Orthofab Prima User manual

USER MANUAL
July 2008

2
inc All rights reserved
Please give this manual to the owner of the
wheelchair.
Please read this manual in it entirety before using your
wheelchair for the first time. Read this
manual until it becomes familiar and pay close attention to
the warnings.
If you have any questions about non-covered subjects in this
manual, please consult a technician in an authorized service
center or contact our customer service at: 1-(418)-847-5225
Center:
Address:
Phone:
The adjustments of your wheelchair must be made by
a health care professional. Inadequate adjustments can
cause wounds and/or damage to the user, the caregiver, the
wheelchair or the environment.
Do not install unauthorized accessories. Always consult a
health care professional for any modifications to your
wheelchair.

3
inc All rights reserved
is proud to count you among its customers and thanks you for having
chosen one of its products.
All the products manufactured by respect or exceed the highest standards
of quality and safety currently in force in the industry. employees are
guided by the desire to satisfy expectations of his customers. This is why
does not hesitate to offer a most complete warranty, applying to the whole wheelchair
elements and components. However, the warranty does not apply to parts and
components damaged by abuse, carelessness, accident and normal use or installed
and modified by an unauthorized person.
This operating instructions manual has been written to enable you to use your
wheelchair safely. You will find in this document, information
relating to safety, operating instructions and adjustments.
In order to optimize the performance of your and to extend its
lifespan, it is essential to have it check regularly by a technician from an authorized
service center.
refuse any responsibility for physical injuries or damages resulting from an
improper use of its products, from a lack of precaution in their use or from a modification
made without it written assent.

TABLE OF CONTENTS
4
inc All rights reserved
1 SAFETY REQUIREMENTS .......................................................................6
1.1 SAFETY REQUIREMENTS ............................................................................................... 6
1.1.1 BEFORE TAKING THE ROAD ........................................................................................................6
1.1.2 MOVING WITH THE WHEELCHAIR...............................................................................................7
1.1.3 TO CARRY OUT TRANSFERT.......................................................................................................7
1.1.4 VARIOUS HANDLING OPERATIONS.............................................................................................8
1.1.5 CLEANING AND MAINTENANCE OF COMPONENTS..................................................................9
1.2 WHAT ABOUT THE ELECTROMAGNETIC ENERGY..................................................... 9
1.2.1 CAUTION.......................................................................................................................................10
1.2.2 USING TRANSMITTERS AND RECEIVERS................................................................................10
2 RECOMMENDED USE............................................................................11
3 SPECIFICATIONS...................................................................................12
4 SETUP INSTRUCTIONS..........................................................................14
4.1 FOOTREST.......................................................................................................................14
4.1.1 TO ADJUST THE FOOTREST LENGHT.......................................................................................14
4.1.2 TO CHANGE THE ANGLE OF THE FOOTPLATE .......................................................................15
4.1.3 TO CHANGE THE DEPTH POSITION OF THE COMPOSITE FOOTPLATE ..............................15
4.1.4 TO CHANGE THE ANGLE OF THE FULL LENGTH FOOTPLATE..............................................16
4.1.5 DEPTH ADJUSTMENT OF THE HEEL LOOPS............................................................................16
4.1.6 ADJUSTMENT OF THE TOE LOOPS...........................................................................................16
4.1.7 TO CHANGE THE HEIGHT OF THE CALF PAD..........................................................................17
4.1.8 TO CHANGE THE POSITION OF THE CALF PAD ......................................................................17
4.2 ARMREST ........................................................................................................................18
4.2.1 HEIGHT ADJUSTMENT, REMOVABLE, SWINGAWAY ARMREST............................................18
4.2.2 RIGID SIDEGUARD.......................................................................................................................18
4.2.3 REMOVABLE “U” SHAPE SWINGAWAY ARMREST...................................................................20
4.3 ADJUSTABLE BACKREST ANGLE...............................................................................21
4.3.1 TO CHANGE THE BACKREST ANGLE........................................................................................21
4.3.2 TO CHANGE THE BACKREST HEIGHT ......................................................................................23
4.3.3 PUSH HANDLES INSTALLATION ................................................................................................24
4.4 DYNAMIC BACKREST.................................................................................................... 26
4.4.1 DYNAMIC BACKREST INSTALLATION .......................................................................................26
4.4.2 DYNAMIC BACKREST ADJUSTMENT.........................................................................................28
4.5 SEAT................................................................................................................................. 29
4.5.1 SLING SEAT..................................................................................................................................29
4.5.2 RIGID SEAT...................................................................................................................................30
4.6 ADJUSTABLE ISCHIATIC PROFILE SEAT CUSHION................................................. 31
4.6.1 ADJUSTABLE ISCHIATIC PROFILE SEAT CUSHION INSTALLATION......................................32
4.6.2 ISCHIATIC SEAT CUSHION ADJUSTMENT................................................................................35
4.7 FRONT CASTERS ........................................................................................................... 36
4.7.1 TO CHANGE THE MODEL OR THE HEIGHT OF THE FRONT CASTER...................................36
4.7.2 FORKS PERPENDICULAR ADJUSTMENT..................................................................................37
4.8 REAR WHEELS ............................................................................................................... 38
4.8.1 TO CHANGE THE MODEL OF REAR WHEELS..........................................................................38
4.8.2 CENTER OF GRAVITY ADJUSTMENT........................................................................................40
4.8.3 REAR HEIGHT ADJUSTMENT.....................................................................................................41
4.9 PARKING BRAKES.........................................................................................................42
4.9.1 TO ADJUST THE POSITION OF THE PARKING BRAKE (Pushing or pulling brake type)..........42
4.9.2 TO CHANGE THE BRAKE LEVERS.............................................................................................43
4.9.3 TO CHANGE THE ANGLE OF THE BRAKE LEVER (pushing brake type only)..........................45
4.10 ANTI-TIPPERS................................................................................................................. 46
4.10.1 HEIGHT ADJUSTMENT POSITION..............................................................................................46
4.11 ANCHOR POINTS............................................................................................................ 47

