AEMC MN213 User manual

99-MAN 100138.v8 01/16
OPERATION
Please make sure that you have already read and fully understand the WARNING section on page 1.
Making Measurements with the AC Current Probe Model MN213
• Connect the black lead of the current probe to “common” and the red lead to the AC current input on
your DMM or other current measuring instrument. Select the appropriate current range (400mAAC
range). Clamp the probe around the conductor to be tested with the arrow pointed toward the load. If the
reading is less than 400mA, select the lower range until you obtain the best resolution. Read the value
display on the DMM and multiply it by the probe ratio (1000/1). (If reading = 0.159A, the current flowing
through the probe is 0.159A x 1000 = 159AAC)
• For best accuracy, avoid if possible, the proximity of other conductors which may create noise.
Tips for Making Precise Measurements
• When using a current probe with a meter, it is important to select the range that provides the best
resolution. Failure to do this may result in measurement errors.
• Make sure that probe jaw mating surfaces are free of dust and contamination. Contaminants cause air
gaps between the jaws, increasing the phase shift between primary and secondary. It is very critical for
power measurement.
MAINTENANCE:
Warning
• For maintenance use only original factory replacement parts.
• To avoid electrical shock, do not attempt to perform any servicing unless you are qualified to do so.
• To avoid electrical shock and/or damage to the instrument, do not get water or other foreign agents
into the probe
Cleaning
To ensure optimum performance, it is important to keep the probe jaw mating surfaces clean at all times.
Failure to do so may result in error in readings. To clean the probe jaws, use very fine sand paper (fine
600) to avoid scratching the jaw, then gently clean with a soft oiled cloth.
REPAIR AND CALIBRATION
You must contact our Service Center for a Customer Service Authorization number (CSA#). This will
ensure that when your instrument arrives, it will be tracked and processed promptly. Please write the CSA#
on the outside of the shipping container.
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
15 Faraday Drive  Dover, NH 03820 USA
[phone] (Ext. 360) • [phone] (Ext. 360) • [e-mail]
(Or contact your authorized distributor)
NOTE: All customers must obtain a CSA# before returning any instrument.
TECHNICAL AND SALES ASSISTANCE
If you are experiencing any technical problems, or require any assistance with the proper use or
application of this instrument, please contact our technical hotline:
[phone] • [phone] • [email protected]
LIMITED WARRANTY
The current probe is warranted to the owner for a period of one year from the date of original purchase
against defects in manufacture. This limited warranty is given by AEMC® Instruments, not by the
distributor from whom it was purchased. This warranty is void if the unit has been tampered with, abused
or if the defect is related to service not performed by AEMC® Instruments.
Full warranty coverage and product registration is available on our website at:
www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
AC Current Probe
Model MN213
User Manual
DESCRIPTION
The MN213 (Cat. #2115.75) is the latest in compact AC current probes. Designed to meet the most
stringent demands in industry and electrical contracting, it also meets the latest safety and performance
standards. The probe has a measurement range up to 240Arms which makes it a perfect tool for
measurement with DMMs, recorders, power and harmonic meters. The Model MN213 is compatible with
any AC ammeter, multimeter, or other current measurement instrument with an input impedance lower
than 1. To achieve the stated accuracy, use the MN213 with an ammeter having an accuracy of
0.75% or better.
WARNING
The safety warnings are provided to ensure the safety of personnel and proper operation of the
instrument. Read the instruction completely.
• Use caution on any circuit: potentially high voltages and currents may be present and may pose
a shock hazard.
• Do not use the probe if damaged. Always connect the current probe to the measuring device
before it is connected around the conductor
• Do not use on non-insulated conductor with a potential to ground greater than 600V CAT III
pollution 2. Use extreme caution when clamping around bare conductors or bus bars.
• Before each use, inspect the probe; look for cracks in housing or output cable insulation.
• Do not use clamp in wet environment or in locations that hazardous gases exist.
• Do not use the probe anywhere beyond the tactile barrier.
INTERNATIONAL ELECTRICAL SYMBOLS
This symbol signifies that the current probe is protected by double or reinforced insulation. Use
only factory specified replacement parts when servicing the instrument.
This symbol signifies CAUTION! and requests that the user refer to the user manual before
using the instrument.
This is a type A current sensor. This symbol signifies that application around and removal from
HAZARDOUS LIVE conductors is permitted.
DEFINITION OF MEASUREMENT CATEGORIES
CAT II: For measurements performed on circuits directly connected to the electrical distribution system.
