Orllo LX-400G User manual

High Definition Car DVR
User Guide
Ver:11
DVR Configuration

1.MIC port 2.Mute button 3.GPS button 4.power button
5.DVR button 6.HOME button 7.Reset button 8.Power indicator
9.USB port 10.AV IN port 11.TF card slot1 12. TF card slot 2
13.SENSOR

Functions of Buttons
Mute button
Press it shortly can turn on/off the sound
GPS button
Press it shortly will turn into the GPS navigation interface
1. <Power> Button
Function 1: Power on/off
In power-off state, press and hold <Power> for three seconds, the DVR is
powered on. In power-on state, press and hold <Power> for three seconds, the
DVR saves the file automatically and is powered off.
Function 2: Close the display backlight
In any state, press <power> shortly will close the backlight of the display,
and press it again the backlight will be turn on.
DVR button
Press the button will enter the car dvr interface.
HOME button
Press the button shortly can back to main interface.
Reset button：
If the DVR is crashed, press <Reset> to power off the DVR.

Introduction of main interface

1.car dvr entrance
It is the main features for the A10 products. Click this area, enter for using
car dvr, it will bring you different user experience.
2.GPS entrance.
Click it one time can enter the default navigation system.
3. Blue tooth entrance
Click it one time will enter the setting interface.
4. The application list entrance
Click it shortly will enter the system as well as the installation program list.
Can click here to enter other application, it is fast and convenient. Pictures as
below:
5.mini music player

Click the icon can control the playing of songs, if the songs had been
download in the product or in SD card, it will also be smart to get cover songs.
6.Function setting
Click to enter the setting interface.
7.Entrance of FM launch
With the Innovative FM transmission techniques, click to enter. When
FM opened, can set the frequency after click the small page button.
8.Navigation selection
Click it to set the application, especially the default navigation settings.
9. picture, video playing
The area will get and show the pictures if there are pictures in the SD
card, see the picture as below:
Operation Guide

I：Installing the DVR
1. Power off the automobile engine
2. Insert the TF card into the TF card slot
【Note】Please use a well-branded high-speed TF card(Class 10 or above)
with a capacity of at least 512MB. The TF card supports a maximum of
64GB).
3. Secure the DVR to the rear mirror of the automobile.
4. Insert the in-vehicle charger into the cigar lighter of the automobile
【Note】Run up the charging cable along one stage of the windscreen
when wiring.
5.Install the back camera in the back of the automobile, keep an eye on
the direction when installing. Wiring along the roof of the car. Insert the
back camera into the slot on the DVR after installing.
6. Adjust the angle of the dvr, ensuring that the camera lens keeps level
with the ground.
7.Start up the engine and check whether the DVR is mounted properly.
【Note】If installing it correctly, the indicator will light. The recorder icon
will glitter if it comes into video recording. Please check that if the picture in
the screen is normal. If the picture is inverted image, please contact us rapidly.
Function Description
1.Operating mode

in the video recording mode, sliding this button can switch the video recording
and photograph.
2.Channel switch
There modes for selecting: front camera, back camera, dual camera.
3.Loop video recording
The loop video recording time can be settled as 1 minute, 2 minutes, 5 minutes,
OFF. When settled as OFF, the video can’t be coverd.
4.Video quality
The video can be settled as VGA, 720P, 1080P.
5.Picture quality

In photograph mode, the picture can be settled as 100W, 200W, 300W,500W.
6.White balance, exposure, color
About the white balance, please select it accordingly.
7.Color select
Color selecting including default, black and white, puce, negative, sketch, sky
blue.
8.Time the watermark

When it opened, the time and date will show on the video and the pictures.
9.Speed watermark
When it opened, the speed watermark will show in the last place of time
watermark.
10.Motion detection
Open the motion detection, it will record automatically when detecting the
scene changed.And it will also stop recording after the scene not change for 20
seconds.
11.Video mute
When it opened, there is no voice in the video.