TABLE OF CONTENTS
5
inc All rights reserved
4.12 6 WHEELS CONFIGURATION........................................................................................ 48
4.12.1 6 WHEELS CONFIGURATION INSTALLATION...........................................................................48
4.13 OXYGEN CYLINDER SUPPORT ....................................................................................51
4.13.1 OXYGEN CYLINDER SUPPORT INSTALLATION.......................................................................51
5 OPERATING INSTRUCTIONS ................................................................52
5.1 HOW TO FOLD AND UNFOLD YOUR PRIMA WHEELCHAIR.....................................52
5.1.1 TO UNFOLD THE WHEELCHAIR.................................................................................................52
5.1.2 TO FOLD THE WHEELCHAIR......................................................................................................53
5.2 BACKREST PUSH HANDLE AND HEADREST ANCHOR ...........................................53
5.2.1 BACKREST PUSH HANDLE.........................................................................................................53
5.2.2 BACKREST PUSH HANDLE WITH HEADREST ANCHOR .........................................................53
5.3 SWINGAWAY, REMOVABLE ARMRESTS.................................................................... 54
5.3.1 TO SWINGAWAY THE ARMREST ...............................................................................................54
5.3.2 REMOVE AND/OR REPLACE THE ARMREST............................................................................54
5.4 FLIP-UP, REMOVABLE ARMRESTS ............................................................................. 55
5.4.1 TO SWINGAWAY ..........................................................................................................................55
5.4.2 TO REMOVE AND/OR INSTALL...................................................................................................56
5.4.3 HEIGHT ADJUSTMENT ................................................................................................................56
5.5 FOOTRESTS.................................................................................................................... 57
5.5.1 TO SWINGAWAY ..........................................................................................................................57
5.5.2 TO REMOVE AND/OR INSTALL THE FOOTREST......................................................................59
5.5.3 TO RAISE AND LOWER THE LEGREST .....................................................................................59
5.6 TENSION ADJUSTABLE BACKREST........................................................................... 60
5.7 REAR WHEELS ............................................................................................................... 61
5.7.1 TO INSTALL AND/OR TO REMOVE.............................................................................................61
5.7.2 PNEUMATIC TIRE PRESSURE....................................................................................................61
5.8 PARKING BRAKES.........................................................................................................62
5.8.1 TO APPLY AND DISENGAGE THE PARKING BRAKE the PUSHING type................................62
5.8.2 RETRACTABLE HANDLES...........................................................................................................62
5.8.3 APPLY – DISENGAGE THE HILL HOLDER.................................................................................63
5.9 ANTI-TIPPERS................................................................................................................. 64
5.9.1 TO REMOVE AND/OR RETRACT ................................................................................................64
5.9.2 TO RETRACT................................................................................................................................64
5.9.3 TO REPLACE ................................................................................................................................65
5.10 CANE AND CRUTCH HOLDER ...................................................................................... 65
5.11 SEAT BELT......................................................................................................................66
5.12 TRANSPORTATION ........................................................................................................ 67
5.12.1 ANCHOR POINTS LOCALIZATION..............................................................................................67
5.12.2 ADVICE FOR TRANSPORTATION...............................................................................................68
6 MAINTENANCE.......................................................................................69
7 BREAKDOWN SERVICE GUIDE ............................................................71
8 WARRANTY ............................................................................................72
9 AUTHORIZED SERVICE CENTRES.......................................................74