Examples are measurements on household appliances or portable tools.
CAT III: For measurements performed in the building installation at the distribution level such as on
hardwired equipment in fixed installation and circuit breakers.
CAT IV: For measurements performed at the primary electrical supply (<1000V) such as on primary
overcurrent protection devices, ripple control units, or meters.
RECEIVING YOUR SHIPMENT
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify
your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately
with the carrier and notify your distributor at once, giving a detailed description of any damage.

ELECTRICAL SPECIFICATIONS
Current Range: 50mA to 100AAC, continuous
Output Signal: 1mAAC/AAC (150mA @ 150A)
Accuracy*:
50mA to 100A: 1% ± 0.05A
(with non inductive load)
Phase Shift: N/A
(*Reference conditions: 23°C ± 3°K, 20 to
70% RH, external magnetic field < 40 A/m,
48 to 65Hz sine wave, no DC component, no
external current carrying conductor, test
sample centered.) Load impedance 1Ω.
Overload:
150A continuously
Frequency Range:
48 to 65Hz
Load Impedance:
5Ωmax
Working Voltage:
300V on insulated conductor
Common Mode Voltage:
100VAC Cat. III
MECHANICAL SPECIFICATIONS
Operating Temperature:
-13° to 122°F (-25° to 50°C)
Storage Temperature:
-40° to 176°F (-40° to 80°C)
Maximum Cable Diameter:
0.43” Ø max. (11mm)
Dimensions:
1.4 x 4.53 x 0.87"
(36 x 115 x 22mm)
Weight:
160 g (6 oz)
Colors:
Dark gray handles with red cover
Polycarbonate Material:
Handle: 10% Fiberglass charged polycarbonate
UL 94 V0
Output:
Insulated 5 ft (1.5 m) lead with safety 4mm
banana plug
SAFETY SPECIFICATIONS
Electrical:
300V working voltage on insulated conductor
100V max common mode between output and
ground, Cat. III
3kV 50/60Hz dielectric for 1mn
ORDERING INFORMATION
AC Current Probe MN123...............Cat #2129.12
Accessories:
Banana plug adapter
(to non-recessed plug) .....................Cat #1017.45
Black
Red
0.87" (22mm)
1.36" (35mm)
4.53" (115mm)
Ø=0.43" max
(11mm)
1.4" (36mm)

ELECTRICAL SPECIFICATIONS
Current Range: 50mA to 100AAC, continuous
Output Signal: 1mAAC/AAC (150mA @ 150A)
Accuracy*:
50mA to 100A: 1% ± 0.05A
(with non inductive load)
Phase Shift: N/A
(*Reference conditions: 23°C ± 3°K, 20 to
70% RH, external magnetic field < 40 A/m,
48 to 65Hz sine wave, no DC component, no
external current carrying conductor, test
sample centered.) Load impedance 1Ω.
Overload:
150A continuously
Frequency Range:
48 to 65Hz
Load Impedance:
5Ωmax
Working Voltage:
300V on insulated conductor
Common Mode Voltage:
100VAC Cat. III
MECHANICAL SPECIFICATIONS
Operating Temperature:
-13° to 122°F (-25° to 50°C)
Storage Temperature:
-40° to 176°F (-40° to 80°C)
Maximum Cable Diameter:
0.43” Ø max. (11mm)
Dimensions:
1.4 x 4.53 x 0.87"
(36 x 115 x 22mm)
Weight:
160 g (6 oz)
Colors:
Dark gray handles with red cover
Polycarbonate Material:
Handle: 10% Fiberglass charged polycarbonate
UL 94 V0
Output:
Insulated 5 ft (1.5 m) lead with safety 4mm
banana plug
SAFETY SPECIFICATIONS
Electrical:
300V working voltage on insulated conductor
100V max common mode between output and
ground, Cat. III
3kV 50/60Hz dielectric for 1mn
ORDERING INFORMATION
AC Current Probe MN123...............Cat #2129.12
Accessories:
Banana plug adapter
(to non-recessed plug) .....................Cat #1017.45
Black
Red
0.87" (22mm)
1.36" (35mm)
4.53" (115mm)
Ø=0.43" max
(11mm)
1.4" (36mm)

99-MAN 100315.v1 09/06
OPERATION
Making Measurements with the AC Current Probe Model MN123
• Connect the black (S2) and red (S1) terminals to the 200mA range of your DMM or instrument. The
MN123 has a ratio of 1000:1. This means that for 100AAC in the conductor around which the probe is
clamped, 100mAAC will come out of the probe leads to your DMM or instrument. The output is 1mAAC
per Amp. Select the range on your DMM or instrument which best corresponds to the measured
current. If the magnitude is unknown, start with the highest range (200mAAC) then work down until the
appropriate range and resolution is reached. Clamp the probe around the conductor. Take the reading
on the meter and multiply it by 1000 to obtain the measured current (e.g., 59mA reading: 59 x 1000 =
59,000mA or 59A).
