Osburn 2500 User manual

Operation Manual
2500
(OP00025 Model)
Safety tested according to ULC S627,
UL 1482 and ASTM E1509 by an
accredited laboratory.
INSTALLATION BY A
PROFESSIONAL IS STRONGLY
RECOMMENDED
Printed in Canada 45910OA
READ AND KEEP THIS MANUAL FOR REFERENCE
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-BURNING ROOM HEATER. FAILURE TO
FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
ENGLISHFRANÇAIS
2018-01-23

Page 3Operation Manual - 2500
ENGLISH
RECOMMENDATIONS
It is highly recommended that this appliance be installed and serviced by professionals who are
certified in the United States by NFI (National Fireplace Institute ® ) or in Canada by WETT (Wood
Energy Technology Transfer) or in Quebec by APC (Association des Professionnels du Chauffage).
If this appliance is not properly installed, combustible materials near it may overheat and
catch fire. To reduce the risk of fire, follow the installation instructions in this manual exactly. Contact
local building or fire officials about restrictions and installation inspection requirements in local area. It
is also recommended to inform your home insurance company.
It may be needed to get a building permit for the installation of this appliance and the venting system
that it is connected to.
Read this entire manual before operating this stove.
SAFETY INFORMATION
Using a stove with cracked or broken components, such as glass or baffle may produce an unsafe
condition and may damage the stove.
The viewing door must be closed and latched at all times during operation. The ash drawer access
panel must also be closed during operation.
A smoke detector, a carbon monoxide detector and a fire extinguisher should be installed in the
house. The location of the fire extinguisher should be known by all family members.
Do not disable sensors and safety switches.
This product can expose you to chemicals including carbon monoxide, which is
known to the State of California to cause cancer, birth defects or other reproductive
harm. For more information go to www.P65warnings.ca.gov/
GENERAL INFORMATION
It is highly recommended to buy this product from a retailer who can provide installation and
maintenance advice.
The stove will not operate during a power outage. If an outage does occur, check the stove for
smoke spillage. Opening a window will prevent negative pressure and smoke spillage in the room.
This stove has been developed and built to be used as a residential heater. Commercial or industrial
use is prohibited and will void the warranty.
This heating unit is designed to serve as a supplementary heat source. We recommend that a
primary heat source also be available in the home. The manufacturer cannot be responsible for costs
associated with the use of another heating system.
DANGER
HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.
CONTACT MAY CAUSE SKIN BURNS.

Page 4 Operation Manual - 2500
ENGLISH
This stove must be connected to a standard 120V / 60Hz, grounded electrical outlet. Do not use
an outlet adapter, an extension cord or sever the grounding plug. Do not route the electrical cord
underneath, in front or over the stove.
It is important that adequate oxygen is being supplied to the fire for proper combustion. At all time,
make sure the outside air register is not obstructed by ice, snow or other objects as this will starve the
fire of air and prevent the proper operation of the stove.
Mixing of appliance components from different sources or modifying components is prohibited and
will void the warranty.
Any modification to the stove that has not been approved in writing by the testing authority is prohibited
and violates CSA B365 (Canada), and ANSI NFPA 211 (USA).
Stove builder international inc. (SBI) grants no warranty, implied or stated, for the poor installation or
lack of maintenance of your appliance and assumes no responsibility of any consequential damages.
This stove is certified to comply with EPA NSPS 2015 particulate emission standards and is not
approved for sale after May 15th 2020.
REGISTER YOUR WARRANTY ONLINE
Should warranty service be required, you must show proof of purchase. Keep
your sales invoice. The date on these records establishes the warranty period.
If proof of purchase cannot be supplied, the warranty period will be determined
from the date of manufacture of the product.
We also recommend that you register your warranty online at:
https://www.osburn-mfg.com/en/warranty/warranty-registration/
Registering your warranty online will help us to quickly track the information we
need about your stove.
AVAILABLE OPTIONS AND ACCESSORIES
• Hopper extension;
• Fresh air kit;
• Wall thermostat;
• Programmable thermostat;
• Glass hearth pad;
For more details, visit our web site www.osburn-mfg.com or refer to an authorized dealer.

Page 5Operation Manual - 2500
ENGLISH
TABLE OF CONTENTS
Recommendations ................................................................................................................... 3
Safety Information.................................................................................................................... 3
General Information.................................................................................................................. 3
Available Options and Accessories......................................................................................... 4
Specifications........................................................................................................................... 7
Certification Label ...............................................................................................................8
Fuel ........................................................................................................................................... 9
Recommended Pellets.........................................................................................................9
Storage ..............................................................................................................................9
Stove Controls........................................................................................................................ 10
Stove Operation...................................................................................................................... 11
Before Operating the Stove................................................................................................11
First Startup / Beginning of Season ....................................................................................12
Every Day Startup and Use ................................................................................................12
Running Out of Pellets .......................................................................................................12
Shutting Down Procedure ..................................................................................................13
Signs of an Overheating Stove ...........................................................................................13
Using a Thermostat ...........................................................................................................14
Pilot Mode Selection ....................................................................................................14
Convection adjustments ....................................................................................................14
Air Intake Adjustments.......................................................................................................15
Maintenance ........................................................................................................................... 16
Maintenance Schedule.......................................................................................................16
Recommended tools..........................................................................................................17
Ash removal......................................................................................................................17
Burn pot ...........................................................................................................................18
Combustion Chamber........................................................................................................18
Glass Maintenance ............................................................................................................19
Replacing the Glass...........................................................................................................19
Maintaining Door Gasket....................................................................................................21
Adjusting the Door.............................................................................................................21
Verifying the Door Seal.......................................................................................................21
Heat Exchangers and Exhaust Channels .............................................................................22
Baffle................................................................................................................................23
Maintaining the Venting System..........................................................................................24
Facing a Chimney Fire ..................................................................................................24
Fly Ash and Soot ..........................................................................................................24