1 SAFETY REQUIREMENTS
6
inc All rights reserved
1 SAFETY REQUIREMENTS
1.1 SAFETY REQUIREMENTS
(Applies to all wheelchairs)
The adjustments of your wheelchair must be made by
a health care professional or a technician in an authorized
service center.
1.1.1 BEFORE TAKING THE ROAD
•Always put the key switch OFF before getting on or off your vehicle.
•Make sure that the batteries are sufficiently charged (see battery status
indicator).
•Make sure that the anti-tippers are installed.
•Make sure that brakes immobilize your wheelchair completely.
•Make sure that the tire pressure is appropriate.
•Make sure that nothing interferes with wheels (scarf, umbrella, etc…).
•Make sure that your seating position is stable.
•Position the backrest in the raised position.
•Make sure the 45° tilt mechanism is in driving position (seat horizontal with the
ground).
•Fasten your seat belt correctly and without too much slack.
•Make sure that swing away legrests are locked in position and that your feet are
stable on them.
•Push down the elevator legrests.
•Make sure that the swing away or removable armrests are locked in their
positions.
•Make sure that the position of the joystick box enable you to carry out all your
movements comfortably and easily.
•Make sure that the joystick rubber cover is in good condition, if not, try to have it
fixed as soon as possible.
•Make sure that your personal effects do not block in anyway the wheelchair
functions.
•Do not install or transport heavy objects on the backrest of your wheelchair
(backpack, bags, grocery, etc).

1 SAFETY REQUIREMENTS
7
inc All rights reserved
1.1.2 MOVING WITH THE WHEELCHAIR
•Avoid any shock to the joystick box or the joystick itself.
•Avoid slippery surfaces (snow, ice, etc).
•Do not change direction abruptly at high speed.
•Do not use your wheelchair on expressways or streets with intense car circulation.
•Do not transport passengers.
•Do not use your wheelchair under extreme climatic conditions (storm, rain, etc).
•If you drive outside at night, ensure that you will be seen by others.
•Do not approach a slope in a diagonal trajectory, always approach the slope in a
straight line, perpendicularly to the slope.
•Do not go down in a slope in reverse.
•Always actuate the lever gently when you start moving in a slope in order to avoid
tipping the wheelchair.
•Do not make a half-turn in a slope.
•Reduce your speed in restricted or encumbered areas.
•Reduce your speed in a crowd and use your horn to announce your presence.
•In front of an obstacle you must stop and cross it perpendicularly and gradually.
•Avoid thresholds of more than 1 ½ in (38 mm), they can endanger your stability.
•Use the elevators to move you from one level to another.
•Do not approach a slope surface exceeding 10° (17% slope).
•Always fasten your seat belt.
•Keep legs on the legrest while driving.
1.1.3 TO CARRY OUT TRANSFERT
•Always put the on/off switch of the joystick box on the OFF position before carrying
out a transfer.
•Never lean forward or backward to reach an object.
•Always place yourself sideway and the nearest you can to the object to reach.
•Use the transfer supports on the armrests to raise yourself, after you made sure that
they are correctly in position.
•If your backrest is inclined, do not sit down on the backrest, you could damage the
backrest and tip the wheelchair.
•Do not raise yourself upright on the footplates, you could damage and/or tip the
wheelchair.
•Do not sit on the armrests. The wheelchair could tip over.

