current Fuse Compartment.................................................................................... 7-6
7-3. Accessing the Air Filter.......................................................................................... 7-8

5080A
Operators Manual
viii

1-1
Chapter 1
Introduction and Specifications
Title Page
Introduction.......................................................................................................... 1-3
Safety Information............................................................................................... 1-3
Operation Overview............................................................................................. 1-5
Where to Go from Here ....................................................................................... 1-5
Instruction Manuals ............................................................................................. 1-6
5080A Operators Manual ................................................................................ 1-6
5080A Getting Started Manual........................................................................ 1-6
How to Contact Fluke.......................................................................................... 1-6
General Specifications......................................................................................... 1-7
Detailed Specifications ........................................................................................ 1-8
DC Voltage...................................................................................................... 1-8
DC Current ...................................................................................................... 1-8
Resistance........................................................................................................ 1-9
AC Voltage (Sine Wave)................................................................................. 1-10
AC Current (Sine Wave) ................................................................................. 1-11
DC Power Summary........................................................................................ 1-12
AC Power Summary........................................................................................ 1-12
Power and Dual Output Limits........................................................................ 1-12
Phase................................................................................................................ 1-13
Calculating Power Specifications.................................................................... 1-13
Frequency........................................................................................................ 1-14

5080A
Operators Manual
1-2

Introduction and Specifications
Introduction 1
1-3
Introduction
 Warning
If the 5080A Calibrator is operated in any way not specified by
this manual or other documentation provided by Fluke, the
protection provided by the Calibrator may be impaired.
The 5080A Calibrator is a fully programmable precision source of the following:
•DC voltage from 0 V to ±1020 V.
•AC voltage from 1 mV to 1020 V, with output from 45 Hz to 1 kHz.
•AC current from 29 μA to 20.5 A, with variable frequency limits.
•DC current from 0 to ±20.5 A.
•Discrete resistance values from a short circuit to 190 MΩ.
Features of the 5080A Calibrator include the following:
•Automatic meter error calculation.
•and keys that change the output value to pre-determined cardinal values for
various functions.
•Programmable entry limits that prevent entering invalid amounts.
•Simultaneous output of voltage and current, up to an equivalent of 20.9 kVA.
•Simultaneous output of two voltages.
•Variable phase signal output.
•EIA Standard RS-232 serial data interface for printing, displaying, or transferring
internally stored calibration constants, and for remote control of the 5080A.
Safety Information
This Calibrator complies with:
•ANSI/ISA-61010-1 (82.02.01)
•CAN/CSA C22.2 No. 61010-1-04
•ANSI/UL 61010-1:2004
•EN 61010-1:2001
In this manual, a Warning identifies conditions and actions that pose a hazard to the
user. A Caution identifies conditions and actions that may damage the Calibrator or the
equipment under test.

5080A
Operators Manual
1-4
Symbols used on the Calibrator and in this manual are explained in Table 1-1.
Table 1-1. Symbols
Symbol Description Symbol Description
AC (Alternating Current) Earth Ground
Important Information: refer to manual Shock Hazard
Complies with EU directives Complies with relevant North
American Safety Standards.
CAT I
IEC Measurement Category I – CAT I
is for measurements not directly
connected to mains. Maximum
transient Overvoltage is as specified by
terminal markings.

Do not dispose of this product as
unsorted municipal waste. Go to
Fluke’s website for recycling
information.
This manual contains information, warnings, and cautions that must be followed to
ensure safe operation and to maintain the Calibrator in a safe condition.
 Warning
To avoid possible electric shock or personal injury, follow these
guidelines:
•Use this Calibrator only as specified in this manual or the
protection provided by the Calibrator might be impaired.
•Do not apply more than 264 V ac rms between the supply
conductors or between either supply conductor and ground.
•Use caution when working with voltages above 30 V ac rms,
42 V peak, or 60 V dc. These voltages pose a shock hazard.
•Ensure the Calibrator is in STANDBY by pressing the RESET
key before disconnecting test leads.
•Ensure the grounding conductor in the power cord is
properly connected to a protective ground. The output
terminals are clamped to the earth referenced chassis and
rely on the protective earth bond to limit accessible voltage
to the operator. Any disruption of the protective earth could
place lethal voltage onto the chassis of the Calibrator due to
abnormal output terminal configuration or mains transient
condition.
•Use only the replacement fuses specified by the manual.
•Do not position the Calibrator such that the power cord
cannot be accessed in the event of an emergency. In the
event that customer installation interferes with access to the
power cord, a suitable power disconnection switch shall be
provided by the customer.
•Use only the power cord and connector appropriate for the
voltage and plug configuration in your country.