Page 6 Operation Manual - 2500
ENGLISH
Troubleshooting...................................................................................................................... 25
Main Error Codes ..............................................................................................................25
CODE P........................................................................................................................25
CODE E........................................................................................................................25
CODE L ........................................................................................................................26
CODE H .......................................................................................................................26
CODE d........................................................................................................................26
CODE C .......................................................................................................................26
Other possible error codes............................................................................................27
Recommandations ................................................................................................................. 32

Page 7Operation Manual - 2500
ENGLISH
SPECIFICATIONS
Model 2500 (OP00025)
Fuel Type1Wood pellets (Premium grade or better)
Recommended heating area (sq. ft.)2500 - 2,000 pi2 (46 - 186 m2)
Hopper capacity 60 lb (27,3 kg)
Maximum burn time251 hours
Recommended chimney diameter 3 in. or 4 in (see installation manual).
Flue outlet diameter 3 po. (76 mm)
Type of chimney ULC/ORD-C441, CAN/ULC S609
UL 641 (TYPE L)
Approved for alcove installation Yes
Approved for mobile home installation3Yes
Shipping weight (without option) 286 lb (130 kg)
Appliance weight (without option) 253 lb (115 kg)
Baffle material Stainless Steel
Type of door Simple, glass with cast iron frame
Type of glass Ceramic glass
Blower Included (176 CFM)
Noise level at 6 feet Min. 47 dBa (+/- 3 dBa)
Max. 60 dBa (+/- 3 dBa)
1 Grades of pellet fuel are determined by organizations such as Pellet Fuels Institute (PFI), ENplus and CANplus.
2 Recommended heating area and maximum burn time may vary subject to location in home, chimney draft, heat loss factors, climate, fuel type, feed
rate, fuel level, and other variables.The recommended heated area for a given appliance is dened by the manufacturer as its capacity to maintain a
minimum acceptable temperature considering that the space conguration and the presence of heat distribution systems have a signicant impact
in making heat circulation optimum.
3Mobile home (Canada) or manufactured home (USA): The US department of Housing and Urban Development describes “manufactured homes”
better known as “mobile homes” as followed; buildings built on xed wheels and those transported on temporary wheels/axles and set on a
permanent foundation. In Canada, a mobile home is a dwelling for which the manufacture and assembly of each component is completed or
substantially completed prior to being moved to a site for installation on a foundation and connection to service facilities and which conforms to the
CAN/CSA-Z240 MH standard.

Page 8 Operation Manual - 2500
ENGLISH
Certification Label
Since the information given on the certification label affixed to the stove always overrides the
information published in any other media (owner’s manual, catalogues, flyers, magazines or web sites),
it is important to refer to it in order to have a safe and compliant installation. In addition, important
information about the stove can be found (model, serial number, etc.). The certification label is located
on the inner side of the hopper lid of the stove.
Certification label - Page 1 Certification label - Page 2

Page 9Operation Manual - 2500
ENGLISH
FUEL
Recommended Pellets
Type: Wood pellet, premium grade or better, certified by PFI, Enplus or CANplus.
Size: Diameter between ¼" or 5/16" and not over 1" long. Longer or thicker pellets will affect the
constancy of pellet feed. The pellets length may vary from one lot to another, even if it comes from the
same manufacturer.
Short pellets Long pellets
Ash contents: Less than 1%. Ash contents more than 1% will increase maintenance frequency, create
combustion problems and will increase the stove emission.
Moisture content: Wet pellets will be very hard to ignite and will greatly affect the feeding process of the
stove. Using dry pellets will maintain the performance of your stove.
Note that the pellets quality may vary depending on the manufacturer. It can also vary from
one bag to another, even if it comes from the same manufacturer. It is recommended to
try several different manufacturers to find the one that best suits your use. Then, buy the
pellets in lots of several tons to ensure satisfaction.
Burning other types of pellets is prohibited. It violates the building codes for which the
stove has been approved and will void the warranty.
Storage
Pellets should remain in their original packaging until ready for use.
Pellets bags should be stored in a dry and well ventilated area, if possible. If they are to be stored
outside, remember that pellets bags are not water tight. It is best to keep the pallet wrapper as intact
as possible and cover it with a tarp.
Having a bag or two in the same room as the stove for refueling is a good idea. The minimum
clearances to combustible materials and the space required for refilling and ash removal needs to be
respected.
DO NOT STORE FUEL WITHIN STOVE MINIMUM CLEARANCES TO COMBUSTIBLE.

Page 10 Operation Manual - 2500
ENGLISH
STOVE CONTROLS
The stove, the pellet feeding system and the blowers are controlled by a control panel on the right-
hand side of the stove. The control panel buttons and display areas are as follows:
3
1
5
2
4
6
A
C
B
Stove controls
No Description
AControl panel display area.
BStove state display area.
CStove heating intensity display area, level 1 to 6.
1MODE: the «MODE» button is used to either turn off the appliance (OFF), turn it on in manual
operation (MANUAL) or in thermostatic operation (THERMOSTAT).
2RESET: The «RESET» button is used to reset the stove after the appearance of most of the
warning codes.
3AUX: The «AUX» button is used to adjust the convection air speed.
4AUGER: The «Auger» button is used to fill the auger with pellets.
5MINUS: The « - » button is used to reduce the pellet feeding rate thus reducing the heat
output of the stove.
6PLUS: The « + » button is used to increase the pellet feeding rate thus increasing the heat
output of the stove.