1 SAFETY REQUIREMENTS
8
inc All rights reserved
1.1.4 VARIOUS HANDLING OPERATIONS
Never try to recharge the batteries in your bedroom while you
sleep. During recharge, batteries can produce a harmful gas
who can cause you health problem.
•Do not immerse your wheelchair, it could cause a dangerous electrical problem.
•Do not store or leave your wheelchair without someone taking care of it.
•Do not leave your wheelchair under the rain.
•Do not store your wheelchair in a wet or very cold place, this could cause a
dangerous problem on your motorized wheelchair.
• does not limit nor exclude that the user remains seated in his
wheelchair when using a road vehicle adapted for transportation (paratransit),
provided the driver and the owner of the aforesaid road vehicle respects, on this
subject, all legislative requirements, rules, laws, protocols, directives, norms,
standards, instructions and recommendations pertaining to such use by
competent authorities.
•Do not travel on tilted surfaces when the wheelchair is in free wheel. If you have
to do it, the caregiver must always be oriented in the direction of the bottom of
the slope.
•Do not raise the wheelchair by its detachable components (armrest, seat, etc).
•Do not use your battery charger in a hermetic place (backpack, drawer, etc.).
•Always put the on/off switch of the charger on the OFF position before
disconnecting the charging connector on the wheelchair.
•Never try to modify the connector (110 V AC) of the battery charger.
•Never try to modify the battery charger connector (24 V DC) which connect to the
wheelchair.
•Never try to recharge the batteries in your bedroom while you sleep.
•Never connect an electric component other than those manufactured by
.
•Never modify the electric circuit of the wheelchair.
•Always protect the joystick box when you have to carry the wheelchair.
•Always immediately replace any damaged electric wires.
•Always carry out regularly maintenance of your motorized wheelchair as
recommended by .

1 SAFETY REQUIREMENTS
9
inc All rights reserved
1.1.5 CLEANING AND MAINTENANCE OF COMPONENTS
•Clean as soon as possible your joystick box once it been soiled.
•Use a soft rag and a diluted soft soap.
•Do not use detergent based on alcohol or thinner.
•Regularly carry out maintenance of your wheelchair as recommended by
.
1.2 WHAT ABOUT THE ELECTROMAGNETIC ENERGY
All electronic instruments which transmit remote informations are generally
apparatus which emit in the environment some radio waves. These radio waves
are called " electromagnetic energy ".
The functionality of an electronic instrument can be deteriorated by this
electromagnetic energy field. It is what we call " an electromagnetic
interference". Stronger the intensity of energy is, greater the risk of bad
functional problem of the apparatus increase. This energy is measured in volt
per meter (V/m).
All motorized wheelchair are suitable to be affected by these interferences.
However, current technology makes it possible to immunize them against these
risks. It is what is called their electromagnetic level of immunity to the
interference, measured also in volt per meter (V/m).
20 V/m is a level of immunity which offer a good protection against the
electromagnetic interferences. The electronic parts of the R-NET electronic from
do meet standard directive IEC 1000-4-3.
To avoid electromagnetic interferences, it is important to read
and respect the following warning section, before to use your
wheelchair for the first time.

