Ork Hunter NIGHT B-1 v1.0 User manual

NIGHT B-1 v1.0
User manual (EN)
Návod k obsluze (CZ)
Інструкція користувача (UA)

2
Contents
Product Overview ...................................................... 6
Specication ............................................................. 8
About Charge ........................................................... 9
Inserting Memory Card ........................................... 10
Basic operations ..................................................... 11
Turn On And Turn Off ......................................... 11
New and Special Color Effects ........................... 11
Adjust the display ................................................ 11
Changing The Modes .......................................... 12
Taking pictures .................................................... 12
Recording Video .................................................. 14
Device Power Off ................................................... 16
Poor Image ............................................................. 16
IR-LED (Night vision function) .............................. 17
Settings in Photo and Video Mode ....................... 18
Playback .................................................................. 20
Download les to PC ............................................. 21
Notes on Cleaning ................................................. 22
EN

3
NIGHT B-1 v1.0
Obsah
Přehled produktu .................................................. 24
Specikace ............................................................. 26
O nabíjení ............................................................... 27
Vložení paměťové karty ........................................ 28
Základní operace ................................................... 29
Zapnutí a vypnutí ................................................ 29
Nové a speciální barevné efekty ...................... 29
Upravení zobrazení ............................................. 29
Změna režimů ..................................................... 30
Fotografování ....................................................... 31
Nahrávání videa .................................................. 33
Vypnutí zařízení ..................................................... 35
Špatný obraz .......................................................... 35
IR-LED (funkce nočního vidění) ........................... 36
Nastavení v režimu Foto a Video ......................... 37
Přehrávání ............................................................... 39
Stažení souborů do PC ......................................... 40
Poznámky k čištění ............................................... 42
CZ

4
UA
Зміст
Загальний вигляд ................................................. 44
Технічні характеристики ..................................... 46
Заряджання ........................................................... 47
Карта памʼяті ........................................................ 48
Основні операції ................................................... 49
Увімкнення та вимкнення .............................. 49
Колірні ефекти ................................................... 49
Налаштування дисплею .................................. 49
Зміна режимів ................................................... 50
Фотографування ................................................ 51
Запис відео ........................................................ 52
Перезавантаження пристрою ........................... 54
Низька якість зображення ................................ 55
Функція нічного бачення ................................... 55
Налаштування в режимі фото та відео ........... 56
Відтворення ........................................................... 58
Завантаження файлів на ПК ............................. 59
Поради щодо обслуговування .......................... 61

5
NIGHT B-1 v1.0

6
EN
Product Overview

7
NIGHT B-1 v1.0
EN
1. Lens focus wheel.
2. IR LED.
3. USB port/Charging Indicator/Reset Port/
Memory Card Slot Cover.
4. Mode Button.
5. Strap Hole.
6. Eyepiece/Display.
7. Shot/OK button.
8. Power Button.
9. IR Down/Zoom Out/Down Button.
10. IR Up/Zoom In/Up Button.
11. Menu Button.
12. Tripod xing screw.

8
EN
Specication
• Photo Resolution: 36M, 12M, 8M, 5M, 3M, 2M, 1M.
• Video Resolution: 4K, FHD, HD.
• Lens: F1.2 large aperture, F=25mm, automatic
infrared lter.
• Lens angle: FOV=10°, diameter 24mm.
• Display: 3.2” 480*854 HD TFT, 7 levels of
brightness adjustment.
• Memory card: up to 32GB.
• USB port: TYPE-C.
• Auto Power Off: Off/1min/3min/5min/10min.
• Infrared light: 3W, 850nm strong infrared spotlight,
7 levels of infrared adjustment.
• Viewing distance in complete darkness: about
250-300 meters.
• Low-light sight distance: 3 meters to innity.
• Digital zoom: 8x digital zoom.
• Color effects: color, black and white, luminous
green, infrared light.
• Power supply: 2600mAh lithium battery.
• Date Stamp: supports setting date and time. Date
and time stamp on photo and video les.
• Operation buttons: 6 buttons.
• Operating temperature: -20° C to +50° C.
• Storage temperature: -30° C to +60° C.
• Size and weight: 145*120*55mm / 336 g.