• For best accuracy, avoid if possible, the proximity of other conductors which may create noise.
Tips for Making Precise Measurements
• When using a current probe with a meter, it is important to select the range that provides the best
resolution. Failure to do this may result in measurement errors.
• Make sure that probe jaw mating surfaces are free of dust and contamination. Contaminants cause air
gaps between the jaws, increasing the phase shift between primary and secondary. It is very critical for
power measurement.
MAINTENANCE:
Warning
• For maintenance use only original factory replacement parts.
• To avoid electrical shock, do not attempt to perform any servicing unless you are qualified to do so.
• To avoid electrical shock and/or damage to the instrument, do not get water or other foreign agents into
the probe.
Cleaning
To ensure optimum performance, it is important to keep the probe jaw mating surfaces clean at all times.
Failure to do so may result in error in readings. To clean the probe jaws, use very fine sand paper (fine
600) to avoid scratching the jaw, then gently clean with a soft oiled cloth.
REPAIR AND CALIBRATION
You must contact our Service Center for a Customer Service Authorization number (CSA#). This will
ensure that when your instrument arrives, it will be tracked and processed promptly. Please write the CSA#
on the outside of the shipping container. If the instrument is returned for calibration, we need to know if you
want a standard calibration, or a calibration traceable to N.I.S.T. (includes calibration certificate plus
recorded calibration data).
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive •Dover, NH 03820 USA
Tel: [phone] (Ext. 360)
[phone] (Ext. 360)
Fax: [phone] or [phone]
[email protected]
(Or contact your authorized distributor)
Costs for repair, standard calibration, and calibration traceable to N.I.S.T. are available.
NOTE: All customers must obtain a CSA# before returning any instrument.
TECHNICAL AND SALES ASSISTANCE
If you are experiencing any technical problems, or require any assistance with the proper use or
application of this instrument, please call our technical hotline:
[phone] • [phone] • Fax [phone]
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
[email protected]
www.aemc.com
AC Current Probe
Model MN123
User Manual
DESCRIPTION
The MN123 (Catalog #2129.12) is a high accuracy current probe for tight areas such as crowded
wiring. Extends DMM AC measurements to 150AAC. The Model MN123 offers a 5 ft lead with safety
4mm banana plug.
WARNING
These safety warnings are provided to ensure the safety of personnel and proper operation of the
instrument.
• Read the instruction manual completely and follow all the safety information before attempting
to use or service this instrument.
• Use caution on any circuit: Potentially high voltages and currents may be present and may
pose a shock hazard.
• Read the Safety Specifications section prior to using the current probe. Never exceed the
maximum voltage ratings given.
• Safety is the responsibility of the operator.
• ALWAYS connect the current probe to the display device before clamping the probe onto the
sample being tested.
• ALWAYS inspect the instrument, probe, probe cable, and output terminals prior to use.
Replace any defective parts immediately.
• NEVER use the current probe on electrical conductors rated above 300V in overvoltage
category III (Cat. III). Use only on insulated conductors.
INTERNATIONAL ELECTRICAL SYMBOLS
This symbol signifies that the current probe is protected by double or reinforced insulation. Use
only factory specified replacement parts when servicing the instrument.
This symbol signifies CAUTION! and requests that the user refer to the user manual before
using the instrument.
This is a type B current sensor. Do not apply around or remove from HAZARDOUS LIVE
conductors without additional protective means (de-energizing the circuit or wearing protective
clothing suitable for high voltage work).
In conformity with WEEE 2002/96/EC
RECEIVING YOUR SHIPMENT
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify
your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately
with the carrier and notify your distributor at once, giving a detailed description of any damage.
PACKAGING
The AC Current Probe MN123 is shipped with this instruction manual and a product warranty and
registration card.
INSTRUMENT COMPATIBILITY
The Model MN123 is compatible with any ammeter, multimeter, or other current measuring instruments
with an input impedance of less than 5Ω. To achieve the stated accuracy, use the MN123 with a meter
having an accuracy of 0.75% or better. The accuracy of the meter must be added to the probe
accuracy.