1 SAFETY REQUIREMENTS
10
inc All rights reserved
1.2.1 CAUTION
Waves emitted by :
•Radio and television stations;
•Amateur radio;
•Radio transmitters and receivers;
•Cellular phones;
•Computers laptop.
CAN AFFECT THE CORRECT FUNCTIONALITY OF MOTORIZED WHEELCHAIR.
1.2.2 USING TRANSMITTERS AND RECEIVERS
•Avoid proximity of these sources of electromagnetic emissions.
•Always put the joystick box in the OFF POSITION before using a cellular phone
or a CB apparatus.
•The addition of electric accessories and/or electric modifications made to the
wheelchair will modify its level of immunity to the electromagnetic emissions.
•Always put the key in the OFF POSITION as soon as it safe to do it and that
appears an erratic operation with the wheelchair.
•Please forward any incident of this kind to .

2 RECOMMENDED USE
11
inc All rights reserved
2 RECOMMENDED USE
The manual collapsible wheelchair offers all the mechanical
characteristics and necessary functions in order to ensure powerful propulsion with the
least effort possible.
Its structural concept and its frame entirely composed of light and resistant aluminum
alloy offer all the necessary mechanical functions for the adjustment of multiple
components.

3 SPECIFICATIONS
12
inc All rights reserved
3 SPECIFICATIONS
Dimensions Front casters
Weight:9.4 kg - 20 pounds (without wheels and footrests) Pneumatic of 6 x 1 ¼, 7 x 1 ¾, 8 x 1 ¼, 8 x 2 inches
Overall width : Width + 8 ¼ inches Foam filled insert
Minimum folded width : 12 ½ inches Semi-pneumatic of 5 x 1 ½”, 6 x 1 ½”, 8 x 1 ½” inches
Overall length : 22 inches without anti-tippers and footrests High density tires 5 x 1, 6 x 1, 7 x 1 and 8 x 1 inch
(rear wheels 20 inches) Narrow fork at 3 positions
Capacity : 250 pounds Large fork at 3 positions
Frame
Lower fork at 4 positions
Aluminum structure Suspension fork
Epoxy paint – 4 choices of color
Rear wheel
Central propulsion Pneumatic of 20-22-24-26 inches
Seating
Polyurethane of 22-24 inches
Single cross width frame : 14-15-16-17-18 inches Semi-pneumatic of 20-22-24 inches
Double cross width frame : 16-17-18-19-20-21-22-23 inches Foam filled insert of 20-22-24-26 inches
Depth : 14-15-16-17-18-19-20 inches Spoke wheel of 20-22-24 inches
Removable rigid seat embedded of (0,-1 or -2 inches) Mag wheels of 20-22-24 inches
Profiled or straight cushion 2 or 3 inches Reinforced spoke wheel of 20-22-24-26 inches
Front seat to floor height adjustable from 14 to 21 ½ inches
Hand rims
Rear seat to floor height adjustable from 13 3/8 to 20 ½ inches Aluminum 20-22-24-26 inches
Adjustable Ischiatic seat Plastic coated 20-22-24-26 inches
Backrest
Foam coated 20-22-24-26 inches
Aluminum tubing structure of 1 inch diameter
Wheel locks
Telescopic backrest post angle of 0° or 8° at 8 inches Standard wheel lock by (pushing or pulling)
Backrest height 13 to 22 inches Angle adjustable lever
Removable rigid plate
Wheel lock extension
Nylon sling backrest Hill holder
Adjustable tension sling backrest
Wheel axle
Adjustable angles -5°, 0°, 5°, 10°, 15°, 20°Standard
Push bar (rigid and collapsible) Quick release
Dynamic backrest
Footplates
Armrest
Foldable
Swingaway and removable Composite
Height adjustable from 7 to 14 inches Aluminum narrow or large
Armrest pad length from 10 to 14 inch, straight or profiled Aluminum narrow or large, angle adjustable
Telescopic clothes guard Aluminum full width
Clothes guard rigid or supple Heel loops
Width of armrest pad straight 2 inches Toe loops
Width of armrest pad profiled 3 inches Front roller bumper
Deported + 3 inches H strap
Footrest Accessories
Swingaway - Removable Adjustable headrest
Angle 60° / 70°or 90° parallel or tapered Restraint belt (car, airplane and velcro) type
Length adjustment of 14 to 19 inches Paratransit anchor points
Length modification less than 14 inches or more than 19 inches Anti-tippers retracted or adjustable in height
Elevating
Cane and crutch holder
Articulated
Oxygen tank support
Calf pad flat or profiled Auxiliary motorized propulsion system

