Remote Control Setup and Operation
This section provides safety information and instructions for setting up and operating the remote control.
The redesigned GV60 handsets G6R-H…FB and G6R-H…FW operate exactly the same as the previous
handset G6R-H…
Only the symbols on the buttons have changed. See the figure below for the corresponding symbols.

Radio Frequency Handset
433.92 MHz for Europe; 315 MHz for U.S. and Canada. This device complies with part 15 of the FCC Rules.
Operation is subject to the following conditions:
•This device may not cause harmful interference
•This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: Wiring of valve and receiver must be completed before starting ignition. Failure to do so
could damage the electronics.
Setting the Electronics Code
Follow these guidelines to set the code on the radio frequency handset.

Batteries
Handset:
•3 x “AAA” (alkaline recommended).
•Low battery indicator on handsets with display.
•Handsets without display: the red LED gets darker.
•Battery replacement is recommended after 2 years.
•The handset may display options that are not available on all fireplaces
Receiver:
•4 x 1.5V “AA” (alkaline recommended).
•Low battery indication: Frequent beeps for 3 seconds when motor turns.
•The AC Mains Adapter must be used for all units except screen units with no options.
•The module for fan speed control and light/dimmer includes mains power together with
batteries in the receiver for automatic backup in case of power outage.
NOTE: Double glass and power vented units will not operate during a power failure, and need to
be run with the AC Adapter.
•Without using a mains adapter, battery replacement is recommended at the beginning of each
heating season.
NOTE: Only the Mertik Maxitrol AC Mains Adapter or one pre-approved by Mertik Maxitrol can
be used. Use of other adapters can render the system inoperable.
The handsets, receivers, wall switches switchpanels and touchpads are not interchangeable with
previous electronics.

Operating Instructions
Some options on the remote may not be available on all fireplaces. For complete operating instructions,
please refer to the Homeowner’s manual.