Introduction and Specifications
Operation Overview 1
1-5
•Use only a power cord that is in good condition. Refer
power cord and connector changes to qualified service
personnel.
•Do not operate the Calibrator in an atmosphere of explosive
gases.
•Verify the voltage applied to the unit under test does not
exceed the insulation rating of the UUT and the
interconnecting cables.
•Do not remove the Calibrator cover without first
disconnecting the power cord.
•Do not operate the Calibrator without the cover properly
installed. Access procedures and the warnings for such
procedures are contained in the Service Manual. Service
procedures are for qualified service personnel only.
•Do not use the Calibrator if it appears damaged or operates
abnormally. Refer all questions of proper Calibrator
operation to qualified service personnel.
Caution
To avoid damage to the Calibrator, do not apply voltage in
excess of the marked rating to any terminal.
Operation Overview
The 5080A Calibrator may be operated at the front panel in the local mode, or remotely
using RS-232 or Ethernet ports. For remote operations, several software options are
available to integrate 5080A operation into a wide variety of calibration requirements.
Typical local operations include front panel connections to the Unit Under Test (UUT),
and then manual keystroke entries at the front panel to place the Calibrator in the desired
output mode. The front panel layout facilitates hand movements from left to right, and
multiply and divide keys make it easy to step up or down at the press of a single key. You
can also review 5080A Calibrator specifications at the push of two buttons. The backlit
liquid crystal display is easy to read from many different viewing angles and in different
lighting conditions, and the large, easy-to-read keys are color-coded and provide tactile
feedback.
Where to Go from Here
To locate specific information concerning the installation and operation of the 5080A
Calibrator, refer to the following list:
•Unpacking and setup: Chapter 2, “Preparing for Operation”
•AC line power and interface cabling: Chapter 2, “Preparing for Operation”
•Controls, indicators, and displays: Chapter 3, “Features”
•Front-panel operation: Chapter 4, “Front-Panel Operation”
•Cabling to a UUT (Unit Under Test): Chapter 4, “Front-Panel Operation”
•Remote operation (Ethernet or serial): Chapter 5, “Remote Operation”
•Performance Specifications: Chapter 1, “Introduction and Specifications”

5080A
Operators Manual
1-6
Instruction Manuals
The 5080A Manual Set provides complete information for operators and service or
maintenance technicians. The set includes:
•5080A Operators Manual (provided on CD-ROM)
•5080A Getting Started Manual (PN 3502934)
•5080A Service Manual (PN 3790039)
The Operators and Getting Started manuals listed above are shipped with the Calibrator.
For ordering instructions, refer to the Fluke Catalog, or ask a Fluke sales representative
(see “Service Information” in Chapter 2).
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
5080A Operators Manual
This 5080A Operators Manual provides complete information on installing the 5080A
Calibrator and operating it from the front-panel keys and in remote configurations. This
manual also provides a glossary of calibration, specifications, and error code information.
The Operators Manual includes the following topics:
•Installation
•Operating controls and features, including front-panel operation
•Remote operation (Ethernet or serial port remote control)
•Serial port operation (printing, displaying, or transferring data, and setting up for
serial port remote control)
•Operator maintenance, including verification procedures and calibration approach for
the 5080A
•Accessories and Options
5080A Getting Started Manual
The 5080A Getting Started Manual contains a brief introduction to the 5080A Manual
Set, instructions on how to get your Calibrator prepared for operation and a complete set
of specifications.
How to Contact Fluke
To order accessories, receive operating assistance, or get the location of the nearest Fluke
distributor or Service Center, call:
•Technical Support USA: 1-800-99-FLUKE (1-800-993-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: [phone]
•China: [phone]
•Japan: [phone]
•Singapore: [phone]
•Anywhere in the world: [phone]
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.

Introduction and Specifications
General Specifications 1
1-7
General Specifications
All specifications are valid after a warm-up period of 30 minutes, or twice the time since last warmed up, to a maximum of
30 minutes. For example, if the 5080A has been turned off for 5 minutes, the warm-up period is 10 minutes.
All specifications apply for the temperature and time period indicated. For temperatures outside of tcal ±5 °C (tcal is the
ambient temperature when the 5080A was calibrated), the temperature coefficient as stated in the General Specifications
must be applied.
The specifications also assume the 5080A is zeroed every seven days or whenever the ambient temperature changes by
more than 5 °C.
Warmup Time ......................................................... Twice the time since last warmed up, to a maximum of 30 minutes.
Settling Time........................................................... Less than 7 seconds for all functions and ranges except as noted.
Standard Interfaces................................................. RS-232 and Ethernet
Temperature
Operating ............................................................ 0 °C to 50 °C
Calibration (tcal).................................................. 15 °C to 35 °C
Storage ............................................................... -20 °C to +70 °C
Temperature Coefficient ......................................... Temperature coefficient for temperatures outside tcal ±5 °C is 10 % of
the stated specification per °C for temperatures in the range of 0 °C to
35 °C. Above 35 °C, the temperature coefficient is 20 % of the stated
specification per °C.
Relative Humidity
Operating............................................................ <80 % to 30 °C, <70 % to 40 °C, <40 % to 50 °C.
Storage ............................................................... <95 %, non-condensing
Altitude
Operating............................................................ 2,000 m (6,500 ft) maximum
Non-operating ..................................................... 12,200 m (40,000 ft) maximum
Safety...................................................................... Meets EN 61010-1:2001, CAN/CSA-C22.2 No. 61010-1-04, UL 61010-
1:2004 Insulation Class I (bonded enclosure) Pollution Degree 2 Indoor
use only.
Analog Low Isolation............................................... 20 V
EMC........................................................................ Meets EN 61326-1:2006.
Line Power
Line Voltage (selectable) .................................... 100 V, 120 V, 220 V, 240 V
Line Frequency ................................................... 47 to 63 Hz
Line Voltage Variation.........................................±10 % about line voltage setting
Power Consumption................................................ 600 VA
Dimensions
Height.................................................................. 19.3 cm (7.6 in)
Width................................................................... 43.2 cm (17 in), 44.3 cm (17.5 in) including handles
Depth .................................................................. 53.8 cm (21.2 in)
Weight..................................................................... 22 kg (48 lb)
Specification Definition............................................ The specifications include stability, temperature coefficient, linearity,
line and load regulation, and the traceability of the external standards
used for calibration. It is not necessary to add anything to determine
the total specification for the temperature range indicated.
Specification Confidence Level............................... 99 %