3 SPECIFICATIONS
13
inc All rights reserved
Rear seat to floor height table
PRIMA 4 wheels and 6 wheels
Front seat to floor height table
20" Wheel
113 3/8 14 3/8 13 3/4 15 1/4 14 5/8 16 1/8 15 1/2
214 15 14 3/8 15 7/8 15 1/4 16 3/4 16 1/8
314 5/8 15 5/8 15 16 1/2 15 7/8 17 3/8 16 3/4
415 1/4 16 1/4 15 5/8 17 1/8 16 1/2 18 17 3/8
515 7/8 16 7/8 16 1/4 17 3/4 17 1/8 18 5/8 18
616 1/2 17 1/2 16 7/8 18 3/8 17 3/4 19 1/4 18 5/8
717 1/8 18 1/8 17 1/2 19 18 3/8 19 7/8 19 1/4
817 3/4 18 3/4 18 1/8 19 5/8 19 20 1/2 19 7/8
Rear seat to floor height15
Rear seat to floor
22" Wheel 24" Wheel 26" Wheel
Pneumatic
Pneumatic and
Semi pneumatic Pneumatic and Semi pneumatic Polyurethane and Hight pressure Pneumatic and Semi pneumatic Polyurethane and Hight pressure High pressure

4 SETUP INSTRUCTIONS
14
inc All rights reserved
4 SETUP INSTRUCTIONS
After having carried out an adjustment and before using the
wheelchair, make sure that all hardware is tight. Make sure
that all functions are secure before using the wheelchair.
The adjustments of your wheelchair must be made by
a health care professional. Inadequate adjustments can
cause wounds and/or damage to the user, the caregiver, the
wheelchair or the environment.
4.1 FOOTREST
4.1.1 TO ADJUST THE FOOTREST LENGHT
Figure 1 : To adjust the footrest lenght.
To adjust the length of all types of footrest:
1. Remove the adjustment screw (A) using a 7/16" wrench;
2. Adjust the telescopic tubing (C) at the needed length;
3. Put back the (A) screw and tighten firmly.
B
C
A
TELESCOPIC
TUBING

4 SETUP INSTRUCTIONS
15
inc All rights reserved
4.1.2 TO CHANGE THE ANGLE OF THE FOOTPLATE
1. Loosen screw (B) using a 10 mm key:
2. Install the footplate at the desired angle;
3. Tighten screw (B) firmly (tightening at 140 Pounds/inch).
Figure 2 : To change the angle of the footplate.
4.1.3 TO CHANGE THE DEPTH POSITION OF THE COMPOSITE FOOTPLATE
1. Remove the two (2) Phillips screws (A) at the end of the footplate (see; figure 2) ;
2. Pull the footplate to release it from the support ;
3. Readjust the footplate at the needed depth ;
4. Replace the end part of the footplate with the Phillips screws (A).
Aluminum footplate
B
COMPOSITE FOOTPLATE
INSERTION GROOVE
A

4 SETUP INSTRUCTIONS
16
inc All rights reserved
4.1.4 TO CHANGE THE ANGLE OF THE FULL LENGTH FOOTPLATE
Figure 3 : To change the angle of the full lenght footplate.
4.1.5 DEPTH ADJUSTMENT OF THE HEEL LOOPS
Figure 4 : Depth adjustment of the heel loops.
4.1.6 ADJUSTMENT OF THE TOE LOOPS
Figure 5 : Adjustment of the toe loops.
Angle adjustment
See section 4.1.3
Pull the "Velcro" and
adjust at the needed
length.
Pull the "Velcro" and
adjust at the needed
length.