9
NIGHT B-1 v1.0
EN
About Charge
The device has a built-in rechargeable battery,
please fully charge it before rst use.
Please use a universal USB power adapter* (DC
5V/2A) (*not included) to charge this device. When
charging, the charging indicator on the left side
of the TYPE-C USB port will turn red; when fully
charged, the charging indicator will turn off. If the
device is completely out of power, it can be fully
charged in about 4 hours.

10
EN
Inserting Memory Card
• Please prepare a Class 10 Micro SD card (up to
32GB) in advance.
• Open the card slot cover (3); you will see the card
slot.
• Insert the Micro SD card into the slot. Make sure
the direction is right. Never insert the card forcibly.
• Format the Micro SD card; this can improve the
compatibility of Micro SD card.
• To remove the card from the memory card slot
of the device, press the edge of the memory card
gently, the card will pop out. Then remove the
card.
Note:
If the Micro SD card is not inserted correctly, after
power on device will prompt “NO CARD” and the icon
of the card with X will be displayed in the lower right
corner. The number of pictures that can be taken or the
recording time at the top right will be displayed as 0.

11
NIGHT B-1 v1.0
EN
Basic operations
Turn On And Turn Off
Press the Power button (8) for 3 seconds to turn on
the device. Press the Power button for 3 seconds again
to turn off the device.
New and Special Color Effects
Luminous Green Color Effect & Film Color Effect:
these 2 color effects are available in both normal mode
and infrared night vision mode.
Steps: Long press Menu (11) > Luminous Green Color
Effect, Long press Menu > Infrared light Color Effect, Long
press Menu > Get back to the normal color mode.
Adjust the display
After turn on the device, please press the Menu
button to enter the menu. When you viewing the
eyepiece/display screen if the Menu font is not
clear enough, please adjust the eyepiece diopter
adjustment wheel until the Menu font looks clear,
press the Menu button again to exit the Menu. Then
adjust the focus wheel to focus according to the
actual distance of the viewed scene until the screen
is the clearest. If the light is insucient or using at
night, please press the IR Up/Zoom in/Up Button (10)
to turn on the infrared light and please select the IR

12
EN
gear according to the light at that time. The darker
is the light, the higher is the gear adjustment. Long
press the IR Up/Zoom In/Up Button to zoom.
Changing The Modes
The night version has 3 different modes: photo mode,
video mode and playback mode. Press the Mode
button (4) to change mode.
• Photo Mode: for taking still photos.
• Video Mode: for recording video.
• Playback Mode: for playing the recorded les.
Taking pictures

13
NIGHT B-1 v1.0
EN
1. Camera mode.
2. Night vision sensitivity.
3. Photo resolution.
4. Number of pictures that can be taken.
5. Battery status.
6. Micro SD card prompt.
7. Digital zoom indication.
8. Shooting time stamp.
9. Display brightness.
10. Infrared light gear.
Turn on the device, the default is Video mode. Please
press the Mode button (4) to switch to Camera
mode.
Zooming:
Keep pressing the Zoom Out (9) or Zoom In (10)
button to zoom in or zoom out the image.
The value of magnication level appears on the
LCD screen.
To take a still photo:
• View your subject via the LCD screen.
• Adjust the focus by turning the focus wheel.
• For night or insucient light use, turn on the IR by
pressing the IR Up/Zoom in/Up Button. Increase
the brightness by pressing the button repeatedly.

14
EN
It has 7 levels of brightness. The brightness can be
adjusted according to your needs. The darker the
light, the higher the gear adjustment.
• Press the Shot/OK button (7) to take a photo.
Recording Video
1. Video mode.
2. Night vision sensitivity.
3. Video resolution.
4. Recording switch indication.
5. Available video recording time.
6. Battery status.
7. Micro SD card prompt.
8. Digital zoom indication.

15
NIGHT B-1 v1.0
EN
9. Shooting time stamp.
10. Display brightness.
11.Infrared light gear.
Turn on the device. The default is Video mode. If not,
press the Mode button to switch to Video mode.
Zooming:
Keep pressing the Zoom Out or Zoom In button
to zoom in or zoom out the image. The value of
magnication level appears on the LCD screen.
To start to record video:
• View your subject via the LCD screen.
• Adjust the focus by turning the focus wheel.
• For night or insucient light turn on the IR by
pressing the IR button. Increase the brightness
by pressing the button repeatedly. It has 7 levels
of brightness. The brightness can be adjusted
according to your needs.
• Press the Shot button to start to record. The
record duration will be shown on the LCD screen.
To nish recording:
Press the Shot button again to stop recording.
The device will stop recording automatically once
capacity of the memory card is full.