5080A
Operators Manual
1-8
Detailed Specifications
DC Voltage
Range
Specification, tcal ±5 °C ±(% of output
+ μV) Stability
Resolution (μV) Max Burden [1]
90 days 1 year 24 hours, ±1 °C ±(%
of output + μV)
0 to 329.999 mV 0.011 % + 10 0.013 % + 10 0.0035 % + 6 1 60 Ω
0 to 3.29999 V 0.008 % + 15 0.010 % + 15 0.0025 % + 10 10 300 mA
0 to 32.9999 V 0.008 % + 150 0.010 % + 150 0.0025 % + 100 100 600 mA
10 to 101.999 V 0.010 % + 1500 0.012 % + 1500 0.003 % + 1000 1000 300 mA
30 to 329.999 V 0.010 % + 1500 0.012 % + 1500 0.003 % + 1000 1000 120 mA
100 to 1020.00 V 0.010 % + 5500 0.012 % + 5500 0.003 % + 5000 10000 40 mA
Auxiliary Output (dual output mode only)
0 to 329.99 mV 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 10 5 mA
0.33 to 3.2999 V 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 100 5 mA
3.3 to 7.000 V 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 1000 5 mA
[1] Remote sensing is not provided. Output resistance is 60 Ωfor outputs <330 mV. Output resistance is <5 mΩfor outputs ≥0.33 V.
The AUX output has an output resistance of <1 Ω.
Range Noise
Bandwidth 0.1 Hz to 10 Hz, p-p ±(ppm
of output + floor) Bandwidth 10 Hz to 10 kHz, rms ±( floor)
0 to 329.999 mV 0 + 3 μV 20 μV
0 to 3.29999 V 0 + 30 μV 200 μV
0 to 32.9999 V 0 + 300 μV 2 mV
10 to 101.999 V 30 + 5 mV 60 mV
30 to 329.999 V 30 + 5 mV 60 mV
100 to 1020.00 V 30 + 20 mV 100 mV
Auxiliary Output (dual output mode only)
0 to 329.99 mV 0 + 20 μV 60 μV
0.33 to 3.2999 V 0 + 200 μV 600 μV
3.3 to 7.000 V 0 + 2 mV 3 mV
DC Current
Range Specification, tcal ±5 °C ±(% of output
+ μA) Resolution Max. Compliance
Voltage (V) Max. Inductive Load
90 days 1 year
0 to 329.99 μA 0.07 % + 0.1 0.075 % + 0.1 10 nA 9
2.5 H
0 to 3.2999 mA 0.06 % + 0.25 0.065 % + 0.25 0.1 μA 9
0 to 32.999 mA 0.048 % + 1.25 0.05 % + 1.25 1 μA 50
0 to 329.99 mA 0.048 % + 16.5 0.05 % + 16.5 10 μA 35
0 to1.0999 A
(in 3 A range) 0.14 % + 220 0.15 % + 220 100 μA 6
1.1 to 2.9999 A 0.18 % + 220 0.19 % + 220 100 μA 6
0 to 10.999 A
(in 20 A range) 0.23 % + 2500 0.25 % + 2500 1 mA 4
11 to 20.500 A [1] 0.48 % + 3750 0.5 % + 3750 1 mA 4
[1] Duty Cycle: Currents <11 A may be provided continuously. For currents >11 A, the current may be provided 60-T-I minutes in any
60 minute period where T is the temperature in °C (room temperature is about 23 °C) and I is the output current in Amps. For
example, 17 A at 23 °C could be provided for 60-17-23 = 20 minutes each hour. When the 5080A is outputting currents between 5
and 11 amps for long periods, the internal self-heating reduces the duty cycle. Under those conditions, the allowable “on” time
indicated by the formula is achieved only after the 5080A is outputting currents <5 A for the “off” period first.