4 SETUP INSTRUCTIONS
17
inc All rights reserved
4.1.7 TO CHANGE THE HEIGHT OF THE CALF PAD
NOTE: The calf pad is adjustable in height, depth and width (see; figure 6).
a) To adjust the calf pad height :
1. Loosen screw (A) using a 5 mm Allen key ;
2. Slide support (B) until you reach the adequate position ;
3. Put back in place screw (A) and tighten firmly.
NOTE : The calf pad is not adjustable in height with the articulated legrest.
Figure 6 : Calf pad adjustment.
4.1.8 TO CHANGE THE POSITION OF THE CALF PAD
b) To adjust the width :
1. Loosen screws (C) using a 4 mm Allen key ;
2. Slide calf pad (D) until you reach the adequate position ;
3. Tighten screws (C).
c) To adjust the depth :
1. Loosen screw (E) using a 5 mm Allen key ;
2. Loosen screw (F) ;
3. Adjust at the needed position and tighten screws (E) and (F).
AB
C
D
E
F

4 SETUP INSTRUCTIONS
18
inc All rights reserved
4.2 ARMREST
4.2.1 HEIGHT ADJUSTMENT, REMOVABLE, SWINGAWAY ARMREST
Figure 7 : Height adjustment, removable, swingaway armrest (A).
The height can be adjusted in 2 ways (see; figure 7) ;
1. By positioning the support screw (B) in the selected adjustment hole (C) using a
7/16" key ;
2. Installing the base of the armrest to a different height on the wheelchair frame
using the adjustment screws (D).
4.2.2 RIGID SIDEGUARD
TO ADJUST THE HEIGHT :
In order to maximize rigidity and to reduce movement, it is preferable to install the support
(A) as close as possible to the seat.
The height can be adjusted in 2 manners s (see; figure 8);
a) Adjustment of the support (A):
1. Using a 5 mm Allen key and unscrew the (B) bolt;
2. Install the support (A) at the needed position;
3. Tighten back the screws (B).
D B
A
C

4 SETUP INSTRUCTIONS
19
inc All rights reserved
Figure 8 : Clothes guard adjustment.
b) Rod (D) adjustment :
1. Using a flat screwdriver of 1 cm x 1 mm; unscrew screws (C) and remove the two
(2) shoulder nuts (non illustrated) ;
2. Slide the rod (D) until you reach the needed height ;
3. Put back screws (C) and shoulder nuts and tighten.
B
A
D
C

4 SETUP INSTRUCTIONS
20
inc All rights reserved
4.2.3 REMOVABLE “U” SHAPE SWINGAWAY ARMREST
4.2.3.1 TO PROHIBIT ADJUSTMENT IN HEIGHT
The screw (A) located at the back of the armrest gives the possibility of prohibiting the
adjustment in height of the armrest. To prohibit the height adjustment, loosen the
counter-nut (8 mm key), screw (4 mm Allen key) the bolt (A) in the hole and tighten back
the counter-nut (see; figure 9-A).
Figure 9-A : "U" shape armrest to prohibit the height adjustment.
4.2.3.2 PROHIBIT REMOVING OF THE ARMREST
The (A) screw located at the base of the armrest, gives the possibility of installing in a
permanent way the armrest to the wheelchair. This removes the "DETACHABLE" function
of the armrest while preserving the swingaway possibility. Loosen the counter-nut (8 mm
key), and screw (4 mm Allen key) the bolt (A) in the hole and tighten back the counter-nut.
(see; figure 9-B).
Figure 9-B : "U" shape armrest to prohibit removing.
A
A