16
EN
Device Power Off
• If the device is fully charged and cannot be turned
on or the screen cannot move during use and
cannot be turned off, please insert a small hard
strip such as toothpick or wire into the RST hole,
when you feel the resistance, press it and then
turn it on.
• Please use an universal USB power adapter* (DC
5V/2A) (*not included) to charge this device. After
the TYPE-C USB is connected to the device, when
the red light of the charging indicator of the device
is on, long press the power button to turn on the
device, unplug the TYPE-C USB to turn off the
device, which means that the built-in battery has
no power and it needs to be fully charged.
Poor Image
• If at day, make sure the IR is off (if IR is on, screen
is black and white or the screen is colored).
• If at night, make sure you have turned on the IR,
press IR up (if IR is on, screen is black and white).
Adjust the most appropriate brightness according
to your need.
• Adjust the focus by slowing turning the Focus
wheel (1), make sure it is focused.

17
NIGHT B-1 v1.0
EN
IR-LED (Night vision function)
• Users can manually focus the focus wheel
according to the actual observation distance to
debug the best focus until the display is clear.
• In photo/video mode, if you have to view the
darkness environment, please short press IR
Up button to activate the IR LED, the image will
change to black and white. The IR LED have seven
levels, short press IR Up button to up the level,
short press IR Down button to down the level.
• If the battery voltage is not enough, the IR LED
level will down automatically. IR level can up to
7 levels when the battery power is full. If only
left half power, the level just can up to 5. If only
left 25% power, the level just can up to 3. If the
battery power is lower than 25%, IR LED cannot be
activated.

18
EN
Settings in Photo and Video Mode
Press Menu button in photo or video mode to change
the settings.
Menu Function
Resolution Set the video resolution.
Options: 4K / FHD / HD.
Resolution Set the photo resolution. Options: 36M, 12M,8M, 5M, 3M, 2M, 1M.
Night
vision
sensitivity
Choose the night vision sensitivity.
Options: Low / Middle / High.
Screen
Brightness Adjust the screen brightness as required.
Options: Level 1 / Level 2 / Level 3 /
Level 4 / Level 5 / Level 6 / Level 7.
Audio On / Off.
Date Tag On / Off.
Date
Setting Set the date and time of device. Press the Up or Down button to adjust the date
or time, press the OK button to complete
settings.
Auto
Power-Off
Set the time to shut down the device
for power saving if the device is idle.
Options: OFF / 1 min / 3 min / 5 min /
10 min.

19
NIGHT B-1 v1.0
EN
Language
Setting Set OSD (on-screen) language. Options: English / Traditional Chinese /
Simple Chinese / Japanese / Deutsch /
Francais / Russian / Italiano / Korean /
Nederlands / Espanol / Portugues.
Flicker Set the light source frequency to match
frequency of electricity supply in local
region to prevent interference.
Options: 50Hz/60Hz.
Format Format your Micro SD card. Format
Micro SD will delete all les including
the protected les. Please copy the
important les before conrm.
Options: OK / Cancel.
Reset
System Restore the setup to factory default settings.
Options: OK / Cancel.
Version User can see the rmware version
information.

20
EN
Playback
1. Turn on the device, press the Mode button to
switch to playback mode.
2. Press Up/Down button to view photos and video
les.
3. Playback the video:
• Press the Shot button to start playing the video
les.
• Press the Shot button again to have a pause.
• Press Menu button to stop the current video
playing.
4. Press Menu button in playback mode, the screen
will display the playback menu. Press Up/Down
button to scan lock or delete. Press Shot button
to select one to enter the sub-menu.
Playback menu list:
Menu Function
Delete Delete the current one le in memory card.
Options: Yes / No.
Delete
All Delete all les in memory card. Options: Yes / No.
Lock
This Lock the current le in memory card. Options: Yes / No.
Unlock
This Unlock the current le in memory card. Options: Yes / No.
Unlock
All Unlock the all les in memory card. Options: Yes / No.
